Volkswagen Golf Variant, Jetta. Manual - part 31

♦ Torque wrench -V.A.G 1331-
♦ Torque wrench -V.A.G 1332-
♦ Sealing grease -G 052 128 A1-
♦ Drip tray
Perform the following steps:

Note

♦

Do not remove both securing bolts in left and right flange shafts

at the same time. If the differential bevel gears turn, it is difficult

to reinstall the bolts.

♦

Remove drive shaft from gearbox and carefully lay to side.

Drive shaft is fixed onto suspension strut with tensioning belt

-T10038- .

♦

You do not need to remove the centre bolt of the drive shaft.

- noise insulation .

overview - front wheel housing liner .

– If present: Unbolt front left vehicle level sender -G78- from

suspension link.

left vehicle level sender -G78- .
– Turn steering wheel to left lock and remove left drive shaft from

shafts .

Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤

1. Oil seals

121
