6-1. Maintenance and care

SEQUOIA_OM_USA_OM0C035U

NOTICE

■

To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels, etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the

paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

●

Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.

401

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

NOTICE

■

When using a high pressure car wash

●

Do  not  spray  water  directly  on  the  radar  which  is  equipped  behind  the
emblem. Otherwise it may cause the device to be damaged.

●

Do not bring the nozzle tip close to boots (rubber or resin manufactured
cover),  connectors  or  the  following  parts. The  parts  may  be  damaged  if
they come into contact with high-pressure water.
• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

●

Keep the cleaning nozzle at least 11.9 in. (30 cm) away from the vehicle

body.  Otherwise  resin  section,  such  as  moldings  and  bumpers,  may  be

deformed and damaged. Also, do not continuously hold the nozzle in the

same place.

●

Do not spray the lower part of the windshield continuously.

If  water  enters  the air  conditioning system  intake located  near  the  lower

part  of  the  windshield,  the  air  conditioning  system  may  not  operate  cor-

rectly.

●

Do  not  wash  the  underside  of  the  vehicle  using  a  high  pressure  car

washer.

402

6-1. Maintenance and care

SEQUOIA_OM_USA_OM0C035U

Cleaning and protecting the vehicle interior

●

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces
with a cloth dampened with lukewarm water.

●

If dirt cannot be removed, wipe it off with a soft cloth dampened with
neutral detergent diluted to approximately 1%.
Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe off any excess dirt and dust with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

●

Wring out any excess water from the cloth and thoroughly wipe off
all remaining traces of detergent.

●

Wipe  the  surface  with  a  dry,  soft  cloth  to  remove  any  remaining
moisture. Allow the leather to dry in a shaded and ventilated area.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe it off with a soft cloth dampened with neutral detergent diluted
to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

The following procedures will help protect your vehicle’s interior
and keep it in top condition:

Protecting the vehicle interior

Cleaning the leather areas

Cleaning the synthetic leather areas

403

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Caring for leather areas

Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle’s interior.

■

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a sponge
or  brush  to  apply  the  foam.  Rub  in  overlapping  circles.  Do  not  use  water.
Wipe dirty surfaces and let them dry. Excellent results are obtained by keep-
ing the carpet as dry as possible.

■

Seat belts

Clean  with  mild  soap  and  lukewarm  water  using  a  cloth  or  sponge.  Also
check the belts periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.
Doing so may cause electrical components, etc., to malfunction or catch
fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
(



P. 41)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use a polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

404

6-1. Maintenance and care

SEQUOIA_OM_USA_OM0C035U

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat  portions:  Organic  substances  such  as  benzene  or  gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

●

Do not use a polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

■

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of
leather surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.

■

Water on the floor

Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

■

When cleaning the inside of the windshield

Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
(



P. 249)

■

Cleaning the inside of the rear quarter windows and back window

●

Do  not  use  a  glass  cleaner  to  clean  the  rear  quarter  windows  and  back
window, as  this may  cause damage to  the  rear  window  defogger heater
wires  or  antenna.  Use  a  cloth  dampened  with  lukewarm  water  to  gently
wipe the window clean. Wipe the window in strokes running parallel to the
heater wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

405

6-2. Maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Maintenance requirements

General maintenance should be performed on a daily basis. This can
be done by yourself or by a Toyota dealer.

Scheduled  maintenance  should  be  performed  at  specified  intervals
according to the maintenance schedule.

For details about maintenance items and schedules, refer to the “Sched-
uled Maintenance Guide” or “Owner’s Manual Supplement”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty
coverage.

The use of Toyota Repair Manuals is recommended.
For details about warranty coverage, refer to the separate “Owner’s War-
ranty Information Booklet” or “Owner’s Manual Supplement”.

■

Repair and replacement

It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.

To ensure safe and economical driving, day-to-day care and reg-
ular maintenance are essential. It is the owner’s responsibility to
perform regular checks. Toyota recommends the following main-
tenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

406

6-2. Maintenance

SEQUOIA_OM_USA_OM0C035U

■

Resetting the message indicating maintenance is required

After  the  required  maintenance  is  performed  according  to  the  maintenance
schedule, please reset the reminder light or message.
To  reset  the  reminder  light  or  message,  follow  the  procedure  described
below:

Press “<“ or “>” of the meter control switches, select

 on the multi infor-

mation display.

Press “



” or “



” of the meter control switches and select “Vehicle Settings”,

and then press

.

Press “



” or “



” of the meter control switches, select “Maintenance Reset”

and then press

.

Select the “Yes” and press

.

■

Allow inspection and repairs to be performed by a Toyota dealer

●

Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operations
of all systems on your vehicle.

●

Keep  a  copy  of  the  repair  order.  It  proves  that  the  maintenance  that  has
been  performed  is  under  warranty  coverage.  If  any  problem  should  arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.

WARNING

■

If your vehicle is not properly maintained

Improper  maintenance  could  result  in  serious  damage  to  the  vehicle  and
possible death or serious injury.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause  cancer  and  birth  defects  and  other  reproductive  harm.  Work  in  a
well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor-
nia  to  cause  cancer  and  birth  defects  or  other  reproductive  harm. Avoid
exposure and wash any affected area immediately.

●

Battery  posts,  terminals  and  related  accessories  contain  lead  and  lead
compounds which  are known  to cause brain damage. Wash your hands
after handling. (



P. 423)

1

2

3

4

407

6-2. Maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

General maintenance

Listed below are the general maintenance items that should be
performed  at  the  intervals  specified  in  the  “Owner’s  Warranty
Information  Booklet”  or  “Owner’s  Manual  Supplement/Sched-
uled Maintenance Guide”. It is recommended that any problem
you  notice  should  be  brought  to  the  attention  of  your  Toyota
dealer or qualified service shop for advice.

Engine compartment

Items

Check points

Battery

Check the connections.

(



P. 423)

Brake fluid

Is the brake fluid at the correct level?

(



P. 421)

Engine coolant

Is the engine coolant at the correct level?(



P. 419)

Engine oil

Is the engine oil at the correct level?

(



P. 416)

Exhaust system

There should not be any fumes or strange sounds.

Power steering fluid

Is the power steering fluid at the correct level?

 (



P. 422)

Radiator/condenser

The radiator and condenser should be free from
foreign objects.

(



P. 420)

Washer fluid

Is there sufficient washer fluid?

