Toyota Sienna (2020 year). Manual in english - part 2

78

1-2. Theft deterrent system

SIENNA_OM_OM08035U_(U)

■

System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the grip portion of the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

■

Certifications for the engine immobilizer system



For vehicles sold in the U.S.A.

Vehicles without a smart key system
FCC ID: WRKRI-44BTY
Vehicles with a smart key system
FCC ID: NI4TMIMB-1
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence,  and  (2)  this  device  must  accept  any  interference  received,  including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

WARNING

■

Certifications for the engine immobilizer system

Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

NOTICE

■

To ensure the system operates correctly

Do  not  modify  or  remove  the  system.  If  modified  or  removed,  the  proper
operation of the system cannot be guaranteed.

79

1-2. Theft deterrent system

SIENNA_OM_OM08035U_(U)

1

Fo
r safety and securi

ty

Alarm



The alarm uses light and sound to give an alert when an intrusion is
detected.
The  alarm  is  triggered  in  the  following  situations  when  the  alarm  is
set:

●

A locked door is unlocked or opened in any way other than using
the  entry  function  (vehicles  with  a  smart  key  system)  or  wireless
remote control. (The doors will lock again automatically.)

●

The hood is opened.

Close  the  doors  and  hood,  and
lock  all  the  doors  using  the  entry
function (vehicles with a smart key
system)  or  wireless  remote  con-
trol. The  system  will  be  set  auto-
matically after 30 seconds.

The  indicator  light  changes  from
being on to flashing when the sys-
tem is set.

Do one of the following to deactivate or stop the alarm:

●

Unlock the doors using the entry function (vehicles with a smart key
system) or wireless remote control.

●

Vehicles without a smart key system: Turn the engine switch to the
“ACC” or “ON” position, or start the engine.
Vehicles  with  a  smart  key  system:  Turn  the  engine  switch  to
ACCESSORY or IGNITION ON mode, or start the engine.
(The alarm will be deactivated or stopped after a few seconds.)



: If equipped

The alarm

Setting the alarm system

Deactivating or stopping the alarm

80

1-2. Theft deterrent system

SIENNA_OM_OM08035U_(U)

■

System maintenance

The vehicle has a maintenance-free type alarm system.

■

Items to check before locking the vehicle

To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:

●

Nobody is in the vehicle.

●

The windows and moon roof (if equipped) are closed before the alarm is set.

●

No valuables or other personal items are left in the vehicle.

■

Triggering of the alarm

The alarm may be triggered in the following situations.
(Stopping the alarm deactivates the alarm system.)

●

The doors are unlocked using the key.

●

A person inside the vehicle opens a door
or hood.

●

The  battery  is  recharged  or  replaced
when the vehicle is locked. (



P. 505)

81

1-2. Theft deterrent system

SIENNA_OM_OM08035U_(U)

1

Fo
r safety and securi

ty

■

Alarm-operated door lock

In the following cases, depending on the situations, the door may automati-
cally lock to prevent improper entry into the vehicle:

●

When a person left in the vehicle triggers the alarm by unlocking a door or
the back door.

●

When a person left in the vehicle unlocks a door or the back door while the
alarm is operating.

●

When recharging or replacing the battery.

NOTICE

■

To ensure the system operates correctly

Do  not  modify  or  remove  the  system.  If  modified  or  removed,  the  proper
operation of the system cannot be guaranteed.

82

1-2. Theft deterrent system

SIENNA_OM_OM08035U_(U)

83

SIENNA_OM_OM08035U_(U)

Instrument cluster

2

2.

Instrument cluster

Warning lights and

indicators .......................... 84

Gauges and meters ............ 89
Multi-information display ..... 92
Fuel consumption

information ........................ 99

84

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

Warning lights and indicators

The units used on the meters and some indicators may differ depending on
the target region.

The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s vari-
ous systems.
For  the  purpose  of  explanation,  the  following  illustration  dis-
plays the instrument cluster with all warning lights and indica-
tors illuminated.

SIENNA_OM_OM08035U_(U)

85

2. Instrument cluster

2

Instru

me
nt clu

ster

Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.

Warning lights

*

1

(U.S.A.)

Brake system warning
light (



P. 471)

*

1, 2

PCS warning light
(



P. 472)

*

1

(Canada)

Brake system warning
light (



P. 471)

*

3

(Amber)

LDA indicator (



P. 472)

*

3

Charging system
warning light (



P. 471)

*

1

Slip indicator (



P. 473)

*

3

Low engine oil pressure
warning light (



P. 471)

Low fuel level warning
light (



P. 473)

*

1

(U.S.A.)

Malfunction indicator
lamp (



P. 471)

Seat belt reminder light
(



P. 473)

*

1

(Canada)

Malfunction indicator
lamp (



P. 471)

*

3

Low engine oil level
warning light (



P. 473)

*

1

SRS warning light
(



P. 472)

*

1

Master warning light
(



P. 473)

*

1

(U.S.A.)

ABS warning light
(



P. 472)

*

1

Tire pressure warning

light (



P. 474)

*

1

(Canada)

ABS warning light
(



P. 472)

*

3

Low windshield

washer fluid level

warning light (



P. 474)

*

1

Electric power steering
system warning light
(



P. 472)

*

4

Third seat warning light
(



P. 474)

86

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

*

1

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles  without  a  smart  key  system)  or  IGNITION  ON  mode  (vehicles
with  a  smart  key  system)  to  indicate  that  a  system  check  is  being  per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.

*

2

: The light comes on or flashes to indicate a malfunction.

*

3

: This light illuminates on the multi-information display.

*

4

: If equipped

The indicators inform the driver of the operating state of the vehicle’s
various systems.

*

3

Brake Override System
warning light (



P. 474)

*

3

High coolant
temperature warning
light (



P. 474)

Indicators

Turn signal indicator
(



P. 239)

*

2

Cruise control indicator
(



P. 288)

(U.S.A.)

Headlight indicator
(



P. 241)

*

2

Dynamic radar cruise
control indicator
(



P. 288)

(Canada)

Tail light indicator
(



P. 241)

*

2

Cruise control “SET”
indicator (



P. 288)

Headlight high beam
indicator (



P. 242)

*

2

(White)

LDA indicator (



P. 278)

Automatic High Beam
indicator (



P. 246)

*

2

(Green)

LDA indicator (



P. 278)

*

1

Fog light indicator
(



P. 251)

*

2, 4

(Amber)

LDA indicator (



P. 278)

SIENNA_OM_OM08035U_(U)

87

2. Instrument cluster

2

Instru

me
nt clu

ster

*

1

: If equipped

*

2

: This light illuminates on the multi-information display.

*

3

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles  without  a  smart  key  system)  or  IGNITION  ON  mode  (vehicles
with  a  smart  key  system)  to  indicate  that  a  system  check  is  being  per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.

*

4

: The light flashes to indicate that the system is operating.

