3. Light Emitting Diode (LED)

This Light Emitting Diode (LED)
must light up when remote control is
operated.

If Light Emitting Diode (LED) does
not light up when remote control is
operated, battery is completely
discharged and must be replaced.

4. Battery

Remove battery

57-2, Removing

Install battery

57-2, Installing

5. Radio-frequency unit - lower part

Removing

- Insert screwdriver in slot between radio-frequency unit - 1
- and key - 2 - .

- Rotate screwdriver in direction of - arrow - and detach
radio frequency unit from key.

Central locking system

13/2/2005

- Press apart radio-frequency unit - 1 - using key bit of key -
2 - .

- Use a screwdriver to unclip battery - 1 - out of holders - 2
- in direction of - arrow - .

Installing

Note polarity and installation position of battery when
installing.

- Place battery - 1 - in radio-frequency unit - 2 - with
positive terminal downward (positive terminal is marked in
housing).

- Press on battery with light pressure to engage it in radio-
frequency unit.

- Reattach cover to radio-frequency unit (do not damage
seal).

- Then engage radio-frequency unit on key.

Adaptation of keys with radio remote
control

Adaptation of keys with remote control is performed using
Vehicle Diagnostic, Testing and Information System

Central locking system

13/2/2005

VAS5051 .

- Select "Guided Fault-Finding" on diagnostic tester
VAS5051 .

- Via Go To button, select "Function-/Component
selection" and following menu points in sequence:

Chassis

Body-Interior; Repair

01 - On Board Diagnostic (OBD) capable systems

Comfort system

Functions - Comfort system

Adaptation of keys with radio-frequency remote control

Central locking system

13/2/2005

58 - 1

Rear doors

Tools

Special tools, testers and auxiliary items
required

Socket wrench T10011

Socket wrench T10072

Assembly tool T10034

Box spanner 3320/2 for 3320

Box spanner 3320/3 for 3320

Socket 3410

Rear doors

13/2/2005