(



P. 425)

408

6-2. Maintenance

SEQUOIA_OM_USA_OM0C035U

Vehicle interior

Items

Check points

Accelerator pedal

• The  accelerator  pedal  should  move  smoothly

(without uneven pedal effort or catching).

Automatic  transmis-
sion  “Park”  mecha-
nism

• When parked on a slope and the shift lever is in P,

is the vehicle securely stopped?

Brake pedal

• Does the brake pedal move smoothly?
• Does the brake pedal have appropriate clearance

from the floor?

(



P. 528)

• Does the brake pedal have the correct amount of

free play?

(



P. 528)

Brakes

• The vehicle should not pull to one side when the

brakes are applied.

• The brakes should work effectively.
• The brake pedal should not feel spongy.
• The  brake  pedal  should  not  get  too  close  to  the

floor when the brakes are applied.

Head restraints

• Do  the  head  restraints  move  smoothly  and  lock

securely?

Indicators/buzzers

• Do the indicators and buzzers function properly?

Lights

• Do all the lights come on?

Parking brake

• Does the parking brake pedal move smoothly?
• When parked on a slope and the parking brake is

on, is the vehicle securely stopped?

Seat belts

• Do the seat belts operate smoothly?
• The seat belts should not be damaged.

Seats

• Do the seat controls operate properly?

Steering wheel

• Does the steering wheel rotate smoothly?
• Does the steering wheel have the correct amount

of free play?

• There should not be any strange sounds coming

from the steering wheel.

409

6-2. Maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Vehicle exterior

Items

Check points

Doors

• Do the doors operate smoothly?

Engine hood

• Does the engine hood lock system work properly?

Fluid leaks

• There  should  not  be  any  signs  of  fluid  leakage

after the vehicle has been parked.

Tires

• Is the tire inflation pressure correct?
• The tires should not be damaged or excessively

worn.

• Have  the  tires  been  rotated  according  to  the

maintenance schedule?

• The wheel nuts should not be loose.

Windshield  wipers/
rear window wiper

• The  wiper  blades  should  not  show  any  signs  of

cracking,  splitting,  wear,  contamination  or  defor-
mation.

• The wiper blades should clear the windshield/rear

window without streaking or skipping.

WARNING

■

If the engine is running

Turn the engine off and ensure that there is adequate ventilation before per-
forming maintenance checks.

410

6-2. Maintenance

SEQUOIA_OM_USA_OM0C035U

Emission inspection and maintenance (I/M)

programs

The OBD system determines that a problem exists somewhere in the
emission control system. Your vehicle may not pass the I/M test and
may need  to  be  repaired. Contact  your Toyota  dealer to  service  the
vehicle.

●

When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also,  depending  on  your  driving  habits,  the  readiness  codes  may
not be completely set.

●

When the fuel tank cap is loose
The  malfunction  indicator  lamp  comes  on  indicating  a  temporary
malfunction and your vehicle may not pass the I/M test.

The error code in the OBD system will not be cleared unless the vehi-
cle is driven 40 or more times.

Contact your Toyota dealer to prepare the vehicle for re-testing.

Some states have vehicle emission inspection programs which
include OBD (On Board Diagnostics) checks. The OBD system
monitors the operation of the emission control system.

If the malfunction indicator lamp comes on

Your vehicle may not pass the I/M test in the following situations:

When the malfunction indicator lamp still remains on after sev-
eral driving trips

If your vehicle does not pass the I/M test

411

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Do-it-yourself service precautions

If  you  perform  maintenance  by  yourself,  be  sure  to  follow  the
correct procedure as given in these sections.

Items

Parts and tools

Battery condition
(



P. 423)

• Warm water

• Baking soda

• Grease

• Conventional wrench (for terminal clamp bolts)

Brake fluid level
(



P. 421)

• FMVSS No.116 DOT 3 or SAE J1703 brake fluid

• Rag or paper towel

• Funnel (used only for adding brake fluid)

Engine coolant
level (



P. 419)

• “Toyota  Super  Long  Life  Coolant”  or  a  similar  high

quality  ethylene  glycol-based  non-silicate,  non-
amine, non-nitrite and non-borate coolant with long-
life hybrid organic acid technology
For the U.S.A.:
“Toyota  Super  Long  Life  Coolant”  is  pre-mixed  with
50% coolant and 50 % deionized water.
For Canada:
“Toyota  Super  Long  Life  Coolant”  is  pre-mixed  with
55 % coolant and 45 % deionized water.

• Funnel (used only for adding coolant)

Engine oil level
(



P. 416)

• “Toyota Genuine Motor Oil” or equivalent

• Rag or paper towel

• Funnel (used only for adding engine oil)

412

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Items

Parts and tools

Fuses (



P. 448)

• Fuse with same amperage rating as original

Light bulbs
(



P. 451)

• Bulb with same number and wattage rating as origi-

nal

• Phillips-head screwdriver

• Flathead screwdriver

• Wrench

Power steering
fluid level
(



P. 422)

• Automatic transmission fluid DEXRON

®

II or III

• Rag or paper towel

• Funnel (used only for adding power steering fluid)

Radiator and
condenser
(



P. 420)



Tire inflation

pressure

(



P. 438)

• Tire pressure gauge

• Compressed air source

Washer fluid
(



P. 425)

• Water or washer fluid containing antifreeze (for win-

ter use)

• Funnel (used only for adding water or washer fluid)

413

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

WARNING

The  engine  compartment  contains  many  mechanisms  and  fluids  that  may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury, observe the following precautions.

■

When working on the engine compartment

●

Keep  hands,  clothing  and  tools  away  from  the  moving  fan  and  engine
drive belt.

●

Be  careful  not  to  touch  the  engine,  radiator,  exhaust  manifold,  etc.  right
after driving as they may be hot. Oil and other fluids may also be hot.

●

Do not leave anything that may burn easily, such as paper and rags, in the
engine compartment.

●

Do not smoke, cause sparks or expose an open flame to fuel or the bat-
tery. Fuel and battery fumes are flammable.

●

Be extremely cautious when working on the battery. It contains poisonous
and corrosive sulfuric acid.

■

When working near the electric cooling fan or radiator grille

Be sure the engine switch is off. With the engine switch on, the electric cool-
ing fans may automatically start to run if the air conditioning is on and/or the
coolant temperature is high. (



P. 420)

■

Safety glasses

Wear  safety  glasses  to  prevent  flying  or  falling  material,  fluid  spray,  etc.
from getting in your eyes.

NOTICE

■

If you remove the air cleaner filter

Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air.

414

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Hood

Pull the hood lock release lever.

