– Loosen the catches -1- on both sides in the direction of the
-arrow A-.
– Remove the rain sensor trim -2-.
– Loosen the locking mechanisms -1- in the direction of the
-arrow A-.
– Fold out the Distance Regulation Control Module - J428- -3-
in the direction of the -arrow B-.
– Remove the Distance Regulation Control Module - J428- -3-
from the adapter frame -2-.
Installing
Install in the reverse order of removal while paying attention to
the following:
– Calibrate the adaptive cruise control. Refer to
⇒ “6.3 Adaptive Cruise Control, Calibrating”, page 45
.
6.3
Adaptive Cruise Control, Calibrating
Conditions
– The Distance Regulation Control Module - J428- must be cali‐
brated during the following conditions:
♦ Distance Regulation Control Module - J428- was removed and
installed or replaced.
♦ Bumping into the Distance Regulation Control Module - J428-
when not cautiously assembling the front bumper cover.
♦ Damage to the front bumper cover due to an accident or
something similar.
♦ The front bumper carrier was remove and installed or re‐
placed.
♦ Rear axle toe was adjusted.
Too great of a horizontal adjustment of the Distance Regulation
Control Module - J428- causes the ACC/Front Assist functions to
remain switched off. This will show the following message in the
Instrument Cluster - KX2- :
ACC/Front Assist not availa-
ble
.
A limited sensor view due to a dirty sensor or inclement weather
conditions such as heavy rain, snowfall or iced-over sensor cau‐
ses the ACC/Front Assist functions to be temporarily unavailable.
This is indicated by the following message in the Instrument Clus‐
ter - KX2- :
ACC/Front Assist: No sensor view
.
– Calibrate the adaptive cruise control. Refer to ⇒ Suspension,
Wheels, Steering; Rep. Gr. 44 ; Adaptive Cruise Control
(ACC); Adaptive Cruise Control (ACC), Calibrating .
