481

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

(U.S.A.)

(Canada)

ABS warning light

Indicates a malfunction in:
• The ABS; or
• The brake assist system

 Have the vehicle inspected by your Toyota dealer

immediately.

Electric power steering system warning light (warning
buzzer)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system

 Have the vehicle inspected by your Toyota dealer

immediately.

(Comes on)

Slip indicator

Indicates a malfunction in:
• The VSC (Vehicle Stability Control) system;
• The TRAC (Traction Control) system; or
• The hill-start assist control system
The light will flash when the VSC or the TRAC

system is

operating.

 Have the vehicle inspected by your Toyota dealer

immediately.

Low fuel level warning light

Indicates that remaining fuel is approximately 2.0 gal. (7.5
L, 1.7 Imp. gal.) or less

 Refuel the vehicle.

Driver’s and front passenger’s seat belt reminder light
(warning buzzer)

Warns the driver and/or front passenger to fasten their
seat belts

 Fasten the seat belt.

If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

Rear passengers’ seat belt reminder lights (warning
buzzer)

Warns the rear passengers to fasten their seat belts.

 Fasten the seat belt.

Master warning light

A buzzer sounds and the warning light comes on and
flashes to indicate that the master warning system has
detected a malfunction.

 P. 489

Warning light

Warning light/Details/Actions

482

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

(Flashes or illumi-

nates)

PCS warning light

Indicates a malfunction in the PCS (Pre-Collision System)
or that the system is temporarily unavailable due to the
vehicle being extremely hot/cold, or dirt around a front
sensor, etc. (

P. 225, 489 )

 Follow the instructions displayed on the multi-infor-

mation display. (

P. 225, 489)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.

 P. 225

(Orange)

LDA (Lane Departure Alert with steering control) indica-
tor

The  warning  light  comes  on  and  a  warning  message  is
displayed  to  indicate  that  the  LDA  (Lane  Departure Alert
with  steering  control)  system  is  not  available  temporarily
or has detected a malfunction.

 P. 491, 492

Tire pressure warning light

When the light comes on:

Low tire inflation pressure such as

• Natural causes (

P. 484)

• Flat tire (

P. 509)

 Adjust the tire inflation pressure to the specified

level.

The light will turn off after a few minutes. In case

the light does not turn off even if the tire inflation

pressure is adjusted, have the system checked by

your Toyota dealer.

When the light comes on after blinking for 1 minute:

Malfunction in the tire pressure warning system

 Have the system checked by your Toyota dealer.

Warning light

Warning light/Details/Actions

483

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

: Parking brake engaged warning buzzer:

P. 490

: Driver’s seat belt buzzer:

Vehicles without a smart key system: The driver’s seat belt buzzer sounds
to alert the driver that his or her seat belt is not fastened. Once the engine
switch is turned to the “ON” position, the buzzer sounds for 6 seconds. If
the vehicle reaches a speed of 12 mph (20 km/h), the buzzer sounds once.
If the seat belt is still unfastened after 24 seconds, the buzzer will sound
intermittently  for  6  seconds. Then,  if  the  seat  belt  is  still  unfastened,  the
buzzer will sound in a different tone for 90 more seconds.
Vehicles with a smart key system: The driver’s seat belt buzzer sounds to
alert the driver that his or her seat belt is not fastened. Once the engine
switch is turned to IGNITION ON mode, the buzzer sounds for 6 seconds.
If  the  vehicle  reaches  a  speed  of  12  mph  (20  km/h),  the  buzzer  sounds
once. If the seat belt is still unfastened after 24 seconds, the buzzer will
sound intermittently for 6 seconds. Then, if the seat belt is still unfastened,
the buzzer will sound in a different tone for 90 more seconds.
Front passenger’s seat belt buzzer:
The front passenger’s seat belt buzzer sounds to alert the front passenger
that  his  or  her  seat  belt  is  not  fastened.  The  buzzer  sounds  once  if  the
vehicle reaches a speed of 12 mph (20 km/h). If the seat belt is still unfas-
tened after 24 seconds, the buzzer will sound intermittently for 6 seconds.
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 90 more seconds.
Rear passenger’s seat belt buzzer:
The rear passenger’s seat belt buzzer sounds to alert the rear passengers
that his or her seat belt is not fastened. The buzzer sounds for 6 seconds
after the vehicle reaches a speed of 12 mph (20 km/h). Then, if the seat
belt is still unfastened, the buzzer will sound in a different tone for 24 more
seconds.

