Volvo C30 (2013 year). Instruction

10 Audio

Audio functions

250

NOTE

Any Bluetooth cell phones used must sup-
port Audio/Video Remote Control Profile
(AVRCP) and Advanced Audio Distribution
Profile (A2DP). The phone must use AVRCP
version 1.3 and A2DP 1.2. If older versions
of these standards are used, certain fea-
tures (e.g., scan or random) may not func-
tion.

Not all cell phones are fully compatible with
the vehicle's Bluetooth system. A list of
compatible phones is available at you Volvo
retailer or at www.volvocars.us.

Listening to streaming audio

Press MODE several times to select BT as a
sound source.

Audio files on the connected device can be
selected in three ways:

•

Turn the TUNING dial (4) in either direction.

•

Use the navigation buttons

(6) to

select an audio file.

•

Use the

buttons on the steering

wheel keypads.

Sound settings

Optimal sound reproduction

The audio system is calibrated for optimal
sound reproduction through the use of digital
signal processing. This calibration takes into
account the speakers, amplifier, cabin acous-
tics, the seating position of the listener, etc., for
each combination of vehicle and audio system.
There is also dynamic calibration that takes
into account the setting of the volume control,
radio reception, and the vehicle's speed. The
sound settings described in this manual, such
as

BASS

TREBLE

, and

Equalizer front…

Equalizer rear…

are only intended to enable

the user to adapt sound reproduction to his/her
personal preferences.

Press SOUND (5). Press this button
repeatedly until you come to the setting
that you wish to change.

Turn the TUNING dial (4) to make the
desired setting.

The following settings can be made:

BASS

–set the bass level

TREBLE

–set the treble level

BALANCE

–set the left/right sound balance

FADER

–set the front/rear sound balance

CENTER

–make settings for the center speaker

SURROUND

–make settings for surround

sound

Surround sound

Surround sound settings are used to
balance sound levels throughout the
vehicle. Surround settings for the var-
ious sound sources are made sepa-

rately.

G021216

NOTE

•

Dolby Surround Pro Logic II is only
available on the Premium Sound sys-
tem.

•

When listening to FM radio stations,
Dolby Surround Pro Logic II functions
best in areas with strong reception. If
reception is weak, selecting 2 or 3-
channel stereo may provide better
sound quality.

The Dolby symbol will appear in the display
when Dolby Pro Logic II is activated.

There are three alternative settings:

•

Pro Logic II

•

3-channel

•

Off (normal 2-channel stereo)

Dolby Surround Pro Logic II

distributes the

stereo sound's two channels to the left, center,

10 Audio

Audio functions

251

right and rear speakers, making sound repro-
duction more authentic than ordinary two-
channel stereo.

Dolby Surround Pro Logic II

and the Dolby

symbol

are trademarks of Dolby

Laboratories Licensing Corporation.

The Dolby Surround Pro Logic II System

manufactured under licence from Dolby
Laboratories Licensing Corporation.

Activating/deactivating Surround sound

Press MENU followed by ENTER.

Select

SUBWOOFER

in the menu and

press ENTER.

Select Surround

SURROUND AM

SURROUND FM

SURROUND CD

SURROUND AUX

and press ENTER.

Select

Dolby Pro Logic II

, 3-channel

stereo or

Off

and press ENTER.

Equalizer Front/Rear

This function is used to fine-tune the sound
level for different frequencies separately.

NOTE

This function is only available on certain
sound systems.

To adjust the equalizer settings:

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

in the menu and

press ENTER.

Select

Equalizer front…

Equalizer

rear…

and press ENTER.

The column in the display indicates the sound
level for the current frequency.

•

Adjust the level with the TUNING dial (4),
or use the Up/Down arrows. Additional fre-
quencies can be selected with the Right/
Left arrows.

•

Save the settings by pressing ENTER or
exit without saving by pressing EXIT.

Automatic sound control

The audio system's volume is adjusted auto-
matically according to the speed of the vehicle.
There are three settings available, which deter-
mine the level of volume compensation:

•

Low

•

Medium

•

High

To set the automatic sound level:

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

in the menu and

press ENTER.

Select

Auto. volume control…

in the

menu and press ENTER.

Select

Low

Medium

, or

High

and press

ENTER.

Default setting.

