Toyota Prius C (2019 year). Instruction - part 2

FEATURES & OPERATIONS

Audio

ENTUNE™ AUDIO

Push to access

Bluetooth hands-free

Eject CD

Touch screen display

system

Seek station/

CD track select

Turn to tune

radio stations

Push to turn

manually or

ON/OFF

select tracks

or files

Push to

display audio

screen

ENTUNE™ PREMIUM AUDIO WITH INTEGRATED NAVIGATION AND APP SUITE

Press to

display

APPS

Press to

display

Home

screen

MAP card insert

Refer to the “Navigation and Multimedia System Owner’s Manual” and “2019

Entune™ Audio Quick Reference Guide.”

Power outlet-12V DC

For vehicles with a “POWER” button, make sure vehicle is in “POWER ON” mode.

Or, for vehicles with an ignition switch, key must be in the “ACC” or “ON” position

for use.

USB media/AUX port

USB media port

By connecting a USB-compatible portable audio device or USB memory stick into

the USB media port, you can listen to music through the vehicle’s speaker system.

AUX port

By inserting an AUX cable into the AUX port, you can listen to music from a

portable audio device through the vehicle’s speaker system while in AUX mode.

Clock

Display

Meter control switches

Scroll up/down or select menu

Enter/select

Previous screen

(1) Press “

” switches and select

from the Multi-Information Display (MID).

(2) Press “

” switches and press “

” to select Meter Settings screen.

(3) Press “

” to select Time and date screen.

(4) Press “

” switches and press “

” to select Clock screen to adjust time.

You can press “

” to go back to the previous screen at any time.

FEATURES & OPERATIONS

Cruise control

TURNING SYSTEM ON/OFF

System ON/OFF

FUNCTIONS

Increase speed

Resume2

Cancel1

Set

Decrease speed

1 The set speed may also be cancelled by depressing the brake pedal.

2 The set speed may be resumed once vehicle speed exceeds 25 mph.

Parking brake

Set

Release

(2) Push

Pull

(1) Pull slightly

(3) Lower

Tilt & telescopic steering wheel

Angle

Lock release lever

Length

Hold wheel, push lever down, set angle and length, and return lever.

NOTE: Do not attempt to adjust while the vehicle is in motion.

Multi-Information Display (MID)

Display

Meter controls

: Select menu

: Sroll up/down

Enter/select

Previous screen

Push “

” or “

” to scroll through the following information screens:

(1) Drive information

(2) Settings and screen OFF

(3) Warning messages

(4) Menu icons

Menu icons

Drive information

ECO fuel consumption information

LDA operational status

Settings display

FEATURES & OPERATIONS

Steering wheel switches

& telephone controls (Bluetooth®)

Steering wheel telephone switches

“MODE”

Push to change the audio source.

Push and hold to mute or pause the audio.

“

”

Use to search within the selected

audio medium (radio, etc.).

Voice command switch

Volume control

End call

Start call/

Mobile Assistant access*

Microphone

Bluetooth® technology allows dialing or receipt of calls without taking hands from

the steering wheel or using a cable to connect the telephone and the system.

* Push and hold to access Mobile Assistant. When a compatible smartphone is

Bluetooth® connected push and hold the off hook switch 2-3 seconds to access

Siri® Eyes Free.

Refer to the “Navigation and Multimedia System Owner’s Manual” for more details.

Refer to “Bluetooth® Device Pairing Section” in this guide for more information

about phone connections and compatibility.

NOTE: Concentrating on the road should always be your first priority while

driving. Do not use the hands-free phone system if it will distract you.

Hill-start Assist Control (HAC)

Brake

pedal

HAC helps prevent rolling backwards on an incline. To engage, push the brake

pedal farther down while at a complete stop until a beep sounds and slip indicator

illuminates. HAC holds for approximately two seconds after releasing brake pedal.

Refer to the Owner’s Manual for more details.

Rear view monitor system

The rear view monitor system displays an image of the view from the bumper of

the rear area of the vehicle. The camera for the rear view monitor system is located

above the license plate.

To adjust the image on the rear view monitor screen, press the “SETUP” button

and select “Display” on the “Setup” screen. Select “Camera” to adjust the screen

contrast and brightness.

Refer to the Owner’s Manual and the Navigation and Multimedia System Owner‘s

Manual for limitations and more details on this system.

Vehicle Stability Control (VSC)/TRAC OFF switch

Push

The VSC OFF switch can be used to help free a stuck vehicle in surroundings like

mud, dirt or snow. While the vehicle is stopped, press switch to disable the TRAC

system.

