Diagnostic system: reading out fault memory and activating systems

Subsequent work

1125

39 82 19 Removing and installing sealing ring for
cardan flange - as of MY 2006

- Preliminary work
- Removing sealing ring for cardan flange
- Installing sealing ring for cardan flange
- Subsequent work

Tools

Designation

Type

Number Explanation

pressure piece

commercially available tool

9671

slide hammer kit commercially available tool

NR.168

pressure piece

special tool

P 9668

hook

VW-tool

VW 681

 39 82 19 Removing and installing sealing ring for cardan flange - as of MY 2006

1126

Preliminary work

Preliminary work

1. Raise the vehicle at the specified jacking points. → 401000  Lifting the vehicle.

2. Remove underbody panel. → 519419 Removing and installing rear cover - Removing→ 519320

21 Removing and installing middle cover - Removing→ 519219 Removing and installing front cover
- Removing

3. Remove cardan shaft. → 390219 Removing and installing cardan shaft - section on "Removing"

4. Remove cardan flange. → 396419 Removing and installing cardan flange - section on "Removing"

5. Place oil collection pan under the transmission.

Removing sealing ring for cardan flange

Removing sealing ring for cardan flange

Circlip

1. Remove

circlip.

2. Remove

washer.

Diagnostic system: reading out fault memory and activating systems

Tools

1127

Punching hole

3. Use a suitable tool, e.g. a sharp punch, to make a hole in the sealing ring.

Sheetmetal screw

4. Screw sheetmetal screw approx. 1 cm into the sealing ring.

Knocking out sealing ring

5. Knock out sealing ring on screw using slide hammer kit NR.168.

Removing sealing ring for cardan flange

Diagnostic system: reading out fault memory and activating systems

Removing sealing ring for cardan flange

1128
