3. CHECK THE (D704) PARK ASSIST SENSOR NO. 10 SIGNAL CIRCUIT FOR A SHORT TO (X750) PARK Turn the ignition off. Disconnect the Park Assist Module harness connector. Measure the resistance between the (D704) Park Assist Sensor No. 10 Is the resistance below 10K ohms? Yes >> Repair the (D704) Park Assist Sensor No. 10 Signal circuit for a short to the (X750) Park Assist Sensor Ground circuit. Perform BODY VERIFICATION TEST - VER 1. (Refer to No >> Go To 4 4. CHECK THE (D704) PARK ASSIST SENSOR NO. 10 SIGNAL CIRCUIT FOR A SHORT TO (Z171) PARK Measure the resistance between the (D704) Park Assist Sensor No. 10 Is the resistance below 10K ohms? Yes >> Repair the (D704) Park Assist Sensor No. 10 Signal circuit for a short to the (Z171) Park Assist Display Ground circuit. Perform BODY VERIFICATION TEST - VER 1. (Refer to No >> Go To 5 8B - 26 CHIME/BUZZER - ELECTRICAL DIAGNOSTICS LX |
