Toyota Sienna (2019 year). Instruction

193

SIENNA_OM_OM08025U_(U)

Driving

4-1. Before driving

Driving the vehicle............. 194
Cargo and luggage ........... 203
Vehicle load limits ............. 209
Trailer towing

(with towing package) ..... 210

Dinghy towing ................... 224

4-2. Driving procedures

Engine (ignition) switch

(vehicles without a
smart key system)........... 225

Engine (ignition) switch

(vehicles with a smart
key system)..................... 228

Automatic transaxle........... 233
Turn signal lever................ 239
Parking brake .................... 240

4-3. Operating the lights

and wipers

Headlight switch................ 241
Automatic High Beam ....... 246
Fog light switch ................. 251
Windshield wipers and

washer ............................ 252

Rear window wiper and

washer ............................ 256

4-4. Refueling

Opening the fuel tank

cap .................................. 258

4-5. Using the driving support

systems

Toyota Safety Sense P ..... 261
PCS (Pre-Collision

system) ........................... 267

LDA (Lane Departure Alert

with steering control)....... 279

Dynamic radar cruise

control ............................. 289

BSM (Blind Spot

Monitor)........................... 303
• The Blind Spot Monitor

function ......................... 307

• The Rear Cross Traffic

Alert function................. 310

Intuitive parking assist....... 315
Driving assist systems ...... 323

4-6. Driving tips

Winter driving tips ............. 328

194

SIENNA_OM_OM08025U_(U)

4-1. Before driving

Driving the vehicle

P. 225, 2 28

With the brake pedal depressed, shift the shift lever to D. (

P. 233)

Release the parking brake. (

P. 240)

Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.

With the shift lever in D, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. (

P. 233)

With the shift lever in D, depress the brake pedal.
Set the parking brake. (

P. 240), and shift the shift lever to P.

(

P. 233)

Vehicles without a smart key system:
Turn the engine switch to the “LOCK” position and stop the engine.
Vehicles with a smart key system:
Press the engine switch to stop the engine.
Lock the door, making sure that you have the key on your person.

If parking on a hill, block the wheels as needed.

Make sure that the parking brake is set and shift the shift lever to D.
Gently depress the accelerator pedal.
Release the parking brake.

The following procedures should be observed to ensure safe
driving:

Starting the engine

Driving

Stopping

Parking the vehicle

Starting off on a steep uphill

SIENNA_OM_OM08025U_(U)

195

4-1. Before driving

Drivin

When starting off on a uphill
The hill-start assist control is available. (

P. 323)

Driving in the rain

Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.

Drive carefully when it starts to rain, because the road surface will be espe-
cially slippery.

Refrain from high speeds when driving on an expressway in the rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.

Engine speed while driving
In the following conditions, the engine speed may become high while driving.
This is due to automatic up-shifting control or down-shifting implementation to
meet driving conditions. It does not indicate sudden acceleration.

The vehicle is judged to be driving uphill or downhill

When the accelerator pedal is released

Restraining the engine output (Brake Override System)

When the accelerator and brake pedals are depressed at the same time, the
engine output may be restrained.

A warning message is displayed on the multi-information display while the
system is operating. (

P. 474, 481)

Breaking in your new Toyota
To extend the life of the vehicle, observing the following precautions is recom-
mended:

For the first 200 miles (300 km):
Avoid sudden stops.

For the first 500 miles (800 km):
Do not tow a trailer.

For the first 1000 miles (1600 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for extended periods.

Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system. This type of brake
system needs bedding-down of the brake shoes periodically or whenever the
parking brake shoes and/or drum are replaced. Have your Toyota dealer per-
form the bedding down operation.

Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (

P. 518)

196

SIENNA_OM_OM08025U_(U)

4-1. Before driving

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

When starting the vehicle
Always keep your foot on the brake pedal while stopped with the engine
running. This prevents the vehicle from creeping.

When driving the vehicle

Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake

pedal will result in sudden acceleration that may lead to an accident.

• When backing up, you may twist your body around, leading to a diffi-

culty in operating the pedals. Make sure to operate the pedals properly.

• Make sure to keep a correct driving posture even when moving the

vehicle only slightly. This allows you to depress the brake and accelera-
tor pedals properly.

• Depress the brake pedal using your right foot. Depressing the brake

pedal using your left foot may delay response in an emergency, result-
ing in an accident.

Do not drive the vehicle over or stop the vehicle near flammable materials.
The exhaust system and exhaust gases can be extremely hot. These hot
parts may cause a fire if there is any flammable material nearby.

