Engine
Tire size
Tire pressure
psi
kPa
bar
2.0L/210 hp (155 kW)
215/55 R17 94H
31
220
2.2
235/45 R18 94H
31
220
2.2
235/40 R19 92H
33
230
2.3
2.0L/150 hp (110 kW) TDI
215/60 R16 95T
30
210
2.1
215/55 R17 94H
30
210
2.1
235/45 R18 94H
30
210
2.1
235/40 R19 92H
33
220
2.2
Compact spare wheel
T125/90 R16
60
420
4.2
The Tire Pressure Monitoring System is configured at the factory with the correct tire inflation pres-
sure applicable for the vehicle model, engine and factory-installed tires. The tire inflation pressure is
listed on the tire inflation pressure label on the driver door jamb. The tire inflation pressures for the
road tires are listed on this label. The inflation pressure for the compact spare is as specified on the
tire pressure label or on a separate label for the compact spare, if there is one. In the event of a
discrepancy between the above figures and the tire pressures listed on the tire inflation pressure
label, the pressures listed on the label are the ones you should use. The listed pressure applies to all
road tires. The Tire Pressure Monitoring System must be recalibrated using the SET button whenev-
er you change or adjust the cold tire inflation pressures or remove and remount or change any wheel
or tire on the vehicle, even if the reinstalled or replacement wheels and tires are identical to those
that were removed and even if the tire pressure does not change
Tread depth and tread wear indicators
Fig. 94 Tread pattern: Wear indicator.
Please first read and note the introductory information and heed the WARNINGS
