– Turn the bulb socket -1- in the direction of the -arrow A-. the tail lamp. – Remove the bulb for the back-up lamp. the following: Caution There is a risk of damaging the lamp. ♦ Do not touch glass cone of bulb with bare fingers. Fingers will leave traces of grease on the glass which, when the bulb is switched on, will evaporate and cloud the glass. ♦ Use clean cloth gloves to insert the bulbs. – Perform a function test. 4.9.2 Back-Up Lamp Bulb, Removing and In‐ stalling, Wagon The removal and installation is described for the left side. Re‐ moving and installing on the right side is identical. Caution Risk of damaging the component surfaces. ♦ When positioning a prying tool, put for example commer‐ cially available adhesive tape over the component in the visible area. – If necessary insert a narrow screwdriver in the opening on the side -1-. – Remove the cover -2- in the direction of the -arrow A-. |
