Tools

Note

♦

The use of different types and different thicknesses of steel

requires that only the welding units (inverters) authorised by

Volkswagen AG may be used to carry out repairs properly.

♦

The welding units (inverters) and body tools authorised by

Volkswagen AG are listed in ⇒  ServiceNet, Workshop Equip‐

ment, EH catalogue, Workshop equipment, Body and paint‐

work .

13.2

Removing

– Separate original joint to C-pillar reinforcing and to inner wheel

housing liner.

– Separate bonded areas -1- between lock reinforcing and

wheel housing liner.

Passat 2011 ➤ , Passat Variant 2011 ➤

13. Renewing outer wheel housing liner

353

-1- and to rear connecting plate -2-.

Passat 2011 ➤ , Passat Variant 2011 ➤

354

surface back to bare metal.

13.3

Installing

Note

Only welding units authorised by Volkswagen AG may be used

⇒ page 353

 .

Passat 2011 ➤ , Passat Variant 2011 ➤

13. Renewing outer wheel housing liner

355

Preparing new part

New part
♦ Outer wheel housing liner -1-
♦ Reinforcing plate -2-
♦ 2K body adhesive -D 180 KD3 A2-
– Grind bonding surfaces back to bare metal.

13.3.2

Welding in

Note

New part must be welded in within 90 minutes or adhesion of ad‐

hesive will be impaired.

Passat 2011 ➤ , Passat Variant 2011 ➤

356
