REAR SUSPENSION/TRACK/TRACTION

7.35

Suspension Lubrication

2000 EDGE Style

Grease at fittings

L

L

L

L

L

2001 EDGE Pro X
Style

Grease at fittings

L

L

L

L

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.36

Rear Suspension Components - 2001 XCF SP/440, 600 Edge Pro X

Rear Torsion Spring

Limiter
Strap

Front Track Shock

Forward

Rear Track Shock

Rear Torque
Arm

Front Track Shock

Limiter
Strap

Rear Torsion Spring

Rear Track Shock

Idler Wheel

Slide Rail

Hi-fax

Rail
Bumper

Bogie
Wheel

Front
Torque Arm

Carrier Wheel

Rear Shock Reservoir

Rear Xtra Travel Arm (XTA)

Front Xtra Travel Arm (XTA)

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.37

Rear Suspension Exploded View - Edge Pro X Style

2001 XCF/Edge Pro X Front Torque Arm

2001 XCF/Edge Pro X Rear Torque Arm

2001 XCF/Edge Pro X Rear Suspension, Rear rail

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.38

Rear Suspension Components - XTRA-Lite

Forward

NO TAG

Torsion Springs

Carrier Wheel

Rail Bumper

Rear Track
Shock

Front Track Shock

Front Torque Arm

Front Track
Spring

Torsion Spring

Bogie Wheel

Rear Torque Arm

Rear Pivot Arm

Idler Wheel

Rail Bumper

Slide Rail

Rear Track
Shock

Bogie Wheel

Rail
Bumper

Hi-fax

Rail Tip
