Removing cardan flange 1. Engage first gear and firmly set the hand brake. Loosening nut Note Transmission shaft and collar nut are connected by a left thread. When loosening and tightening, the direction 2. Loosen collar nut using socket-wrench insert a/f 30, 1/2" long NR.64 and unscrew. Pulling off flange 3. Remove cardan flange using three-arm puller: span width 100mm, span depth 100mm . Installing cardan flange Installing cardan flange 1. Replace O-ring for cardan flange. 2. Screw on new collar nut and tighten using a socket wrench P 9669. Location Explanation Type Basic value Tolerance 1 Tolerance 2 Diagnostic system: reading out fault memory and activating systems Removing cardan flange 1121 |