*

5

: The light comes on when the system is turned off.

*

3, 4

Slip indicator (



P. 323)

*

3, 8

Eco Driving Indicator
Light (



P. 88)

*

3, 5

VSC OFF indicator
(



P. 323)

*

2

Low outside
temperature indicator
(



P. 91)

*

3, 5

PCS warning light
(



P. 266)

*

3, 9

(U.S.A.)

“AIR BAG ON/OFF”
indicator (



P. 52)

*

1, 6, 7

BSM (Blind Spot
Monitor) outside rear
view mirror indicators
(



P. 302)

*

1, 2

“BSM” (Blind Spot
Monitor) indicator
(



P. 302)

*

3, 9

(Canada)

“AIR BAG ON/OFF”
indicator (



P. 52)

*

1, 2

“RCTA” (Rear Cross
Traffic Alert) indicator
(



P. 302)

Security indicator
(



P. 77, 79)

*

2

“ECT PWR” indicator
(



P. 234)

88

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

*

6

: In order to confirm operation, the BSM outside rear view mirror indicators

illuminate in the following situations:

• When the engine switch is turned to the “ON” position (vehicles without a

smart key system) or IGNITION ON mode (vehicles with a smart key sys-
tem) while the BSM function is turned on.

• When  the  BSM  function  is  turned  on  while  the  engine  switch  is  in  the

“ON”  position  (vehicles  without  a  smart  key  system)  or  IGNITION  ON
mode (vehicles with a smart key system).

If the system is functioning correctly, the BSM outside rear view mirror indi-
cators will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not
turn off, there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Toyota dealer.

*

7

: This light illuminates on the outside rear view mirrors.

*

8

: The light does not turn on when the system is disabled.

*

9

: This light illuminates on the center panel.

■

Eco Driving Indicator Light

●

The vehicle is set to power mode. (



P. 234)

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

During  Eco-friendly  acceleration  (Eco
driving),  Eco  Driving  Indicator  Light  will
turn  on.  When  the  acceleration  pedal  is
depressed excessively, or when the vehi-
cle is stopped, the light turns off.
Eco Driving Indicator Light will not operate
in the following conditions:

●

The shift lever is in anything other than
D.

WARNING

■

If a safety system warning light does not come on

Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

89

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

2

Instru

me
nt clu

ster

Gauges and meters

The  displayed  content  may  differ  depending  on  the  type  of
meter.

90

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

Tachometer

Displays the engine speed in revolutions per minute

Multi-information display

Presents the driver with a variety of driving-related data (



P. 92)

Speedometer

Displays the vehicle speed

Fuel gauge

Displays the quantity of fuel remaining in the tank

Odometer/trip meter display change button
Outside temperature



P. 91

Odometer and trip meter display

Odometer:
Displays the total distance that the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters “A” and “B” can be used to record and display different
distances independently.

Shift position and range



P. 233

Meter panel lights control button



P. 91

Engine coolant temperature gauge

Displays the engine coolant temperature

Pressing  this  button  switches
among  the  odometer,  trip  meter
“A”  and  trip  meter  “B”  displays.
When the trip meter  is displayed,
pressing  and  holding  the  button
will reset the trip meter.

Changing the trip meter display

1

2

3

4

5

6

7

8

9

10

SIENNA_OM_OM08035U_(U)

91

2. Instrument cluster

2

Instru

me
nt clu

ster

The brightness of the meter panel lights can be adjusted.
Pressing the button will adjust the
brightness  of  the  meter  panel
lights.

The brightness level of the meters
when  the  surroundings  are  bright
(day mode) and dark (night mode)
can  be  adjusted  individually.  How-
ever, when in day mode, adjusting
the  brightness  level  will  also
change  the  brightness  level  of
night mode.

■

Outside temperature display

●

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/

exit of a garage, tunnel, etc.)

●

The temperature range that can be displayed is from -40°F (-40°C) to 122°F
(50°C).
When  the  outside  temperature  drops  below  37°F  (3°C),  the  Low  outside
temperature  indicator  will  be  displayed  on  the  multi-information  display.
(



P. 86)

●

When “--” or “E” is displayed, the system may be malfunctioning. Take your
vehicle to your Toyota dealer.

Meter panel light control

NOTICE

■

To prevent damage to the engine and its components

●

Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.

●

The engine may be overheating if the engine coolant temperature gauge is
in  the  red  zone  (H).  In  this  case,  immediately  stop  the  vehicle  in  a  safe
place, and check the engine after it has cooled completely. (



P. 509)

92

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

Multi-information display

The

multi-information

display

presents  the  driver  with  a  variety
of vehicle data.

●

Menu icons
Displays the following information when an icon is selected.
(



P. 93)

Some of the information may be displayed automatically depending
on the situation.

Drive information

Select to display various drive data. (



P. 94)

Navigation system-linked display (if equipped)

Select to display the following navigation system-linked information.

• Route guidance
• Compass display (north-up display/heading-up display)

Audio/visual system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Dynamic radar cruise control display

Select  to  display  the  information  and  operation  procedures  of  the
dynamic radar cruise control. (



P. 288)

The

 tab will change to

 when the vehicle is in constant

speed control mode. (



P. 297)

Display contents

SIENNA_OM_OM08035U_(U)

93

2. Instrument cluster

2

Instru

me
nt clu

ster

Warning message display

Select to display warning messages and measures to be taken if a
malfunction is detected. (



P. 481)

When there is a warning message that can be displayed, the color of

 changes to Amber.

Settings display

Select to change the meter display settings. (



P. 540)

●

Intuitive parking assist display (if equipped)
Automatically displayed when the system is used (



P. 314)

●

Power mode (



P. 234)

The  multi-information  display  is
operated  using  the  meter  control
switches.

Enter/Set
Select an item/Change pages
Return to the previous screen
Press: Displays the screen reg-
istered as the top screen

When no screen has been registered, the drive information screen will be
displayed.

Press and hold: Registers the currently displayed screen as the top
screen

When  the  confirmation  screen  is  displayed,  select  yes  to  register  the
screen. If the selected screen cannot be registered, a registration failure
message will be shown.

Operating the meter control switches

1

2

3

4

94

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

●

Average fuel economy

*

1, 2

Displays  the  average  fuel  consumption  since  the  function  was
reset.

*

3

●

Tank average fuel economy

*

1, 2

Displays the average fuel consumption since the vehicle was refu-
eled.

●

Trip average fuel economy

*

1, 2

Displays  the  average  fuel  consumption  since  the  engine  was
started.

●

Current fuel economy

*

1, 2

Displays the current rate of fuel consumption.

●

Distance to empty

*

1

Displays the estimated maximum distance that can be driven with
the quantity of fuel remaining.

• This distance is computed based on your average fuel consump-

tion. As a result, the actual distance that can be driven may differ
from that displayed.

