Toyota Yaris (2020 year). Manual in english - part 5

268

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-1. Climate Control System

■

Air intake selector

Outside  or  recirculated  air  positions  can  be  selected.  Press  the
switch to select outside/ recirculated air positions.

●

Recirculated air position (indicator light illuminated)
Outside air is shut off. Use this position when going through tun-
nels, driving in congested traffic (high engine exhaust areas) or
when quick cooling is desired.

●

Outside air position (indicator light turned off)
Outside air is allowed to enter the cabin. Use this mode for venti-
lation or windshield defrosting.

■

Rear window defogger switch

Press the rear window defogger switch to defrost the rear window.
Refer to Rear Window Defogger on P. 207.

■

Mode selector dial

●

With the airflow mode set to the

 position and the temperature control

dial set at a medium temperature, heated air is directed to the feet and air at
a comparably lower temperature will flow through the central, left and right
vents.

●

When the fan control dial is ON, and the mode selector dial is in the
or

 position, the air conditioner is automatically turned on and the out-

side  air  position  is  automatically  selected  to  defrost  the  windshield.  In  the

 or

 position, the outside air position cannot be changed to the

recirculated air position.

■

A/C switch

The  air  conditioner  may  not  function  when  the  outside  temperature
approaches 0 °C (32 °F).

WARNING

■

Do not use the

 position in cold or rainy weather:

Using  the

  position  in  cold  or  rainy  weather  is  dangerous  as  it  will

cause  the  windows  to  fog  up.  Your  vision  will  be  hampered,  which  could
lead to a serious accident.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

269

4-1. Climate Control System

4

In

te

rior

F

ea

tu

res

Set the mode selector dial to the AUTO position.
Set the air intake selector to the outside air position (indicator light
turned off).
Set the fan control dial to the AUTO position.
Press  the A/C  switch  to  operate  the air  conditioner  (turn  indicator
light on).
Set the temperature control dial to the desired position.
To turn off the system, set the fan control dial to the 0 position.

■

Operation of Automatic Air conditioner

●

If the recirculated air position is used for long periods in cold weather or high
humidity, the windshield may fog up more easily.

●

Setting the temperature to maximum hot or cold will not provide the desired
temperature at a faster rate.

●

When selecting heat, the system will restrict airflow until it has warmed to
prevent cold air from blowing out of the vents.

Set the mode selector dial to the

 position and turn the fan con-

trol dial to the desired speed.
In this position, the outside air position is automatically selected, and
when the fan control dial is ON, the air conditioner automatically turns
on. The air conditioner will directly dehumidify the air to the front wind-
shield and side windows (



P. 258). Airflow amount will be increased.

Use  the  temperature  control  dial  to  increase  the  air  flow  temperature  and
defog the windshield more quickly.

Operation of Automatic Air Conditioner

Windshield Defrosting and Defogging

WARNING

■

Set the temperature  control  to  the  hot  or  warm  position when  defog-
ging (

 position):

Using the

 position with the temperature control set to the cold posi-

tion  is  dangerous  as  it  will  cause  the  outside  of  the  windshield  to  fog  up.
Your vision will be hampered, which could lead to a serious accident.

1

2

3

4

5

6

270

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-1. Climate Control System

■

Rear window defogger switch

●

Sunlight sensor
Do  not  place  objects  on  the
sunlight  sensor.  Otherwise,
the  interior  temperature  may
not adjust correctly.

●

Interior temperature sensor
Do not cover the interior tem-
perature  sensor.  Otherwise,
the  interior  temperature  may
not adjust correctly.

Sunlight/Temperature Sensor

Sunlight sensor

Interior temperature sensor

271

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Antenna



4-Door

■

AM/FM Radio Antenna

The AM/FM radio antenna receives both AM and FM signals.
The antenna is embedded into the window glass.

■

Satellite Radio Antenna (if equipped)

The  satellite  radio  antenna
receives SiriusXM signals.



5-Door

■

AM/FM Radio Antenna (if equipped)

The AM/FM radio antenna receives both AM and FM signals.



Type A

To remove the  antenna, turn
it counterclockwise.
To install the antenna, turn it
clockwise.

Make  sure  the  antenna  is
securely installed.

Antenna

NOTICE

■

AM/FM Radio Antenna

When washing the inside of the window which has an antenna, use a soft
cloth dampened in lukewarm water, gently wiping the antenna lines. Use of
glass cleaning products could damage the antenna.

1

2

272

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System



Type B

■

Antenna for AM/FM and Satellite Radio Antenna (if equipped)

The  antenna  for  AM/FM  and
satellite radio antenna receives
both  AM  and  FM  signals  and
SiriusXM signals.

NOTICE

■

AM/FM Radio antenna

Type A only:

●

To prevent damage to the antenna, remove it before entering a car wash
facility or passing beneath a low overhead clearance.

●

Be careful around the antenna when removing snow from the roof. Other-
wise the antenna could be damaged.

●

When leaving your vehicle unattended, we recommend that you remove
the antenna and store it inside the vehicle.

273

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Operating Tips for Audio System

Do not spill any liquid on the audio
system.

●

To prevent the battery from being discharged, do not leave the audio system
on for a long period of time when the engine is not running.

●

If a cellular phone or CB radio is used in or near the vehicle, it could cause
noise to occur from the audio system, however, this does not indicate that
the system has been damaged.

WARNING

■

Always adjust the audio while the vehicle is stopped

Do not adjust the audio control switches while driving the vehicle. Adjusting
the  audio  while  driving  the  vehicle  is  dangerous  as  it  could  distract  your
attention from the vehicle operation which could lead to a serious accident.
Even if the audio control switches are equipped on the steering wheel, learn
to use the switches without looking down at them so that you can keep your
maximum attention on the road while driving the vehicle.

NOTICE

For  the  purposes  of  safe  driving,  adjust  the  audio  volume  to  a  level  that
allows  you  to  hear  sounds  outside  of  the  vehicle  including  car  horns  and
particularly emergency vehicle sirens.

274

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

AM characteristics

AM signals bend around such things as buildings or mountains and
bounce off the ionosphere.
Therefore, they can reach longer distances than FM signals.
Because  of  this,  2  stations  may  sometimes  be  picked  up  on  the
same frequency at the same time.

Ionosphere
Station 1
Station 2

■

FM characteristics

An FM broadcast range is usually about 25 - 30 miles (40 - 50 km)
from  the  source.  Because  of  extra  coding  needed  to  break  the
sound into 2 channels, stereo FM has even less range than monau-
ral (non-stereo) FM.

FM Station
25 - 30 miles (40 - 50 km)

Radio Reception

1
2
3

1
2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

275

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Signals  from  an  FM  transmitter  are  similar  to  beams  of  light
because  they  do  not  bend  around  corners,  but  they  do  reflect.
Unlike AM  signals,  FM  signals  cannot  travel  beyond  the  horizon.
Therefore,  FM  stations  cannot  be  received  at  the  great  distances
possible with AM reception.

Ionosphere
FM wave
AM wave
60 - 120 miles (100 - 200 km)
Obstruction

Atmospheric conditions can also affect FM reception. High humidity
will cause poor reception. However, cloudy days may provide better
reception than clear days.

1
2
3
4
5

276

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

Multipath noise
Since FM signals can be reflected by obstructions, it is possible
to  receive  both  the  direct  signal  and  the  reflected  signal  at  the
same time. This causes a slight delay in reception and may be
heard as a broken sound or a distortion. This problem may also
be encountered when in close proximity to the transmitter.

Direct
Reflected wave

●

Flutter/Skip noise
Signals from an FM transmit-
ter move in straight lines and
become  weak  in  valleys
between tall buildings, moun-
tains,  and  other  obstacles.
When  a  vehicle  passes
through  such  an  area,  the
reception  conditions  may
change suddenly, resulting in
annoying noise.

●

Weak signal noise
In suburban areas, broadcast
signals

become

weak

because of distance from the
transmitter.  Reception  in
such  fringe  areas  is  charac-
terized by sound breakup.

1
2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

277

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Strong signal noise
This  occurs  very  close  to  a
transmitter tower. The broad-
cast  signals  are  extremely
strong, so the result is noise
and  sound  breakup  at  the
radio receiver.

●

Station drift noise
When a vehicle reaches the area of 2 strong stations broadcast-
ing at similar frequencies, the original station may be temporarily
lost and the second station picked up. At this time there will be
some noise from this disturbance.

Station 1
88.1 MHz
Station 2
88.3 MHz

MP3  stands  for  MPEG Audio  Layer  3,  which  is  standardized  voice
compression established by the ISO

*

1

 working group (MPEG).

Use of MP3 allows for audio data to be compressed to approximately
a tenth of the source data size.
This unit plays files with the extension (.mp3) as MP3 files.

*

1

: International Organization for Standardization

• When  naming  an  MP3  file,  be  sure  to  add  an  MP3  file  extension

(.mp3) after the file name.