The hood will pop up slightly.

Pull  up  the  hood  catch  lever
and lift the hood.

Release the lock from the inside of the vehicle to open the hood.

1

2

WARNING

■

Pre-driving check

Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehicle is in motion
and cause an accident, which may result in death or serious injury.

415

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Engine compartment

Washer fluid tank (



P. 425)

Engine oil level dipstick

(



P. 416)

Engine coolant reservoir

(



P. 419)

Engine oil filler cap (



P. 417)

Brake fluid reservoir

(



P. 421)

Fuse box

(



P. 448)

Battery

(



P. 423)

Radiator

(



P. 420)

Cooling fans
Condenser

(



P. 420)

Power steering fluid reservoir

(



P. 422)

416

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

With the engine at operating temperature and turned off, check the oil
level on the dipstick.

■

Checking the engine oil

Park  the  vehicle  on  level  ground. After  warming  up  the  engine
and  turning  it  off,  wait  more  than  5  minutes  for  the  oil  to  drain
back into the bottom of the engine.
Holding a rag under the end,
pull the dipstick out.

Wipe the dipstick clean.
Reinsert the dipstick fully.
Holding a rag under the end,
pull  the  dipstick  out  and
check the oil level.

Low
Normal
Excessive

The  shape  of  the  dipstick  may
differ  depending  on  the  type  of
vehicle or engine.

Wipe the dipstick and reinsert it fully.

Engine oil

1

2

3

4

5

6

417

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Adding engine oil

If  the  oil  level  is  below  or  near
the low level mark, add engine
oil  of  the  same  type  as  that
already in the engine.

Make  sure  to  check  the  oil  type  and  prepare  the  items  needed
before adding oil.

Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.

■

Engine oil consumption

A certain amount of engine oil will be consumed while driving. In the following
situations,  oil  consumption  may  increase,  and  engine  oil  may  need  to  be
refilled in between oil maintenance intervals.

●

When the engine is new, for example directly after purchasing the vehicle or
after replacing the engine

●

If low quality oil or oil of an inappropriate viscosity is used

●

When driving at high engine speeds or with a heavy load, when towing, or
when driving while accelerating or decelerating frequently

●

When leaving the engine idling for a long time, or when driving frequently
through heavy traffic

Engine oil selection



P. 524

Oil quantity
(Low



 Full)

1.6 qt. (1.5 L, 1.3 Imp.qt.)

Items

Clean funnel

1

2

3

418

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

WARNING

■

Used engine oil

●

Used  engine  oil  contains  potentially  harmful  contaminants  which  may
cause  skin  disorders  such  as  inflammation  and  skin  cancer,  so  care
should be taken to avoid prolonged and repeated contact. To remove used
engine oil from your skin, wash thoroughly with soap and water.

●

Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground.
Call your Toyota dealer, service station or auto parts store for information
concerning recycling or disposal.

●

Do not leave used engine oil within the reach of children.

NOTICE

■

To prevent serious engine damage

Check the oil level on a regular basis.

■

When replacing the engine oil

●

Be careful not to spill engine oil on the vehicle components.

●

Avoid overfilling, or the engine could be damaged.

●

Check the oil level on the dipstick every time you refill the vehicle.

●

Be sure the engine oil filler cap is properly tightened.

419

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

The coolant level is satisfactory if it is between the “FULL” and “LOW”
lines on the reservoir when the engine is cold.

Reservoir cap
“FULL” line
“LOW” line

If  the  level  is  on  or  below  the
“LOW”  line,  add  coolant  up  to  the
“FULL” line.

■

Coolant selection

Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene
glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion-
ized water. (Minimum temperature: -31 °F [-35 °C])
Canada:
“Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deion-
ized water. (Minimum temperature: -44 °F [-42 °C])
For more details about engine coolant, contact your Toyota dealer.

■

If the coolant level drops within a short time of replenishing

Visually check the radiator, hoses, engine coolant reservoir caps, drain cock
and water pump.
If you cannot find a leak, have your Toyota dealer test the cap and check for
leaks in the cooling system.

Engine coolant

420

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Check the radiator and condenser and clear away any foreign objects.
If  either of  the  above parts  is  extremely  dirty  or you  are not  sure of
their condition, have your vehicle inspected by your Toyota dealer.

WARNING

■

When the engine is hot

Do not remove the engine coolant reservoir cap or the radiator cap.
(



P. 514)

The cooling system may be under pressure and may spray hot coolant if the
cap is removed, causing serious injuries, such as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor straight antifreeze. The correct mixture of
water and antifreeze must be used to provide proper lubrication, corrosion
protection and cooling. Be sure to read the antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to prevent it from damaging parts or paint.

Radiator and condenser

WARNING

■

When the engine is hot

Do not touch the radiator or condenser as they may be hot and cause seri-
ous injuries, such as burns.

421

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Checking fluid level

The brake fluid level should be
between  the  “MAX”  and  “MIN”
lines on the reservoir.

■

Adding fluid

Make sure to check the fluid type and prepare the necessary item.

■

Brake fluid can absorb moisture from the air

Excess moisture in the brake fluid can cause a dangerous loss of braking effi-
ciency. Use only newly opened brake fluid.

Brake fluid

Fluid type

FMVSS No.116 DOT 3 or SAE J1703 brake fluid

Items

Clean funnel

WARNING

■

When filling the reservoir

Take  care  as  brake  fluid  can  harm  your  hands  and  eyes  and  damage
painted surfaces.
If fluid gets on your hands or in your eyes, flush the affected area with clean
water immediately.
If you still experience discomfort, see a doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level to go down slightly as the brake pads
wear out or when the fluid level in the accumulator is high.
If the reservoir needs frequent refilling, there may be a serious problem.

■

If you spill fluid

Be sure to wash it off with water to prevent damage to parts or paint.

422

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Fluid level

The fluid level should be within the appropriate range.

Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)

Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min-

utes, or slightly longer in frigid temperatures. (Fluid tempera-
ture, 140 °F - 175 °F [60 °C - 80 °C]).

Cold: Engine has not been run for about 5 hours. (Room tempera-

ture, 50 °F - 85 °F [10 °C - 30 °C]).

■

Checking the fluid level

Make sure to check the fluid type and prepare the necessary items.

Clean all dirt off the reservoir.
Remove the cap by turning it counterclockwise.
Wipe the dipstick clean.
Reinstall the cap and remove it again.
Check the fluid level.