10 Audio

Radio functions

252

Radio function controls

G026366

AM/FM1/FM2 selection

Station preset buttons

TUNING dial for selecting radio stations

SCAN

MENU NAVIGATION CONTROL–press
the up or down arrow keys to scroll in a
menu, or the keys on the left/right sides of
the control to search for or change radio
stations/CD tracks

EXIT–press to cancel a menu selection or
a selected function

AUTO–search for and store the strongest
radio stations in the area in which you are
driving

Searching for stations

There are two ways to manually tune a radio
station:

–

Turn the TUNING dial (3) to the desired fre-
quency.

–

Press the left or right arrow key on the
menu navigation control and hold it down.
The radio scans slowly in the selected
direction and will increase the scanning
speed after a few seconds. Release the
button when the desired frequency
appears in the display.

The frequency can be fine-tuned by short
presses on the left/right arrow keys.

Storing preset stations

Manually storing a station

Tune to the desired station.

Press and hold the preset button under
which the station is to be stored. The audio
system sound will be interrupted for a few
seconds and

Station stored

will appear in

the display.

NOTE

A total of 30 stations can be stored; 10 sta-
tions each in AM, FM1 and FM2.

Automatically storing a station

Pressing AUTO (7) automatically searches for
and stores up to ten strong AM or FM stations
in a separate memory. If more than ten stations
are found, the ten strongest ones are stored.
This function is especially useful in areas in
which you are not familiar with radio stations or
their frequencies.

To use the AUTO function:

Select a waveband using the AM/FM but-
ton (1).

Start the search by pressing AUTO until

Autostoring

appears in the display.

When the search is completed,

Autostoring

will no longer be displayed. If there are no sta-

10 Audio

Radio functions

253

tions with sufficient signal strength,

No AST

found

is displayed.

The auto-stored stations can be selected using
the preset buttons (2).

–

Press EXIT (6) to terminate the automatic
storing function.

When the radio is in auto-store mode,

Auto

shown in the display.

Auto

disappears when

you return to normal radio mode, which can be
done by briefly pressing AM/FM (1), EXIT (6),
or AUTO (7).

To return to the Auto-store mode, press the
AUTO button briefly and select a stored station
by pressing one of the preset buttons (2).

Saving auto-stored stations in the preset
memory

An auto-stored station can be saved in the
memory for manually preset stations.

Press AUTO (7) briefly.

> Auto is displayed.

Press one of the preset buttons (2) under
which the station is to be stored. Hold
down the button until

Station stored

displayed.

The radio will then exit auto-store mode and
the stored station can be selected by pressing
the preset button.

Scanning

SCAN (4) automatically searches through the
selected waveband for strong AM or FM sta-
tions. When the radio finds a station, that sta-
tion will be played for approximately 8 sec-
onds, after which scanning resumes.

Activating/deactivating SCAN

Select radio mode using the AM/FM but-
ton (2).

Press SCAN to activate the function.

SCAN

is shown in the display.

Press the SCAN or EXIT button to deacti-
vate the scan function and listen to the
selected station.

Storing a station found with SCAN

A station can be stored as a preset while the
SCAN function is activated.

–

Press one of the preset buttons (2) under
which the station is to be stored. Hold
down the button until

Station stored

displayed.

The SCAN function will be deactivated and the
station can be selected by pressing the preset
button.

Radio text

Certain stations broadcast program informa-
tion, which can be shown in the display.

To start this function:

Select

FM1

FM2

and press the MENU

button.

Press ENTER.

Select

Radio text

in the menu and press

ENTER.

To deactivate this function, select

Radio text

again and press ENTER.

10 Audio

Radio functions

254

HD Radio

൅

൅reception

(U.S.

models only)

Introduction

Display when the radio is receiving an HD Radio
broadcast

HD radio is a brand name registered by the
Ibiquity digital corporation

. They are the

developer of a broadcasting technology called
IBOC or In Band On Channel, which refers to
the method of transmitting a digital radio
broadcast signal centered on the same fre-
quency as the AM or FM station's present fre-
quency.

The IBOC system is referred to as a "hybrid"
since it is both analogue and digital. During
hybrid operation, receivers still continue to
receive the analogue (non-digital) signal. HD
radio receivers incorporate both modes of
reception, where the receiver will automatically
switch to the analogue signal if the digital signal
cannot be decoded or is lost by the receiver.
When you have tuned to an HD Radio station,
the

symbol will appear in the audio sys-

tem display.

