Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not – Slacken cylinder head bolts in the sequence -1 ... 10-. Note ♦ A second mechanic is required for removal of the cylinder head. ♦ The toothed belt tensioning roller is detached from the stud when the cylinder head is lifted out. ♦ The oil return line from the turbocharger is pulled out of the support when the cylinder head is lifted out. – Lift cylinder head at gearbox end first and guide out of toothed belt cover. Make sure toothed belt tensioning roller does not drop out. – Take care to place cylinder head down without bending oil re‐ turn line. If necessary, place a block of wood below exhaust manifold. Caution Risk of damage to glow plugs when putting down cylinder head. ♦ After removal, the cylinder head must not be put down on the gasket side with the glow plugs still installed, because the glow plugs project slightly beyond the gasket surface. Installing 2. Cylinder head 111 |