To disable both VSC and TRAC systems, press and hold the switch for at least 3

seconds.

Refer to the Owner’s Manual for limitations and more details.

TOYOTA SAFETY SENSE™

Quick overview-Toyota Safety Sense™ C (TSS-C)

Toyota Safety Sense™ C (TSS-C) is a set of active safety technologies designed to

help mitigate or prevent collisions across a wide range of traffic situations, in certain

conditions. TSS-C is designed to help support the driver’s awareness, decision making

and vehicle operation contributing to a safe driving experience.

Refer to the Owner’s Manual for operation, setting adjustments, limitations and

more details to understand these functions and complete safety precautions. For

more information, please go to http://www.toyota.com/safety-sense.

Pre-Collision System with Pedestrian Detection (PCS w/PD)

PCS w/PD is designed to provide alert, mitigation, and/or avoidance

support in certain conditions, when the system detects a potential collision

with a preceding vehicle is likely to occur.

Laser sensors are designed to work with the camera sensor to help

recognize a preceding pedestrian, and provide an alert, mitigation and/or

avoidance support in certain conditions.

Lane Departure Alert (LDA)

LDA is designed to provide notification when the system detects an

unintended lane departure.

Automatic High Beams (AHB)

AHB is designed to detect the headlights of oncoming vehicles and the

tail lights of preceding vehicles and switch between high beams and low

beams as appropriate.

Sensors

TSS-C combines an in-vehicle camera and lasers mounted in front of the inside rear

view mirror. These sensors support the driver assist systems.

Camera sensor

Laser sensors

Pre-Collision System with Pedestrian

Detection (PCS w/PD)

The Pre-Collision System uses laser sensors and camera

sensor to help detect a

vehicle or pedestrian in front of your vehicle.

As there is a limit to the degree of recognition accuracy and control performance

that this system can provide, do not overly rely on this system. This system will not

prevent collisions or lessen collision damage or injury in every situation. Do not use

PCS instead of normal braking operations under any circumstances. Do not attempt to

test the operation of the pre-collision system yourself, as the system may not operate

or engage, possibly leading to an accident. In some situations, such as when driving

in inclement weather such as heavy rain, fog, snow or a sandstorm or while driving on

a curve and for a few seconds after driving on a curve, a vehicle may not be detected

by the laser and camera sensors, preventing the system from operating or engaging

properly.

Refer to a Toyota Owner’s Manual for a list of additional situations in which the

system may not operate properly.

Pre-Collision Warning

When the system determines that the possibility of a frontal collision is high, a buzzer

will sound and a warning message will be displayed on the Multi-Information Display

(MID) to urge the driver to take evasive action.

Pre-Collision Brake Assist

If the driver notices the hazard and brakes, the system may provide additional braking

force using Brake Assist. This system may prime the brakes and may apply greater

braking force in relation to how strongly the brake pedal is depressed.

Pre-Collision Braking

If the driver does not brake in a set time and the system determines that the possibility

of a frontal collision with a preceding vehicle is extremely high, the system may

automatically apply the brakes, reducing speed in order to help the driver reduce the

impact and in certain cases avoid the collision.

Refer to the Toyota Owner’s Manual for additional information on PCS w/PD

operation, settings adjustments, limitations, and precautions before attempting to

use it.

TOYOTA SAFETY SENSE™

PEDESTRIAN DETECTION FUNCTION

In certain conditions, the PCS system included with the TSS-C package may also

help to detect a pedestrian in front of your vehicle. With Toyota Safety Sense™ C,

PCS uses an in-vehicle camera and lasers to help detect a pedestrian in front of your

vehicle in certain conditions. The system of PCS detects a potential pedestrian based

on size, profile, and motion of the detected pedestrian. However, a pedestrian may

not be detected depending on the conditions, including the surrounding brightness

and the motion, posture and angle of the potential detected pedestrian, preventing the

system from operating or engaging. Refer to a Toyota Owner’s Manual for additional

information.

Monocular camera sensor

Lasers

As part of the Pre-Collision System, this function is also designed to first provide an

alert and then automatic braking if needed.

CHANGING PCS ALERT TIMING

Far

Middle

(default)

Near

Each time the PCS switch is pressed, the response to the PCS alert timing changes.

Note: PCS is enabled each time the engine switch is turned to Ignition On.

The system can be disabled/enabled and the alert timing of the system can be

changed. (Alert timing only, brake operation remains the same).