• When only a small amount of fuel is added to the tank, the dis-

play may not be updated.
When refueling, turn the engine switch off. If the vehicle is refu-
eled without turning the engine switch off, the display may not be
updated.

●

Trip distance

*

1

Displays the driving distance after the engine was started.

●

Distance

*

1

Displays the driving distance since the function was reset.

*

3

●

Trip elapsed time

*

1

Displays the elapsed time since the function was reset.

*

3

●

Elapsed time

*

1

Displays the elapsed time since the engine was started.

●

Trip average speed

*

1

Displays the average vehicle speed since the function was reset.

*

3

●

Average speed

*

1

Displays the average vehicle speed since the engine was started.

Drive information

SIENNA_OM_OM08035U_(U)

95

2. Instrument cluster

2

Instru

me
nt clu

ster

●

AWD control (if equipped)
Displays the torque distribution between the front and rear axles of
the AWD control system

●

Digital speedometer

*

1

●

Display off
A blank screen is displayed.

*

1

: Can be registered to Drive information 1 through 3. (



P. 96)

*

2

: Use the displayed fuel consumption as a reference.

*

3

: Resetting procedures:

• Select a function to be reset using the meter control switches and then

press and hold to reset.

• If there is more than one function that can be reset, check boxes will be

displayed next to those functions.

96

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

The settings of the following items can be changed, refer to P. 540

●

Language
Select to change the language on the display.

●

Units
Select to change the unit for measure of the fuel consumption and
outside temperature.

●

Drive information 1 through 3
Select to select up to 2 items that will be displayed on a Drive infor-
mation screen, up to 3 Drive information screens can be set.

●

Eco Driving Indicator Light
Select to activate/deactivate the Eco Driving Indicator Light.
(



P. 88)

●

 switch settings

You can register 1 screen as the top screen. To register, press and
hold

 while the desired screen is displayed.

●

Pop-up display
Select  to  set  the  following  pop-up  displays,  which  may  appear  in
some situations, on/off.

• Instrument panel brightness adjustment display
• Route guidance display of the navigation system-linked system

(if equipped)

• Incoming call display of the hands-free phone system
• Shift position display

Settings display

SIENNA_OM_OM08035U_(U)

97

2. Instrument cluster

2

Instru

me
nt clu

ster

●

Speed limit display (if equipped)
Select to set the display of speed limit information stored in the nav-
igation system to on with the speed limit caution indicator (yellow)
enabled,  on  with  the  speed  limit  caution  not  enabled,  or  off.  If
enabled, the speed limit caution indicator will come on if the vehicle
speed exceeds the displayed speed limit.

The display may not be available for some regions.

●

BSM (Blind Spot Monitor) (if equipped)
The  brightness  of  the  outside  rear  view  mirror  indicators  can  be
adjusted. (



P. 548)

●

RCTA (Rear Cross Traffic Alert buzzer) (if equipped)
The buzzer sound volume can be adjusted. (



P. 548)

●

Maintenance Reset
Select to reset the maintenance data (



P. 399)

●

Initialization
Registered or changed meter settings will be deleted or returned to
their default setting.

■

Pop-up display

In some situations, such as when a switch operation is performed, a pop-up
display, such as the operating shift position, will be temporarily displayed on
the multi-information display.
The pop-up display function can be set on/off. (



P. 540)

■

Setting display automatic cancelation

In  the  following  situations,  setting  display  in  which  the  settings  can  be
changed through the meter control switch will automatically be turned off.

●

If a warning message appears while the setting display is displayed

●

When the vehicle begins to move while the setting display is displayed

■

Liquid crystal display

Small  spots  or  light  spots  may  appear  on  the  display. This  phenomenon  is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

98

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

WARNING

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the display monitor may
respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift  again,  causing  rapid  and  excessive  engine  braking  and  possibly  an
accident resulting in death or injury.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may  collect  and  enter  the  vehicle.  This  may  lead  to  death  or  a  serious
health hazard.

NOTICE

■

During setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

99

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

2

Instru

me
nt clu

ster

Fuel consumption information



Entune Audio or Entune Audio Plus (vehicles without Data Commu-
nication Module)

Press the “MENU” button.
Select  “Info”  on  the  “Menu”
screen.

If the “History” screen is displayed,
select “Trip Information”.

Fuel  consumption  information  can  be  displayed  on  the  audio/
visual system screen.

Trip information

1

2

100

SIENNA_OM_OM08035U_(U)

2. Instrument cluster



Entune Audio or Entune Audio Plus (vehicles with Data Communi-
cation Module)/Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “History” screen is displayed, select “Trip Information”.

Resetting the consumption data
Average  vehicle  speed  since
the engine was started
Elapsed  time  since  the  engine
was started
Fuel consumption in the past 15
minutes
Cruising range (



P. 102)

Current fuel consumption

Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last  turned  to  IGNITION  ON  mode.  Use  the  displayed  average  fuel
consumption as a reference.

This image is an example only.

1

2

3

1

2

3

4

5

6

SIENNA_OM_OM08035U_(U)

101

2. Instrument cluster

2

Instru

me
nt clu

ster



Entune Audio or Entune Audio Plus (vehicles without Data Commu-
nication Module)

Press the “MENU” button.
Select  “Info”  on  the  “Menu”
screen.

If  the  “Trip  Information”  screen  is
displayed, select “History”.



Entune Audio or Entune Audio Plus (vehicles with Data Communi-
cation Module)/Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “Trip Information” screen is displayed, select “History”.

Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous

fuel

consumption

record



Entune  Audio  and  Entune
Audio Plus

Displays  the  daily  average  fuel  consumption.  (Instead  of  the  date,
“Trip 1” through “Trip 5” will be displayed.)



Entune Premium Audio

Displays the daily average fuel consumption.

Updating the average fuel consumption data

The  average  fuel  consumption  history  is  divided  by  color  into  past
averages  and  the  average  fuel  consumption  since  the  last  updated.
Use the displayed average fuel consumption as a reference.

This image is an example only.

History

1

2

1

2

3

1

2

3

4

5

102

SIENNA_OM_OM08035U_(U)

2. Instrument cluster

■

Updating the past record data

Update the average fuel consumption by selecting “Clip” to measure the cur-
rent fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted by selecting “Clear”.

■

Cruising range

Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

103

SIENNA_OM_OM08035U_(U)

3

Operation of

each component

3-1. Key information

Keys .................................. 104

3-2. Opening, closing and

locking the doors

Front doors........................ 110
Sliding doors ..................... 121
Back door.......................... 133
Smart key system ............. 143

3-3. Adjusting the seats

Front seats ........................ 149
Rear seats......................... 152
Driving position memory ... 169
Head restraints.................. 173

3-4. Adjusting the steering

wheel and mirrors

Steering wheel .................. 177
Inside rear view mirror ...... 179
Outside rear view

mirrors............................. 181

3-5. Opening, closing the

windows and moon roof

Power windows ................. 184
Quarter windows ............... 187
Moon roof.......................... 189

104

SIENNA_OM_OM08035U_(U)

3-1. Key information

Keys

The following keys are provided with the vehicle.



