Using a small screwdriver, carefully unclip and remove the cover for the fastening screws at the openings
-arrows-

 provided.

Unclipping cover for motor for sliding roof

3. Unscrew the two fastening screws.

4. Unclip cover for motor for sliding roof at the rear to the left and right -arrows A- and push it out to the

front towards the windscreen -arrow B- .

Removing connectors at sliding roof switch and interior light

5. Release connecters at sliding roof switch and at the interior light -arrows a- and remove them. Remove

cover for motor for sliding roof.

Disconnecting electric plug connection

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing cover for motor for sliding roof

3093

Installation position for headliner

Disconnecting plug connection

1. Unclip plug connection for interior mirror -1- from the support -arrow A- and disconnect connector

-arrows a-

 .

2. Unclip support for wire harness -2- -arrow B- and disengage electric lines -arrows C- .

Removing mounting saddle and pivot bearing for sun visor

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Disconnecting electric plug connection

3094

Installation position for headliner

Removing mounting saddle and pivot bearing

1. Unclip cap on the mounting saddle -1- with a screwdriver and open -arrow A- .

2. Unscrew fastening screw -2- and remove mounting saddle -3- -arrow B- .

3. Carefully insert a screwdriver between headliner and pivot bearing and release cover -4- -arrow C- .

4. Unscrew fastening screw -5- and remove pivot bearing -6- -arrow

D-

 .

Removing headliner

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing mounting saddle and pivot bearing for sun visor

3095

Installation position for headliner

Undoing headliner at the front

1. Unscrew fastening screws -1- at the front in the headliner -2- and unclip the headliner from the cowl

panel frame -3- in a downward direction at the left and right.

Disengaging headliner at the sides

2. Unclip the metal strut of the roof liner -1- from the plastic clips -2- at the right and left.

Diagnostic system: reading out fault memory and activating systems

Removing headliner