DISABLING PRE-COLLISION SYSTEM (PCS)

To disable the system

Press the PCS switch for 3 seconds or more.

The

will turn on and a message will be displayed on the

Multi-Information Display (MID).

To enable the system

Press the PCS switch again. The system is enabled.

Note: PCS is enabled each time the engine switch is turned to Ignition On.

The system can be disabled/enabled and the alert timing of the system can be

changed. (Alert timing only, brake operation remains the same).

Refer to a Toyota Owner’s Manual for additional information on PCS w/PD

operation, settings adjustments, limitations, and precautions before attempting to

use it.

Lane Departure Alert (LDA)

LDA in TSS-C uses an in-vehicle camera designed to detect visible white and yellow

lane markers in front of the vehicle and the vehicle’s position on the road. If the system

determines that the vehicle is

starting to unintentionally deviate from its lane, the system

alerts the driver with an audio and visual alert. When the alerts occur, the driver must

check the surrounding road situation and carefully operate the steering wheel to move

the vehicle back to the center part of their lane.

LDA is designed to function at speeds of approximately 32 MPH or higher on relatively

straight roadways.

TOYOTA SAFETY SENSE™

TURNING ON THE LDA SYSTEM

Press the LDA switch to turn the LDA system on. Depress again to turn it off.

Note: Operation of the LDA system and setting adjustments continues in the

same condition regardless of Ignition cycle until changed by the driver or the

system is reset.

Refer to the Toyota Owner’s Manual for additional information on LDA operation,

settings adjustments, limitations, and precautions before attempting to use it.

LANE DEPARTURE ALERT

The LDA function displays when the Multi-Information Display (MID) is switched to the

driving assist system information screen.

LDA function display

Lane markers

Lane Departure Alert (LDA) indicator flashes orange when operating.

The system displays solid white lines

The system displays outlines on the

on the LDA indicator when visible lane

LDA indicator when lane markers on the

markers on the road are detected. A

road are not detected or the function is

side flashes orange to alert the driver

temporarily cancelled.

when the vehicle deviates from its lane.

Note: When operation conditions are no longer met, a function may be

temporarily canceled. However, when the operation conditions are met again,

operation of the function is automatically restored. For example, LDA may not

function on the side(s) where white/yellow lines are not detectable.

Refer to the Toyota Owner’s Manual for additional information on LDA operation,

settings adjustments, limitations, and precautions before attempting to use it.

Automatic High Beams (AHB)

(1)

(2)

AHB is a safety system designed to help drivers see more of what’s ahead at nighttime

and reduce glare for oncoming drivers. When enabled, AHB uses an in-vehicle camera

to help detect the headlights of oncoming vehicles and tail lights of preceding vehicles,

then automatically switches between high and low beams as appropriate to provide

the most light possible and enhance forward visibility. By using high beams more

frequently, the system may allow earlier detection of pedestrians and obstacles.

Refer to the Toyota Owner’s Manual for additional information on AHB operation,

settings adjustments, limitations, and precautions before attempting to use it.

ACTIVATING THE AHB SYSTEM

With the engine switch in IGNITION ON mode and headlight switch turned to

position, push lever away from you.

The

will come on when the headlights are turned on automatically to indicate

that the system is active.

Note: Pull the lever back toward you to turn the AHB system off.

The

will turn off and the high beam indicator turns on.

CONDITIONS WHERE AHB WILL TURN ON/OFF AUTOMATICALLY

When all of these conditions are met, high beams will be automatically turned on

(after approximately 1 second):

• Vehicle speed is above approximately 21 mph (33 km/h).

• The area ahead of the vehicle is dark.

• There are no oncoming or preceding vehicles with headlights or tail lights turned on.

• There are few streetlights on the road ahead.

If any of these conditions occur, high beams will be automatically turned off:

• Vehicle speed drops below approximately 17 mph (27 km/h).

• The area ahead of the vehicle is not dark.

• Oncoming or preceding vehicles have headlights or tail lights turned on.

• There are many streetlights on the road ahead.

SAFETY & EMERGENCY FEATURES

Seat belts

Take up slack

Too high

Keep as low on

hips as possible

NOTE: If a passenger’s seat belt is fully extended, then retracted even slightly,

the Automatic Locking Retractor (ALR) will prevent it from being re-extended

beyond that point, unless fully retracted again. This feature is used to help

hold child restraint systems securely.