Vehicles without a smart key system

Master keys (black)
Valet key (gray)
Key number plate



Vehicles with a smart key system

Electronic keys

• Operating the smart key system

(



P. 143)

• Operating  the  wireless  remote

control function

Mechanical keys
Key number plate

The keys

1

2

3

1

2

3

SIENNA_OM_OM08035U_(U)

105

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t



Vehicles without a smart key system (type A)

Locks all doors (



P. 111)

Unlocks all doors (



P. 111)

Sounds the alarm (



P. 106)



Vehicles without a smart key system (type B)

Locks all doors (



P. 111)

Unlocks all doors (



P. 111)

Opens  and  closes  the  left  side
power sliding door (



P. 124)

Opens and closes the right side
power sliding door (



P. 124)

Opens  and  closes  the  power
back door

*

 (



P. 135)

Sounds the alarm (



P. 106)

*

: If equipped



Vehicles with a smart key system

Locks all doors (



P. 111)

Unlocks all doors (



P. 111)

Opens  and  closes  the  left  side
power sliding door (



P. 124)

Opens and closes the right side
power sliding door (



P. 124)

Opens  and  closes  the  power
back door

*

 (



P. 135)

Sounds the alarm (



P. 106)

*

: If equipped

Wireless remote control

1

2

3

1

2

3

4

5

6

1

2

3

4

5

6

106

SIENNA_OM_OM08035U_(U)

3-1. Key information

To  take  out  the  mechanical  key,
push the release button and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock  cylinder,  turn  it  over  and  re-
attempt to insert it.
After  using  the  mechanical  key,  store  it  in  the  electronic  key.  Carry  the
mechanical key together with the electronic key. If the electronic key bat-
tery  is  depleted  or  the  entry  function  does  not  operate  properly,  you  will
need the mechanical key. (



P. 503)

■

Panic mode



Vehicles without a smart key system



Vehicles with a smart key system

Using the mechanical key (vehicles with a smart key system)

When

  is  pressed  for  longer  than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.

When

  is  pressed  for  longer  than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

SIENNA_OM_OM08035U_(U)

107

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

■

When required to leave the vehicle’s key with a parking attendant

Lock the glove box as circumstances demand. (



P. 351)

On  vehicles  without  the  smart  key  system,  provide  the  attendant  with  the
valet key.
On vehicles with the smart key system, remove the mechanical key for your
own use and provide the attendant with the electronic key only.

■

If you lose your keys

New genuine keys can be made by your Toyota dealer using a master key
(vehicles without a smart key system) or the other key (vehicles with a smart
key system) and the key number stamped on your key number plate. Keep
the plate in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft

When  bringing  a  key  with  wireless  remote  control  function  onto  an  aircraft,
make sure you do not press any buttons on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.

■

Conditions affecting the operation of the smart key system or wireless
remote control



P. 118

■

Key battery depletion



Vehicles without a smart key system

If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (



P. 436)



Vehicles with a smart key system

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine
stops. (



P. 436, 481)

●

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate  that  the  electronic  key  battery  may  be  depleted.  Replace  the  battery
when necessary. (



P. 436)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

●

To  avoid  serious  deterioration,  do  not  leave  the  electronic  key  within  3 ft.
(1 m) of the following electrical appliances that produce a magnetic field.
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Induction cookers
• Table lamps

108

SIENNA_OM_OM08035U_(U)

3-1. Key information

■

When the key battery is fully depleted



P. 436

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

■

Certification  for  wireless  remote  control  (vehicles  without  a  smart  key
system)

This  device  complies  with  Part  15  of  the  FCC  Rules  and  with  RSS-210  of
Industry Canada. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept
any  interference  received,  including  interference  that  may  cause  undesired
operation.

■

Certification for wireless remote control (vehicles with a smart key sys-
tem)



For vehicles sold in the U.S.A.

FCC ID: HYQ14ADR

FCC ID: HYQ14AEH

FCC ID: HYQ13CZM

FCC ID: HYQ13CZN

FCC ID: NI4TMLF8-20
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence,  and  (2)  this  device  must  accept  any  interference  received,  including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

NOTE:
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.

■

Customization

Settings (e.g. wireless remote control system) can be changed.
(Customizable features:



P. 543, 544)

SIENNA_OM_OM08035U_(U)

109

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as
TVs,  audio  systems  and  induction  cookers,  or  medical  electrical  equip-
ment, such as low-frequency therapy equipment.

■

Carrying the electronic key on your person (vehicles with a smart key
system)

Carry  the  electronic  key  3.9 in.  (10 cm)  or  more  away  from  electric  appli-
ances  that  are  turned  on.  Radio  waves  emitted  from  electric  appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.

■

In case of a smart key system malfunction or other key-related prob-
lems (vehicles with a smart key system)

Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.

■

When a vehicle key is lost (vehicles with a smart key system)

If the key remains lost, the risk of vehicle theft increases significantly. Visit
your Toyota dealer immediately with all remaining electronic keys that were
provided with your vehicle.

110

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

Front doors

◆

Entry function (vehicles with a smart key system)

Carry the electronic key to enable this function.

Grip the driver’s door handle
to  unlock  the  door.  Grip  the
passenger’s  door  handle  to
unlock all the doors.

*

Make  sure  to  touch  the  sensor
on the back of the handle.
The  doors  cannot  be  unlocked
for 3 seconds after the doors are
locked.

*

: The door unlock settings can be changed. (



P. 117)

Touch the lock sensor (the indentation on the upper part of the
door handle) to lock all the doors.

Check that the door is securely locked.

Unlocking and locking the doors from the outside

1

2

SIENNA_OM_OM08035U_(U)

111

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

◆

Wireless remote control



Vehicles without a smart key system (type A)

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.



Vehicles without a smart key system (type B)

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.



Vehicles with a smart key system

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.

1

2

1

2

1

2

112

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

◆

Key



Vehicles without a smart key system

Locks all the doors
Unlocks all the doors

Turning  the  key  unlocks  the
driver’s  side  doors.  Turning  the
key  again  within  3  seconds
unlocks the other doors.



Vehicles with a smart key system

The  doors  can  also  be  locked  and  unlocked  with  the  mechanical
key. (



P. 503)

1

2

SIENNA_OM_OM08035U_(U)

113

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

■

Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

■

When the door cannot be locked by the lock sensor on the upper part of
the front door handle

■

Door lock buzzer

If an attempt to lock the doors (except for power sliding doors or power back
door) is made when a door is not fully closed, a buzzer sounds continuously.
Fully close the door to stop the buzzer, and lock the vehicle once more.

