Toyota Sienna (2019 year). Instruction - part 9

WARNING

When opening or closing the sliding doors with windows open, keep all
body parts clear of the windows.

If anyone is in the vicinity, make sure they are safe and let them know that
the sliding door is about to open or close.

Do not leave the sliding door at half-opened position because the sliding
door is not latched at this position. The sliding door may move unexpect-
edly on an incline.

When the vehicle is stopped on a slope,
the door will slide faster when opening
or closing, so be especially careful that
the passengers do not get hit or
pinched by the door.

Open  the  sliding  door  fully  while  pas-
sengers are getting on or off on a down-
ward slope. Do not operate the outside
handle  or  inside  handle  while  the  door
is  open  as  the  door  could  suddenly
close by itself causing injury.

When closing the sliding door, take
extra care to prevent your fingers etc.
from being caught.

130

SIENNA_OM_OM08025U_(U)

WARNING

Sliding door closer (if equipped)

Use caution when using the sliding door closer. The sliding door closer
operates even when the power sliding door system is canceled.

Power sliding doors (vehicles with power sliding doors)
Observe the following precautions when the power sliding door system is
on.
Failure to do so may cause death or serious injury.

When using the door handle to open or close the power sliding door,
remove your hand from the door handle immediately after starting power
sliding door operation. If you leave your hand on the door handle during
operation, your hand, fingers, wrist etc. may be subjected to an excessive
amount of force.

Check the safety of the surrounding area to make sure there are no obsta-
cles or anything that could cause any of your belongings to get caught.

In the event that the sliding door is left
slightly open, the sliding door closer will
automatically close it to the fully closed
position. It takes several seconds
before the sliding door closer begins to
operate. Be careful not to catch fingers
or anything else in the sliding door, as
this may cause bone fractures or other
serious injuries.

Do not get in and out of the vehicle
while the power sliding door is being
operated.

If  anyone  is  in  the  vicinity,  make  sure
they are safe and let them know that the
sliding door is about to open or close.
Also,  do  not  operate  the  power  sliding
door  if  anyone  inside  or  outside  the
vehicle is leaning against the vehicle in
the area around the sliding door.

SIENNA_OM_OM08025U_(U)

131

WARNING

If the power sliding door system is turned off with the main switch while the
sliding door is operating automatically, the automatic operation is stopped.
The sliding door then has to be operated manually. Take extra care when
on an incline, as the sliding door may open or close unexpectedly.

If the operating conditions of the power sliding door are no longer met, a
buzzer may sound and the sliding door may stop opening or closing. The
sliding door then has to be operated manually. Take extra care when on an
incline, as the sliding door may open or close abruptly.

On an incline, a sliding door may close by itself after it opens automati-
cally. Make sure the sliding door is fully open and secure.

In the following situations, the power sliding door may detect an abnormal-
ity and automatic operation may be stopped. In this case, the sliding door
has to be operated manually. Take extra care when on an incline, as the
sliding door may open or close abruptly.
• When the sliding door contacts an obstacle
• When the battery voltage suddenly drops, such as when the engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system) or the
engine is started during automatic operation

Do not attach any accessories other than genuine Toyota parts to the
power sliding door. The power sliding door may not operate, causing itself
to malfunction, or the power sliding door may close again after it is
opened.

When the child-protector locks are set, make sure to turn off the power
sliding door system with the main switch in order to totally disable the sys-
tem.

Jam protection function (vehicles with power sliding doors)
Observe the following precautions.
Failure to do so may cause death or serious injury.

Never use any part of your body to intentionally activate the jam protection
function.

The jam protection function may not work if something gets caught just
before the power sliding door fully closes. Be careful not to catch fingers or
anything else.

The jam protection function may not work depending on the shape of the
object that is caught. Be careful not to catch fingers or anything else.

132

SIENNA_OM_OM08025U_(U)

NOTICE

Sliding door

To prevent damage to your vehicle

Vehicles with the power sliding door:
• Do not apply excessive force when the sliding door is operating.
• Do not place your hand or foot near door hinges or rollers when the slid-

ing door is operating.

• Avoid forcibly opening the left side sliding door fully when the fuel filler

door is opened. Otherwise, the fuel filler door may be damaged.

• Take care not to damage the sensors (installed on the front edge of the

power sliding door) with a knife or other sharp object.

Make sure there is nothing in the doorway before closing.

Do not close the sliding door by applying the brakes. Doing so could cause
the sliding door to be damaged.

