ASSEMBLY - LOWER CONTROL ARM (REAR CAUTION: Do not apply grease or any other type of (1) Secure lower control arm in a vise. NOTE: Hydro bushings and grooves on control arm (2) Align master spline on bushing inner sleeve with groove on lower control arm rear bushing stem (3) Install Remover/Installer, Special Tool 8460, over bushing and lower control arm as shown (Fig. (4) Begin to tighten forcing screw. As bushing nears lower control arm flange, place Spacer Plate, (5) Install bushing up against Spacer Plate, tight- ening the bridge forcing screw with a torque wrench (6) Back off the forcing screw and remove tool. - SUSPENSION/FRONT/LOWER CONTROL ARM - INSTALLATION - LOWER CONTROL ARM (1) Position lower control arm assembly into front suspension cradle crossmember guiding bushings into (2) Install NEW pivot bolt attaching front bushing of lower control arm to front suspension cradle cross- Fig. 26 BUSHING MASTER SPLINE LINED UP WITH GROOVE (RIGHT SIDE SHOWN) 1 - GROOVE Fig. 27 HYDRO-BUSHING INSTALLATION 1 - LOWER CONTROL ARM FLANGE Fig. 28 SPACER PLATE POSITIONED 1 - SPACER PLATE (8460-4) RS FRONT SUSPENSION 2 - 15 LOWER CONTROL ARM (Continued) |