■

Alarm (if equipped)

Using the wireless remote control to lock the doors will set the alarm system.
(



P. 79)

■

If the smart key system or the wireless remote control does not operate
properly

Vehicles with a smart key system: Use the mechanical key to lock and unlock
the doors. (



P. 503)

Replace the key battery with a new one if it is depleted. (



P. 436)

Touch both lock sensors on the upper and
lower part of the front door handle simul-
taneously.

114

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

◆

Door lock switch

Locks all the doors
Unlocks all the doors

◆

Inside lock button

Locks the door
Unlocks the door

The  front  doors  can  be  opened
by  pulling  the  inside  handle
even  if  the  lock  buttons  are  in
the lock position.

Move the inside lock button to the lock position.
Close the door.



Vehicles without a smart key system

The doors cannot be locked if either of the front doors is open and the
key is in the engine switch.



Vehicles with a smart key system

The door cannot be locked if the engine switch is in ACCESSORY or
IGNITION ON mode, or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

Unlocking and locking the doors from the inside

1

2

1

2

Locking the front doors from the outside without a key

1

2

SIENNA_OM_OM08035U_(U)

115

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

The following functions can be set or canceled:

For instructions on customizing, refer to P. 543

Automatic door locking and unlocking systems

Function

Operation

Shift  position  linked  door
locking function

Shifting  the  shift  lever  out  of  P  locks  all  the
doors.

Shift  position  linked  door
unlocking function

Shifting  the  shift  lever  to  P  unlocks  all  the
doors.

Speed linked door locking
function

All  the  doors  are  locked  when  the  vehicle
speed  is  approximately  12  mph  (20  km/h)  or
higher.

Driver’s  door  linked  door
unlocking function

Vehicles without a smart key system:
All  the  doors  are  unlocked  when  the  driver’s
door  is  opened  within  approximately  45  sec-
onds after turning the engine switch to “ACC”
or “LOCK”.
Vehicles with a smart key system:
All  the  doors  are  unlocked  when  the  driver’s
door  is  opened  within  approximately  45  sec-
onds after turning the engine switch off.

116

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

■

Setting and canceling the functions

To switch between set and canceled, follow the procedure below:

Close all the doors and turn the engine switch to the “ON” posi-
tion  (vehicles  without  a  smart  key  system)  or  IGNITION  ON
mode (vehicles with a smart key system). (Perform step   within
10 seconds.)
Shift the shift lever to P or N,
and press and hold the door
lock  switch  (

  or

)  for

approximately 5 seconds and
then release.

The  shift  lever  and  switch  posi-
tions  corresponding  to  the
desired  function  to  be  set  are
shown in the following table.
Use the same procedure to cancel the function.

When the setting or canceling operation is complete, all the doors are
locked and then unlocked.

1

2

2

Function

Shift lever

position

Door lock switch

position

Shift  position  linked  door  locking
function

P

Shift  position  linked  door  unlock-
ing function

Speed linked door locking function

N

Driver’s  door  linked  door  unlocking
function

SIENNA_OM_OM08035U_(U)

117

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

■

Switching the door unlock function (vehicles with a smart key system)

It is possible to set which doors the entry function unlocks using the wireless
remote control.

Turn the engine switch off.

When  the  indicator  on  the  key  surface  is  not  on,  press  and  hold

,

,

,

  or

  for  about  5  seconds  while  pressing  and  holding

.

The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step  .)

For vehicles equipped with an alarm, to prevent unintended triggering of the
alarm, unlock the doors using the wireless remote control and open and close
a door once after the settings have been changed. (If a door is not opened
within 60 seconds after

 is pressed, the doors will be locked again and

the alarm will automatically be set.)
In case that the alarm is triggered, immediately stop the alarm. (



P. 79)

1

2

2

Multi-information

display

Unlocking function

Beep

Holding  the  driver’s  door
handle  unlocks  only  the
driver’s door and driver side
power sliding door.

Exterior:  Beeps  three
times
Interior: Pings once

Holding  the  front  passen-
ger’s door handle or pulling
either  power  sliding  door
handle unlocks all doors.

Holding  either  front  door
handle  or  pulling  either
power  sliding  door  handle
unlocks all doors.

Exterior: Beeps twice
Interior: Pings once

118

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

■

When all the doors are locked with the wireless remote control or key

The doors cannot be unlocked with the door lock switch.
The door lock switch can be reset by unlocking all the doors with the wireless
remote control or key.

■

Using the mechanical key (vehicles with a smart key system)

The doors can also be locked and unlocked with the mechanical key.
(



P. 503)

■

Conditions affecting the operation of the smart key system or wireless
remote control



Vehicles without a smart key system

The wireless remote control function may not operate normally in the follow-
ing situations:

●

Near a TV tower, radio station, electric power plant, airport or other facility
that generates strong radio waves

●

When carrying a portable radio, cellular phone or other wireless communi-
cation devices

●

When multiple wireless keys are in the vicinity

●

When the wireless key is in contact with, or is covered by, a metallic object

●

When a wireless key (that emits radio waves) is being used nearby

●

When the wireless key has been left near an electrical appliance such as a
personal computer

●

If window tint with a metallic content or metallic objects is attached to the
rear window

●

Vehicles  with AUTO ACCESS  SEAT:  If  the  wireless  remote  control  of  the
AUTO  ACCESS  SEAT  is  operated  simultaneously,  the  AUTO  ACCESS
SEAT may not operate properly.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.

SIENNA_OM_OM08035U_(U)

119

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t



Vehicles with a smart key system

The smart key system uses weak radio waves. In the following situations, the
communication between the electronic key and the vehicle may be affected,
preventing the smart key system and wireless remote control from operating
properly. (Way of coping



P. 503)

●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When  carrying  a  portable  radio,  cellular  phone,  cordless  phone  or  other
wireless communication devices

●

When  the  electronic  key  is  in  contact  with,  or  is  covered  by  the  following
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

●

When multiple electronic keys are in the vicinity

●

When another wireless key (that emits radio waves) is being used nearby

●

When  carrying  or  using  the  electronic  key  together  with  the  following
devices that emit radio waves
• Another vehicle’s electronic key
• A wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the
rear window

●

Vehicles  with AUTO ACCESS  SEAT:  If  the  wireless  remote  control  of  the
AUTO  ACCESS  SEAT  is  operated  simultaneously,  the  AUTO  ACCESS
SEAT may not operate properly.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.

■

Customization

Settings (e.g. unlocking function using a key) can be changed.
(Customizable features:



P. 543)

120

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

WARNING

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failing to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Do not pull the inside handle of the doors while driving.
Be especially careful of the front doors, as the doors may be opened even
if the inside lock buttons are in the locked position.

121

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

Sliding doors

◆

Entry function (vehicles with a smart key system)

Carry the electronic key to enable this function.
Pull the handle to unlock all the
doors.

There is no touch type sensor in
slide door handle. You must pull
the handle to activate the opera-
tion.

