Inspection Service

Service based on time or kilometers traveled
Vehicles with “Service based on time or kilometers traveled” have

the PR numbers: QG0.
Inspection intervals
Vehicles with service depending on time or kilometers traveled,

every 30,000 km or 2 years and every 60,000 km or 4 years (for

Europe on vehicles model ▸2007).
Vehicles with service depending on time or kilometers traveled,

every 60,000 km or 3 years and, then, every 2 years (for Europe

on vehicles model 2008▸ , except Europe on vehicles 2009▸) .
Vehicles with service depending on time or kilometers traveled,

every 1 year, 30,000 km, and 60,000 km (except Europe for ve‐

hicles model ▸2008).
If the vehicle runs 30.000 km, 60.000 km, etc. before elapsing 1

year, the Inspection Service for 30,000 km, 60,000 km, etc. shall

be performed together with the inspection service for 1 year.
If the vehicle runs 30.000 km or 60.000 km after the performance

of the Inspection Service for 1 year, perform only the items ex‐

clusive for the Inspection Service for 30,000 km or 60,000 km.
A tolerance of “up to 1,000 km” is acceptable, above or below the

indicated kilometer traveled, in services based on kilometers trav‐

eled, and “one month”, after or before the indicated time, for

services based on time.

Note

♦

Inform the customer in case of problems within a service scope

that require a Repair action.

♦

Use oils with high lubrication performance according to spec‐

ifications VW 502 00 (petrol) and VW 505 00 or 505 01 (SDI),

(diesel PD) and VW 505 01 (TDI).

♦

For countries with high sulfur content in Diesel, the Engine Oil

Change Service must be carried out every 7500 km. Countries

where the sulfur content is higher

⇒ page 28

Notes for carrying out tasks
The sequence of each service operation was tested and opti‐

mized. It shall be adhered to so as to prevent unnecessary service

interruptions.
If the battery is disconnected, the power window drive automatic

closing function will not operate. Thus, this function must be re‐

programmed before delivering the vehicle. The vehicle battery

cannot be disconnected after reprogramming. Power window

drive - reprogram

⇒ page 36

Ask the customer about installing new Windshield wiper blades

and adding window cleaning -G 052 131 A1- until 07/2005 and

window cleaning -G 052 184 A2- until 08/2005 or cleaning and

antifreeze product -G 052 164 A1- to the Windshield/rear window

wiper system.

Application

Windshield/rear window washer

additive

Proportion

EUROPE only

-G 052 164 A1- or -G 052 164 A2- 300 ml of additive for 700 ml of wa‐

ter.

Tropical climate countries

-G 052 131 A1- until 07/2005

1.69 fl oz additive for 28.74 fl oz wa‐

ter.

FOX 2004 ➤

2. Service plans

Windshield/rear window washer

additive

Proportion

-G 052 184 A2- from 08/2005

100 ml additive for 990 ml water.

Service for vehicles with “service based on time and kilometers traveled”

Service

Electrics

– Battery: check with Battery tester with printer -VAS 5097A- .

♦ for Europe on vehicles model 2011▸

⇒ page 43

– Passenger compartment's lighting, cigarette lighter, horn and control lights:

check operation.

– Front lighting: check operation of parking lights, low beam, high beam, fog

lights, indicator system and warning lights

– Rear lighting: check operation of brake lights (including the third brake light),

rear lights, reversing lights, fog light, license plate light, boot lighting, indi‐

cator lights and warning lights.

– Driver and passenger airbag: make a visual inspection in relation to external

damages.

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008)

⇒ page 48

– Self-diagnosis: Refer to the failure memory of every system with the Diag‐

nosis, Measurement and Information System .

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

⇒ page 24

– Dust and pollen filter: Replace the filter element.

♦ at every 30,000 km
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

♦ every 18,641.14 mi or 2 years
♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 84

– Spare wheel support stop: lubricate.

♦ CrossFox only

⇒ page 35

Vehicle exterior
– Windshield: check for damage

♦ for Europe on vehicles model 2011▸

– Windshield and rear window wiper: check operation.

⇒ page 49

– Windshield and rear window wiper blades: check the resting position and,

if necessary, adjust it; for malfunctioning wiper blades: correct the sweeping

angle.

⇒ page 51

– Body and paintwork: check for damage.

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008.

♦ every 60,000 km or 3 years and after every 2 years
♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

FOX 2004 ➤

2. Service plans

Service

– Sunroof: check operation, clean the guide rails and lubricate them with Spe‐

cial grease -G 000 450 02- .