More information about HD radio and IBOC
can be found on Ibiquity's website,
www.hdradio.com and www.ibiquity.com.

Benefits of digital broadcasting

•

Better sound (FM sounds near CD quality
and AM as analogue FM).

•

Some FM frequencies offer a greater num-
ber of listening choices through “multicast-
ing” (consisting of a frequency's main
channel and any sub-channels that may
also be available on that particular fre-
quency. See also the section "Sub-chan-
nels" below).

•

When receiving a digital signal there is no
multipath disturbance or hisses/pops/
crackling due to outside influences.

How HD broadcasting works

HD Radio works similarly to conventional radio
and broadcasts of this type are available in
many areas of the United States. However,
there are a few key differences:

•

Instead of transmitting one analogue sig-
nal, stations send out a bundled signal –
both analogue and digital.

•

An HD radio receiver can receive both dig-
ital and analogue broadcasts. Depending
on the terrain and location of the vehicle
(which will influence the signal strength),
the receiver will determine which signal to
receive.

Limitations

•

Main channel vs. sub-channels (FM
only): The main channel is the only channel
that can receive in hybrid mode (both dig-
ital and analogue). If a frequency has sub-
channels, they are broadcast in digital
mode only. The main FM channel will be
displayed as, for example, 93.9 WNYC
(Volvo uses the symbol > to indicate there
are sub-channels available) The sub-FM

HD Radio(TM) technology is manufactured under license from iBiquity Digital Corp. U.S. and Foreign Patents. HD Radio(TM) and the HD and HD Radio logos are proprietary trademarks of iBiquity
Digital Corp.

HD Radio (TM) technology is manufactured under license from iBiquity Digital Corp. U.S. and Foreign Patents. HD Radio(TM) and the HD and HD Radio logos are proprietary trademarks of iBiquity
Digital Corp.

10 Audio

Radio functions

255

channels will be displayed as 93.9 – 2
WNYC, 93.9 - 3 WNYC, etc.

•

Reception coverage area: Due to current
IBOC transmitter power limitations, the
reception coverage area in digital mode is
somewhat more limited than the station's
analogue coverage area. Please be aware
that as with any radio broadcast technol-
ogy, terrain, time of day, foliage level and
building location can have positive or neg-
ative effects on radio reception.

•

Analogue to digital/digital to analogue
blending: Analogue to digital blending will
occur as the signal strength reaches a pre-
set threshold in the receiver. This will be
noticeable in fringe areas (areas with weak
reception) and is normal.

NOTE

There may be a noticeable difference in
sound quality when a change from analogue
to digital or digital to analogue occurs, such
as:

•

Volume increase or decrease

•

Equalizer settings, i.e., Bass/ Midrange/
Treble cut or boost

•

Time alignment (Digital program mate-
rial in extreme cases can be as much as
8 seconds behind the analogue). This
will noticeable as a "stuttering" effect.

The above items are dependant on the
broadcaster's equipment settings and do
not indicate a fault in the vehicle's radio
receiver or antenna systems.

Switching HD on or off

The factory setting for HD radio is on. However,
when driving through areas with weak HD sig-
nals (fringe areas), you may experience that the
radio repeatedly switches between analogue/
digital and digital/analogue reception. If this
happens, it may be desirable to switch HD off.
To do so:

Be sure the audio system is switched on
and is in AM or FM mode.

Press MENU in the center console control
panel.

Press ENTER to turn HD off (the X will dis-
appear from the box on the display screen).

This will disable the radio's capability to receive
digital broadcasts but it will continue to func-
tion as a conventional (analogue) AM/FM
receiver. Please note that when HD is switched
off, it will not be possible to tune to sub-chan-
nels (see the following section for a more
detailed explanation of sub-channels).

Repeat steps 2 and 3 above to reactivate HD
(an X will appear in the box on the display
screen).

Sub-channels

Example of an HD Radio station with sub-channels

10 Audio

Radio functions

256

In many cases, a main HD Radio station (FM
wavebands only) will also have sub-channels
offering additional types of programming or
music.

In such cases, a number will be displayed to
the right of the frequency number indicating
that the currently tuned frequency has at least
one sub-channel. The "2" in the illustration indi-
cates that you are currently listening to the first
sub-channel on frequency 93.9.