• The number of characters which can be displayed is restricted.

1

2

Operating Tips for MP3

278

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Supply of this product only conveys a license for private, non-commercial use
and does not convey a license nor imply any right to use this product in any
commercial (i.e. revenue-generating) real time broadcasting (terrestrial, satel-
lite, cable and/or any other media), broadcasting/streaming via the Internet,
intranets and/or other networks or in other electronic content distribution sys-
tems, such as  pay-audio  or  audio-on-demand applications. An  independent
license for such use is required.
For details, please visit http://www.mp3licensing.com.

WMA is short for Windows Media Audio and is the audio compression
format used by Microsoft.
Audio data can be created and stored at a higher compression ratio
than MP3.
This unit plays files with the extension (.wma) as WMA files.

*

: Microsoft and Windows Media are registered trademarks of Microsoft Cor-

poration U.S. in the United States and other countries.

• WMA  files  written  under  specifications  other  than  the  indicated

specification may not play normally or files or folder names may not
display correctly.

• The file extension may not be provided depending on the computer

operating system, version, software, or settings. In this case, add
the file extension “.wma” to the end of the file name, and then write
it to the memory.

NOTICE

Do not use an audio file extension on files other than audio files. In addition,
do not change the audio file extension. Otherwise, the unit will not recog-
nize the file correctly resulting in noise or a malfunction.

Operating Tips for WMA

NOTICE

Do not use an audio file extension on files other than audio files. In addition,
do not change the audio file extension. Otherwise, the unit will not recog-
nize the file correctly resulting in noise or a malfunction.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

279

4-2. Audio System

4

In

te

rior

F

ea

tu

res

AAC stands for Advanced Audio Coding, which is standardized voice
compression established by the ISO

*

1

 working group (MPEG). Audio

data  can  be  created  and  stored  at  a  higher  compression  ratio  than
MP3.
This unit plays files with the extensions (.aac/.m4a/.wav) as the AAC
files.

• AAC files written under specifications other than the indicated spec-

ification may not play normally or files or folder names may not dis-
play correctly.

• The file extension may not be provided depending on the computer

operating system, version, software, or settings. In this case, add
the  file  extension  “.aac”,  “.m4a”,  or  “.wav”  to  the  end  of  the  file
name, and then write it to the memory.

*

1

: International Organization for Standardization

Operating Tips for AAC

NOTICE

Do not use an audio file extension on files other than audio files. In addition,
do not change the audio file extension. Otherwise, the unit will not recog-
nize the file correctly resulting in noise or a malfunction.

280

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

OGG is the audio compression format for Xiph. Org Foundation.
Audio data can be created and stored at a higher compression ratio
than MP3.
This unit plays files with the extension (.ogg) as OGG files.

• OGG  files  written  under  specifications  other  than  the  indicated

specification may not play normally or files or folder names may not
display correctly.

• The file extension may not be provided depending on the computer

operating system, version, software, or settings. In this case, add
the file extension “.ogg” to the end of the file name, and then write it
to the disc.

This unit plays audio files as follows:

MP3/WMA/AAC/OGG

*

1

  files  written  under  specifications  other  than

the indicated specification may not play normally or files/folder names
may not display correctly.

Operating Tips for OGG

NOTICE

Do not use an audio file extension on files other than audio files. In addition,
do not change the audio file extension. Otherwise, the unit will not recog-
nize the file correctly resulting in noise or a malfunction.

Operating Tips for USB device

Extension

Playback with this unit

.mp3

MP3

.wma

WMA

.aac

AAC

.m4a

.wav

.ogg

OGG

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

281

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Playback may not be possible depending on the type and condition of the
USB flash memory even if the audio file complies with the standard above.

●

A copyright protected WMA/AAC file cannot be played in this unit.

●

The order of the music data stored in the device may differ from the play-
back order.

●

To prevent loss or damage of stored data, we recommend that you always
back up your data.

●

If  the  current  consumption  of  the  connected  device  exceeds  the  following
current value, it may not operate or recharge.
• Apple device is connected: 2,100mA
• Device compatible with BC1.2 is connected: 1,500 mA
• Device other than the above is connected: 500 mA

●

Do not pull out the USB device while in the USB mode (only pull it out while
in FM/AM radio mode).

●

The device will not operate if the data is password protected.

This  unit  is  compatible  with Apple  CarPlay™  which  can  operate  an
iPhone

®

 using the vehicle’s audio device.

• iPhone,  Siri  and Apple  Music  are  registered  trademarks  of Apple

Inc.

• Apple CarPlay is trademarks of Apple Inc.
• iOS is a trademark or registered trademark of Cisco in the U.S. and

other countries and is used under license.

May not be compatible depending on the model or OS version.

To prevent loss or  damage  of  stored  data,  we recommend that  you always
back up your data.

NOTICE

Do not use an audio file extension on files other than audio files. In addition,
do not change the audio file extension. Otherwise, the unit will not recog-
nize the file correctly resulting in noise or a malfunction.

Agreements and disclaimers related to Apple CarPlay™

282

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Requires the Android Auto app on Google Play and an Android com-
patible smartphone running Android™ 5.0 Lollipop or higher.

• Google, Android, Android Auto and other related marks are trade-

marks of Google LLC.

To prevent loss or  damage  of  stored  data,  we recommend that  you always
back up your data.

NOTICE

●

For the purposes of safety, do not operate your iPhone

®

 while driving.

●

Disconnect  the  iPhone

®

  when  it  is  not  in  use.  If  the  device  is  left  in  the

cabin,  it  could  be  damaged  or  the  battery  may  deteriorate  due  to  the
excessive temperature or humidity inside the cabin.

●

If the iPhone

®

 battery has deteriorated, it may not recharge or play audio

even if it is connected to this unit.

●

Before use, carefully read the user instructions for the iPhone

®

.

Operating Tips for Android™

NOTICE

●

For  the  purposes  of  safety,  do  not  operate  your Android™  Smartphone
while driving.

●

Disconnect the Android™ Smartphone when it is not in use. If the device is
left in the cabin, it could be damaged or the battery may weaken due to the
excessive temperature or humidity inside the cabin.

●

If the Android™ Smartphone battery has deteriorated, it may not recharge
or play audio even if it is connected to this unit.

●

Before use, carefully read the user instructions for the Android™ Smart-
phone.

283

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Audio Set

The explanation of functions described in this manual may differ from
the actual operation, and the shapes of screens and buttons and the
letters  and  characters  displayed  may  also  differ  from  the  actual
appearance.
Additionally, depending on future software updates, the content may
successively change without notice.

■

Commander switch operation

For safety reasons, some operations are disabled while the vehicle
is being driven.

●

Volume dial operation
Press  the  volume  dial  to
mute  and  pause.  However,
while an audio  source  which
cannot  be  paused  such  as
FM  radio  is  playing,  only
mute  is  available.  Press  the
volume  dial  again to  resume
the audio.
Turn the volume dial to adjust
the  volume.  The  volume
increases  by  turning  the  dial
clockwise, and decreases by
turning it counterclockwise.

Audio Set has 3 different human interfaces.

• Commander switch
• Touch panel
• Voice recognition with steering switch and microphone

Volume dial

284

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

Switches around commander knob
The following operations can be done by pressing the switches
around the commander knob.

: Displays  the  home

screen.

: Displays  the  Enter-

tainment screen.

: Displays the Naviga-

tion  screen  (Only
navigation-equipped
vehicles).
For operation of the Navigation screen, refer to the navi-
gation system manual. If the SD card for the navigation
system is not inserted, the compass indicating the direc-
tion in which the vehicle is moving is displayed.

: Displays the Favorites screen. Long-press to store par-

ticular items in Favorites. (Radio, phonebook and desti-
nation of the navigation system can be programmed.)

: Returns to previous screen.

●

Commander knob operation
Selection of icons on screen:

Tilt or turn the commander
knob and move the cursor
to the desired icon.
Press  the  commander
knob and select the icon.

1

2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

285

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Touch panel operation

For safety reasons, operation of
the  center  display  is  disabled
while  the  vehicle  is  being
driven. However, items not dis-
played in gray can be operated
using  the  commander  switch
while  the  vehicle  is  being
driven.

■

Commander switch operation

Long-press operation of the commander knob is also possible for some func-
tions.

■

TOUCH & TAP

Touch or tap on the item indi-
cated on the screen.
The  operation  is  launched
and  the  next  item  is  dis-
played.

NOTICE

■

Touch panel operation

Do  not  press  the  screen  strongly  or  press  it  with  a  sharp-pointed  object.
Otherwise, the screen could be damaged.

Basic Operation Method

1

2

286

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

SLIDE

Touch  the  setting  item  dis-
playing a slider bar.
Touch the slider with your fin-
ger and move to the desired
level.