SIENNA_OM_OM08025U_(U)

197

4-1. Before driving

Drivin

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

When driving the vehicle

During normal driving, do not turn off the engine. Turning the engine off
while driving will not cause loss of steering or braking control, but the
power assist to these systems will be lost. This will make it more difficult to
steer and brake, so you should pull over and stop the vehicle as soon as it
is safe to do so.
However, in the event of an emergency, such as if it becomes impossible
to stop the vehicle in the normal way:

P. 463

Use engine braking (downshift) to maintain a safe speed when driving
down a steep hill.
Using the brakes continuously may cause the brakes to overheat and lose
effectiveness. (

P. 233)

Do not adjust the position of the steering wheel, the seat, or the inside or
outside rear view mirrors while driving.
Doing so may result in a loss of vehicle control.

Always check that all passengers’ arms, heads or other parts of their body
are not outside the vehicle.

AWD models: Do not drive the vehicle off-road.
This is not an AWD vehicle designed for off-road driving. Proceed with all
due caution if it becomes unavoidable to drive off-road.

AWD models: Do not drive across a river or through other bodies of water.
This may cause electric/electronic components to short circuit, damage
the engine or cause other serious damage to the vehicle.

Do not drive in excess of the speed limit. Even if the legal speed limit per-
mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high-
speed capability tires. Driving over 85 mph (140 km/h) may result in tire
failure, loss of control and possible injury. Be sure to consult a tire dealer
to determine whether the tires on your vehicle are high-speed capability
tires or not before driving at such speeds.

198

SIENNA_OM_OM08025U_(U)

4-1. Before driving

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

When driving on slippery road surfaces

Sudden braking, acceleration and steering may cause tire slippage and
reduce your ability to control the vehicle.

Sudden acceleration, engine braking due to shifting, or changes in engine
speed could cause the vehicle to skid.

After driving through a puddle, lightly depress the brake pedal to make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are wet
and not functioning properly, steering control may be affected.

When shifting the shift lever

Do not let the vehicle roll backward while the shift lever is in a driving posi-
tion, or roll forward while the shift lever is in R. Doing so may cause the
engine to stall or lead to poor brake and steering performance, resulting in
an accident or damage to the vehicle.

Do not shift the shift lever to P while the vehicle is moving.
Doing so can damage the transmission and may result in a loss of vehicle
control.

Do not shift the shift lever to R while the vehicle is moving forward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

Do not shift the shift lever to a driving position while the vehicle is moving
backward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

Moving the shift lever to N while the vehicle is moving will disengage the
engine from the transmission. Engine braking is not available when N is
selected.

Be careful not to shift the shift lever with the accelerator pedal depressed.
Shifting the shift lever to a gear other than P or N may lead to unexpected
rapid acceleration of the vehicle that may cause an accident and result in
death or serious injury. Doing so can damage the transmission and may
result in a loss of vehicle control.

SIENNA_OM_OM08025U_(U)

199

4-1. Before driving

Drivin

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

If you hear a squealing or scraping noise (brake pad wear limit indica-
tors)
Have the brake pads checked and replaced by your Toyota dealer as soon
as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.

When the vehicle is stopped

Do not race the engine.
If the vehicle is in any gear other than P or N, the vehicle may accelerate
suddenly and unexpectedly, causing an accident.

In order to prevent accidents due to the vehicle rolling away, always keep
depressing the brake pedal while the engine is running, and apply the
parking brake as necessary.

If the vehicle is stopped on an incline, in order to prevent accidents caused
by the vehicle rolling forward or backward, always depress the brake pedal
and securely apply the parking brake as needed.

Avoid revving or racing the engine.
Running the engine at high speed while the vehicle is stopped may cause
the exhaust system to overheat, which could result in a fire if combustible
material is nearby.

When the vehicle is parked

Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in
the vehicle when it is in the sun.
Doing so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a

fire.

• The temperature inside the vehicle may cause the plastic lenses and

plastic material of glasses to deform or crack.

• Soft drink cans may fracture, causing the contents to spray over the

interior of the vehicle, and may also cause a short circuit in the vehicle’s
electrical components.

200

SIENNA_OM_OM08025U_(U)

4-1. Before driving

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

When the vehicle is parked

Do not leave cigarette lighters in the vehicle. If a cigarette lighter is in a
place such as the glove box or on the floor, it may be lit accidentally when
luggage is loaded or the seat is adjusted, causing a fire.

Do not attach adhesive discs to the windshield or windows. Do not place
containers such as air fresheners on the instrument panel or dashboard.
Adhesive discs or containers may act as lenses, causing a fire in the vehi-
cle.

Do not leave a door or window open if the curved glass is coated with a
metallized film such as a silver-colored one. Reflected sunlight may cause
the glass to act as a lens, causing a fire.