Power steering fluid

Fluid type

Automatic transmission fluid DEXRON

®

 II or III

Items

Rag or paper, clean funnel (only for adding fluid)

1

2

3

4

5

423

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Check the battery as follows.

■

Battery exterior

Make  sure  that  the  battery  terminals  are  not  corroded  and  that
there are no loose connections, cracks, or loose clamps.

Terminals
Hold-down clamp

■

Before recharging

When recharging, the battery produces hydrogen gas which is flammable and
explosive. Therefore, observe the following before recharging:

●

If recharging with the battery installed on the vehicle, be sure to disconnect
the ground cable.

●

Make sure the power switch on the charger is off when connecting and dis-
connecting the charger cables to the battery.

WARNING

■

When checking the reservoir

Take care as the reservoir may be hot.

NOTICE

■

When adding fluid

Avoid overfilling, or the power steering may be damaged.

■

After replacing the reservoir cap

Check the steering box case, vane pump and hose connections for leaks or
damage.

Battery

424

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

WARNING

■

Chemicals in the battery

Batteries  contain  poisonous  and  corrosive  sulfuric  acid  and  may  produce
hydrogen gas which is flammable and explosive. To reduce the risk of death
or serious injury, take the following precautions while working on or near the
battery:

●

Do not cause sparks by touching the battery terminals with tools.

●

Do not smoke or light a match near the battery.

●

Avoid contact with eyes, skin and clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when working near the battery.

●

Keep children away from the battery.

■

Where to safely charge the battery

Always charge the battery in an open area. Do not charge the battery in a
garage or closed room where there is insufficient ventilation.

■

How to recharge the battery

Only  perform  a  slow  charge  (5  A  or  less).  The  battery  may  explode  if
charged at a quicker rate.

■

Emergency measures regarding electrolyte

●

If electrolyte gets in your eyes
Flush your eyes with clean water for at least 15 minutes and get immedi-
ate medical attention. If possible, continue to apply water with a sponge or
cloth while traveling to the nearest medical facility.

●

If electrolyte gets on your skin
Wash the affected area thoroughly. If you feel pain or burning, get medical
attention immediately.

●

If electrolyte gets on your clothes
It can soak through clothing on to your skin. Immediately take off the cloth-
ing and follow the procedure above if necessary.

●

If you accidentally swallow electrolyte
Drink a large quantity of water or milk. Get emergency medical attention
immediately.

425

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Add  washer  fluid  in  the  following
situations:

●

A washer does not work.

●

The warning message appears
on the multi-information display.

NOTICE

■

When recharging the battery

Never  recharge  the  battery  while  the  engine  is  running. Also,  be  sure  all
accessories are turned off.

Washer fluid

WARNING

■

When adding washer fluid

Do not add washer fluid when the engine is hot or running as washer fluid
contains alcohol and may catch fire if spilled on the engine, etc.

NOTICE

■

Do not use any fluid other than washer fluid

Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’s painted surfaces, as well as
damaging the pump leading to problems of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bot-
tle.

426

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Tires

Check if the treadwear indicators are showing on the tires. Also check
the tires for uneven wear, such as excessive wear on one side of the
tread.
Check the spare tire condition and pressure if not rotated.

New tread
Worn tread
Treadwear indicator

The location of treadwear indicators is shown by a “TWI” or “



” mark,

etc., molded into the sidewall of each tire.

Replace the tires if the treadwear indicators are showing on a tire.

Replace or rotate tires in accordance with maintenance sched-
ules and treadwear.

Checking tires

427

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Rotate  the  tires  in  the  order
shown.

To equalize tire wear and extend
tire life, Toyota recommends that
tire  rotation  is  carried  out  at  the
same interval as tire inspection.
Do  not  fail  to  initialize  the  tire
pressure  warning  system  after
tire rotation.

Your vehicle is equipped with a tire pressure warning system that uses
tire pressure warning valves and transmitters to detect low tire infla-
tion pressure before serious problems arise.

●

The tire pressure detected by the tire pressure warning system can
be displayed on the multi-information display.

●

If the tire pressure drops below
a  predetermined  level,  the
driver  is  warned  by  a  screen
display and a warning light.

The

illustration

used

is

intended  as  an  example,  and

may differ from the image that

is  actually  displayed  on  the

multi-information display.

◆

Installing tire pressure warning valves and transmitters

When  replacing  tires  or  wheels,  tire  pressure  warning  valves  and
transmitters must also be installed.
When  new  tire  pressure  warning  valves  and  transmitters  are
installed,  new  ID  codes  must  be  registered  in  the  tire  pressure
warning  computer  and  the  tire  pressure  warning  system  must  be
initialized.

Tire rotation

Front

Tire pressure warning system

428

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

◆

Initializing the tire pressure warning system

■

The tire pressure warning system must be initialized in the fol-
lowing circumstances:

●

When rotating the tires.

●

When the tire inflation pressure is changed such as when chang-
ing tire size. (When there are multiple specified pressures)

●

After registering the ID codes. (



P. 429)

When the tire pressure warning system is initialized, the current tire
inflation pressure is set as the benchmark pressure.

■

How to initialize the tire pressure warning system

Park the vehicle in safe place and turn the engine switch off.

Initialization cannot be performed while the vehicle is moving.

Adjust the tire inflation pressure to the specified cold tire inflation
pressure level. (



P. 529)

Make sure to adjust the tire pressure to the specified cold tire infla-

tion  pressure  level.  The  tire  pressure  warning  system  will  operate

based on this pressure level.

Turn the engine switch to ON.
Push  and  hold  the  tire  pres-
sure  warning  reset  switch
until  the  tire  pressure  warn-
ing light blinks 3 times.

A message is displayed on the

multi-information display. Also,

“-  -”  is  displayed  for  inflation

pressure  of  each  tire  on  the

multi-information  display  while

the  tire  pressure  warning  sys-

tem determines the position.

1

2

3

4

429

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Drive  straight  (with  occasional  left  and  right  turns)  at  approxi-
mately 25 mph (40 km/h) or more for approximately 10 to 30 min-
utes.

Initialization is complete when the position of each tire is determined

and the inflation pressure of each tire is displayed on the multi-infor-

mation display.
Initialization may take longer than approximately 30 minutes in cer-

tain situations, such as when the vehicle is stopped for a long time at

traffic lights, etc. (



P. 433)

◆

Registering ID codes

Every tire pressure warning valve and transmitter has a unique ID
code. When replacing a tire pressure warning valve and transmitter,
it is necessary to register the ID codes.
To register the ID codes, perform the following procedure:

Press the tire pressure warn-
ing reset switch 3 times until
the  tire  pressure  warning
light blinks slowly 3 times.

