18– 81 18 a. Turn ignition switch to LOCK and disconnect the negative battery cable. b. Disconnect the wire harness connector E-030. E-030 is short to power. a. Using X-431 3G diagnostic tester, select Read Code. 4 Check if transmission wire harness connector E-030 is short to power RT21181150 E-030 29 30 31 32 33 34 35 36 37 38 39 40 41 42 1 2 3 4 5 6 7 8 9 10 11 12 13 14 43 44 45 46 47 48 49 50 51 52 53 54 55 56 15 16 17 18 19 20 21 22 23 24 25 26 27 28 - + V Repair or replace failed circuit NG 5 Check for DTC OK Replace solenoid and wire harness NG System is normal OK |