Make  sure  magazines  are  not  bent  or
protruding from the sliding door pockets.
Do not insert anything too big so that the
shape of the sliding door pockets is dis-
torted.  Such  objects  may  obstruct  the
opening/closing  of  the  sliding  doors,
damage  the  sliding  door  pockets  or  the
vehicle  body,  and  may  result  in  a  mal-
function.

133

SIENNA_OM_OM08025U_(U)

Back door

Entry function (vehicles with a smart key system)

Carry the electronic key to enable this function.

Press the unlock button to
unlock all the doors.

The door cannot be unlocked for
3  seconds  after  the  door  is
locked.
Lock the back door again when
you leave the vehicle. The back
door  will  not  lock  automatically
after  it  has  been  opened  and
then closed.

Press the lock button to lock all the doors.

Check that the door is securely locked.

Wireless remote control

P. 111

Door lock switch

P. 114

The back door can be locked/unlocked and opened/closed by
the following procedures.

Locking and unlocking the back door

134

SIENNA_OM_OM08025U_(U)

Press and hold the switch to open/
close the back door.

Pressing the switch again while the
power  back  door  is  operating  will
cause the operation to reverse.
However,  the  reverse  operation
cannot  be  performed  for  the  first
second  after  automatic  operation
starts even if the switch is pressed
again.

Back door opener

Raise the back door while
pressing the back door opener
to release the lock to open the
back door.

Opening/closing the back door from inside the vehicle (vehicles
with power back door)

Opening the back door from outside the vehicle

SIENNA_OM_OM08025U_(U)

135

Wireless remote control (vehicles with power back door)

Press and hold the switch to open/close the power back door.

Pressing the switch again while the power back door is operating will
cause the operation to reverse. However, the reverse operation cannot be
performed for the first second after automatic operation starts, even if the
wireless remote control switch is pressed again.

Press the switch to close the back
door.

Pressing the switch again while the
power  back  door  is  closing  will
cause it to open again.
However,  the  reverse  operation
cannot  be  performed  for  the  first
second  after  automatic  operation
starts even if the switch is pressed
again.



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

Power back door switch (if equipped)

136

SIENNA_OM_OM08025U_(U)

Lower the back door using the
back door handle, and make sure
to push the back door down from
the outside to close it.

Turn the main switch off to disable
the power back door system.

Off
On

: The orange line at the top of the

switch indicates that the power
back door system is on.

When closing the back door

Canceling the power back door system (vehicles with power
back door)

SIENNA_OM_OM08025U_(U)

137

Luggage compartment light

If the back door opener is inoperative
The back door can be operated from the inside.

Move the lever.

The luggage compartment light turns on
when the back door is opened with the
luggage compartment light switch on.

On
Off

Remove the inside panel.



Vehicles without power back door



Vehicles with power back door

138

SIENNA_OM_OM08025U_(U)

The power back door can be operated when (vehicles with power back
door)

The shift lever is in P.

The back door is unlocked.

Power back door operation (vehicles with power back door)

A buzzer sounds and the emergency flashers flash twice to indicate that the
back door is opening/closing.

The back door can be opened and closed manually even when the power
back door main switch is off.

Jam protection function (vehicles with power back door)

If anything obstructs the power back door while it is closing or opening, the
back door will automatically operate in the opposite direction.

If the jam protection function operates during two consecutive closing oper-
ations, the back door will be stopped at that position.

Back door closer (if equipped)
In the event that the back door is left slightly open, the back door closer will
automatically close it to the fully closed position.

When the battery is disconnected

The back door will be automatically locked after the battery is reconnected.

The power back door (if equipped) must be initialized in order to ensure
proper operation.

Unlock the back door with the wireless remote control or door lock switch.
Close the back door completely by hand.

Conditions affecting the operation of the smart key system or wireless
remote control
P. 118

SIENNA_OM_OM08025U_(U)

139

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

Before driving

Make sure that the back door is fully closed. If the back door is not fully
closed, it may open unexpectedly while driving and hit near-by objects or
luggage in the luggage compartment may be thrown out, causing an acci-
dent.

Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or other injuries.

Do not allow a child to open or close the back door.
Doing so may cause the back door to operate unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.

Important points while driving
Never let anyone sit in the luggage compartment. In the event of sudden
braking, sudden swerving or a collision, they are susceptible to death or
serious injury.

Operating the back door
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.

Remove any heavy loads, such as snow and ice, from the back door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.

When opening or closing the back door, thoroughly check to make sure
the surrounding area is safe.

If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.

Use caution when opening or closing the back door in windy weather as it
may move abruptly in strong wind.