Selecting sub-channels

To listen to a station's sub-channel(s), press
the right arrow key on the center console or on
the steering wheel keypad. To go back to the
main channel, press the left arrow key. To go
to subchannel 2 (if available), press the right
arrow key.

If you are currently tuned to a frequency's main
channel, pressing the left arrow key will tune to
the next lower radio frequency.

NOTE

•

When the radio has gone into HD mode,
it may take several seconds before the
">" symbol (if the current frequency has
any sub-channels) is displayed to the
right of the frequency. Pressing the
arrow keys before the number is dis-
played will cause the radio to tune to the
next available radio station, not to the
current station's sub-channels.

•

When you are no longer in broadcasting
range of the currently tuned sub-chan-
nel,

No HD reception

will be dis-

played. The radio will then be muted
and it will be necessary to tune to or
search for a new radio station.

Sub-channels can also be stored as presets,
see page 252 for information on storing sta-
tions.

If you press a sub-channel's preset button, it
may take up to 6 seconds before the channel
becomes audible. If you press this button while
you are out of digital range of the transmitter,

No HD reception

will be displayed.

Listening to satellite radio

The SiriusXM

൅ satellite system consists of a

number of high elevation satellites in geosyn-
chronous orbit.

NOTE

•

The digital signals from the SiriusXM

൅

satellites are line-of-sight, which means
that physical obstructions such as
bridges, tunnels, etc, may temporarily
interfere with signal reception.

•

Avoid any obstructions, such as metal-
lic objects transported on roof racks or
in a ski box, or other antennas that may
impede signals from the SiriusXM

൅

satellites.

Selecting SiriusXM

൅ radio mode

Press Power to switch on the audio system
(see page 252 for information on the stand-
ard radio functions).

Press the MODE button repeatedly until
SiriusXM

൅ 1 or 2 is displayed.

Activating SiriusXM

൅ radio

Tune to a satellite channel that has no
audio, which means that the channel is
unsubscribed and the text "

CALL

888-539-SIRIUS TO SUBSCRIBE

" is dis-

10 Audio

Radio functions

257

played (see also "Selecting a channel" in
the right column).

Call SiriusXM

൅ at 1-888-539-SIRIUS

(7474).

When asked for the SiriusXM

൅ ID number

press AUTO to display this number. It is
also possible to retrieve the SiriusXM

൅ ID

from the MENU.

Updating subscription

" will be dis-

played while the subscription is being
updated, after which the display will return
to the normal view.

SIRIUS ID

The SiriusXM

൅ ID is required when contacting

the Sirius Call Center. It is used to activate your
account and when making any account trans-
actions. The SiriusXM

൅ ID is sometimes refer-

red to as the Electronic Serial Number (ESN).

Selecting a channel category

Select SiriusXM

൅ radio mode as descri-

bed above.

Press ENTER.

Use the up/down arrow keys to scroll
through the list of categories.

Press ENTER or the right arrow key to
select a category.

Use the left or right arrow keys to select a
channel in the currently chosen category.

Press ENTER to listen to a channel.

NOTE

•

The category "All" is default, which ena-
bles you to scroll through the entire list
of available satellite channels.

•

The channel categories are automati-
cally updated several times a year. This
takes approximately two minutes and
will interrupt normal broadcasting. A
message will be displayed while updat-
ing is in progress. Information on chan-
nel or feature updates is available at
www.sirius.com.

Selecting a channel

There are three ways of tuning in a channel:

•

Using the left and right arrow keys

•

By turning the tuning control

•

Through direct channel entry

Direct channel entry

The SiriusXM

൅ satellite channels are num-

bered consecutively throughout all of the cat-
egories. To access a channel directly:

Press MENU and scroll to "Direct channel
entry."

Use the numerical keypad to enter the
channel's number.

Press ENTER. The radio will tune to this
channel, even if it belongs to a category
other than the currently selected one.

NOTE

•

The numbers of skipped or locked
channels will not be displayed.

•

If a channel is locked, the access code
must be entered before the channel can
be selected. See "Unlocking a channel"
on page 258.

Scanning

NOTE

SCAN automatically searches through the
list of satellite channels, see page 253 for
more detailed information.

Storing a channel

•

A long press on one of the number keys
stores the currently tuned channel on that
key.

•

A short press on a number key while the
radio is in SiriusXM

൅ 1 or 2 mode will tune

10 Audio

Radio functions

258

to the preset satellite channel stored on
that button, regardless of the currently
selected channel category.

