23-157
23-157
Voice Control Switch Replacement
Microphone Replacement
B
E
D
A
C
B
A
A
B
SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service.
1. Remove the steering wheel (see page 17-6).
2. Remove the voice control switch (see page 17-7).
3. Install the audio remote switch in the reverse order
of removal.
1. Remove the front individual map light lens (A).
2. Remove the bolts (B), then disconnect the
connectors, and remove the map lights housing (C).
3. Carefully pry off the moonroof switch (D) from the
map light housing while pressing in on the
retaining tabs (E).
4. From the moonroof switch (A), remove the screw
and microphone (B).
5. Install the microphone in the reverse order of
removal.
