Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 125
DTC /
Descrip‐
tion
Monitor
Strategy
Descrip‐
tion
Malfunction Crite‐
ria and Threshold
Value
Secondary Parame‐
ters with Enable
Conditions
Monitoring
Time
Length
MIL Il‐
lum.
Component Diag‐
nostic Procedure
Air Fuel
Imbal‐
ance
Monitor‐
ing Out
Of Range
Low
• Cylinder 4:
• Weighted
adaptive value
< -15.0 %
• Or
• Catalyst diagno‐
sis n.a.
• Depending on
catalyst diagno‐
sis:
• Canister purge
(conditions) n.a.
• Or
• Evap purge valve
n.a.
• Or
• Evap purge n.a.
• And
• O2S dynamic di‐
agnosis n.a.
• O2S delay diag‐
nosis n.a.
• Lambda control
closed loop
• Catalyst purge
not active
• Canister load <=
2.00 [-]
• Engine no full
load
• Fuel cut off not
active
• Segment adapta‐
tion finished
• Catalyst damag‐
ing misfire not de‐
tected
• Emission thresh‐
old misfire not de‐
tected
• No gear switch
for segments >=
90.00 [-]
• Segments after
start > 0.00 [-]
• Time after engine
start > 0.0 [s]
• Rough road n.a.
• And depending
on gear:
• 1st gear not ac‐
tive
GTI 2014 ➤