To find more information about seat belts, and how to install a child restraint system,

refer to the Owner’s Manual.

Tire Pressure Monitoring (warning) System (TPMS)

System reset initialization

1. Push and hold “ SET” button until the

indicator blinks three times.

2. Wait a few minutes to allow initialization to

complete.

After adjusting tire pressures, or after tires have been rotated or replaced, turn

the “POWER”/ignition switch “ON” and press and hold the “ SET” button until

indicator blinks three times. Let the vehicle sit for a few minutes to allow initialization

to complete.

Refer to the load label on the door jamb or the Owner’s Manual for tire inflation

specifications.

If the tire pressure indicator flashes for more than 60 seconds and then remains on,

take the vehicle to your local Toyota dealer.

NOTE: The warning light may come on due to temperature changes or

changes in tire pressure from natural air leakage. If the system has not been

initialized recently, setting the tire pressures to factory specifications should

turn off the light.

Rear door child safety locks

Rear door

Lock

Moving the lever to the lock position will allow the

door to be opened only from the

outside.

Spare tire & tools

Tool location

Luggage

floor cover

Jack1

Spare wheel

cushions

Spare tire

Tool bag2

For detailed directions on removing the jack from under the driver’s seat, refer to

the Owner’s Manual.

Jack handle, wheel nut wrench and towing eyelet

Removing the spare tire

Refer to the Owner’s Manual for tire changing and jack positioning procedures.

SAFETY & EMERGENCY FEATURES

Star Safety System™

Your vehicle comes standard with the Star Safety SystemTM, which combines Anti-

lock Braking System (ABS), Brake Assist (BA), Electronic Brake-force Distribution

(EBD), Smart Stop Technology (SST), Traction Control (TRAC) and Vehicle Stability

Control (VSC),

Refer to the Owner’s Manual for more details and important information on limitations

to these systems.

ANTI-LOCK BRAKE SYSTEM (ABS)

Toyota’s ABS sensors detect which wheels are locking up and limits wheel lockup

by “pulsing” each wheel’s brakes independently. Pulsing releases brake pressure

repeatedly for fractions of a second. This helps the tires attain the traction that

current road conditions will allow, helping you to stay in directional control.

BRAKE ASSIST (BA)

Brake Assist is designed to detect sudden or “panic” braking, and then add braking

pressure to help decrease the vehicle’s stopping distance. When there’s only a split

second to react, Brake Assist can add additional brake pressure more quickly than

just the driver alone can.

ELECTRONIC BRAKE FORCE DISTRIBUTION (EBD)

Toyota’s ABS technology has Electronic Brake-force Distribution (EBD) to help

maintain control and balance when braking. EBD responds to sudden stops by

redistributing brake force to enhance the braking effectiveness of all four wheels.

SMART STOP TECHNOLOGY (SST)

Smart Stop Technology automatically reduces engine power when the accelerator

and brake pedals are pressed simultaneously under certain conditions.

SST engages when the accelerator is depressed first and the brakes are applied

firmly for longer than one-half second at speeds greater than five miles per hour.

SST doesn’t engage if the brake pedal is depressed before the accelerator pedal,

allowing vehicles to start on a steep hill and safely accelerate without rolling

backward.

VEHICLE STABILITY CONTROL (VSC)

VSC helps prevent loss of traction during cornering by reducing engine power and

applying brake force to selected wheels.

Toyota’s VSC monitors steering angle and the direction your vehicle is traveling.

When it senses that the front or rear wheels begin to lose traction, VSC reduces

engine power and applies braking to selected wheels. This helps restore traction

and vehicle control.

TRACTION CONTROL (TRAC)

VSC helps prevent loss of traction during cornering by reducing engine power, and

Traction Control helps maintain traction on loose gravel and wet, icy, or uneven

surfaces by applying brake force to the spinning wheel(s).

Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip.

TRAC limits engine output and applies the brakes to the spinning wheel. This

transfers power to the wheels that still have traction to help keep you on track.

Floor mat installation

There are two types of Toyota floor mats: carpeted and all-weather. Each vehicle

has model-specific floor mats. Installation is easy.

To keep your floor mat properly positioned, follow these steps:

• Only use Toyota floor mats designed for your specific model.

• Use only one floor mat at a time, using the retaining hooks to keep the mat in

place.

• Install floor mats right side up.

Always align the Δ marks

BLUETOOTH® DEVICE PAIRING

SECTION

Do not attempt the Bluetooth® Pairing process while driving.

Content .. 1 2 3 ..
