DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Min. fuel mass >=

0.00 [mg/rev]

• Intake manifold

runner flap posi‐

tion change not

active

• Injection mode

change (DFI/MFI)

not equipped

• Valve lift position

change not active

• Depending on

gear:

• 1st gear not ac‐

tive

• 2nd gear not ac‐

tive

• 3rd gear not ac‐

tive

• 4th gear active
• 5th gear active
• 6th gear active
• 7th gear active
• 8th gear not ac‐

tive

• And
• Integrated MAF

>= 1.0 – 12.0 kg

• Diff. engine

speed vs. dynam‐

ic engine speed <

200 RPM

• Diff. MAF vs. dy‐

namic MAF <

29.99 mg/rev

• ECT @ cylinder

head 60 – 143° C

• Adaptation cycles

<= 255 [-]

• Engine speed

1,312 – 3,008

RPM

• And
• Mass fuel flow

lower range >=

11.00 mg/rev

• Mass fuel flow

upper range <=

32.00 mg/rev

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

353

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

P219F

Cylinder

4 Air-

Fuel Ra‐

tio Im‐

balance

Air Fuel

Imbal‐

ance

Monitor‐

ing Out

Of Range

High

• Cylinder 1:
• Weighted

adaptive value

> 10.0 %

• Fuel pressure

setpoint not cali‐

brated [kPa]

• Modeled catalyst

temperature @

start <= 850° C

• Lambda set value

0.97 – 1.03 [-]

• Catalyst heating

not active

• Engine rough‐

ness signal valid

• Cylinder shut off

not active

• AAT >= -48° C
• Barometric pres‐

sure >= 73.0 kPa

• Min. injection

time not reached

• And
• Choice of:
• Catalyst diagno‐

sis n.a.

• Or
• Catalyst diagno‐

sis n.a.

• Depending on

catalyst diagno‐

sis:

• Canister purge

(conditions) n.a.

• Or
• Evap purge valve

n.a.

• Or
• Evap purge n.a.
• And
• O2S dynamic di‐

agnosis n.a.

• O2S delay diag‐

nosis n.a.

• Lambda control

closed loop

• Catalyst purge

not active

• Canister load <=

2.00 [-]

• 90 s
• Once /

DCY

• 2

DCY

– Check the Fuel

Injectors . Refer

to

⇒ “3.6.15  Fuel

Injectors ,

Checking”, page

487

 .