■

SWIPE

Touch  the  screen  with  your
finger and move up or down.
Items  which  were  not  dis-
played can be displayed.

1

2

1

2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

287

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Return to previous screen

Touch the

.

■

Displaying the home screen

Touch the

.

Home screen

Icon

Function

Applications

Information such as average fuel economy, maintenance,
and  warnings  can  be  verified.  Depending  on  the  grade
and specification, the screen display may differ.

Entertainment

Operates audio such as the radio. The audio source most
recently used is displayed. An audio source which cannot
be  used  at  that  time  is  skipped  and  the  previous  audio
source is displayed.
To  change  the  audio  source,  select  the

  icon  dis-

played at the bottom of the screen.

Communication

Bluetooth

®

 related functions are available.

Navigation

Navigation  screen  is  displayed  (vehicles  with  navigation
system).
If the SD card for the navigation system is not inserted, the
compass  indicating  the  direction  in  which  the  vehicle  is
moving is displayed.
The compass may not indicate the correct bearing when
the vehicle is stopped or traveling at a slow speed.

Settings

Overall setting menu (Such as display, sound, Bluetooth

®

and  Language).  Depending  on  the  grade  and  specifica-
tion, the screen display may differ.

288

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Volume adjustment

Turn the commander switch volume dial. The volume switch on the
steering switch can also be pressed.

Press  the  volume  dial  to  mute  and  pause.  However,  while  an  audio
source which cannot be paused such as FM radio is playing, only mute
is available. Press the volume dial again to resume the audio.

■

Display setting

Select the

 icon on the home screen and display the Settings

screen.

Select the

 tab to select the item you would like to change.

●

Display OFF/Clock

The center display can be turned off. Select

 to turn

the display off. When

 is selected the cen-

ter display turns off and the clock is displayed.
The center display can be turned back on as follows:

• Touch the center display.
• Operate the commander switch.

●

Daytime/nighttime (System) screen setting
The daytime or nighttime screen can be selected.

: Switches  screen  automatically  according  to  parking  lights

illumination condition

*

1

: Daytime screen setting

: Nighttime screen setting

*

1

: The display is constantly on daytime screen when the illumination dim-

mer is cancelled.

Volume/Display/Sound Controls



Commander switch



Audio control switch

Volume dial

Volume

switch

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

289

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Brightness adjustment
Adjust the center display brightness using the slider.

●

Contrast adjustment
Adjust the center display contrast using the slider.

●

Display setting reset
All  of  the  screen  setting  values  can  be  reset  to  their  initial  set-
tings.

Select

.

Select

.

■

Audio sound adjustment

Select the

 icon on the home screen and display the Settings

screen.
Select the

 tab to select the item you would like to change.

1

2

Indication

Setting value

Bass (Low pitch sound)

 Side: Low  pitch  enhance-

ment

 Side: Low pitch reduction

Treble (Treble sound)

 Side: Treble enhancement

 Side: Treble reduction

Fade (Front/Rear volume balance)

Front: Front

speaker

volume

enhancement

Rear: Rear

speaker

volume

enhancement

Balance (Left/right volume balance)

Right: Right

speaker

volume

enhancement

Left: Left

speaker

volume

enhancement

ALC (Automatic volume adjustment) Off—Adjustment at seven levels

Beep (Audio operation sound)

On/Off

290

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

ALC (Automatic volume adjustment)
The automatic level control (ALC) is a feature that automatically
adjusts  audio  volume  according  to  the  vehicle  speed.  The  vol-
ume increases in accordance with the increase in vehicle speed,
and decreases as vehicle speed decreases.

■

Radio ON

Select the

 icon on the home screen to display the Entertain-

ment screen. When selecting the desired radio, the following icons
are indicated in the lower part of the center display.

●

AM/FM Radio

Operating the Radio

Icon

Function

Displays the Entertainment menu. Use to switch to a dif-
ferent audio source.

Displays the station list.
Select

 to display the frequencies of up to

ten radio stations on the auto memory preset list.
Select the desired frequency.

Displays the Favorites list. Long-press to store radio sta-
tion currently being aired.

Switches  the

  on  and  off.  Displays  the  multi-

cast channel list of the

.

You  can  search  for  receivable  radio  stations.  Scanning
stops at each station for about five seconds. Select again
to continue receiving the radio station.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

291

4-2. Audio System

4

In

te

rior

F

ea

tu

res

You can change the radio frequency manually.
Rotate  the  commander  knob,  slide  the  screen,  or  touch
the radio frequency.

Press

  or

  to  change  the  radio  frequency

one step at a time.

When

  or

  is  long-pressed,  the  radio  fre-

quency  changes  continually.  It  stops  when  you  remove
your hand from the icon or the commander knob.

Launches the iTunes Tagging function (for Apple devices

with USB use only). Can be used when the

 is

on.

Automatic radio station selection.
When long-pressed, the radio frequency changes continu-
ally. It stops when you remove your hand from the icon or
the commander knob.

Displays sound settings to adjust audio quality level. Refer
to Volume/Display/Sound Controls on P. 288.

Icon

Function

292

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Favorites Radio

Selected stations can be registered for convenient operation. Up to
50 stations can be registered. The Favorites list is common to AM,
FM, and satellite radio.

●

Registering to Favorites
Long-press the

 icon to register the current radio station.

The registration can also be performed using the following proce-
dure.

Select the

 icon to display the Favorites list.

Select

.

Select

.

The station is added to the bottom of the Favorites list.

●

Selecting radio station from Favorites

Select the

 icon to display the Favorites list.

Select the radio frequency to tune in the radio station.

●

Deleting from Favorites

Select the

 icon to display the Favorites list.

Select

.

Select

.

Select the radio frequency you want to delete.

Select

.

●

Changing Favorites list order

Select the

 icon to display the Favorites list.

Select

.

Select

.

Select  a  radio  frequency.  The  selected  radio  station  can  be
moved.
Slide the radio station or move it using the commander switch,
then select

.

1

2

3

4

1

2

1

2

3

4

5

1

2

3

4

5

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

293

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Radio Broadcast Data System (RBDS) (if equipped)

●

Radio text information display
Radio  text  information  sent  from  a  broadcasting  station  is  dis-
played in the center display.

●

Genre Seek
Some  FM  stations  transmit  Genre  codes  (Program  type  like  a
Rock, News, and so on). This code enables alternative stations
transmitting the same Genre code to be found quickly.
To scan for Genre Seek:

Select the

 icon while in the FM mode.

Select

 to open the genre list.

Select the genre type you want to select.
Select the

,

 icon.

Ex.)
89.3  is  currently  being  received.  With  Rock  selected  as  the
Genre, the radio stations broadcasting Rock are at the following
frequencies.
98.3

*

1

, 98.7, 104.3

*

1

, 107.1

*

1

: Radio stations with good reception

The frequency changes as follows each time

 is pressed.

89.3



98.3



104.3



98.3

■

HD Radio

●

What is HD Radio™ Technology and how does it work?
HD Radio™ Technology is the digital evolution of analog AM/FM
radio. Your radio product has a special receiver which allows it to
receive  digital  broadcasts  (where  available)  in  addition  to  the
analog  broadcasts  it  already  receives.  Digital  broadcasts  have
better sound quality than analog broadcasts as digital broadcasts
provide  free,  crystal  clear  audio.  For  more  information,  and  a
guide  to  available  radio  stations  and  programming,  please  visit
www.hdradio.com.

1

2

3

4

294

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

Benefits of HD Radio™ Technology
Information:
The song title, artist name, album name and genre will appear on
the screen when available by the radio station.
Multicast:
On the FM radio frequency most digital stations have “multiple”
or supplemental programs on each FM station.

●

Listening to HD Radio™ Technology

If

  icon  turns  on  by  selecting  a  radio  station  which  is  an

  broadcasting  station,  the  analog  broadcast  is

switched  to  an

  broadcast  automatically  after  a  few

seconds and then received.

If the

 broadcast is stopped and changed to an analog

broadcast, press down

 to turn off

.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

295

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Multicast channel selection (FM)
If  multi-cast  channels  are  available  for  an

  broadcast

currently being received, the multi-cast channel list is displayed.
Select the desired radio station.

●

iTunes Tagging (for Apple devices with USB use only)
By  tagging  a  song  currently  being  aired,  the  song  can  later  be
purchased  from  the  iTunes  Store.  One  hundred  tags  can  be
stored. A maximum of 100 tags (for 100 songs) can be stored for
later downloading.

Select the

 icon. The tag is stored in the audio unit.

Connect  the  device  via  the  vehicle’s  USB. Any  stored  tag(s)
will be sent automatically to the connected device.
Once at home or after parking the vehicle safely, log onto the
iTunes Store with your device. Your previously tagged song(s)
can now be easily purchased.

■

Favorites Radio

If the battery is disconnected, your Favorites list will not be deleted.