Song Seek and Song Memory

The Song Seek and Song Memory functions
provide both audio and visual notification when
SiriusXM

൅ is broadcasting your favorite

songs. Song Seek enables you to store the
name of the song for future advance notifica-
tion when that song is being played. The Song
Memory feature makes it possible to view all of
the current songs that are stored in memory.

Song memory

Up to ten songs can be saved in the system's
memory.

Press MENU.

Scroll to "

Add song to song memory

and follow the instructions shown in the
display.

If a new song is selected when the memory is
full, you will be prompted to press ENTER to
delete the last song on the list.

NOTE

The remaining songs in the list will move
down one position, and the newly added
song will be placed at the top of the list.

Song seek

When a satellite radio channel plays one of the
songs stored in the song memory, the listener
will be alerted by a text message and an audi-
ble signal.

–

Press ENTER to listen to the song or
EXIT to cancel.

To activate/deactivate the song seek function:

Press MENU

Scroll to "

Song seek

Press ENTER to activate or deactivate the
function.

NOTE

When the song has ended, the radio will
remain tuned to the channel on which the
song was played.

Radio text

The text that is displayed about the song that
is currently playing can be changed. Use the
AUTO button or the menu to display

Artist

Track title:

Composer

, or switch off radio

text using

Sirius radio text…

Advanced settings

This menu function enables you to make set-
tings on certain SiriusXM

൅ satellite radio func-

tions. To access this menu:

Press MENU.

Scroll to SiriusXM

൅ menu.

Select

ADVANCED SIRIUS SETTINGS

WARNING

Settings should be made when the vehicle
is at a standstill.

The following settings can be made in the Sir-
iusXM

൅menu.

•

Songs can be added to the song list

•

Channel skip settings can be made

•

Channel lock settings can be made

•

The channel access code can be displayed
or changed

•

Your SiriusXM

൅ ID can be displayed

Skip options

This function is used to remove a channel from
the list of available channels.

Skip current

Select

Channel skip list

and press

ENTER.

10 Audio

Radio functions

259

Select a category in the list and press
ENTER.

Skip channels in the list presented by
pressing ENTER or right arrow key.

Unskip all channels

This permanently removes all channels from
the skip list and makes them available for
selection.

Temp. unskip all ch.

This function will temporarily unskip all chan-
nels and make them available for selection. The
channels remain on the skip list and will again
be skipped the next time the ignition is
switched on.

Channel lock

Access to specific channels can be restricted
(locked). A locked channel will not provide
audio, song titles, or artist information.

NOTE

All channels are initially unlocked.

Locking a channel

Select "

Sirius ID:

" in the menu and select

LOCK OPTIONS

and press ENTER.

Select

Channel lock list

and press

ENTER

Enter the channel access code and press
ENTER.

Select a category in the list and press
ENTER.

Lock channels in the list presented by
pressing ENTER or right arrow.

The channel is now locked and a checked box
will be displayed to indicate this. It will be nec-
essary to enter the channel access code1 in
order to listen to a locked channel.

Unlocking a channel:

A channel's access code1 is required to unlock
a channel.

Unlock all channels

This permanently removes all channels from
the locked list and makes them available for
selection.

Temp. unlock all ch.

This function will temporarily unlock all chan-
nels and make them available for selection. The
channels remain on the locked list and will
again be locked the next time the ignition is
switched on.

CHANGE CODE

This function makes it possible to change the
channel access code. The default code
is 0000.

To change the code:

Select

Change code

and press ENTER.

Enter the current code and press ENTER.

Enter the code and press ENTER.

Confirm the new code and press ENTER.

If an incorrect code is entered, the text

Incorrect code

is displayed.

If you have forgotten the access code:

Select "

Sirius ID:

" in the SiriusXM

൅ set-

tings menu and press ENTER.

Press and hold the ENTER button for
2 seconds.

The current code will be displayed.

Your Volvo retailer can also provide you with
assistance.

SiriusXM

൅ ID

This function displays the 12-digit SiriusXM

൅

activation ID.

10 Audio

CD player

260

CD function controls

MENU NAVIGATION CONTROL–press
the up or down arrow keys to scroll in a
menu, or the keys on the left/right sides of
the control to change CD tracks/fast for-
ward/back

CD eject button

CD slot

MODE button

TUNING dial for selecting tracks

CD player

Playing a CD

Start the CD player by pressing the MODE but-
ton (5) and inserting a disc in the slot (4). If there
is already a disc inserted, it will begin to play.

