Position stop -2- and screw down locking pins -1- . Tightening torque → Tightening torque: 37 ftlb. +1.5 Securing side trim panel 4. Check plug-in nut -3- and replace if necessary. Position and tighten fastening screw -2- in the Installing collar of opening for belt 5. Position locking tabs of collar of opening for belt -1- on side trim panel and press them in. Aligning seal 6. Lift up the pillar seal -1- using a plastic spatula -2- along the side trim panel -3- . 7. Fold up rear backrest and lock it. Diagnostic system: reading out fault memory and activating systems Installing rear side trim panel 3089 |