■

Radio Broadcast Data System (RBDS)

●

Radio text information is a function of FM radio only. There is no text func-
tion on AM radio. Text information is not displayed in the following:
• During

 reception

• Not an RBDS broadcast
• RBDS broadcast, but radio text is not transmitted from the radio station

●

To change the desired genre, select the

 icon.

●

Only one Genre can be selected.

●

It may not be possible to receive any station even if the Genre Seek function
is used.

●

If a program in the selected genre is not broadcast to a region, reception is
not possible even if the Genre Seek function is used.

●

The Genre Seek function searches for genre code (program type) which FM
analog broadcasts transmit.

 specialty programs (HD2-HD8) can-

not be searched because they are not FM analog broadcasts.

●

If radio stations which are selected by scanning using the Genre Seek func-
tion  are

  broadcasting  stations,  they  are  changed  from  analog

broadcasts to

 broadcdiffer.

1

2

3

296

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

HD Radio

●

If an analog broadcast is received once and

 is received while HD1

is selected, the audio unit switches to the

 station automatically.

●

When the

 icon is illuminated, there could be a noticeable difference in

sound  quality  and  volume  when  a  change  from  digital  to  analog  signals
occurs.  If  the  sound  quality  and  volume  become  noticeably  diminished  or
cut off, select the

 icon to turn off

 (

 icon is not illumi-

nated).

●

Once  an  analog  broadcast  is  received  when  HD1  is  selected  from  the
Favorite  channels,  it  is  switched  to

  automatically.  If  the  radio

reception conditions are poor, or HD is off, switching to

 broadcasts

is not possible.

●

When an HD specialty channel (HD2 to HD8) is selected from the Favorite
channels, “Signal Lost” is displayed and no audio is output until

 is

received. If the radio reception conditions are poor, “Signal Lost” continues
to be displayed.

●

If  the

  icon  is  not  illuminated,  information  such  as  song  titles  of  the

 station are received, however, the audio output is analog.

■

iTunes Tagging (for Apple devices with USB use only)

●

Both AM and FM

 can be used.

●

Because  iTunes  tagging  only  supports  purchases  from  the  iTunes  Store,
direct downloading of music from the vehicle’s audio unit is not possible.

●

If the available memory for the connected device is insufficient, the tag is not
sent.

●

If an error occurs while the tag is being sent, reconnect the device.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

297

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

What is satellite radio?

●

SiriusXM

®

 Satellite Radio

SiriusXM satellite radio is a subscription-based  satellite radio ser-
vice that broadcasts a variety of music, sports, news, weather, traf-
fic and entertainment programming.
Your new Toyota vehicle is factory-installed with SiriusXM satellite
radio  hardware  and  includes  a  limited  trial  subscription  term  that
begins on the date of sale or lease of your vehicle. See an autho-
rized dealer for availability.
The satellite radio service should be active in your vehicle, if you can-
not  hear  SiriusXM  audio,  please  activate  online  by  visiting  siri-
usxm.com/refresh or by calling SiriusXM Listener Care at 1-877-447-
0011 (U.S.A.)/1-888-539-7474 Customer Care (Canada).
You  can  find  the  radio  ID  by  turning  to  Channel  0  or  visiting  siri-
usxm.com/activationhelp  (U.S.A),  and  siriusxm.ca/subscribe-now/
(Canada).
For more information on extended subscription terms (a service fee
is required), the online media player and a list of SiriusXM satellite
radio channels, and other features, please visit www.siriusxm.com
(U.S.A), and www.siriusxm.ca (Canada), or call SiriusXM at 1-877-
447-0011 (U.S.A.)/1-888-539-7474 (Canada).

This feature may not be available in all markets and requires an active
subscription.  SiriusXM  reserves  the  unrestricted  right  to  change,  rear-
range, add or delete programming. This includes canceling, moving or
adding particular channels, and its prices, at any time, with or without
notice to you. Toyota shall not be responsible for any such programming
changes.

■

Displaying the Radio ID (ESN)

When  channel  0  is  selected,  the  radio  ID  is  displayed.  Use  the
PREVIOUS or NEXT channel buttons to select channel 0.

Operating the Satellite Radio (if equipped)

298

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

SiriusXM operation

Select the

 icon on the home screen to display the Entertain-

ment  screen.  When

  is  selected,  the  following  icons  are  indi-

cated in the bottom part of the center display.

●

Selection from channel list
Receivable  channels  can  be  displayed  on  the  channel  list
screen. You can easily select the channel you want to listen from
the list. Each category can be also displayed.

Select the

 icon to display the channel list.

Select a desired channel.

Select from category list:

Select the

 icon to display the channel list.

Select

 to display the category list.

Select a desired category.

Icon

Function

Displays the Entertainment menu. Use to switch to a
different audio source.

Displays the channel list of the current category.

Displays  the  favorites  list.  Long-press  to  store  the
channel  currently  being  aired.  Refer  to  Operating
the Radio on P. 290.

Indicates that the parental lock function is in use.
Switching  of  Lock/Unlock  and  PIN  code  setting
changes can be performed.

Plays each channel in the current channel list for 5
seconds.  Select  again  to  continue  receiving  the
channel.

Plays the previous channel.

Plays the next channel.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on P. 288.

1

2

1

2

3

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

299

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Audio can be heard from the vehicle’s speakers by connecting a com-
mercially-available portable audio unit to the auxiliary jack.
Use a commercially-available, non-impedance (3.5



) stereo mini plug

cable.
In addition, audio can be played from the vehicle audio device by con-
necting a USB device to the USB port.
Refer to AUX/USB mode on P. 307.

How to use Auxiliary jack/USB port

300

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Select the

 icon on the home screen and display the Settings

screen. Switch the tab and select the setting item you want to change.
You can customize settings in the setup display as follows:

Settings

Tab

Item

Function

Display

Refer to Volume/Display/Sound Controls on P. 288.

Safety

Low  Speed  Pre-Collision
System

Refer  to  Customizable  Features
on P. 555.

Sound

Refer to Volume/Display/Sound Controls on P. 288.

Clock

Adjust Time

Displays the currently set time is
displayed.

Press

  to  advance  the

hour/minute,  and  select
to move the hour/minute back.
AM/PM can only be selected with
the 12-hour clock display.

GPS Sync

Synchronizes  with  GPS  when
turned on.
When turned off, the time can be
changed from “Adjust Time”.

Time Format

Changes the display between 12
and 24-hour clock time.

Time Zone Select

When  it’s  not  synchronized  with
GPS, select the region you want
to specify.

Daylight Savings Time

Turns  the  daylight  saving  time
setting on/off. When ON, the time
advances  1  hour.  When  OFF,  it
returns to normal time.

Vehicle

Rain Sensing Wiper
Door Locks
Other

Refer  to  Customizable  Features
on P. 555.

Devices Bluetooth

®

Refer  to  Bluetooth

®

  Preparation

on P. 330.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

301

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Devices

Android Auto

An  Android  Auto™  mode  con-
nection can be set on or off when
connecting  an Android™  Smart-
phone.
For  setting  to  take  effect,  it  is
necessary

to

connect

the

Android Phone Again
Displays  in  gray  and  cannot  be
selected  if  an  Android™  Smart-
phone is not connected.

Apple CarPlay

An  Apple  CarPlay™  connection
can  be  set  on  or  off  when  con-
necting an iPhone

®

.

For  setting  to  take  effect,  it  is
necessary

to

connect

the

iPhone

®

 again.

Displays  in  gray  and  cannot  be
selected if an iPhone

®

 is not con-

nected.

Tab

Item

Function

302

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Depending on the grade and specification, the screen display may differ.

System

Tool Tips

Turns  button  explanations  ON/
OFF.

Language

Changes the language.

Temperature

Changes  the  setting  between
Fahrenheit and Celsius.

Distance

Changes  the  setting  between
miles and kilometers.

Music Database Update

Used  to  update  Gracenote

®

.

Gracenote

®

  is  used  with  USB

Audio and Bluetooth

®

 Audio, and

provides:
• Supplemental  music  informa-

tion (Such as song name, artist
name)

• Voice  recognition  assistance

for Play Artist and Play Album

Gracenote

®

  can  be  downloaded

from the Toyota website.
Refer  to  Gracenote

®

  Database

on P. 313.

Restore All Factory Settings

Memory  and  settings  are  initial-
ized to the factory settings.
The  initialization  launches  by
selecting the

 button.

About

Agreements  and
Disclaimers

Verify the disclaimer and agree.

Version  Informa-
tion

Can verify the current audio unit
OS  version  and  Gracenote

®

Database version.

Tab

Item

Function

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

303

4-2. Audio System

4

In

te

rior

F

ea

tu

res

Select the

 icon on the home screen to display the Applications

screen. The following information can be verified.

Depending on the grade and specification, the screen display may differ.

Applications

Top screen

Item

Function

Fuel Economy Monitor

Fuel

Consumption

Display

Refer to Fuel Economy
Monitor on P. 221.