♦ at every 30,000 km
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

♦ every 60,000 km or 3 years and after every 2 years
♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 46

Tyres and wheels

– Spare wheel tyre: check the state of tread, sides and depth of grooves _____

mm.

⇒ page 54

– Left front wheel tyre: check the state of tread, sides and depth of grooves

_____ mm

⇒ page 53

– Left rear wheel tyre: check the state of tread, sides and depth of grooves

_____ mm.

⇒ page 53

– Right rear wheel tyre: check the state of tread, sides and depth of grooves

_____ mm.

⇒ page 53

– Front right wheel tyre: check the state of tread, sides and depth of grooves

_____ mm.

⇒ page 53

– Tyres: calibrate, including the spare wheel.

⇒ page 53

Underside of the vehicle
– Engine oil: drain or aspirate

⇒ page 58

– Engine and components in engine compartment (from below): perform a

visual check for leaks and damage.

⇒ page 65

– Poly-V belt: check state.

♦ at every 37,282.27 mi
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

♦ every 60,000 km or 3 years and after every 2 years
♦ for Europe on vehicles model 2008▸except Europe on vehicles model

2009▸.

⇒ page 65

– Transmission: check for damage and leaks, including the state of the con‐

stant velocity joint bellows.

⇒ page 66

– Mechanical transmission: check the oil level.

♦ at every 18,641.14 mi
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

♦ every 60,000 km or 3 years and after every 2 years
♦ for Europe on vehicles model 2008▸ and except Europe on vehicles model

2009▸.

⇒ page 66

– Brake system: perform a visual check for leaks and damage.

⇒ page 67

– Rear pads and linings: check the thickness.

⇒ page 67

– Brake discs: check the level of wear and corrosion

⇒ page 69

– Lower floor protection: make a visual inspection for damage.

⇒ page 73

– Steering bar swivel tips: check the clearance, fastening and state of pro‐

tection bellows.

⇒ page 73

– Front suspension arm joints: check for fastening and clearance, as well as

for damage and leakages in sealing bellows.

⇒ page 76

FOX 2004 ➤

2. Service plans

Service

– Anti-roll bar buffers and front/rear suspension arm joints rubber bushings:

check for damage

♦ for Europe on vehicles model 2011▸

– Front/rear shock absorber springs and rubber buffers

♦ for Europe on vehicles model 2011▸

– Rear wheels: adjust roller bearing gaps.

♦ only for vehicles without ABS and with the following engines: AQZ, BAH,

BLH, and CFZA from 07/01/2007.

⇒ page 74

– Exhaust system: make a visual inspection for leaks and damage.

– Fuel filter: replace.

♦ Identification letters AQZ, BAH, BLH, and CFZA.
♦ at every 30,000 km

⇒ page 87

Engine compartment
– Engine oil filter: replace.

⇒ page 58

– Engine oil: fill

Diesel engine: Identification letter BNM, filling capacity 4,2 l; standard 505 01

(VW).

Diesel engine: Identification letters ASY, 4.3-l filling volume, standard 505 00

(VW) or 505 01 (VW).

Petrol engines: Identification letters AQZ, filling capacity 3.3 l; standard 502 00

(VW).

Petrol engines: Identification letters BAH, BLH, and CFZA, filling capacity 4.0

l; standard 502 00 (VW).

Petrol engine: Identification letter BMD, filling capacity 2.85 l; standard 502 00

(VW).

Petrol engine: Identification letter BKR, filling capacity 3,3 l; standard 502 00

(VW).

⇒ page 58

– Engine and components in engine compartment (from above): check visu‐

ally for damage and leakage.

⇒ page 65

– Windshield/rear window washer: adjust the water jet from ejectors and re‐

plenish the reservoir additive liquid level.

⇒ page 49

– Engine oil: replenish with oil (inspection service without oil change).

♦ for Europe on vehicles model 2008▸ and except Europe on vehicles model

2009▸.

⇒ page 45

– Engine cooling system fluid: correct the proportion of antifreeze and fill up

to the level.

Theoretical value – 25° C (in Arctic climate countries – 35° C) actual value

(value measured) ____ °C.

⇒ page 76

– Spark plugs: replace.

♦ at every 60,000 km or every 4 years, whichever occurs first.

⇒ page 79

– Timing belt and tensioning pulley for camshaft drive: replace. Additional

work with separate payment!

♦ Diesel engine: Identification letters ASY.
♦ at every 93,205.68 mi

⇒ page 85

FOX 2004 ➤

2. Service plans