Then  a  message  will  be  dis-

played  on  multi-information

display.

When registration is being per-

formed, the tire pressure warn-

ing

light

will

blink

for

approximately  1  minute  then

illuminate and “- -” will be dis-

played  for  the  inflation  pres-

sure  of  each tire  on  the  multi-

information display.

5

1

430

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Drive  straight  (with  occasional  left  and  right  turns)  at  approxi-
mately 25 mph (40 km/h) or more for approximately 10 to 30 min-
utes.
Registration  is  complete  when  the  tire  pressure  warning  light
turns off and the inflation pressure of each tire is displayed on the
multi-information display.
Registration  may  take  longer  than  approximately  30  minutes  in
certain situations, such as when the vehicle is stopped for a long
time at traffic lights, etc. (



P. 433)

After  registering  the  ID  codes,  make  sure  to  initialize  the  tire
pressure warning system. (



P. 428)

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on a tire.

●

You  have  tire  damage  such  as  cuts,  splits,  cracks  deep  enough  to
expose the fabric, and bulges indicating internal damage

●

A tire goes flat repeatedly or cannot be properly repaired due to the size
or location of a cut or other damage

If you are not sure, consult with your Toyota dealer.

■

When replacing the tires and wheels

If the ID code of the tire pressure warning valve and transmitter is not reg-
istered, the tire pressure warning system will not work properly. After driv-
ing  for  about  20  minutes,  the  tire  pressure  warning  light  blinks  for  1
minute and stays on to indicate a system malfunction.

■

Tire life

Any tire over 6 years old must be checked by a qualified technician even
if it has seldom or never been used, or damage is not obvious.

■

Routine tire inflation pressure checks

The  tire  pressure  warning  system  does  not  replace  routine  tire inflation
pressure  checks.  Make  sure  to  check  tire  inflation  pressure  as  part  of
your routine of daily vehicle checks.

2

431

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Maximum load of tire

Check that the number given by dividing the maximum load by 1.10 of the
replacement  tire  is  greater  than  1/2  of  the  Gross Axle  Weight  Ratings
(GAWR) of either the front axle or the rear axle, whichever is greater.

■

Tire types

●

Summer tires
Summer tires are high-speed performance tires best suited to highway
driving under dry conditions. Since summer tires do not have the same
traction  performance  as  snow  tires,  summer  tires  are  inadequate  for
driving  on  snow-covered  or  icy  roads.  For  driving  on  snow-covered
roads or icy roads, the use of snow tires is recommended. When install-
ing snow tires, be sure to replace all four tires.

●

All season tires
All season tires are designed to provide better traction in snow and to
be  adequate  for  driving  in  most  winter  conditions  as  well  as  for  use
year-round. All  season  tires,  however,  do  not  have  adequate  traction
performance compared with snow tires in heavy or loose snow. Also, all
season tires fall short in acceleration and handling performance com-
pared with summer tires in highway driving.

●

Snow tires
For driving on snow-covered roads or icy roads, we recommend using
snow tires. If you need snow tires, select tires of the same size, con-
struction and load capacity as the originally installed tires. Since your
vehicle  has  radial  tires  as  original  equipment,  make  sure  your  snow
tires also have radial construction. Do not install studded tires without
first  checking  local  regulations  for  possible  restrictions.  Snow  tires
should be installed on all wheels. (



P. 334)

For  the  GAWR,  see  the  Certification
Label. For the maximum load of the tire,
see the load limit at maximum cold tire
inflation  pressure  mentioned  on  the
sidewall of the tire. (



P. 534)

432

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Initializing the tire pressure warning system

Initialize the system with the tire inflation pressure adjusted to the speci-
fied level.

■

If the tread on snow tires wears down below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is lost.

■

Situations in which the tire pressure warning system may not oper-

ate properly

●

In the following cases, the tire pressure warning system may not operate

properly.
• If non-genuine Toyota wheels are used.

• A tire has been replaced with a tire that is not an OE (Original Equip-

ment) tire.

• A tire has been replaced with a tire that is not of the specified size.

• Tire chains, etc., are equipped.

• An auxiliary-supported run-flat tire is equipped.

• If a window tint that affects the radio wave signals is installed.

• If there is a lot of snow or ice on the vehicle, particularly around the

wheels or wheel housings.

• If  the  tire  inflation  pressure  is  extremely  higher  than  the  specified

level.

• If  wheel  without  the  tire  pressure  warning  valve  and  transmitter  is

used.

• If the ID code on the tire pressure warning valves and transmitters is

not registered in the tire pressure warning computer.

●

Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio station, large

display, airport or other facility that generates strong radio waves or

electrical noise

• When  carrying  a  portable  radio,  cellular  phone,  cordless  phone  or

other wireless communication device

If  tire  position  information  is  not  correctly  displayed  due  to  the  radio

wave conditions, the display may be corrected by driving and changing

the radio wave conditions.

●

When the vehicle is parked, the time taken for the warning to start or go

off could be extended.

●

When tire inflation pressure declines rapidly for example when a tire has

burst, the warning may not function.

433

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

The initialization operation

●

Make sure to carry out initialization after adjusting the tire inflation pres-

sure.

Also, make sure the tires are cold before carrying out initialization or tire

inflation pressure adjustment.

●

If you have accidentally turned the engine switch to OFF during initial-

ization, it is not necessary to press the reset switch again as initialization

will restart automatically when the engine switch has been turned to ON

for the next time.

●

If you accidentally press the reset switch when initialization is not neces-

sary,  adjust  the  tire  inflation  pressure  to  the  specified  level  when  the

tires are cold, and conduct initialization again.

●

While the position of each tire is being determined and the inflation pres-

sures  are  not  being  displayed  on  the  multi-information  display,  if  the

inflation pressure of a tire drops, the tire pressure warning light will come

on.

■

Warning performance of the tire pressure warning system

The  warning  of  the  tire  pressure  warning  system  will  change  in  accor-

dance with the conditions under which it was initialized. For this reason,

the system may give a warning even if the tire pressure does not reach a

low enough level, or if the pressure is higher than the pressure that was

adjusted to when the system was initialized.

■

When initialization of the tire pressure warning system has failed

Initialization  may  take  longer  to  complete  if  the  vehicle  is  driven  on  an

unpaved  road.  When  performing  initialization,  drive  on  a  paved  road  if

possible. Depending on the driving environment and condition of the tires,

initialization will be completed in approximately 10 to 30 minutes. If initial-

ization is not complete after driving approximately 10 to 30 minutes, con-

tinue driving for a while.
If  the  inflation  pressure  of  each  tire  is  not  displayed  after  driving  for

approximately 1 hour, perform the following procedure.