Vehicle
Status
Monitor

Warning
Guidance

Warnings

currently

active can be verified.

Refer  to  If  a  Warning
Light  Turns  On  or
Flashes on P. 489.

Maintenance

• Scheduled

Maintenance

• Tire Rotation
• Oil Change

Refer  to  Maintenance
Monitor on P. 388.

Apple CarPlay

―

Refer  to  How  to  use
Apple CarPlay™ on
P. 317

Android Auto

―

Refer  to  How  to  use
Android Auto™  mode
on P. 321

304

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Audio Control Switch Operation

To increase the volume, press up

the volume switch (

).

To  decrease  the  volume,  press

down the volume switch (

).

Adjusting the Volume

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

305

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

AM/FM radio

Press  the  seek  switch  (

,

).  The  radio  switches  to

the  next/previous  stored  sta-
tion  in  the  order  that  it  was
stored.
Press and hold the seek switch
(

,

)  to  seek  all

usable  stations  at  a  higher  or
lower  frequency  whether  pro-
grammed or not.
Radio  stations  which  have  been  previously  stored  in  the  favorite
radio can be called up by pressing the seek switch (

,

)

while any radio station stored in the favorite radio is being received.
Radio stations can be called up in the order they were stored with
each press of the switch (

,

).

Seek Switch

306

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

USB Audio/Bluetooth

®

 Audio

Press the seek switch (

) to skip forward to the beginning of

the next track.
Press the seek switch (

) within a few seconds after playback

begins to track down to the beginning of the previous track.

Press the seek switch (

) after a few seconds have elapsed to

start  playback  from  the  beginning  of  the  current  track.  Press  and

hold  the  seek  switch  (

,

)  to  continuously  switch  the

tracks up or down.

■

Pandora

®

/Aha™/Stitcher™ Radio

Press the seek switch (

) to skip forward to the beginning of

the next track.
Press and hold the seek switch (

) to evaluate the playback of

the current song as “Like”.
Press and hold the seek switch (

) to evaluate the playback of

the current song as “Dislike”.

307

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

4

In

te

rior

F

ea

tu

res

AUX/USB mode

●

How to use AUX mode (



P. 310)

●

How to use USB mode (



P. 310)

●

How to use Apple CarPlay™ (



P. 317)

●

How to use Android Auto™ mode (



P. 321)

Audio can be heard from the vehicle’s speakers by connecting a
commercially-available portable audio unit to the auxiliary jack.
A  commercially-available,  non-impedance  (3.5



)  stereo  mini

plug cable is required. Contact your Toyota dealer for details.
In addition, audio can be played from the vehicle audio device
by connecting a USB device to the USB port.

Auxiliary jack

USB port

308

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

The SD card slot is for the navigation system. For vehicles with the naviga-
tion system, the SD card (Toyota genuine) with stored map data is inserted
into the SD card slot and used.

●

This mode may not be usable depending on the portable audio device to be
connected.

●

Before using the auxiliary jack/USB port, refer to the instruction manual for
the portable audio device.

●

Use  a  commercially-available,  non-impedance  (3.5



)  stereo  mini  plug  for

connecting  the  portable  audio  unit  to  the  auxiliary  jack.  Before  using  the
auxiliary jack, read the manufacturer’s instructions for connecting a portable
audio unit to the auxiliary jack.

●

To prevent discharging of the battery, do not use the auxiliary input for long
periods with the engine off or idling.

●

When  connecting  a  device  to  the  auxiliary  jack  or  USB  port,  noise  may
occur depending on the connected device. If the device is connected to the
vehicle’s accessory socket, the noise can be reduced by unplugging it from
the accessory socket.

WARNING

■

Do not adjust the portable audio unit or a similar product while driving
the vehicle

Adjusting the portable audio unit or a similar product while driving the vehi-
cle is dangerous as it could distract your attention from the vehicle opera-
tion  which  could  lead  to  a  serious  accident.  Always  adjust  the  portable
audio unit or a similar product while the vehicle is stopped.

NOTICE

Depending on the portable audio device, noise may occur when the device
is connected to the vehicle accessory socket. (If noise occurs, do not use
the accessory socket.)

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

309

4-2. Audio System

4

In

te

rior

F

ea

tu

res

USB port
Auxiliary jack

■

Connecting a device

Connect the connector on the device to the USB port.

■

Connecting with a connector cable

Connect the device plug/connector cable to the auxiliary jack/USB
port.

●

Insert the plug into the auxiliary jack/USB port securely.

●

Insert or pull out the plug with the plug perpendicular to the auxiliary jack/
USB port hole.

●

Insert or remove the plug by holding its base.

●

Use  the  USB  terminal  indicated  by  the

  mark  when  using Apple  Car-

Play™ and Android Auto™.

How to connect USB port/Auxiliary jack

1
2

WARNING

■

Do not allow the connection plug cord to get tangled with the parking
brake or the shift lever

Allowing the plug cord to become tangled with the parking brake or the shift
lever is dangerous as it could interfere with driving, resulting in an accident.

NOTICE

Do not place objects or apply force to the auxiliary jack/USB port with the
plug connected.

310

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

Select the

 icon on the home screen and display the Enter-

tainment screen.
Select

 to switch to the AUX mode. The following icons are dis-

played in the lower part of the center display.

●

If a device is not connected to the auxiliary jack, the mode does not switch
to the AUX mode.

●

Adjust  the  audio  volume  using  the  portable  audio  device,  commander
switch, or audio control switch.

●

Audio adjustments can also be made using the portable audio device’s vol-
ume setting.

●

If  the  connection  plug  is  pulled  out  from  the  auxiliary  jack  while  in AUX
mode, noise may occur.

This  unit  does  not  support  a  USB  3.0  device.  In  addition,  other
devices may not be supported depending on the model or OS version.
USB devices formatted to FAT32 are supported (USB devices format-
ted to other formats such as NTFS are not supported).

How to use AUX mode

1

2

Icon

Function

Displays the Entertainment menu. Use to switch to a dif-
ferent audio source.

Displays sound settings to adjust audio quality level. Refer
to Volume/Display/Sound Controls on P. 288.

How to use USB mode

Type

Playable data

USB mode

MP3/WMA/AAC/OGG file

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

311

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Playback

Select the

 icon on the home screen and display the Enter-

tainment screen.
Select

  or

  to  switch  the  USB  mode.  The  following

icons are displayed in the lower part of the center display.

1

2

Icon

Function

Displays the Entertainment menu. Use to switch to a dif-
ferent audio source.

Category list is displayed.

Current track list is displayed.
Select a desired track to play it.

Plays the current track repeatedly.
Select  it  again  to  play  the  tracks  in  the  current  track  list
repeatedly.
When selected again, the function is canceled.

Tracks in the current track list are played randomly.
Select it again to cancel.

Starts  playing  a  track  similar  to  the  current  track  using
Gracenote

®

’s More Like This™.

Select  the  desired  song  from  the  category  list  to  cancel
More Like This

™

.

If selected within a  few  seconds from the  beginning of  a
song  which  has  started  to  play,  the  previous  song  is
selected.
If more than a few seconds have elapsed, the song cur-
rently being played is replayed from the beginning.
Long-press to fast reverse. It stops when you remove your
hand from the icon or the commander knob.

Track is played. When selected again, playback is tempo-
rarily stopped.

Advances to the beginning of the next song.
Long-press to fast forward.

Displays sound settings to adjust audio quality level. Refer
to Volume/Display/Sound Controls on P. 288.

312

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

●

Category list
Select the

 icon and display the following category list.

Select a desired category and item.

●

Example of use (to play all tracks in USB device)



Method 1
Select

 to display the category list.

Select

.

All the tracks in the USB device are displayed.
Select a desired track.
The selected track is played. All the tracks in the USB device
can be played by continuing playback.

Only  the  tracks  in  the  desired  category  selected  in  Step

  are

played.

Category

Function

Playlist

Displays playlists on the device.

Artist

Displays the artist name list.
All the tracks or tracks for each album of the selected artist
can be played.

Album

Displays the album name list.

Song

All the tracks in the device are displayed.

Genre

Displays the genre list.
All the tracks or tracks per album or artist in the selected
genre can be played.

Audiobook

Displays the audiobook list.
Chapters can be selected and played.

Podcast

Displays the podcast list.
Episode can be selected and played.
(Special service for some Apple devices.)

Apple Music

Radio

Displays Apple Music Radio stations.
A station can be selected and played.

Folder

Displays the folder/file list.

1

2

3

2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

313

4-2. Audio System

4

In

te

rior

F

ea

tu

res



Method 2

*

1

Select

 to display the category list.

Select

.

All the folders in the USB device are displayed.
Select

.

All the tracks in the USB device are displayed.
Select a desired track.
The selected track is played. All the tracks in the USB device
can be played by continuing playback.