◆

Wireless remote control



P. 111



Vehicles without power sliding doors

The  sliding  doors  can  be  opened  and  closed  using  the  sliding
door handle. The sliding door can be locked and unlocked using
the  wireless  remote  control,  door  lock  switch  or  inside  lock
knob.



Vehicles with power sliding doors

The  power  sliding  doors  can  be  opened  and  closed  using  the
sliding  door  handle,  power  sliding  door  switches  or  wireless
remote  control.  The  power  sliding  doors  can  be  locked  and
unlocked using the wireless remote control, door lock switch or
inside lock knob.

Locking/unlocking the sliding door from outside

122

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

◆

Door lock switch



P. 114

◆

Inside lock knobs

Unlocks
Locks

◆

Sliding door handle

Open/close

Vehicles  with  power  sliding
doors:  The  sliding  door  will  be
automatically  and  completely
opened  and  closed  by  the  fol-
lowing.

• Pulling the outside handle.
• Sliding  the  inside  handle  for-

ward to close or backward to
open.

Locking/unlocking the sliding door from inside

1

2

Opening/closing the sliding door

SIENNA_OM_OM08035U_(U)

123

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

◆

Power  sliding  door  switches  (vehicles  with  power  sliding
doors)

Press and hold the switch to open and close each sliding door.

Left side power sliding door
Right side power sliding door

Pressing the switch again while the door is operating will cause the opera-
tion  to reverse. However, the  reverse  operation  cannot  be  performed  for
the  first  second  after  automatic  operation  starts,  even  if  the  switch  is
pressed and held again.



From front seats



From second seats

1

2

124

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

◆

Wireless remote control (vehicles with power sliding doors)

Press and hold the switch to open/close the power sliding door.

Left side power sliding door
Right side power sliding door

Pressing  the  switch  again  while  the  power  sliding  door  is  operating  will
cause the operation to reverse. However, the reverse operation cannot be
performed for the first second after automatic operation starts, even if the
switch is pressed again.

Turn the main switch off to disable
the power sliding door system.

Off

The  sliding  doors  can  only  be
opened and closed manually.

On

*

The  power  sliding  door  can  be
opened and closed with the power
sliding  door  switches  for  the  front
occupants or wireless remote con-
trol  even  if  the  sliding  door  child-
protectors are locked.

*

: Orange mark on the switch should be visible when the switch is on.



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

Canceling  the  power  sliding  door  system  (vehicles  with  power
sliding doors)

1

2

1

2

SIENNA_OM_OM08035U_(U)

125

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

Move the inside lock knob to the lock position.
Close the sliding door.

The  sliding  door  cannot  be
opened by the inside door handle
and  the  second  seat  sliding  door
switch when the lock is set.

Unlock
Lock

These locks can be set to prevent
children  from  opening  the  sliding
doors.  Push  down  on  each  sliding
door  switch  to  lock  that  sliding
door.

■

The power sliding door can be operated when (vehicles with power slid-
ing doors)

●

Open operation: The shift lever is in P.
Close operation: The vehicle is stopped.

●

The power sliding door system main switch is on.

●

The power sliding door is unlocked. (Except for the wireless remote control
operation or smart key system operation.)

●

The sliding door child-protector lock is not set. (However, the switch for the
front occupants and the outside handle still operate the power sliding door.)

Locking the sliding doors from the outside without the wireless
remote control

Sliding door child-protector locks

1

2

1

2

126

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

■

Power sliding doors

●

If  the  power  sliding  door  outside  handle  is  pulled  while  the  power  sliding
door is opening or closing, the door will reverse the operation direction.

●

During opening operation:
Stroking the power sliding door handle forward will reverse the direction and
start closing.
Stroking the handle backward will continue opening.
During closing operation:
Stroking the power sliding door handle backward will reverse the direction
and start opening.
Stroking the handle forward will continue closing.

●

The  power  sliding  doors  can  be  opened/closed  manually  when  the  power
sliding door function is canceled with the main switch.

●

A buzzer sounds if you put the shift lever out of P with the engine switch in
the  “ON”  position  (vehicles  without  a  smart  key  system)  or  IGNITION  ON
mode (vehicles with a smart key system) and the sliding door not completely
closed.

●

Vehicles  with AUTO ACCESS  SEAT:  If  the AUTO ACCESS  SEAT  has  not
been locked in place after being stowed, the right-hand sliding door will not
close and a beep will sound twice.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.

●

In an emergency, power slide door operation can be stopped by any of the
following:
• Pulling the outside handle three consecutive times
• During opening operation, sliding the inside handle forward three consec-

utive times

• During closing operation, sliding the inside handle backward three con-

secutive times

• Pressing the power sliding door switch three consecutive times
• Pressing the power sliding door button on wireless remote control three

consecutive times (



P. 124)

After stopping, power sliding door brake function will be activated (



P. 127)

■

The situations in which the sliding door does not open completely

The  left  side  sliding  door  does  not  open
completely  when  the  fuel  filler  door  is
opened.

SIENNA_OM_OM08035U_(U)

127

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

■

Jam protection function (vehicles with power sliding doors)

●

If anything obstructs the power sliding door while it is closing or opening, the
power sliding door will automatically operate in the opposite direction.

●

If  the  jam  protection  function  operates  during  two  consecutive  operations,
the power sliding door will be stopped at that position and the power sliding
door system will be canceled.

■

Power sliding door brake function (vehicles with power sliding doors)

When  the  power  sliding  door  detects  an  abnormality  and  stops  operating,
power sliding door brake function may be activated. When brake function is
activated, door movement is restricted by the brake and motion may appear
to be not smooth. This is not malfunction. Move the door to fully closed posi-
tion to reset the system and normal power sliding door function will resume.

■

Sliding door closer (if equipped)

In the event that the sliding door is left slightly open, the sliding door closer
will automatically close it to the fully closed position.

■

Power sliding door operation (vehicles with power sliding door)

Wireless remote control: Even if the door is locked, pressing and holding the
sliding door buttons will unlock all doors and start open operation.

■

If  the  power  sliding  door  is  inoperative  (vehicles  with  power  sliding
doors)

When the power sliding door detects an abnormality and stops opening and
can  not  be  completely  closed  manually,  cancel  the  function  as  follows  and
close the door manually.
After that, have the vehicle inspected and repaired by your Toyota dealer.

Unplug  the  plug  from  the  rear  edge  of
the sliding door.

Insert  a  key  in  the  hole  and  push  the
mechanical cancel lever.

1

2

128

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

■

When the battery is disconnected (vehicles with power sliding doors)

The power sliding door system must be initialized in order to ensure proper
operation. To initialize it, close the sliding doors completely by hand.

■

Conditions affecting the operation of the smart key system or wireless
remote control



P. 118

■

Customization

Settings (e.g. opening and closing operation) can be changed.
(Customizable features:



P. 545)

WARNING

■

To prevent an accident

Observe the following precautions while driving.
Failure to do so may cause a door to open unexpectedly and an occupant to
fall out of the vehicle, resulting in death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Set the sliding door child-protector locks when children are seated in the
vehicle.

