2. Unscrew the fastening nut -2- . 3. Press wiper arm -3- down at joint and pull down from the wiper motor drive. Installing wiper arm for rear window washer system Installing wiper arm for rear window washer system Fitting wiper arm 1. Position wiper arm -3- on the wiper motor drive and do up the fastening nut -2- by hand. Aligning wiper arm 2. Adjust the wiper arm so that the wiper blade is parallel to the roof frame. 3. Screw on fastening nut -2- and push on the cover -1- . → Tightening torque: 14 ftlb. 4. Actuate wiper motor of the rear window washer system, allow it to come to rest and check the position of the wiper arm once more. 997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431, Diagnostic system: reading out fault memory and activating systems Removing wiper arm for rear window washer system 3957 |