The back door may suddenly shut if it is
not  opened  fully.  It  is  more  difficult  to
open  or  close  the  back  door  on  an
incline  than  on  a  level  surface,  so
beware  of  the  back  door  unexpectedly
opening or closing by itself. Make sure
that  the  back  door  is  fully  open  and
secure  before  using  the  luggage  com-
partment.

140

SIENNA_OM_OM08025U_(U)

WARNING

Do not place your hands on the back door damper stay to close the back
door, and do not hang on the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to
break, causing an accident.

If a bicycle carrier or similar heavy object is attached to the back door, it
may suddenly shut again after being opened, causing someone’s hands,
head or neck to be caught and injured. When installing an accessory part
to the back door, using a genuine Toyota part is recommended.

Back door closer (if equipped)

Use caution when using the back door closer as it still operates when the
power back door system is canceled.

Power back door (vehicles with power back door)
Observe the following precautions when operating the power back door.
Failure to do so may cause death or serious injury.

Check the safety of the surrounding area to make sure there are no obsta-
cles or anything that could cause any of your belongings to get caught.

If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.

If the operating conditions of the power back door are no longer met, a
buzzer may sound and the back door may stop opening or closing. The
back door then has to be operated manually. Take extra care when on an
incline, as the back door may open or close abruptly.

On an incline, the back door may suddenly shut after it opens. Make sure
the back door is fully open and secure.

When closing the back door, take extra
care to prevent your fingers etc. from
being caught.

When closing the back door, make sure
to press it lightly on its outer surface. If
the back door handle is used to fully
close the back door, it may result in
hands or arms being caught.

In  the  event  that  the  back  door  is  left
slightly  open,  the  back  door  closer  will
automatically close it to the fully closed
position.  It  takes  several  seconds
before  the  back  door  closer  begins  to
operate. Be careful not to catch fingers
or anything else in the back door, as this
may cause bone fractures or other seri-
ous injuries.

SIENNA_OM_OM08025U_(U)

141

WARNING

In the following situations, the power back door may detect an abnormality
and automatic operation may be stopped. In this case, the back door has
to be operated manually. Take extra care when on an incline, as the back
door may open or close abruptly.
• When the back door contacts an obstacle
• When the battery voltage suddenly drops, such as when the engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system) or the
engine is started during automatic operation

If a bicycle carrier or similar heavy object is attached to the back door, the
power back door may not operate, causing itself to malfunction, or the
back door may move in the closing direction after being opened, causing
someone’s hands, head or neck to be caught and injured. When installing
an accessory part to the back door, ask your Toyota dealer for details.

Jam protection function (vehicles with power back door)
Observe the following precautions.
Failure to do so may cause death or serious injury.

Although the back door stops closing when the jam protection function
detects an object, take extra care as you may still be injured if part of your
body is already caught.

Never use any part of your body to intentionally activate the jam protection
function.

The jam protection function may not work if something gets caught just
before the back door fully closes. Be careful not to catch fingers or any-
thing else.

The jam protection function may not work depending on the shape of the
object that is caught. Be careful not to catch fingers or anything else.

142

SIENNA_OM_OM08025U_(U)

NOTICE

Back door damper stays
The back door is equipped with damper stays that hold the back door in
place.
Observe the following precautions.
Failure to do so may cause damage to the back door damper stay, resulting
in malfunction.

Do not place your hand on the damper stay or apply lateral forces to it.

To prevent back door closer malfunction
Do not apply excessive force to the back door while the back door closer is
operating.

To prevent damage to the power back door

Make sure that there is no ice between the back door and frame that
would prevent movement of the back door. Operating the power back door
when excessive load is present on the back door may cause a malfunc-
tion.

Do not apply excessive force to the back door while the power back door
is operating.

Take care not to damage the sensors (installed on the right and left edges
of the power back door) with a knife or other sharp object. If the sensor is
disconnected, the power back door will not operate in automatic operation.

Do not attach any foreign objects, such
as stickers, plastic sheets, or adhesives
to the damper stay rod.

Do not touch the damper stay rod with
gloves or other fabric items.

Do not attach any accessories other
than genuine Toyota parts to the back
door.

Damper stays

143

SIENNA_OM_OM08025U_(U)

Smart key system



Locks and unlocks the doors

• Front door handles (

P. 110)

• Sliding door handles (

P. 121)

• Back door (

P. 133)

Starts and stops the engine (

P. 228)

Antenna location



: If equipped

The following operations can be performed simply by carrying
the electronic key on your person, for example in your pocket.
The driver should always carry the electronic key.

Antennas outside cabin
Antennas inside cabin
Antenna outside luggage compartment

144

SIENNA_OM_OM08025U_(U)