●

Park  the  vehicle  in  a  safe  place  for  approximately  20  minutes.  Then

drive  straight  (with  occasional  left  and  right  turns)  at  approximately

25 mph (40 km/h) or more for approximately 10 to 30 minutes.

However, in the following situations, the tire inflation pressure will not be

recorded and the system will not operate properly. Perform initialization

again.

●

When operating the tire pressure warning reset switch, the tire pressure

warning light does not blink 3 times.

●

After  performing  initialization,  the  tire  pressure  warning  light  blinks  for

1 minute then stays on while driving about 20 minutes.

If the inflation pressure of each tire is still not displayed, have the vehicle

inspected by your Toyota dealer.

434

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Tire pressure warning system certification



For vehicles sold in the U.S.A.

435

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U



For vehicles sold in Canada

Model: PMV-E000

436

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

WARNING

■

When inspecting or replacing tires

Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train as well as
dangerous  handling  characteristics,  which  may  lead  to  an  accident
resulting in death or serious injury.

●

Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.

●

Do not use tire sizes other than those recommended by Toyota.

●

Do not mix differently constructed tires (radial, bias-belted or bias-ply
tires).

●

Do not mix summer, all season and snow tires.

●

Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.

■

When initializing the tire pressure warning system

Do not initialize tire pressure warning system without first adjusting the

tire inflation pressure to the specified level. Otherwise, the tire pressure

warning light may not come on even if the tire inflation pressure is low,

or it may come on when the tire inflation pressure is actually normal.

437

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

NOTICE

■

Repairing or replacing tires, wheels, tire pressure warning valves,
transmitters and tire valve caps

●

When removing or fitting the wheels, tires or the tire pressure warning
valves  and  transmitters,  contact  your Toyota  dealer  as  the  tire  pres-
sure warning valves and transmitters may be damaged if not handled
correctly.

●

Make sure to install the tire valve caps. If the tire valve caps are not
installed,  water  could  enter  the  tire  pressure  warning  valves  and  the
tire pressure warning valves could be bound.

●

When replacing tire valve caps, do not use tire valve caps other than
those specified. The cap may become stuck.

■

To avoid damage to the tire pressure warning valves and transmit-
ters

When  a  tire  is  repaired  with  liquid  sealants,  the  tire  pressure  warning
valve  and  transmitter  may  not  operate  properly.  If  a  liquid  sealant  is
used, contact your Toyota dealer or other qualified service shop as soon
as possible. Make sure to replace the tire pressure warning valve and
transmitter when replacing the tire. (



P. 427)

■

Driving on rough roads

Take particular care when driving on roads with loose surfaces or pot-
holes.
These conditions may cause losses in tire inflation pressure, reducing
the  cushioning  ability  of  the  tires.  In  addition,  driving  on  rough  roads
may  cause  damage  to  the  tires  themselves,  as  well  as  the  vehicle’s
wheels and body.

■

If tire inflation pressure of each tire becomes low while driving

Do not continue driving, or your tires and/or wheels may be ruined.

438

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Tire inflation pressure

The  recommended  cold  tire  infla-
tion pressure and tire size are dis-
played  on  the  tire  and  loading
information label. (



P. 529)

Tire inflation pressure

439

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Tire valve
Tire pressure gauge

Remove the tire valve cap.
Press the tip of the tire pressure gauge onto the tire valve.
Read the pressure using the gauge gradations.
If the tire inflation pressure is not at the recommended level, adjust
the pressure.
If you add too much air, press the center of the valve to deflate.
After  completing  the  tire  inflation  pressure  measurement  and
adjustment, apply soapy water to the valve and check for leakage.
Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure every two weeks, or at least once
a month.
Do not forget to check the spare.

■

Effects of incorrect tire inflation pressure

Driving with incorrect tire inflation pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating, have it checked by your Toyota dealer.

Inspection and adjustment procedure

1

2

3

4

5

6

440

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Instructions for checking tire inflation pressure

When checking tire inflation pressure, observe the following:

●

Check only when the tires are cold.
If  your  vehicle  has  been  parked  for  at  least  3  hours  or  has  not  been
driven for more than 1 mile or 1.5 km, you will get an accurate cold tire
inflation pressure reading.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly inflated based only on its appear-

ance.

●

It  is  normal  for  the  tire  inflation  pressure  to  be  higher  after  driving  as

heat is generated in the tire. Do not reduce tire inflation pressure after

driving.

●

Passengers and luggage weight should be placed so that the vehicle is
balanced.

WARNING

■

Proper inflation is critical to save tire performance

Keep your tires properly inflated.
If the tires are not properly inflated, the following conditions may occur
which could lead to an accident resulting in death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from overheated tires

●

Air leaking from between tire and wheel

●

Wheel deformation and/or tire damage

●

Greater possibility of tire damage while driving (due to road hazards,

expansion joints, sharp edges in the road, etc.)

NOTICE

■

When inspecting and adjusting tire inflation pressure

Be sure to put the tire valve caps back on.
If a valve cap is not installed, dirt or moisture may get into the valve and
cause an air leak, resulting in decreased tire inflation pressure.

441

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Wheels

When replacing wheels, care should be taken to ensure that they are
equivalent to those removed in load capacity, diameter, rim width and
inset

*

.

Replacement wheels are available at your Toyota dealer.

*

: Conventionally referred to as “offset”.

Toyota does not recommend using the following:

●

Wheels of different sizes or types

●

Used wheels

●

Bent wheels that have been straightened

●

Use  only Toyota  wheel  nuts  and  wrenches  designed  for  use  with
your aluminum wheels.

●

When  rotating,  repairing  or  changing  your  tires,  check  that  the
wheel nuts are still tight after driving 1000 miles (1600 km).

●

Be  careful  not  to  damage  the  aluminum  wheels  when  using  tire
chains.

●

Use only Toyota genuine balance weights or equivalent and a plas-
tic or rubber hammer when balancing your wheels.

If  a  wheel  is  bent,  cracked  or  heavily  corroded,  it  should  be
replaced.  Otherwise,  the  tire  may  separate  from  the  wheel  or
cause a loss of handling control.