NOTE

If a CD is in the slot when the audio system
is in CD mode, the CD will be played auto-
matically.

CD eject

–

Press the eject button (3) to eject the disc.

CD Pause

When the audio system volume is turned off
completely, the CD player will pause and will
resume playing when the volume is turned up
again.

Audio files

In addition to playing normal music CDs, the
CD player can also play discs containing files
in mp3 or wma format.

NOTE

Certain discs that are copy protected can-
not be read by the player.

When a disc with audio files is inserted in the
player, the player scans the disc's folders
before it begins playing the files. The length of
time that this takes depends on the quality of
the disc.

Navigating the disc and playing tracks

If a disc with audio files is in the CD player,
press ENTER to display a list of folders on the
disc.

Use the up and down arrows in the navigation
control (see the illustration on page 260) to
move among the folders on the disc. Audio files
have the

symbol and folders containing

these files have the

symbol. Press

ENTER to play a selected folder or a file.

When the music file has been played, the
player will continue to play the rest of the files
in the current folder. When all of the files in the
folder have been played, the player will auto-
matically go to the next folder and play the files
in it.

Press the left or right arrow key on the naviga-
tion control if the entire name of the current
track does not fit in the display.

Changing tracks

Briefly press the left or right arrow keys on the
MENU NAVIGATION CONTROL to skip to the
previous or next track/file.

10 Audio

CD player

261

NOTE

The TUNING dial (6) (turn clockwise to go to
the next track/file, or counterclockwise to
go to the previous track/file) or the steering
wheel keypad can also be used for this pur-
pose.

Fast forward/back

–

Press and hold down the left or right arrows
keys in the menu navigation control (or the
corresponding keys on the steering wheel
keypad) to search within a track/file or the
whole disc. The search continues for as
long as the buttons are held down.

Random play

This function plays the tracks/files on a CD in
random order (shuffle).

Activating/deactivating the random
function

If a normal CD is being played:

Press MENU followed by ENTER.

Select Random and press ENTER.

If a CD with audio files is being played:

Press MENU followed by ENTER.

Select

Random

and press ENTER.

Select

Disc

Folder

and press ENTER.

Scan

This function plays the first 10 seconds of each
track/file on the CD.

–

Press SCAN.

–

Press EXIT or SCAN to stop the scan func-
tion and listen to an entire track/file.

CD eject

Press the eject button (3) to eject the disc.

NOTE

•

The Eject all function can only be used
while the vehicle is at a standstill and will
be cancelled if the vehicle begins to
move.

•

For reasons of traffic safety, the ejected
CD must be removed within 12 seconds
or it will be automatically drawn back
into the slot and the CD player will enter
pause mode. Press the CD button to
restart the disc.

Compact disc care

Keep the following in mind when playing/han-
dling compact discs

•

Do not put tape or labels on the disc itself.
They could become stuck in the player.

•

CDR discs can cause listening problems
due to the quality of the disc or recording
equipment used.

•

DualDisc: The audio side of a DualDisc
(combined CD/DVD) does not meet CD
specifications and may not play in your
audio system.

•

Keep the discs clean. Wipe them with a
soft, clean, lint-free cloth, working from the
center outward. If necessary, dampen the
cloth with a neutral soap solution. Dry thor-
oughly before using.

•

Never use cleaning spray or antistatic liq-
uid. Use only cleaners specifically made for
CDs.

•

Use discs of the correct size only
(3.5" discs should never be used).

•

Volvo does not recommend the use of
plastic outer rings on the disc.

•

Condensation may occur on discs/optical
components of the CD player in cold winter
weather. The disc can be dried with a
clean, lint-free cloth. Optical components
in the CD player may, however, take up to
one hour to dry off.

10 Audio

Audio menu

263

FM1/FM2 menu

Radio text

Audio settings…

AM menu

Audio settings…

CD menu

For normal music CDs

Random

Disc text

Audio settings…

CD menu

For CDs containing files in MP3 format

Playlist

Random…

Disc text

Audio settings…

AUX menu

AUX input volume…

Audio settings…

USB menu

Playlist

Random…

Track information

Audio settings…

10 Audio

Bluetooth

hands-free connection

264

Introduction

System overview

Cell phone

Location of the microphone

Center console control panel and display

Bluetooth

hands-free

This feature makes it possible to set up a wire-
less connection between a Bluetooth

-ena-

bled cell phone and the vehicle’s audio system.
This enables the audio system to function as a
hands-free connection and allows you to
remote-control a number of the phone’s func-
tions. The microphone used by this system is
located in the ceiling console (2). The buttons

and other controls on the cell phone can
always be used regardless of whether or not
the phone is connected to the hands-free sys-
tem.

