Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 89

Test-ID DTC

Component or System

Min.

Max.

Additional Information

$92

P013B Oxygen Sensor Maximum Gradient Of

Sensor Signal During Lean – Rich –

Transition.

650.0

mV/s

65,534.

0 mV/s

Refer to DTC P013B in the

DTC summary table.

⇒ page 70

$93

P013E Oxygen Sensor Dynamic Test, Delay

Rich To Lean.

0.0 s

0.9 s

Refer to DTC P013E in the

DTC summary table.

⇒ page 73

$94

P013F Oxygen Sensor Dynamic Test, Delay

Lean To Rich.

0.0 s

NaN

Refer to DTC P013F in the

DTC summary table.

⇒ page 76

$95

P2270 Oxygen Sensor Target Voltage In Fat

Mode Not Reached.

0.874 V 7.999 V Refer to DTC P2270 in the

DTC summary table.

⇒ page 179

$96

P2271 Oxygen Sensor Target Voltage In

Lean-Burn Mode Not Reached.

0.0 V 0.249 V Refer to DTC P2271 in the

DTC summary table.

⇒ page 182

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $21: Catalytic Converter Monitoring
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $21”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$84

P0420 Catalytic Converter Assessment Of

Oxygen Storage Capacity (OSC) Com‐

pared To Catalytic Converter Map.

0.0

OSC

1.0 OSC Refer to DTC P0420 in the

DTC summary table.

⇒ page 121

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $35: Camshaft Adjustment Bank 1
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $35”.
– Select the desired “Test-ID” or “Hex-ID”.

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$80

P0011 VVT Intake Camshaft Diagnosis, Tar‐

get Position Not Reached, Target Er‐

ror.

0.0°

CRK

10.0°

CRK

Refer to DTC P0011 in the

DTC summary table.

⇒ page 46

$81

P000A VVT Intake Camshaft Diagnosis,

Specified Position Reached Too

Slowly, Slow Response.

10.0°

CRK

655.35°

CRK

Refer to DTC P000A in the

DTC summary table.

⇒ page 46

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $3C: Tank Venting System Leak Test (0.020" / 0.5

mm)
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $3C”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$83

P0456 NVLD Fine Leak Detection.

10.0

65,535.

Refer to DTC P0456 in the

DTC summary table.

⇒ page 127

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $3D: Tank Vent Valve Function Check
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $3D”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$8B

P0441 Tank Vent Valve – Function Check,

Test Using Cross-Correlation.

0.1

655.35 Refer to DTC P0441 in the

DTC summary table.

⇒ page 124

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

Rep. Gr. ST - Generic Scan Tool

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $41: O2 Sensor Heater Bank 1 – Sensor 1
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $41”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$85

P0135 Oxygen Sensor Ceramic Tempera‐

ture Monitoring.

630.0° C 6,513.5°

Refer to DTC P0135 in the

DTC summary table.

⇒ page 66

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $42: O2 Sensor Heater Bank 1 – Sensor 2
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $42”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$90

P0141 Oxygen Sensor Nernst Cell Resist‐

ance Test.

0.0 Ω

700.0 Ω Refer to DTC P0141 in the

DTC summary table.

⇒ page 79

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

Monitor-ID $71: Secondary Air System Bank 1
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $71”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$82

P0491 System Testing, Reduced Secon‐

dary Air Mass.

0.0

1.999 Refer to DTC P0491 in the

DTC summary table.

⇒ page 129

$85

P0410 System Testing Of Pressure Sensor. 0.0 kPa 5.0 kPa Refer to DTC P0410 in the

DTC summary table.

⇒ page 119

$8C

P2440 Functional Testing Of Secondary Air

Valve, Valve Leak Check.

0.0

1.34

Refer to DTC P2440 in the

DTC summary table.

⇒ page 190

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.
Monitor-ID $A2: Misfire Cylinder 1 Data
– Connect the scan tool.
– Start the engine and run at idle.
– Select “Diagnostic Mode 6: Check test the results of compo‐

nents that are not continuously monitored”.

Select “Monitor-ID $A2”.
– Select the desired “Test-ID” or “Hex-ID”.
– Check specified values at idle.

Test-ID

DTC

Component or System

Min.

Max.

Additional Information

$0B

P0301 Misfire Cylinder 1, Average Value

Over 10 Driving Cycles.

0.0

counts

65,535.

0 counts

Refer to DTC P0301 in the

DTC summary table.

⇒ page 98

$0C

P0301 Misfire Cylinder 1, In This Driving

Cycle.

0.0

counts

65,535.

0 counts

Refer to DTC P0301 in the

DTC summary table.

⇒ page 98

– If any of components or systems fail to meet the specified val‐

ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐

ory” to check for stored DTC's or the corresponding diagnostic

repair procedure

⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”,

page 24

– Switch the ignition OFF.

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

Rep. Gr. ST - Generic Scan Tool