Wheel selection

Aluminum wheel precautions

442

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

When replacing wheels

The  wheels  of  your  vehicle  are  equipped  with  tire  pressure  warning
valves  and  transmitters  that  allow  the  tire  pressure  warning  system  to
provide advance warning in the event of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and trans-
mitters must be installed. (



P. 427)

WARNING

■

When replacing wheels

●

Do not use wheels that are a different size from those recommended in
the Owner’s Manual, as this may result in a loss of handling control.

●

Never  use  an  inner  tube  in  a  leaking  wheel  which  is  designed  for  a
tubeless tire. Doing so may result in an accident, causing death or seri-
ous injury.

■

When installing the wheel nuts

●

Be sure to install the wheel nuts with the tapered ends facing inward.
(



P. 499) Installing the nuts with the tapered ends facing outward can

cause the wheel to break and eventually cause the wheel to come off
while driving, which could lead to an accident resulting in death or seri-
ous injury.

●

Never use oil or grease on the wheel bolts or wheel nuts.
Oil and grease may cause the wheel nuts to be excessively tightened,
leading to bolt or disc wheel damage. In addition, the oil or grease can
cause the wheel nuts to loosen and the wheel may fall off, causing an
accident  and  resulting  in  death  or  serious  injury.  Remove  any  oil  or
grease from the wheel bolts or wheel nuts.

443

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

NOTICE

■

Replacing tire pressure warning valves and transmitters

●

Because tire repair or replacement may affect the tire pressure warn-
ing valves and transmitters, make sure to have tires serviced by your
Toyota dealer or other qualified service shop. In addition, make sure to
purchase  your  tire  pressure  warning  valves  and  transmitters  at  your
Toyota dealer.

●

Ensure that only genuine Toyota wheels are used on your vehicle.
Tire pressure warning valves and transmitters may not work properly
with non-genuine wheels.

444

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Air conditioning filter

Turn the engine switch to OFF.
Open the glove box.

Remove the internal tray.

Remove  the  inside  cover  by
sliding  up  while  pulling  toward
you.

The air conditioning filter must be changed regularly to maintain
air conditioning efficiency.

Removal method

1

2

3

4

445

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Remove the filter cover.

Remove the air conditioning fil-
ter  and  replace  it  with  a  new
one.

The “



UP” marks shown on the fil-

ter should be pointing up.

■

Checking interval

Inspect and replace the air conditioning  filter  according to  the  maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement
may be required. (For scheduled maintenance information, please refer to the
“Schedule maintenance guide” or “Owner’s Manual Supplement”.)

■

If air flow from the vents decreases dramatically

The filter may be clogged. Check the filter and replace if necessary.

5

6

NOTICE

■

When using the air conditioning system

Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the
system.

446

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Electronic key battery

●

Flathead screwdriver

●

Small flathead screwdriver

●

Lithium battery CR2032

Take out the mechanical key.

Remove the module.

To  prevent  damage  to  the  key,
cover the tip of the screwdriver with
a rag.

Remove the depleted battery.

Insert  a  new  battery  with  the  “+”
terminal facing up.

Replace the battery with a new one if it is depleted.

You will need the following items:

Replacing the battery

1

2

3

447

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Toyota dealer, local electrical appliance
shops or camera stores.

●

Replace only with the same or equivalent type recommended by the manu-
facturer.

●

Dispose of used batteries according to local laws.

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart key system and wireless remote control will not function properly.

●

The operational range will be reduced.

WARNING

■

Removed battery and other parts

These parts are small and if swallowed by a child, they can cause choking.
Keep away from children. Failure to do so could result in death or serious
injury.

NOTICE

■

For normal operation after replacing the battery

Observe the following precautions to prevent accidents:

●

Always work with dry hands.
Moisture may cause the battery to rust.

●

Do not touch or move any other component inside the remote control.

●

Do not bend either of the battery terminals.

448

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

Checking and replacing fuses

Turn the engine switch to OFF.
Open the fuse box cover.



Engine compartment

Push  the  tab  in  and  lift  the  lid
off.



Under the instrument panel

Remove the lid.

Remove  the  fuse  with  the  pull-
out tool.

Only  type A  fuse  can  be  removed
using the pullout tool.

If any of the electrical components do not operate, a fuse may
have blown. If this happens, check and replace the fuses as nec-
essary.

1

2

3

449

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Check if the fuse is blown.

Normal fuse
Blown fuse

Type A, B:
Replace the blown fuse with a new fuse of an appropriate amperage rat-
ing. The amperage rating can be found on the fuse box lid.
Type C:
Contact your Toyota dealer.

4



Type A



Type B



Type C

450

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

After a fuse is replaced

●

If the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. (



P. 451)

●

If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.

■

If there is an overload in a circuit

The fuses are designed to blow, protecting the wiring harness from damage.

■

When replacing light bulbs

Toyota recommends that you use genuine Toyota products designed for this
vehicle. Because certain bulbs are connected to circuits designed to prevent
overload,  non-genuine  parts  or  parts  not  designed  for  this  vehicle  may  be
unusable.

WARNING

■

To prevent system breakdowns and vehicle fire

Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.

●

Never use a fuse of a higher amperage rating than that indicated, or use
any other object in place of a fuse.

●

Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.

●

Do not modify the fuses or fuse boxes.

NOTICE

■

Before replacing fuses

Have  the  cause  of  electrical  overload  determined  and  repaired  by  your
Toyota dealer as soon as possible.

451

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Light bulbs

Check the wattage of the light bulb to be replaced. (



P. 530)

■

Rear

You may replace the following bulbs by yourself. The difficulty
level of replacement varies depending on the bulb. If necessary
bulb  replacement  seems  difficult  to  perform,  contact  your
Toyota dealer.
For more information about replacing other light bulbs, contact
your Toyota dealer.

Preparing for light bulb replacement

Bulb locations

Stop/tail  and  rear  side  marker
lights
Rear turn signal lights
Back-up lights

Tail lights
License plate light

452

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Stop/tail, rear side marker lights and rear turn signal lights

Open the back door and remove the cover.

To  protect  the  cover,  place  a  rag  between  the  flathead  screwdriver  or
equivalent and cover as shown in the illustrations.



Left side (vehicles without speaker in the luggage)

Replacing light bulbs

1



Right side



Left

side

(vehicles

with

speaker in the luggage)

453

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Turn the bulb bases counter-
clockwise.

Stop/tail  and  rear  side
marker light
Rear turn signal light

Remove the light bulb.

Stop/tail  and  rear  side
marker light
Rear turn signal light

When installing, reverse the steps listed.

