Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 174





DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

P2279

MAP/

MAF -

Throttle

Position

Correla‐

tion

Intake Air

System

Rationali‐

ty Check

• Filtered lamb‐

da controller in‐

cluded correc‐

tion and adap‐

tation -30.0 –

30.0 %

• Lambda con‐

trol active

• And
• Deviation throt‐

tle area control‐

ler > 60.0 %

• Throttle position

> 0.0° TPS

• Throttle position

< 100.003° TPS

• Engine speed >

576; < 3,008

RPM

• Modeled pres‐

sure quotient >

0.27; < 0.57 [-]

• Engine running
• Throttle actuator

commanded on

• Time after engine

start > 5.0 s

• Throttle position

sensor failure not

detected

• Fuel cut off not

active

• Fast throttle

adaptation finish‐

ed

• Gradient intake

manifold pres‐

sure -199.90 –

199.90 kPa/s

• Engine speed

limitation not ac‐

tive

• Barometric pres‐

sure plausibility

diagnosis finish‐

ed

• Intake manifold

modeled adap‐

tion active

• And
• Choice of:
• MAF sensor ac‐

tive

• Or
• Manifold pres‐

sure sensor ac‐

tive

• And
• Choice of:
• Pressure up‐

stream throttle <

135.0 kPa

• 5.0 s
• Con‐

tinu‐

ous

• 2

DCY

– Check visually

for air leaks be‐

tween intake

and throttle

body, oil fill cap

not tight or oil

dipstick not

seated in tube.

– Also visually in‐

spect any en‐

gine gaskets

that can cause

additional air to

enter the crank‐

case can set this

fault as the PCV

system is not

metered. If a

vacuum leak or

crankcase gas‐

ket sealing is at

cause, the idle

may be rough or

unstable.

– Check the In‐

take Manifold

Sensor - GX9- .

Refer to

⇒ “3.6.23  Intake

Manifold Sensor

GX9 , Check‐

ing”, page 505

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

369

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Or
• Pressure up‐

stream throttle

not active

• And
• Choice of:
• Barometric pres‐

sure > 73.00; <

107.50 kPa

• Or
• Barometric pres‐

sure sensor not

active

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

370

     Rep. Gr. ST - Generic Scan Tool

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Filtered lamb‐

da controller

correction >

35.0 %

• Filtered lamb‐

da controller

correction

-50.0 – 50.0 %

• Lambda con‐

trol active

• Throttle position

> 4.50° TPS

• Engine speed >

1,216; < 6,000

RPM

• Modeled pres‐

sure quotient >

0.63; < 0.90 [-]

• Engine running
• Throttle actuator

commanded on

• Time after engine

start > 5.0 s

• Throttle position

sensor failure not

detected

• Fuel cut off not

active

• Fast throttle

adaptation finish‐

ed

• Gradient intake

manifold pres‐

sure -199.90 –

199.90 kPa/s

• Barometric pres‐

sure plausibility

diagnosis finish‐

ed

• And
• Choice of:
• MAF sensor ac‐

tive

• Or
• Manifold pres‐

sure sensor ac‐

tive

• And
• Choice of:
• Pressure up‐

stream throttle <

135.0 kPa

• Or
• Pressure up‐

stream throttle

not active

• And
• Choice of:

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

371

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Barometric pres‐

sure > 73.00; <

107.50 kPa

• Or
• Barometric pres‐

sure sensor not

active

P2300

Ignition

Coil "A"

Primary

Control

Circuit

Low

Ignition

Coils

Open Cir‐

cuit

• Output voltage

in OFF state,

lower range >=

1.92 – 2.21 V

• Output voltage

in OFF state,

upper range

(hardware val‐

ues) <= 2.85 –

3.25 V

• Engine speed >

512 RPM

• ECT @ cylinder

head > -30° C

• Engine stop not

active

• 1.0 s
• Con‐

tinu‐

ous

• 2

DCY

– Check the Igni‐

tion Coils with

Power Output

Stage . Refer to

⇒ “3.6.20  Igni‐

tion Coils with

Power Output

Stage , Check‐

ing”, page 499

 .

Ignition

Coils

Short To

Ground

• Output current

in ON state

(hardware val‐

ues) > 50 – 100

mA

Ignition

Coils

Short To

Battery

Plus

• Diagnosis by

inactive low

side: switch in

ATIC:

• Output voltage

in OFF state

(hardware val‐

ues) > 4.95 –

5.285 V

• Engine speed >

512 RPM

• Engine stop not

active

• Actuator com‐

manded off

• Diagnosis by

inactive low

side: switch in

ATIC:

• Output temper‐

ature from AT‐

IC in ON state >

160.0 – 200.0°

C

• Or
• Output current

in ON state

(hardware val‐

ues) driver

stage internal

value

• Engine speed >

512 RPM

• Engine stop not

active

• Actuator com‐

manded on

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

372

     Rep. Gr. ST - Generic Scan Tool