●

Do not operate the inside handle of the doors while driving.

■

When children are in the vehicle

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Do not leave children alone in the vehicle.
If  a  child  is  accidentally  locked  in  the  vehicle,  they  could  have  heat
exhaustion or other injuries.

●

Do not allow a child to open or close the sliding door.
Doing so may cause the sliding door to move unexpectedly, or cause the
child’s hands, head, or neck to be caught by the moving sliding door.

■

Operating the sliding doors

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.

●

When opening or closing a sliding door, thoroughly check to make sure the
surrounding area is safe.

SIENNA_OM_OM08035U_(U)

129

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

WARNING

●

When  opening  or  closing  the  sliding  doors  with  windows  open,  keep  all
body parts clear of the windows.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the sliding door is about to open or close.

●

Do not leave the sliding door at half-opened position because the sliding
door is not latched at this position. The sliding door may move unexpect-
edly on an incline.

●

When the vehicle is stopped on a slope,
the  door  will  slide  faster when  opening
or closing, so be especially careful that
the  passengers  do  not  get  hit  or
pinched by the door.

●

Open  the  sliding  door  fully  while  pas-
sengers are getting on or off on a down-
ward slope. Do not operate the outside
handle  or  inside  handle  while  the  door
is  open  as  the  door  could  suddenly
close by itself causing injury.

●

When  closing  the  sliding  door,  take
extra  care  to  prevent  your  fingers  etc.
from being caught.

130

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

WARNING

■

Sliding door closer (if equipped)

●

Use  caution  when  using  the  sliding  door  closer.  The  sliding  door  closer
operates even when the power sliding door system is canceled.

■

Power sliding doors (vehicles with power sliding doors)

Observe  the  following precautions when  the  power  sliding door system is
on.
Failure to do so may cause death or serious injury.

●

When  using  the  door  handle  to  open  or  close  the  power  sliding  door,
remove your hand from the door handle immediately after starting power
sliding door operation. If you leave your hand on the door handle during
operation, your hand, fingers, wrist etc. may be subjected to an excessive
amount of force.

●

Check the safety of the surrounding area to make sure there are no obsta-
cles or anything that could cause any of your belongings to get caught.

●

In the event that the sliding door is left
slightly open, the sliding door closer will
automatically close it to the fully closed
position.  It  takes  several  seconds
before the sliding door closer begins to
operate. Be careful not to catch fingers
or  anything  else  in  the  sliding  door,  as
this may cause bone fractures or other
serious injuries.

●

Do  not  get  in  and  out  of  the  vehicle
while  the  power  sliding  door  is  being
operated.

●

If  anyone  is  in  the  vicinity,  make  sure
they are safe and let them know that the
sliding door is about to open or close.
Also,  do  not  operate  the  power  sliding
door  if  anyone  inside  or  outside  the
vehicle is leaning against the vehicle in
the area around the sliding door.

SIENNA_OM_OM08035U_(U)

131

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

WARNING

●

If the power sliding door system is turned off with the main switch while the
sliding door is operating automatically, the automatic operation is stopped.
The sliding door then has to be operated manually. Take extra care when
on an incline, as the sliding door may open or close unexpectedly.

●

If the operating conditions of the power sliding door are no longer met, a
buzzer may sound and the sliding door may stop opening or closing. The
sliding door then has to be operated manually. Take extra care when on an
incline, as the sliding door may open or close abruptly.

●

On  an incline,  a sliding door may close by  itself after it opens automati-
cally. Make sure the sliding door is fully open and secure.

●

In the following situations, the power sliding door may detect an abnormal-
ity and automatic operation may be stopped. In this case, the sliding door
has to be operated manually. Take extra care when on an incline, as the
sliding door may open or close abruptly.
• When the sliding door contacts an obstacle
• When  the  battery  voltage  suddenly  drops,  such  as  when  the  engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system) or the
engine is started during automatic operation

●

Do  not  attach  any  accessories  other  than  genuine  Toyota  parts  to  the
power sliding door. The power sliding door may not operate, causing itself
to  malfunction,  or  the  power  sliding  door  may  close  again  after  it  is
opened.

●

When  the  child-protector  locks  are  set,  make  sure  to  turn  off  the  power
sliding door system with the main switch in order to totally disable the sys-
tem.

■

Jam protection function (vehicles with power sliding doors)

Observe the following precautions.
Failure to do so may cause death or serious injury.

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The  jam  protection  function  may  not  work  if  something  gets  caught  just
before the power sliding door fully closes. Be careful not to catch fingers or
anything else.

●

The jam protection function may not work depending on the shape of the
object that is caught. Be careful not to catch fingers or anything else.

132

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

NOTICE

■

Sliding door

■

To prevent damage to your vehicle

●

Vehicles with the power sliding door:
• Do not apply excessive force when the sliding door is operating.
• Do not place your hand or foot near door hinges or rollers when the slid-

ing door is operating.

• Avoid forcibly opening the left side sliding door fully when the fuel filler

door is opened. Otherwise, the fuel filler door may be damaged.

• Take care not to damage the sensors (installed on the front edge of the

power sliding door) with a knife or other sharp object.

●

Make sure there is nothing in the doorway before closing.

●

Do not close the sliding door by applying the brakes. Doing so could cause
the sliding door to be damaged.

Make  sure  magazines  are  not  bent  or
protruding from the sliding door pockets.
Do not insert anything too big so that the
shape of the sliding door pockets is dis-
torted.  Such  objects  may  obstruct  the
opening/closing  of  the  sliding  doors,
damage  the  sliding  door  pockets  or  the
vehicle  body,  and  may  result  in  a  mal-
function.

133

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

Back door

◆

Entry function (vehicles with a smart key system)

Carry the electronic key to enable this function.

Press  the  unlock  button  to
unlock all the doors.

The door cannot be unlocked for
3  seconds  after  the  door  is
locked.
Lock the back door again when
you leave the vehicle. The back
door  will  not  lock  automatically
after  it  has  been  opened  and
then closed.

Press the lock button to lock all the doors.

Check that the door is securely locked.

◆

Wireless remote control



P. 111

◆

Door lock switch



P. 114

The  back  door  can  be  locked/unlocked  and  opened/closed  by
the following procedures.

Locking and unlocking the back door

1

2

134

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

Press and hold the switch to open/
close the back door.

Pressing the switch again while the
power  back  door  is  operating  will
cause the operation to reverse.
However,  the  reverse  operation
cannot  be  performed  for  the  first
second  after  automatic  operation
starts even if the switch is pressed
again.

◆

Back door opener

Raise  the  back  door  while
pressing  the  back  door  opener
to release the lock to open the
back door.