Always apply the parking brake, shift the shift lever to P, stop the engine
and lock the vehicle.
Do not leave the vehicle unattended while the engine is running.

If the vehicle is parked with the shift lever in P but the parking brake is not
set, the vehicle may start to move, possibly leading to an accident.

Do not touch the exhaust pipe while the engine is running or immediately
after turning the engine off.
Doing so may cause burns.

When taking a nap in the vehicle
Always turn the engine off. Otherwise, if you accidentally move the shift
lever or depress the accelerator pedal, this could cause an accident or fire
due to engine overheating. Additionally, if the vehicle is parked in a poorly
ventilated area, exhaust gases may collect and enter the vehicle, leading to
death or a serious health hazard.

SIENNA_OM_OM08025U_(U)

201

4-1. Before driving

Drivin

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

When braking

When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and this may cause
one side of the vehicle to brake differently than the other side. Also the
parking brake may not securely hold the vehicle.

If the brake booster device does not operate, do not follow other vehicles
closely and avoid hills or sharp turns that require braking.
In this case, braking is still possible, but the brake pedal should be
depressed more firmly than usual. Also, the braking distance will increase.
Have your brakes fixed immediately.

Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power-assisted
brakes.

The brake system consists of 2 individual hydraulic systems: If one of the
systems fails, the other will still operate. In this case, the brake pedal
should be depressed more firmly than usual and the braking distance will
increase. Have your brakes fixed immediately.

If the vehicle becomes stuck (AWD models)
Do not spin the wheels excessively when any of the tires is up in the air, or
the vehicle is stuck in sand or mud, etc. This may damage the driveline
components or unexpectedly propel the vehicle forward or backward, caus-
ing an accident.

202

SIENNA_OM_OM08025U_(U)

4-1. Before driving

NOTICE

When driving the vehicle

Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain the engine output.

Do not use the accelerator pedal or depress the accelerator and brake
pedals at the same time to hold the vehicle on a hill.

When parking the vehicle
Always set the parking brake, and shift the shift lever to P. Failure to do so
may cause the vehicle to move or the vehicle may accelerate suddenly if
the accelerator pedal is accidentally depressed.

Avoiding damage to vehicle parts

Do not turn the steering wheel fully in either direction and hold it there for
an extended period of time.
Doing so may damage the power steering motor.

When driving over bumps in the road, drive as slowly as possible to avoid
damaging the wheels, underside of the vehicle, etc.

If you get a flat tire while driving
A flat or damaged tire may cause the following situations.

It may be difficult to control your vehicle.

The vehicle will make abnormal sounds or vibrations.

The vehicle will lean abnormally.

Hold the steering wheel firmly and gradually depress the brake pedal to
slow down the vehicle.
Information on what to do in case of a flat tire. (

P . 485, 499)

When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may
cause the following serious damage to the vehicle:

Engine stalling

Short in electrical components

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have your Toyota dealer check the following:

Brake function

Changes in quantity and quality of oil and fluid used for the engine, tran-
saxle, transfer (AWD models), rear differential (AWD models), etc.

Lubricant condition for the bearings and suspension joints (where possi-
ble) and the function of all joints, bearings, etc.

203

SIENNA_OM_OM08025U_(U)

4-1. Before driving

Drivin

Cargo and luggage

Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capacity) - (Total weight of occupants)
Steps for Determining Correct Load Limit



(1) Locate the statement “The combined weight of occupants and

cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s
placard.

(2) Determine the combined weight of the driver and passengers that

will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers from

XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and lug-

gage load capacity.
For example, if the “XXX” amount equals 1400 lbs. and there will be
five 150 lb passengers in your vehicle, the amount of available
cargo and luggage load capacity is 650 lbs. (1400 - 750 (5

150) =

650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded

on the vehicle. That weight may not safely exceed the available
cargo and luggage load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be

transferred to your vehicle. Consult this manual to determine how
this reduces the available cargo and luggage load capacity of your
vehicle. (

P. 516)

Take notice of the following information about storage precau-
tions, cargo capacity and load:

Capacity and distribution

204

SIENNA_OM_OM08025U_(U)

4-1. Before driving

Cargo capacity
Total load capacity (vehicle
capacity weight) (

P. 516)

When 2 people with the combined weight of A lb. (kg) are riding in
your vehicle, which has a total load capacity (vehicle capacity weight)
of B lb. (kg), the available amount of cargo and luggage load capacity
will be C lb. (kg) as follows:
B

lb. (kg) - A

lb. (kg) = C

lb. (kg)

: A = Weight of people

: B = Total load capacity

: C = Available cargo and luggage load

In this condition, if 3 more passengers with the combined weight of

D lb. (kg) get on, the available cargo and luggage load will be reduced

E lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb. (kg)

: D = Additional weight of people

: E = Available cargo and luggage load

As shown in the example above, if the number of occupants
increases, the cargo and luggage load will be reduced by an amount
that equals the increased weight due to the additional occupants. In
other words, if an increase in the number of occupants causes an
excess of the total load capacity (combined weight of occupants plus
cargo and luggage load), you must reduce the cargo and luggage on
your vehicle.