: If equipped

484

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

■

SRS warning light
This warning light system monitors the airbag sensor assembly, front impact
sensors, side impact sensors (front door), side impact sensors (front), side
impact sensors (rear), driver’s seat belt buckle switch, front passenger occu-
pant classification system, “AIR BAG ON” indicator light, “AIR BAG OFF” indi-
cator light, front passenger’s seat belt buckle switch, seat belt pretensioners
(front), airbags, interconnecting wiring and power sources. (

P. 36)

■

Front passenger detection sensor, seat belt reminder and warning
buzzer
If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash and the warning buzzer to
sound even if a passenger is not sitting in the seat.

■

If the malfunction indicator lamp comes on while driving
First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.

■

When the tire pressure warning light comes on (vehicles with a tire

pressure warning system)
Check the tire inflation pressure and adjust to the appropriate level. Push-

ing the tire pressure warning reset switch will not turn off the tire pressure

warning light.

■

The tire pressure warning light may come on due to natural causes

(vehicles with a tire pressure warning system)
The tire pressure warning light may come on due to natural causes such

as natural air leaks and tire inflation pressure changes caused by tem-

perature. In this case, adjusting the tire inflation pressure will turn off the

warning light (after a few minutes).

485

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

■

When a tire is replaced with a spare tire (vehicles with a tire pressure

warning system)
The compact spare tire is not equipped with a tire pressure warning valve

and transmitter. If a tire goes flat, the tire pressure warning light will not

turn off even though the flat tire has been replaced with the spare tire.

Replace the spare tire with the repaired tire and adjust the tire inflation

pressure. The tire pressure warning light will go off after a few minutes.

■

Conditions that the tire pressure warning system may not function
properly (vehicles with a tire pressure warning system)
The tire pressure warning system will be disabled in the following condi-

tions:

(When the condition becomes normal, the system will work properly.)

●

If tires not equipped with tire pressure warning valves and transmitters

are used

●

If the ID code on the tire pressure warning valves and transmitters is not

registered in the tire pressure warning computer

●

If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm

or bar) or

higher

The tire pressure warning system may be disabled in the following condi-

tions:

(When the condition becomes normal, the system will work properly.)

●

If electronic devices or facilities using similar radio wave frequencies are

nearby

●

If a radio set at similar frequency is in use in the vehicle

●

If a window tint that affects the radio wave signals is installed

●

If there is a lot of snow or ice on the vehicle, in particular around the

wheels or wheel housings

●

If non-genuine Toyota wheels are used (Even if you use Toyota wheels,

the tire pressure warning system may not work properly with some types

of tires.)

●

If tire chains are used

■

If the tire pressure warning light frequently comes on after blinking

for 1 minute (vehicles with a tire pressure warning system)
If the tire pressure warning light frequently comes on after blinking for 1

minute when the engine switch is turned on, have it checked by your

Toyota dealer.

■

Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

■

Electric power steering system warning light (warning buzzer)
When the battery charge becomes insufficient or the voltage temporarily
drops, the electric power steering system warning light may come on and the
warning buzzer may sound.

486

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

WARNING

■

If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Toyota
dealer. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.

■

When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
When steering wheel operations are heavier than usual, grip the steering
wheel firmly and operate it using more force than usual.

■

If the tire pressure warning light comes on (vehicles with a tire

pressure warning system)
Be sure to observe the following precautions. Failure to do so could

cause a loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire

inflation pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pres-

sure adjustment, it is probable that you have a flat tire. Check the tires.

If a tire is flat, change it with the spare tire and have the flat tire

repaired by the nearest Toyota dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,

you could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur (vehicles with a tire

pressure warning system)
The tire pressure warning system may not activate immediately.

487

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

WARNING

■

Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly

when cold and inflated to the inflation pressure recommended by the

vehicle manufacturer on the vehicle placard or tire inflation pressure

label (tire and load information label). (If your vehicle has tires of a dif-

ferent size than the size indicated on the vehicle placard or tire inflation

pressure label [tire and load information label], you should determine

the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire

pressure monitoring system (TPMS-tire pressure warning system) that

illuminates a low tire pressure telltale (tire pressure warning light) when

one or more of your tires is significantly under-inflated. Accordingly,

when the low tire pressure telltale (tire pressure warning light) illumi-

nates, you should stop and check your tires as soon as possible, and

inflate them to the proper pressure. Driving on a significantly under-

inflated tire causes the tire to overheat and can lead to tire failure.

