Chery Tiggo 5 (T21). Manual - part 61

06–

86

06

DTC

P0271-00 Cylinder 4 - Injector Circuit High

ET21065008

GBr

G

Br

BATTERY

ECM
MAIN
RELAY

10A

EF19

10A

EF17

10A

EF40

A2

F14

2-20

RL

A4

2-35

L

2-5

Br

A6

2-15

2-16

RR

R

86

87

85

30

ENGINE
COMPARTMENT
FUSE AND
RELAY BOX

IGNITION SWITCH
    ON OR START

A1

A2

A3

A4

A5

A6

A7

A8 A9 A10

F12

F24

F11

F23

F10

F22

F9

F21

F8

F20

F7

F19

F6

F18

F5

F17

F4

F16

F3

F15

F2

F14

F1

F13

Gr

E-076

W

E-069

E-076

E-069

B

E-033

49 50 51

63

64

15

16

31

32

47

48

33 34 35

17 18 19

1

2

3

52 53 54 55 56 57 58 59 60 61 62

36 37 38 39 40 41 42 43 44 45 46

20 21 22 23 24 25 26 27 28 29 30

4

5

6

7

8

9 10 11 12 13 14

ECM-2

E-033

RL

C3

15A

EF08

INJECTOR 4

1-10

2

1

12

E-007
E-038

E-013

1

2

C1

C2

C3 C4

C5

C6

C7

C8 C9 C10

L

E-023

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

31

35

39

40

41

42

32

33

36

37

38 34

27

28

29

30

B

E-007

B

E-013

37 38 39 40 41 42 43 44 45 46

47

48

25 26 27 28 29 30 31 32 33 34

35

36

13 14 15 16 17 18 19 20 21 22

23

24

1

2

3

4

5

6

7

8

9 10

11

12

B

E-035

ECM-1

E-035

E-023

06–

87

06

DTC Confirmation Procedure

Confirm that battery voltage is over 12 V before performing the following procedures.
 Turn ignition switch to LOCK.
 Connect X-431 3G diagnostic tester (the latest software) to Data Link Connector (DLC).
 Turn ignition switch to ON.
 Use X-431 3G diagnostic tester to record and clear the DTCs stored in the ECM.
 Select Read Code.
 If the DTC is detected, the malfunction indicated by the DTC is current. Go to the diagnosis 

procedure - Step 1.

 If DTC is not detected, the malfunction indicated by the DTC is intermittent (

See page 06-18

).

Diagnosis Procedure

a. Turn ignition switch to LOCK.
b. Check ECM grounds E-026 and E-028 (

See page 06-18

).

a. Disconnect injector connector E-013 of cylinder 4.
b. Check injector connector.

DTC Code

DTC Definitions

DTC Detection

Conditions

Possible Cause

P0271-00

Cylinder 4 - Injector
Circuit High

Engine running

 Injector of cylinder 4
 Wire harness or connector
 ECM

CAUTION

 When performing circuit diagnosis and test, always refer to the circuit diagram for specific circuit and

component information.

1

Check ECM ground point

Repair or replace ground wire harness or
ground point

NG

2

Check injector connector of cylinder 4

OK

RT21060160

Repair or replace connector

NG

06–

88

06

a. Disconnect injector connector E-013 of cylinder 4.
b. Turn ignition switch to ON.
c. Check voltage between injector connector terminal of

cylinder 4 and body ground.

a. Turn ignition switch to LOCK.
b. Check fuse EF08 and main relay.
c. Disconnect engine compartment fuse and relay box

connector E-023.

d. Check wire harness between injector connector terminals

and engine compartment fuse and relay box connector
terminals.
Check for Open

3

Check injector power supply voltage of cylinder 4

OK

E-013

1

2

-

+

V

RT21065034

Multimeter

Connection

Condition

Specified

Condition

E-013 (1) - Body

ground

Ignition switch ON

11 to 14 V

Go to step 5

OK

4

Check injector power supply circuit of cylinder 4

NG

E-013

E-023

C1

C2

C3 C4

C5

C6

C7

C8 C9 C10

1

2

-

+

RT21065035

Multimeter

Connection

Condition

Specified

Condition

E-013 (1) - E-023

(C3)

Always

Continuity

06–

89

06

Check for Short

a. Disconnect ECM connector E-035.
b. Check wire harness between injector connector terminals

and ECM connector terminals.
Check for Open

Check for Short

Multimeter

Connection

Condition

Specified

Condition

E-013 (1) or

E-023 (C3) - Body

ground

Always

No continuity

E-013 (1) or

E-023 (C3) -

Battery positive

Repair or replace wire harness or
connector (injector of cylinder 4 - engine
compartment fuse and relay box)

NG

5

Check injector control circuit of cylinder 4

OK

E-013

E-035

37 38 39 40 41 42 43 44 45 46

47

48

25 26 27 28 29 30 31 32 33 34

35

36

13 14 15 16 17 18 19 20 21 22

23

24

1

2

3

4

5

6

7

8

9 10

11

12

1

2

-

+

RT21065036

Multimeter

Connection

Condition

Specified

Condition

E-013 (2) - E-035

(10)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

E-013 (2) or

E-035 (10) - Body

ground

Always

No continuity

E-013 (2) or
E-035 (10) -

Battery positive

Repair or replace wire harness or
connector (injector of cylinder 4 - ECM)

NG

OK
