53-66
Welding in
Note:
For the right side panel, butyl adhesive sealing cord -1- must be applied to the wheelhousing
- Install and fasten new part with vehicle standing on wheels or alignment bracket set.
- Check gap dimensions with accessories.
Note: WARNING!
New part must be installed within 30 minutes,
- Apply adhesive to flanged area -2-. 2 beads, each 3.5 mm diameter. Observe repair notes
Page 00-6 . 53 55 55 20 Side panel, partial replacement (Jetta wagon) 13/2/2005 |