Calculation formula for your vehicle

SIENNA_OM_OM08025U_(U)

205

4-1. Before driving

Drivin

Roof luggage carrier components

Roof rails
Cross rails

Adjusting the position of cross rails

Turn the knobs counterclock-
wise to release the cross
rails.

Slide  the  cross  rails  to  the
appropriate position for load-
ing  luggage  and  turn  the
knobs  clockwise  to  tighten
the cross rails securely.

Roof luggage carrier (if equipped)

206

SIENNA_OM_OM08025U_(U)

4-1. Before driving

Cargo capacity
Weight of the removed second
seat

If removing the second seats, it is possible to load extra cargo equal
to the weight of the removed seats.
(Cargo capacity) = (Total load capacity) - (Total weight of occupants) +
(Weight of the removed second seats)
Second seats weight:



7-passenger models

Tip-up seat, fabric: 47.2 lb. (20.5 kg)

Tip-up seat, leather: 49.5 lb. (21.5 kg)

Ottoman seat: 71.4 lb. (32.2 kg)



8-passenger models

Right side, fabric: 47.2 lb. (20.5 kg)

Right side, leather: 49.5 lb. (21.5 kg)

Left side, fabric: 97.1 lb. (42.2 kg)

Left side, leather: 100.3 lb. (43.6 kg)

Seating configuration variation

SIENNA_OM_OM08025U_(U)

207

4-1. Before driving

Drivin

WARNING

Things that must not be carried in the luggage compartment
The following things may cause a fire if loaded in the luggage compart-

ment:

Receptacles containing gasoline

Aerosol cans

Storage precautions
Observe the following precautions.

Failure to do so may prevent the pedals from being depressed properly,

may block the driver’s vision, or may result in items hitting the driver or

passengers, possibly causing an accident.

Stow cargo and luggage in the luggage compartment whenever possi-

ble.

Do not stack cargo and luggage in the luggage compartment higher

than the seatbacks.

Do not place cargo or luggage in or on the following locations.
• Driver’s feet

• Front passenger or rear seats (when stacking items)

• Instrument panel

• Dashboard

• Auxiliary box or tray that has no lid

Secure all items in the occupant compartment.

When you fold down the rear seats, long items should not be placed

directly behind the front seats.

Never allow anyone to ride in the luggage compartment. It is not

designed for passengers. They should ride in their seats with their seat

belts properly fastened. Otherwise, they are much more likely to suffer

death or serious bodily injury, in the event of sudden braking, sudden

swerving or an accident.

Capacity and distribution

Do not exceed the maximum axle weight rating or the total vehicle

weight rating.

Even if the total load of occupant’s weight and the cargo load is less

than the total load capacity, do not apply the load unevenly.

Improper loading may cause deterioration of steering or braking con-

trol which may cause death or serious injury.

208

SIENNA_OM_OM08025U_(U)

4-1. Before driving

WARNING

Cross rail adjustment
Make sure the cross rails are locked securely by pushing forward and

rearward on them.

Failure to do so may cause an unexpected accident.

When loading cargo
To use the roof rails as a roof luggage carrier, you must fit the roof rails

with two or more genuine Toyota cross rails or their equivalent.

When you load cargo on the roof luggage carrier, observe the following:

Place the cargo so that its weight is distributed evenly between the

front and rear axles.

If loading long or wide cargo, never exceed the vehicle overall length

or width. (

P. 516)

Before driving, make sure the cargo is securely fastened on the roof

luggage carrier.

Loading cargo on the roof luggage carrier will make the center of grav-

ity of the vehicle higher. Avoid high speeds, sudden starts, sharp turns,

sudden braking or abrupt maneuvers, otherwise it may result in loss of

control or vehicle rollover due to failure to operate this vehicle correctly

and result in death or serious injury.

If driving for a long distance, on rough roads, or at high speeds, stop

the vehicle now and then during the trip to make sure the cargo

remains in its place.

Do not exceed 150 lb. (68 kg) cargo weight on the roof luggage carrier.

NOTICE

When loading cargo (vehicles with moon roof)
Be careful not to scratch the surface of the moon roof.

Toyota Sienna (2019 year). Instruction - part 13