Only the tracks in the desired folder selected in Step   are played.

*

1

: Can be operated using an Android



 device or USB flash memory.

■

Playback

●

If a file name in the USB memory is too long, it could cause operation prob-
lems such as not being able to playback the song.
(Recommended: Within 80 characters)

●

The album art may not display depending on the album art size.

●

To move to the desired location on the track, move the slider indicating the
playback time.

●

The appearance of the repeat and shuffle icons changes depending on the
type of operation in which the function is used.

When a USB device or Bluetooth

®

 device is connected to this unit and

the audio is played, the album name, artist name, genre and title infor-
mation are automatically displayed if there is a match in the vehicle’s
database  compilation  to  the  music  being  played.  The  information
stored  in  this  device  uses  database  information  in  the  Gracenote

®

music recognition service.

Gracenote

®

 Database

1

2

3

4

3

314

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Introduction

Music recognition technology and related data are provided by Gra-
cenote

®

.  Gracenote  is  the  industry  standard  in  music  recognition

technology and related content delivery. For more information visit
www.gracenote.com.
CD and music-related data from Gracenote, Inc., copyright © 2000
to  present  Gracenote.  Gracenote  Software,  copyright  ©  2000  to
present  Gracenote.  One  or  more  patents  owned  by  Gracenote
apply to this product and service. See the Gracenote website for a
non-exhaustive  list  of  applicable  Gracenote  patents.  Gracenote,
CDDB,  MusicID,  MediaVOCS,  the  Gracenote  logo  and  logotype,
and the “Powered by Gracenote” logo are either registered trade-
marks or trademarks of Gracenote in the United States and/or other
countries.

Gracenote

®

 End User License Agreement

This application or device contains software from Gracenote, Inc. of
Emeryville,  California  (“Gracenote”).  The  software  from  Gracenote
(the  “Gracenote  Software”)  enables  this  application  to  perform  disc
and/or file identification and obtain music-related information, includ-
ing name, artist, track, and title information (“Gracenote Data”) from
online servers or embedded databases (collectively, “Gracenote Serv-
ers”)  and  to  perform  other  functions.  You  may  use  Gracenote  Data
only by means of the intended End-User functions of this application
or device.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

315

4-2. Audio System

4

In

te

rior

F

ea

tu

res

You agree that you will use Gracenote Data, the Gracenote Software,
and  Gracenote  Servers  for  your  own  personal  non-commercial  use
only. You agree not to assign, copy, transfer or transmit the Gracenote
Software or any Gracenote Data to any third party. YOU AGREE NOT
TO  USE  OR  EXPLOIT  GRACENOTE  DATA,  THE  GRACENOTE
SOFTWARE,  OR  GRACENOTE  SERVERS,

EXCEPT  AS

EXPRESSLY PERMITTED HEREIN.
You agree that your non-exclusive license to use the Gracenote Data,
the Gracenote Software, and Gracenote Servers will terminate if you
violate  these  restrictions.  If  your  license  terminates,  you  agree  to
cease  any  and  all  use  of  the  Gracenote  Data,  the  Gracenote  Soft-
ware, and Gracenote Servers. Gracenote reserves all rights in Grace-
note  Data,  the  Gracenote  Software,  and  the  Gracenote  Servers,
including all ownership rights. Under no circumstances will Gracenote
become liable for any payment to you for any information that you pro-
vide. You agree that Gracenote, Inc. may enforce its rights under this
Agreement against you directly in its own name.
The  Gracenote  service  uses  a  unique  identifier  to  track  queries  for
statistical  purposes.  The  purpose  of  a  randomly  assigned  numeric
identifier  is  to  allow  the  Gracenote  service  to  count  queries  without
knowing anything about who you are. For more information, see the
web page for the Gracenote Privacy Policy for the Gracenote service.
The  Gracenote  Software  and  each  item  of  Gracenote  Data  are
licensed to you “AS IS.”
Gracenote  makes  no  representations  or  warranties,  express  or
implied,  regarding  the  accuracy  of  any  Gracenote  Data  from  in  the
Gracenote Servers. Gracenote reserves the right to delete data from
the  Gracenote  Servers  or  to  change  data  categories  for  any  cause
that Gracenote deems sufficient. No warranty is made that the Grace-
note Software or Gracenote Servers are error-free or that functioning
of  Gracenote  Software  or  Gracenote  Servers  will  be  uninterrupted.
Gracenote is not obligated to provide you with new enhanced or addi-
tional  data  types  or  categories  that  Gracenote  may  provide  in  the
future and is free to discontinue its services at any time.

316

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Updating the database

The  Gracenote

®

  media  database  can  be  updated  using  USB

device.

Connect a USB device containing the software for updating Gra-
cenote

®

.

Select the

 icon on the home screen and display the Set-

tings screen.
Select the

 tab and select

.

Select

. The list of the update package stored in the USB

device and the version are displayed.
Select the package to use the update.
Select

.

Gracenote

®

 can be downloaded from the Toyota website.

NOTICE

For information related to the most recent Gracenote database which can
be used and how to install it, go to the Toyota website:

●

U.S.A.
http://www.toyota.com

●

Canada
http://www.toyota.ca

1

2

3

4

5

6

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

317

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

What is Apple CarPlay™?

Apple  CarPlay™  allows  you  to  make  calls,  send  or  receive  mes-
sages,  and  listen  to  music  using  your  iPhone

®

  with  the  vehicle’s

audio system, or search for destinations using the maps. In addi-
tion, voice recognition operation is possible using Siri

®

.

How to use Apple CarPlay™

318

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

NOTICE

●

YOU  EXPRESSLY  ACKNOWLEDGE  AND  AGREE  THAT  USE  OF
APPLE  CARPLAY™  (“THE  APPLICATION”)  IS  AT  YOUR  SOLE  RISK
AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PER-
FORMANCE, ACCURACY AND EFFORT IS WITH YOU TO THE MAXI-
MUM  EXTENT  PERMITTED  BY  APPLICABLE  LAW,  AND  THAT  THE
APPLICATION  AND  INFORMATION  ON  THE  APPLICATION  IS  PRO-
VIDED  “AS  IS”  AND  “AS AVAILABLE”,  WITH ALL  FAULTS AND  WITH-
OUT  WARRANTY  OF ANY  KIND, AND  TOYOTA  HEREBY  DISCLAIMS
ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE APPLI-
CATION  AND  INFORMATION  ON  THE  APPLICATION,  EITHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED
TO,  THE  IMPLIED  WARRANTIES  AND/OR  CONDITIONS  OF  MER-
CHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICU-
LAR

PURPOSE,

ACCURACY,

QUIET

ENJOYMENT,

AND

NONINFRINGEMENT OF THIRD PARTY RIGHTS. AS EXAMPLES, AND
WITHOUT  LIMITATION,  TOYOTA  DISCLAIMS  ANY  WARRANTY
REGARDING THE ACCURACY OF DATA PROVIDED BY THE APPLICA-
TION,  SUCH  AS  THE  ACCURACY  OF  DIRECTIONS,  ESTIMATED
TRAVEL  TIME,  SPEED  LIMITS,  ROAD  CONDITIONS,  NEWS,
WEATHER,  TRAFFIC,  OR  OTHER  CONTENT  PROVIDED  BY APPLE,
ITS AFFILIATES, OR THIRD PARTY PROVIDERS; TOYOTA DOES NOT
GUARANTEE  AGAINST  LOSS  OF  APPLICATION  DATA,  WHICH  MAY
BE LOST AT ANY TIME; TOYOTA DOES NOT GUARANTEE THAT THE
APPLICATION OR ANY SERVICES PROVIDED THROUGH THEM WILL
BE PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL
BE  AVAILABLE  AT  ANY  PARTICULAR  TIME  OR  LOCATION.  FOR
EXAMPLE,  SERVICES  MAY  BE  SUSPENDED  OR  INTERRUPTED
WITHOUT  NOTICE  FOR  REPAIR,  MAINTENANCE,  SECURITY  FIXES,
UPDATES,  ETC.,  SERVICES  MAY  BE  UNAVAILABLE  IN  YOUR AREA
OR  LOCATION,  ETC.  IN  ADDITION,  YOU  UNDERSTAND  THAT
CHANGES IN THIRD PARTY TECHNOLOGY OR GOVERNMENT REG-
ULATION  MAY  RENDER  THE  SERVICES  AND/OR  APPLICATIONS
OBSOLETE AND/OR UNUSABLE.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL
TOYOTA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY,
OR ANY
INCIDENTAL,  SPECIAL,  INDIRECT  OR  CONSEQUENTIAL  DAM-
AGES  WHATSOEVER,  INCLUDING,  WITHOUT  LIMITATION,  DAM-
AGES FOR LOSS OF PROFITS, CORRUPTION OR LOSS OF DATA,
FAILURE  TO  TRANSMIT  OR  RECEIVE  ANY  DATA,  BUSINESS
INTERRUPTION  OR  ANY  OTHER  COMMERCIAL  DAMAGES  OR
LOSSES,  ARISING  OUT  OF  OR  RELATED  TO  THE  APPLICATION
OR  YOUR  USE  OF  OR  INABILITY  TO  USE  THE APPLICATION  OR
INFORMATION ON THE APPLICATION.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

319

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Apple CarPlay™ is provided by Apple

®

 and its use is subject to your agree-

ment to the Apple CarPlay™ terms of use, which are included as part of the
Apple iOS terms of use.