NOTE

Not all cell phones are fully compatible with
the hands-free system. A list of compatible
phones is available at your Volvo retailer or
at www.volvocars.us

WARNING

Never use the hands-free feature or any
other device in your vehicle in a way that
distracts you from the task of driving safely.
Distraction can lead to a serious accident.

Getting started

Use the controls in the center console (3) to
access, navigate and make selections in the
hands-free system’s menus (see page 268).

Activating/deactivating

A short press on the PHONE button in the cen-
ter console activates the hands-free system.
The text

PHONE

will appear at the top of the

display to indicate that the audio system is in
telephone mode.

The

symbol indicates that the hands-free

system is active.

A long press on the PHONE button deactivates
the hands-free system and disconnects the
cell phone.

Connecting cell phones

The procedure for connecting a cell phone var-
ies, depending on the phone itself, and on
whether or not the phone has been previously
connected.

If this is the first time the phone is to be con-
nected to the hands-free system, proceed as
follows:

Alternative 1–using the vehicle's menus

Activate the cell phone’s Bluetooth

func-

tion (refer to the phone’s owner’s manual if
necessary) or go to www.volvocars.com

Activate the vehicle’s Bluetooth

hands-

free system by briefly pressing the
PHONE button.

Add phone

will be displayed. If one or

more cell phones are already registered
in the system, they will also be dis-
played.

Select

Add phone

10 Audio

Bluetooth

hands-free connection

265

> The audio system will search for cell

phones that are in range. This search
takes approximately 30 seconds. Any
phones detected will be displayed with
their Bluetooth

names. The hands-free

system’s Bluetooth

name will appear

in the cell phone’s display as

My Volvo

Car

Select one of the cell phones shown in the
audio system’s (center console) display.

Using the cell phone’s keypad, enter the
digits shown in the audio system’s display.

Alternative 2–using the cell phone’s menus

Activate the hands-free system by briefly
pressing the PHONE button in the center
console. If there is a cell phone connected,
disconnect it from the hands-free system.

Perform a search using the cell phone’s
Bluetooth

function (consult the cell

phone’s owner’s manual if necessary).

Select

My Volvo Car

in the list of devices

shown in the cell phone’s display.

When prompted, enter the PIN code 1234
in the cell phone.

Connect to

My Volvo Car

from the cell

phone.

The cell phone will be registered and will be
connected automatically to the audio system
while the text

Synchronizing

is displayed. For

more information on synchronizing a cell
phone, see page 267.

When a connection has been established, the

symbol and the cell phone’s Bluetooth

name will be displayed. The cell phone can
now be controlled from the audio system.

Making a call

Ensure that

PHONE

is shown at the top of

the center console display and that the

symbol is visible (by pressing briefly on

PHONE on the center console).

Dial the desired phone number or use the
phone book (see page 267).

Press ENTER.

End the call by pressing EXIT.

Disconnecting the cell phone

The cell phone is automatically disconnected
from the audio system if it is moved out of
range. For more information about connec-
tions, see page 264.

The cell phone can be manually disconnected
from the hands-free system by pressing
PHONE. The hands-free system is also deac-
tivated when the ignition is switched off (or if

the driver’s door is opened on vehicles equip-
ped with the optional keyless drive).

When the cell phone is disconnected from the
hands-free system, a call in progress can be
continued using the cell phone’s own speaker
and microphone.

NOTE

Certain cell phones may require confirma-
tion from the phone’s keypad when a call is
transferred from hands-free to the cell
phone.

Handling calls

Incoming calls

–

Press ENTER to answer a call, even if the
audio system is currently in e.g., CD or FM
mode.

–

Press EXIT to defer a call.

Automatic answer

This function means that incoming calls will be
answered automatically. Activate or deactivate
the function in the menu system under

Phone

Menu…

Call options…

Automatic

answer

Volvo C30 (2013 year). Instruction - part 14