Opening/closing the back door from inside the vehicle (vehicles
with power back door)

Opening the back door from outside the vehicle

SIENNA_OM_OM08035U_(U)

135

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

◆

Wireless remote control (vehicles with power back door)

Press and hold the switch to open/close the power back door.

Pressing  the  switch  again  while  the  power  back  door  is  operating  will
cause the operation to reverse. However, the reverse operation cannot be
performed for the first second after automatic operation starts, even if the
wireless remote control switch is pressed again.

Press the switch to close the back
door.

Pressing the switch again while the
power  back  door  is  closing  will
cause it to open again.
However,  the  reverse  operation
cannot  be  performed  for  the  first
second  after  automatic  operation
starts even if the switch is pressed
again.



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

Power back door switch (if equipped)

136

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

Lower  the  back  door  using  the
back door handle, and make sure
to push the back door down from
the outside to close it.

Turn the main switch off to disable
the power back door system.

Off
On

*

*

: The  orange  line  at  the  top  of  the

switch  indicates  that  the  power
back door system is on.

When closing the back door

Canceling  the  power  back  door  system  (vehicles  with  power
back door)

1

2

SIENNA_OM_OM08035U_(U)

137

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

■

Luggage compartment light

■

If the back door opener is inoperative

The back door can be operated from the inside.

Move the lever.

The  luggage  compartment  light  turns  on
when  the  back  door  is  opened  with  the
luggage compartment light switch on.

On
Off

Remove the inside panel.



Vehicles without power back door



Vehicles with power back door

1

2

1

2

138

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

■

The power back door can be operated when (vehicles with power back
door)

●

The shift lever is in P.

●

The back door is unlocked.

■

Power back door operation (vehicles with power back door)

●

A buzzer sounds and the emergency flashers flash twice to indicate that the
back door is opening/closing.

●

The back door can be opened and closed manually even when the power
back door main switch is off.

■

Jam protection function (vehicles with power back door)

●

If anything obstructs the power back door while it is closing or opening, the
back door will automatically operate in the opposite direction.

●

If the jam protection function operates during two consecutive closing oper-
ations, the back door will be stopped at that position.

■

Back door closer (if equipped)

In the event that the back door is left slightly open, the back door closer will
automatically close it to the fully closed position.

■

When the battery is disconnected

●

The back door will be automatically locked after the battery is reconnected.

●

The  power  back  door  (if  equipped)  must  be  initialized  in  order  to  ensure
proper operation.

Unlock the back door with the wireless remote control or door lock switch.
Close the back door completely by hand.

■

Conditions affecting the operation of the smart key system or wireless
remote control



P. 118

1

2

SIENNA_OM_OM08035U_(U)

139

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Before driving

●

Make sure that the back door is fully closed. If the back door is not fully
closed, it may open unexpectedly while driving and hit near-by objects or
luggage in the luggage compartment may be thrown out, causing an acci-
dent.

●

Do not allow children to play in the luggage compartment.
If  a  child  is  accidentally  locked  in  the  luggage  compartment,  they  could
have heat exhaustion or other injuries.

●

Do not allow a child to open or close the back door.
Doing so may cause the back door to operate unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.

■

Important points while driving

Never  let  anyone  sit  in  the  luggage  compartment.  In  the  event  of  sudden
braking,  sudden  swerving  or  a  collision,  they  are  susceptible  to  death  or
serious injury.

■

Operating the back door

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.

●

Remove  any  heavy  loads,  such  as  snow  and  ice,  from  the  back  door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.

●

When  opening  or  closing  the  back  door,  thoroughly  check  to  make  sure
the surrounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.

●

Use caution when opening or closing the back door in windy weather as it
may move abruptly in strong wind.

●

The back door may suddenly shut if it is
not  opened  fully.  It  is  more  difficult  to
open  or  close  the  back  door  on  an
incline  than  on  a  level  surface,  so
beware  of  the  back  door  unexpectedly
opening or closing by itself. Make sure
that  the  back  door  is  fully  open  and
secure  before  using  the  luggage  com-
partment.

140

SIENNA_OM_OM08035U_(U)

3-2. Opening, closing and locking the doors

WARNING

●

Do not place your hands on the back door damper stay to close the back
door, and do not hang on the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to
break, causing an accident.

●

If a bicycle carrier or similar heavy object is attached to the back door, it
may suddenly shut again after being opened, causing someone’s hands,
head or neck to be caught and injured. When installing an accessory part
to the back door, using a genuine Toyota part is recommended.

■

Back door closer (if equipped)

●

Use caution when using the back door closer as it still operates when the
power back door system is canceled.

■

Power back door (vehicles with power back door)

Observe the following precautions when operating the power back door.
Failure to do so may cause death or serious injury.

●

Check the safety of the surrounding area to make sure there are no obsta-
cles or anything that could cause any of your belongings to get caught.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.

●

If  the  operating  conditions  of  the  power  back  door  are  no  longer  met,  a
buzzer may sound and the back door may stop opening or closing. The
back door then has to be operated manually. Take extra care when on an
incline, as the back door may open or close abruptly.

●

On an incline, the back door may suddenly shut after it opens. Make sure
the back door is fully open and secure.

●

When closing the back door, take extra
care  to  prevent  your  fingers  etc.  from
being caught.

●

When closing the back door, make sure
to press it lightly on its outer surface. If
the  back  door  handle  is  used  to  fully
close  the  back  door,  it  may  result  in
hands or arms being caught.

●

In  the  event  that  the  back  door  is  left
slightly  open,  the  back  door  closer  will
automatically close it to the fully closed
position.  It  takes  several  seconds
before  the  back  door  closer  begins  to
operate. Be careful not to catch fingers
or anything else in the back door, as this
may cause bone fractures or other seri-
ous injuries.

SIENNA_OM_OM08035U_(U)

141

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

WARNING

●

In the following situations, the power back door may detect an abnormality
and automatic operation may be stopped. In this case, the back door has
to be operated manually. Take extra care when on an incline, as the back
door may open or close abruptly.
• When the back door contacts an obstacle
• When  the  battery  voltage  suddenly  drops,  such  as  when  the  engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system) or the
engine is started during automatic operation

●

If a bicycle carrier or similar heavy object is attached to the back door, the
power  back  door  may  not  operate,  causing  itself  to  malfunction,  or  the
back door may move in the closing direction after being opened, causing
someone’s hands, head or neck to be caught and injured. When installing
an accessory part to the back door, ask your Toyota dealer for details.

■

Jam protection function (vehicles with power back door)

Observe the following precautions.
Failure to do so may cause death or serious injury.

●

Although  the  back  door  stops  closing  when  the  jam  protection  function
detects an object, take extra care as you may still be injured if part of your
body is already caught.

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The  jam  protection  function  may  not  work  if  something  gets  caught  just
before the back door fully closes. Be careful not to catch fingers or any-
thing else.

●

The jam protection function may not work depending on the shape of the
object that is caught. Be careful not to catch fingers or anything else.