2

3

4

454

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

Tail lights, back-up lights

Vehicles  with  power  back
door  only:  Remove  the  cov-
ers.

To protect the cover, place a rag
between  the  flathead  screw-
driver  or  equivalent  and  cover
as shown in the illustrations.

Remove the nuts.

Remove  the  rear  combina-
tion  light  assembly  in  the
order  shown  in  the  illustra-
tion.

1

2

3

455

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

Turn  the  bulb  base  counter-
clockwise.

Tail light
Back-up light

Remove the light bulb.

Tail light
Back-up light

When installing, reverse the steps listed.

4

5

6

456

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

■

License plate lights

Remove  the  screws  and
lens.

Remove the light bulb.

When installing, reverse the steps listed.

1

2

3

457

6-3. Do-it-yourself maintenance

6

Mainten

ance an

d ca

re

SEQUOIA_OM_USA_OM0C035U

■

Replacing the following bulbs

If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.

●

Headlight low beams

●

Headlight high beams

●

Front side marker lights

●

Daytime running lights

●

Parking lights

●

Front turn signal lights

●

Front fog lights

●

Side turn signal lights (if equipped)

●

High mounted stoplight

●

Outer foot lights (if equipped)

■

LED light bulbs

The following lights consist of a number of LEDs. If any LEDs burn out, take
your vehicle to your Toyota dealer to have the light replaced.

●

Headlight low beams

●

Headlight high beams

●

Front side marker lights

●

Daytime running lights

●

Parking lights

●

Front turn signal lights

●

Front fog lights

●

Side turn signal lights (if equipped)

●

High mounted stoplight

●

Outer foot lights (if equipped)

■

Condensation build-up on the inside of the lens

Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:

●

Large drops of water have built up on the inside of the lens.

●

Water has built up inside the lens.

458

6-3. Do-it-yourself maintenance

SEQUOIA_OM_USA_OM0C035U

WARNING

■

Replacing light bulbs

●

Turn  off  the  lights.  Do  not  attempt  to  replace  the  bulb  immediately  after
turning off the lights.
The bulbs become very hot and may cause burns.

●

Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.

●

Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.

●

Do  not  attempt  to  repair  or  disassemble  light  bulbs,  connectors,  electric
circuits or component parts.
Doing so may result in death or serious injury due to electric shock.

■

To prevent damage or fire

●

Make sure bulbs are fully seated and locked.

●

Check the wattage of the bulb before installing to prevent heat damage.

459

When trouble arises

7

SEQUOIA_OM_USA_OM0C035U

7-1.  Essential information

Emergency flashers .......... 460
If your vehicle has to be

stopped in an
emergency ...................... 461

If the vehicle is trapped

in rising water.................. 463

7-2.  Steps to take in

an emergency

If your vehicle needs to

be towed ......................... 464

If you think something is

wrong .............................. 468

Fuel pump shut off

system ............................ 469

If a warning light turns on

or a warning buzzer
sounds ............................ 470

If a warning message is

displayed......................... 479

If you have a flat tire.......... 491
If the engine will not

start................................. 505

If the electronic key does

not operate properly........ 507

If the vehicle battery is

discharged ...................... 509

If your vehicle overheats ... 513
If the vehicle becomes

stuck ............................... 516

460

7-1. Essential information

SEQUOIA_OM_USA_OM0C035U

Emergency flashers

Press the switch.

All the turn signals will flash.
To  turn  them  off,  press  the  switch
once again.

■

Emergency flashers

●

If the emergency flashers are used for a long time while the engine is not
operating, the battery may discharge.

●

If  any  of  the  SRS  airbags  deploy  (inflate)  or  in  the  event  of  a  strong  rear
impact, the emergency flashers will turn on automatically
The emergency flashers will turn off automatically after operating for approx-
imately 20 minutes. To manually turn the emergency flashers off, press the
switch  twice.  (The  emergency  flashers  may  not  turn  on  automatically
depending on the force of the impact and conditions of the collision.)

The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in the road due to a breakdown, etc.

461

7-1. Essential information

SEQUOIA_OM_USA_OM0C035U

7

Wh
en tro

uble

 a

ris

es

If your vehicle has to be stopped in an

emergency

Steadily step on the brake pedal with both feet and firmly depress it.

Do  not  pump  the  brake  pedal  repeatedly  as  this  will  increase  the  effort
required to slow the vehicle.

Shift the shift lever to N.



If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine.



If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle
speed as much as possible.
To  stop  the  engine,  press  and
hold  the  engine  switch  for  2
consecutive  seconds  or  more,
or  press  it  briefly  3  times  or
more in succession.

Stop the vehicle in a safe place by the road.

Only in an emergency, such as if it becomes impossible to stop
the vehicle in the normal way, stop the vehicle using the follow-
ing procedure:

1

2

3

4

3

Press and hold for 2 seconds or more
or press briefly 3 times or more

4

5

462

7-1. Essential information

SEQUOIA_OM_USA_OM0C035U

WARNING

■

If the engine has to be turned off while driving

Power  assist  for  the  brakes  and  steering  wheel  will  be  lost,  making  the
brake  pedal  harder  to  depress  and  the  steering  wheel  heavier  to  turn.
Decelerate as much as possible before turning off the engine.

463

7-1. Essential information

SEQUOIA_OM_USA_OM0C035U

7

Wh
en tro

uble

 a

ris

es

If the vehicle is trapped in rising water

●

Remove the seat belt first.

●

If the door can be opened, open the door and exit the vehicle.

●

If the door can not be opened, open the window using the power
window switch and exit the vehicle through the window.

●

If the window can not be opened using the power window switch,
remain calm, wait until the water level inside the vehicle rises to the
point that the water pressure inside of the vehicle equals the water
pressure outside of the vehicle, and then open the door and exit the
vehicle.

In the event the vehicle is submerged in water, remain calm and
perform the following.

WARNING

■

Using an emergency hammer

*

 for emergency escape

The front side windows and rear side windows, as well as the rear window
can be shattered with an emergency hammer

*

 used for emergency escape.

However, an emergency hammer can not shatter the windshield as it is lam-
inated glass.

*

: Contact your Toyota dealer or aftermarket accessory manufacturer for

    further information about an emergency hammer.

■

Escaping the vehicle from the window

There are cases where escaping the vehicle from the window is not possi-
ble due to seating position, passenger body type, etc.
When  using  an  emergency  hammer,  consider  your  seat  location  and  the
size  of  the  window  opening  to  ensure  that  the  opening  is  accessible  and
large enough to escape.
