Check input with -> Key
Continue with the - Q key
– Confirm the vehicle data entered or read through the
Q
key.
Upon indication on display:
Visual inspection Ok = j not Ok =
– Enter the visual inspection result.
Upon indication on display:
F1 temperature measurement with sen-
sor
F2 enter manually the temperature meas-
urement
– Press the
F1
key for “temperature measurement with sensor”.
– When the engine oil temperature reaches 80° C, remove the
sensor and insert the oil dipstick up to the stop.
– Proceed with the test by pressing the
Q
key.
Upon indication on display:
Idle speed rotation -
>
ACTUAL rotation xxxx/
min THEORETICAL xxxx/min
– Press the key
→
.
Idle speed rotation out of the theoretical value field:
Note
The idle speed rotation and the maximum rotation can be tested,
but cannot be adjusted.
– If the values are not in the theoretical value field, a Repair
Measure must be performed.
– Proceed with the test by pressing the
Q
key.
Upon indication on display:
Engine cutting rotation
5 sec.
ACTUAL rotation xxxx/
min THEORETICAL xxxx...xxxx/min
– Press the accelerator pedal up to the end for the time required,
and keep it pressed.
WARNING
If the engine cutting rotation is exceeded, release the acceler‐
ator pedal immediately and perform a Repair measure.
Upon indication on display:
Engine cutting rota-
tion ->
ACTUAL rotation xxxx/
min THEORETICAL xxxx...xxxx/min
– Release the pedal.
FOX 2004 ➤
5. Additional tasks due to country legislation
117