Under-inflation also reduces fuel efficiency and tire tread life, and may

affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a sub-

stitute for proper tire maintenance, and it is the driver’s responsibility to

maintain correct tire pressure, even if under-inflation has not reached

the level to trigger illumination of the TPMS low tire pressure telltale (tire

pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-

ing system) malfunction indicator to indicate when the system is not

operating properly. The TPMS (tire pressure warning system) malfunc-

tion indicator is combined with the low tire pressure telltale (tire pressure

warning light). When the system detects a malfunction, the telltale will

flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups

as long as the malfunction exists. When the malfunction indicator is illu-

minated, the system may not be able to detect or signal low tire pres-

sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-

ety of reasons, including the installation of replacement or alternate tires

or wheels on the vehicle that prevent the TPMS (tire pressure warning

system) from functioning properly. Always check the TPMS (tire pres-

sure warning system) malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the replacement or alter-

nate tires and wheels allow the TPMS (tire pressure warning system) to

continue to function properly.

488

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

NOTICE

■

To ensure the tire pressure warning system operates properly

(vehicles with a tire pressure warning system)
Do not install tires with different specifications or makers, as the tire

pressure warning system may not operate properly.

489

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

Master warning light

The  master  warning  light  also
comes  on  or  flashes  in  order  to
indicate  that  a  message  is  cur-
rently being displayed on the multi-
information display.

Multi-information display

If any of the warning message or indicator comes on again after the
following actions have been performed, contact your Toyota dealer.

If a warning message or indicator is displayed

If a warning is shown on the multi-information display, stay calm
and perform the following actions:

Warning message and warning buzzer list

Warning message

Details/Actions

Indicates that:

• There is a high possibility of a frontal colli-

sion; or

• The pre-collision braking function is operating

A buzzer also sounds.

 Slow the vehicle by applying the brakes.



Monochrome display



Color display

Indicates that your vehicle is nearing the vehicle
ahead (in vehicle-to-vehicle distance control
mode)

A buzzer also sounds.

 Slow the vehicle by applying the brakes.

490

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U



Monochrome display



Color display

Indicates that one or more of the doors is not fully
closed.

The system also indicates which doors are not
fully closed.
If the vehicle reaches a speed of 3 mph (5 km/h),

flashes and a buzzer sounds to indicate

that the door(s) are not yet fully closed.

 Make sure that all the doors are closed.



Monochrome display



Color display

Indicates that the trunk is not fully closed.

If the vehicle reaches a speed of 3 mph (5 km/h),

flashes and a buzzer sounds to indicate

that the trunk is not yet fully closed.

 Close the trunk.

Indicates that the vehicle is being driven at 3 mph
(5 km/h) or more with the parking brake still
engaged.

A buzzer also sounds.

 Release the parking brake.

Warning message

Details/Actions

(U.S.A.)

(Canada)

(Flashes)

491

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U



Monochrome display



Color display

Indicates that the vehicle has deviated from the
lane (while the LDA [Lane Departure Alert with
steering control] system is operating)

• Vehicles with a monochrome display: The

lane line on the side the vehicle has deviated
from flashes.

• Vehicles with a color display: The lane line on

the side the vehicle has deviated from
flashes in amber.

• A buzzer also sounds.

 Check around the vehicle and back to

inside of the lane lines.

Indicates that the LDA (Lane Departure Alert with
steering control) system has determined that the
driver does not have their hands on the steering
wheel while the steering control function is on

If the system continues to determine that the
driver does not have his hands on the steering
wheel, a buzzer will sound.

 Firmly hold the steering wheel.

Indicates a malfunction in the LDA (Lane Depar-
ture Alert with steering control) system

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Warning message

Details/Actions

(Orange)

(Flashes)

(Orange)

492

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

Indicates that the LDA (Lane Departure Alert with
steering control) and pre-collision system are
temporarily canceled due to high temperatures
around the camera sensor

 Turn the LDA (Lane Departure Alert with

steering control) system off, wait for the
area around the camera sensor to cool, and
then turn the LDA (Lane Departure Alert
with steering control) system back on.