●

When  using Apple  CarPlay™,  location,  speed,  and  other  vehicle  data  is
transferred  to  your  iPhone

®

.  For  further  details,  refer  to Apple

®

’s  Privacy

Policy.

■

Switching to Apple CarPlay™

Connect  the  iPhone

®

  by  inserting  the Apple

®

  -genuine  connector

cord to the USB terminal indicated by the

 mark.

Refer to How to connect USB port/Auxiliary jack on P. 309

●

When you switch your iPhone

®

 connection from Bluetooth

®

 to the vehicle’s

USB  terminal,  the  system  switches  to Apple  CarPlay™.  The  applications
which was being used via Bluetooth

®

 connection can be used continuously.

However, the available functions of the applications using Bluetooth

®

 con-

nection and those on Apple CarPlay™ may differ.

●

If  the  iPhone

®

  is  connected  to  the  USB  terminal  not  indicated  by  the

mark, the system operates in USB mode.

■

Display of Apple CarPlay™ Screen

Use  any  of  the  following  methods  to  display  the Apple  CarPlay™
screen in the center display.

• Select

 on the home screen.

• Long press

 on the commander switch.

• Select

  on  the  home  screen,  and  select

from the Applications screen.

NOTICE

●

When using Apple CarPlay™, please avoid distraction and use Apple Car-
Play™ responsibly. Stay fully aware of driving conditions and always obey
applicable laws.

320

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Apple CarPlay™ home screen

The icons and icon positions displayed on the Apple CarPlay™ home screen
may differ depending on the connected iPhone

®

 and iOS version.

No.

Icon

Explanation

Launches the Apple CarPlay™ application.
Refer  to  the  help  information  available  with  each
application for the method of using each application.

Switches to the Toyota home screen.

Displays the Apple CarPlay™ home screen.

1

2

3

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

321

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Convenient Ways to Use Apple CarPlay™

■

To End Apple CarPlay™

To end Apple CarPlay™, disconnect the Apple

®

 -genuine connec-

tor  cord  from  the  USB  terminal  and  disconnect  the  iPhone

®

  from

the connector cord.

If  the  connector  cord  is  disconnected  from  the  USB  terminal  during  music
playback using Apple CarPlay™, the audio source selection will no longer be
available and the vehicle’s audio device will be muted.

■

What is Android Auto™?

Android Auto™ is an application which allows the operation of an
Android™  Smartphone  using  the  vehicle’s  audio. Android Auto™
functions  such  as  the  phone,  messages,  music,  and  map  can  be
used with the vehicle’s audio system.

Item

Operation method

Activating the voice recog-
nition function (Siri

®

)

Activate  Siri

®

  using  any  of  the  following  two

methods  to  operate  Apple  CarPlay™  by
voice.
• Press  and  hold/Long  press  the  talk  button

on the audio control switch.

• Press and hold

To display the NowPlaying
screen

When  music  is  playing  in  Apple  CarPlay™
and  a  screen  other  than  the  NowPlaying
screen  is  being  displayed,  press

  on  the

commander switch to display the NowPlaying
screen.

To display the MAP screen

When  using  map  route  guidance  in  Apple
CarPlay™  and  a  screen  other  than  the  MAP
screen  is  being  displayed,  press

  on

the  commander  switch  to  display  the  MAP
screen.

To return to Toyota screen

Press and hold

 on the commander switch.

How to use Android Auto™ mode

322

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

NOTICE

●

YOU  EXPRESSLY  ACKNOWLEDGE  AND  AGREE  THAT  USE  OF
ANDROID AUTO™ (“THE APPLICATION”) IS AT YOUR SOLE RISK AND
THAT THE  ENTIRE  RISK AS TO  SATISFACTORY  QUALITY,  PERFOR-
MANCE, ACCURACY AND  EFFORT  IS  WITH YOU TO THE  MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, AND THAT THE APPLICA-
TION AND  INFORMATION  ON  THE APPLICATION  IS  PROVIDED  “AS
IS”  AND  “AS  AVAILABLE,”  WITH  ALL  FAULTS  AND  WITHOUT  WAR-
RANTY  OF ANY  KIND, AND TOYOTA  HEREBY  DISCLAIMS ALL  WAR-
RANTIES AND  CONDITIONS  WITH  RESPECT  TO  THE APPLICATION
AND  INFORMATION  ON  THE  APPLICATION,  EITHER  EXPRESS,
IMPLIED  OR  STATUTORY,  INCLUDING,  BUT  NOT  LIMITED  TO,  THE
IMPLIED  WARRANTIES  AND/OR  CONDITIONS  OF  MERCHANTABIL-
ITY,  SATISFACTORY  QUALITY,  FITNESS  FOR  A  PARTICULAR  PUR-
POSE,  ACCURACY,  QUIET  ENJOYMENT,  AND  NONINFRINGEMENT
OF  THIRD  PARTY  RIGHTS.  AS  EXAMPLES,  AND  WITHOUT  LIMITA-
TION,  TOYOTA  DISCLAIMS  ANY  WARRANTY  REGARDING  THE
ACCURACY  OF  DATA  PROVIDED  BY  THE  APPLICATION,  SUCH  AS
THE ACCURACY OF DIRECTIONS, ESTIMATED TRAVEL TIME, SPEED
LIMITS, ROAD CONDITIONS, NEWS, WEATHER, TRAFFIC, OR OTHER
CONTENT  PROVIDED  BY  GOOGLE,  ITS  AFFILIATES,  OR  THIRD
PARTY  PROVIDERS;  TOYOTA  DOES  NOT  GUARANTEE  AGAINST
LOSS  OF APPLICATION  DATA,  WHICH  MAY  BE  LOST AT ANY  TIME;
TOYOTA  DOES  NOT  GUARANTEE THAT THE APPLICATION  OR ANY
SERVICES PROVIDED THROUGH THEM WILL BE PROVIDED AT ALL
TIMES OR THAT ANY OR ALL SERVICES WILL BE AVAILABLE AT ANY
PARTICULAR  TIME  OR  LOCATION.  FOR  EXAMPLE,  SERVICES  MAY
BE SUSPENDED OR INTERRUPTED WITHOUT NOTICE FOR REPAIR,
MAINTENANCE,  SECURITY  FIXES,  UPDATES,  ETC.,  SERVICES  MAY
BE UNAVAILABLE IN YOUR AREA OR LOCATION, ETC. IN ADDITION,
YOU UNDERSTAND THAT CHANGES IN THIRD PARTY TECHNOLOGY
OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/
OR APPLICATIONS OBSOLETE AND/OR UNUSABLE.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL
TOYOTA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY,
OR ANY  INCIDENTAL,  SPECIAL,  INDIRECT  OR  CONSEQUENTIAL
DAMAGES  WHATSOEVER,  INCLUDING,  WITHOUT  LIMITATION,
DAMAGES  FOR  LOSS  OF  PROFITS,  CORRUPTION  OR  LOSS  OF
DATA, FAILURE TO TRANSMIT OR RECEIVE ANY DATA, BUSINESS
INTERRUPTION  OR  ANY  OTHER  COMMERCIAL  DAMAGES  OR
LOSSES,  ARISING  OUT  OF  OR  RELATED  TO  THE  APPLICATION
OR  YOUR  USE  OF  OR  INABILITY  TO  USE  THE APPLICATION  OR
INFORMATION ON THE APPLICATION.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

323

4-2. Audio System

4

In

te

rior

F

ea

tu

res

●

Android Auto™ is provided by Google and its use is subject to your agree-
ment to the Android Auto™ terms of use.

●

When  using  Android  Auto™,  location,  speed,  and  other  vehicle  data  is
transferred  to  your  smart  phone.  For  further  details,  refer  to  Google’s  Pri-
vacy Policy.

■

How to use the Android Auto™ mode

Insert  an Android™  Smartphone-genuine  connector  cord  into  the
USB terminal indicated by the

 icon to connect the Smartphone.

Refer to How to connect USB port/Auxiliary jack on P. 309

●

When an Android™  Smartphone connected to Bluetooth

®

 is  connected  to

the vehicle’s USB terminal, Bluetooth

®

 is used by Android Auto™ and the

system switches to Android Auto™ mode.

●

If  the Android™  Smartphone  is  connected  to  a  USB  terminal  with  no
icon indicated, the system operates in USB mode.

■

Display of Android Auto™ Mode Screen

Use  any  of  the  following  methods  to  display  the Android Auto™
mode screen in the center display.

• Select

 on the home screen, and select

 from

the Applications screen.

• Select

 on the home screen.

• Press and hold

 on the commander switch.

NOTICE

●

When  using  Android  Auto™,  please  avoid  distraction  and  use  Android
Auto™ responsibly. Stay fully aware of driving conditions and always obey
applicable laws.

324

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

Android Auto™ mode home screen

The media displayed on the Android Auto™ home screen may differ depend-
ing  on  the  use  conditions  and  version  of  the  connected Android™  Smart-
phone.

No.

Icon

Explanation

―

Displays  the  use  history  of  each  application.  The
displayed contents differ depending on the applica-
tion that has been started and its status.

Switches to the map application.

Switches to the call mode.

Displays the Android Auto™ home screen.

Switches to the Music application.

Switches to the Toyota home screen.

1

2

3

4

5

6

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

325

4-2. Audio System

4

In

te

rior

F

ea

tu

res

■

Convenient ways to use Android Auto™ mode

■

To end Android Auto™

To end the Android Auto™ mode, disconnect the Android™-genu-
ine  connector  cord  from  the  USB  terminal  or  disconnect  the
Android™ Smartphone from the connector cord.
If Android Auto™ cannot be connected
When  the  message,  “Mobile  Device  Error”,  is  displayed  and
Android Auto™ cannot be connected.
Make  sure  that  the  Android™
Smartphone in question is com-
patible with Android Auto™.
Before trying to reconnect your
Android™  Smartphone  to  the
connector  cord,  do  the  Blue-
tooth

®

 device pairing again.

Item

Operation method

Operation using voice rec-
ognition

Any of the following methods can be used to
start the voice recognition mode and operate
Android Auto™ by voice.
• Speak the words, “OK Google”.
• Select  the

  icon  on  the  Android  Auto™

screen.

• Press and hold the talk button on the audio

remote control switch.

To display the NowPlaying
screen

When music is playing in Android Auto™ and
a screen other than the NowPlaying screen is
being displayed, press

 on the commander

switch to display the NowPlaying screen.

To display the MAP screen

When  using  map  route  guidance  in Android
Auto™  and  a  screen  other  than  the  MAP
screen  is  being  displayed,  press

  on

the commander switch to display the Android
Auto™ MAP screen.

To  return  to  the  Toyota
screen

Press and hold

 on the commander switch.

326

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-2. Audio System

■

If the Android Auto™ connection setting cannot be changed

Depending on your Android™ Smartphone, the connection setting
may have been in charging mode only when the connector cord is
connected.
In this case, switch off the Android Auto™ connection setting once,
and then switch it back on while connected to USB mode.
The connection setting can be changed to the Android Auto™ con-
nection in the

 tab on the Settings screen (



P. 300).

327

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-3. Bluetooth

®

4

In

te

rior

F

ea

tu

res

Bluetooth

®

■

Bluetooth

®

 Hands-Free outline

When a Bluetooth

®

 device (mobile phone) is connected to the vehi-

cle’s  Bluetooth

®

  unit  via  radio  wave  transmission,  a  call  can  be

made  or  received  by  pressing  the  talk  button,  pick-up  button,  or
hang-up button on the audio remote control switch, or by operating
the center display.

■

Bluetooth

®

 audio outline

When a portable audio unit equipped with the Bluetooth

®

 communi-

cation  function  is  paired  to  the  vehicle,  you  can  listen  to  music
stored on the paired portable audio device from the vehicle’s speak-
ers. It is not necessary to connect the portable audio device to the
vehicle’s  external  input  terminal. After  programming,  operate  the
vehicle audio control panel to play/stop the audio.

■

Applicable Bluetooth

®

 specification (Recommended)

Ver. 1.1/1.2/2.0 + EDR/2.1 + EDR/3.0 (conformity)

●

For your safety, a device can be paired only when the vehicle is parked. If
the vehicle starts to move, the pairing procedure will end. Park the vehicle in
a safe place before pairing.

●

The communication range of a Bluetooth

®

 equipped device is about 32 ft.

(10 m) or less.

●

Basic audio operation is available using voice commands even if Bluetooth

®

is not connected.

●

For  safety  reasons,  operation  of  the  center  display  is  disabled  while  the
vehicle is being driven. However, items not displayed in gray can be oper-
ated using the commander switch while the vehicle is being driven.

NOTICE

Some Bluetooth

®

 mobile devices are not compatible with the vehicle. Con-

sult your Toyota dealer, Toyota Customer Experience Center (U.S.A. Only),
Toyota Canada Customer Interaction Centre (Canada Only) or Web support
center for information regarding Bluetooth

®

 mobile device compatibility:

●

U.S.A.
Phone: 1-800-331-4331 (Toll-free)
Web: http://www.toyota.com/entune

●

Canada
Phone: 1-888-TOYOTA-8 or 1-888-869-6828 (Toll-free)
Web: http://www.toyota.ca

328

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-3. Bluetooth

®

Component Parts



Audio unit



Talk  button,  Pick-up  button
and Hang-up button

Talk button
Pick-up button
Hang-up button



Microphone

1
2
3

Microphone

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

329

4-3. Bluetooth

®

4

In

te

rior

F

ea

tu

res

■

Microphone (hands-free)

The  microphone  is  used  for  speaking  voice  commands  or  when
making a Hands-free call.

■

Talk button, Pick-Up button and Hang-Up button (hands-free)

The basic functions of Bluetooth

®

 Hands-Free can be used for such

things  as  making  calls  or  hanging  up  using  the  talk,  pick-up  and
hang-up buttons on the steering wheel.

■

Commander switch

The commander switch is used for volume adjustment and display
operation.  Tilt  or  turn  the  commander  knob  to  move  the  cursor.
Press the commander knob to select the icon.

■

Volume adjustment

The volume dial of the commander switch is used to adjust the vol-
ume.  Turn  the  dial  to  the  right  to  increase  volume,  to  the  left  to
decrease it.
The volume can also be adjusted using the volume button on the
steering wheel.

• Press the volume dial to switch the audio MUTE on and off.
• If the volume is lower compared to other audio modes, increase the vol-

ume from the device side.

Conversation  volume  and  the  volume  of  the  voice  guidance  and
ringtone can each be set in advance.

Select the

 icon on the home screen and display the Com-

munication screen.
Select

.

Adjust the

 and the

 using the slider.

1

2

3

330

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

4-3. Bluetooth

®

■

Device pairing

To use Bluetooth

®

 audio and Hands-Free, the device equipped with

Bluetooth

®

 has to be paired to the unit using the following proce-

dure. A maximum of 7 devices including Bluetooth

®

 audio devices

and hands-free mobile phones can be paired.

●

Pairing Procedure

Select  the

  icon  on  the  home  screen  and  display  the

Settings screen.
Select the

 tab.

Select

.

Turn the Bluetooth

®

 setting on.

Select

 to display the message and switch to the

device operation.
Using your device, perform a search for the Bluetooth

®

 device

(Peripheral device).
Select “Toyota” from the device list searched by the device.
Device with Bluetooth

®

 version 2.0:

Input the displayed 4-digit pairing code into the device.
Device with Bluetooth

®

 version 2.1 or higher:

Make sure the displayed 6-digit code on the audio is also dis-
played on the device, and touch the

.

Connection permission and phonebook access permission for
your mobile device may be required depending on the mobile
device.
If pairing is successful, the functions of the device connected
to Bluetooth

®

 are displayed.

Bluetooth

®

 Preparation

1

2

3

4

5

6

7

8

9

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

331

4-3. Bluetooth

®

4

In

te

rior

F

ea

tu

res

Devices compatible with Toyota Email/SMS function:
SMS (Short Message Service) messages, and E-mail for the
device are downloaded automatically. A download permission
operation for  your  device may be  required  depending  on  the
device.

When  Call  history  and  messages  are  downloaded  automatically,
each automatic download setting must be on.
Refer to Communication Settings on P. 351.

After  a  device  is  registered,  the  system  automatically  identifies
the  device.  By  activating  Bluetooth

®

  Hands-Free  again,  or  by

activating Bluetooth

®

 Hands-Free first after switching the ignition

from OFF to ACC, the device connection condition is indicated in
the center display.

●

IMPORTANT note about pairing and automatic reconnection:

• If  pairing  is  redone  on  the  same  mobile  phone  device,  first

clear  “Toyota”  displayed  on  the  Bluetooth

®

  setting  screen  of

the mobile device.

• When the OS of the device is updated, the pairing information

may be deleted. If this happens, reprogram the pairing infor-
mation to the Bluetooth

®

 unit.

• Before  you  pair  your  device,  make  sure  that  Bluetooth

®

  is

“ON”, both on your phone and on the vehicle.

10