The LDA (Lane Departure Alert with steering con-
trol) system is temporarily canceled due to a mal-
function in a sensor other than the camera
sensor.

A buzzer also sounds.

 Turn the LDA (Lane Departure Alert with

steering control) system off and follow the
appropriate  troubleshooting  procedures
for  warning  message. Afterward,  drive  the
vehicle  for  a  short  time,  and  then  turn  the
LDA  (Lane  Departure  Alert  with  steering
control) system back on.

Indicates that the LDA (Lane Departure Alert with
steering control) and pre-collision system are
temporarily canceled because dirt, rain, conden-
sation, ice, snow, etc., are present on the wind-
shield in front of the camera sensor

 Turn the LDA (Lane Departure Alert with

steering control) system off, remove any
dirt, rain, condensation, ice, snow, etc.,
from the windshield, and then turn the LDA
(Lane Departure Alert with steering control)
system back on.

Indicates that the LDA (Lane Departure Alert with
steering control) system cannot be used because
the vehicle speed is lower than approximately 32
mph (50 km/h)

 Drive the vehicle at 32 mph (50 km/h) or

higher.

Warning message

Details/Actions

(Flashes)

(Orange)

(Flashes)

(Orange)

493

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

Indicates that LDA (Lane Departure Alert with
steering control) cannot be used due to the vehi-
cle speed being too high

 Slow down.



Monochrome display



Color display

Indicates a malfunction in the vehicle’s charging
system.

 Immediately stop the vehicle in a safe place

and contact your Toyota dealer. Continuing
to drive the vehicle may be dangerous.



Monochrome display



Color display

Indicates a malfunction in the smart key system
(if equipped).

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Warning message

Details/Actions

(Flashes)

494

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

Indicates that the radar sensor is dirty or covered
with ice

A buzzer also sounds.

 Clean the sensor.

Indicates that the dynamic radar cruise control
system cannot be used temporarily due to bad
weather

A buzzer also sounds.

 Use the dynamic radar cruise control sys-

tem when it becomes available again.

Indicates that the dynamic radar cruise control
system brake control function is temporarily
unavailable

A buzzer also sounds.

 Depress the brake.



Monochrome display



Color display

Indicates a malfunction in the dynamic radar
cruise control system.

• Press the “ON-OFF” button once to deacti-

vate the system, and then press the button
again to reactivate the system.

• A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Warning message

Details/Actions

495

8-2. Steps to take in an emergency

Wh
en tro

uble

ris

COROLLA_TMMMS_TMMC_U

Indicates a malfunction in the dynamic radar
cruise control

• Depress the brake pedal.
• A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Indicates a malfunction in the pre-collision sys-
tem

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Indicates that, since the VSC (Vehicle Stability
Control) system was turned off, the pre-collision
brake system operation is stopped

 Turn the VSC on. (P. 259)

Indicates that the pre-collision system is tempo-
rarily unavailable

 Please wait until the system returns. If the

message  does  not  disappear,  the  system
may  be  malfunctioning.  Have  the  vehicle
inspected  by  your  Toyota  dealer  immedi-
ately.

Warning message

Details/Actions

(Flashes)

496

8-2. Steps to take in an emergency

COROLLA_TMMMS_TMMC_U

Indicates that the pre-collision system sensor is
dirty, covered with ice, etc.

 Remove any dirt, ice, etc.



Monochrome display



Color display

Indicates abnormal engine oil pressure.

• The warning message is shown if the engine

oil pressure is too low.

• A buzzer also sounds.

 Immediately stop the vehicle in a safe place

and contact your Toyota dealer. Continuing
to drive the vehicle may be dangerous.

Vehicles without a smart key system:

Indicates that the engine switch is turned off or

turned to the “ACC” position mode and the

driver’s door is opened while the lights are turned

on.

A buzzer also sounds.

 Turn the lights off.
Vehicles with a smart key system:

Indicates that the engine switch is turned off or

turned to ACCESSORY mode and the driver’s

door is opened while the lights are turned on.

A buzzer also sounds.

 Turn the lights off.

(If equipped)

Indicates that the moon roof is not fully closed
(with the engine switch off, and the driver’s door
open)

A buzzer also sounds.

 Close the moon roof.

Warning message

Details/Actions

(Flashes)

Content .. 29 30 31 32 ..
