Toyota Sequoia (2018 year). Instruction - part 23

5-3. Using the storage features

SEQUOIA_OM_USA_OM0C011U



Type A

Pull the lever upwards to lift the
deck board.



Type B (if equipped)

Open the cover.

Storage compartment

354

SEQUOIA_OM_USA_OM0C011U

WARNING

■

When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.

■

Caution while driving
Keep the auxiliary box closed. Injuries may result in the event of an accident
or sudden braking.

NOTICE

■

To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on them.

■

Grocery bag hook weight capacity
Do not hang any object heavier than 8.8 lb. (4 kg) on the grocery bag hooks.

355

SEQUOIA_OM_USA_OM0C011U

Other interior features

■

Main visor

To set the visor in the forward
position, flip it down.

To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.

To use the side extender, place
the visor in the side position,
then slide it backward.

■

Sub visor (if equipped)

Flip it down.

Sun visors

356

SEQUOIA_OM_USA_OM0C011U



Vehicles without vanity light

Open the cover.



Vehicles with vanity light

Open the cover.

The light turns on when the cover
is opened.

Adjust the brightness of the
light.

Vanity mirrors

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended
periods while the engine is not running.

357

SEQUOIA_OM_USA_OM0C011U

■

12 V DC

Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).

When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.

Power outlets



Instrument panel



Front console box (outside)
(if equipped)

Open the lid.



Luggage compartment

Open the lid.

358

SEQUOIA_OM_USA_OM0C011U



Front console box (inside)

Lift the lid while pulling up the
knob to release the lock.

Open the lid.

■

120 V AC (if equipped)

Accessories that use less than 100 W.

Open the lid.

359

SEQUOIA_OM_USA_OM0C011U

■

The power outlets can be used when



12 V DC

The engine switch is in the “ACC” or “ON” position.



120 V AC

The engine switch is in the “ON” position.

NOTICE

●

To avoid damaging the power outlets, close the power outlet lid when the
power outlet is not in use.

Foreign objects or liquids that enter the power outlet may cause a short
circuit.

●

To prevent blown fuse:



12 V DC

Do not use an accessory that uses more than 12 V 10 A.



120 V AC

Do not use a 120 V AC appliance that requires more than 100 W.

If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.

●

To prevent battery discharge, do not use the power outlet longer than nec-
essary when the engine is not running.

●

The following 120 V AC appliances may not operate properly even if their
power consumption is under 100 W:

• Appliances with high initial peak wattage
• Measuring devices that process precise data
• Other appliances that require an extremely stable power supply

360

SEQUOIA_OM_USA_OM0C011U

Push the lid.

The mirror can be adjusted by
pushing the mirror edge.

Conversation mirror

WARNING

■

Caution while driving
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident, resulting
in death or serious injury.

361

SEQUOIA_OM_USA_OM0C011U



Separated type

Adjusting to the desired angle:

Lower the armrest from the
highest position to the lowest
position.

Raise the armrest to the
desired angle.

Unlock the armrest:
Lift the armrest to raise it to the
highest position.



Bench type

Pull the armrest down for use.

Armrest (second seats)

NOTICE

To prevent damage to the armrest, do not apply too much load or sit on the
armrest.

362

SEQUOIA_OM_USA_OM0C011U

Pull the tab up.

Hook the sunshade onto the anchors.

To lower the sunshade, pull the tab slightly to unhook the shade, and lower
it slowly.

Rear side sunshades (if equipped)



Rear door window



Rear quarter window

NOTICE

●

To ensure normal operation of the sunshade, observe the following pre-
cautions.

• Do not place anything where it may hinder the opening/closing of the

sunshade.

• Do not place anything on the sunshade.

363

SEQUOIA_OM_USA_OM0C011U

An assist grip (type A) installed on the ceiling can be used to support
your body while sitting on the seat.

An assist grip (type B) installed on the pillar can be used when getting
in or out of the vehicle and others.

Assist grip (type A)

Assist grip (type B)

Assist grips

WARNING

Do not use the assist grip (type A) when getting in or out of the vehicle or
rising from your seat.

NOTICE

To prevent damage to the assist grip, do not hang any heavy object or put a
heavy load on the assist grip.

364

SEQUOIA_OM_USA_OM0C011U

Garage door opener

∗

The HomeLink

wireless control system in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming methods on the following pages to determine the
method which is appropriate for the device.

HomeLink

indicator light

Garage door operation indica-
tors

Buttons

■

Before programming the HomeLink

● During programming, it is possible that garage doors, gates, or

other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

● It is recommended that a new battery be placed in the remote

control transmitter for more accurate programming.

● Garage door opener motors manufactured after 1995 may be

equipped with rolling code protection. If this is the case, you may
need a stepladder or other sturdy, safe device to reach the
“Learn” or “Smart” button on the garage door opener motor.

∗

: If equipped

The garage door opener can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting systems,
security systems, and other devices.

HomeLink

365

SEQUOIA_OM_USA_OM0C011U

■

Programming the HomeLink

Steps

through

must be performed within 60 seconds, otherwise

the indicator light will stop flashing and programming will not be able to be
completed.

Press and release the HomeLink

button you want to program

and check that the HomeLink

indicator light flashes orange.

Point the remote control
transmitter for the device at
the rear view mirror, 1 to 3 in.
(25 to 75 mm) from the
HomeLink

buttons.

Keep the HomeLink

indicator

light in view while programming.

Program a device.



Programming a device other than an entry gate (for U.S.A.
owners)

Press and hold the remote control transmitter button until the
HomeLink

indicator light changes from slowly flashing orange to

rapidly flashing green (rolling code) or continuously lit green
(fixed code), then release the button.



Programming an entry gate (for U.S.A. owners)/Programming
a device in the Canadian market

Press and release the remote control transmitter button at 2 sec-
ond intervals, repeatedly, until the HomeLink

indicator light

changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code).

366

SEQUOIA_OM_USA_OM0C011U

Test the HomeLink

operation by pressing the newly pro-

grammed button and observing the indicator light:

● Indicator light illuminates: Programming of a fixed code device

has completed. The garage door or other device should operate
when a HomeLink

button is pressed and released.

● Indicator light flashes rapidly: The garage door opener motor or

other device is equipped with a rolling code. To complete pro-
gramming, firmly press and hold the HomeLink

button for 2 sec-

onds then release it.

● If the garage door or other device does not operate, proceed to

“Programming a rolling code system”.

Repeat the steps above to program another device for any of
the remaining HomeLink

buttons.

■

Programming a rolling code system

2 or more people may be necessary to complete rolling code pro-
gramming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is attached to the unit. The
name and color of the button
may vary by manufacturer.
Refer to the Owner’s manual
supplied with the garage door
opener motor for details.

Press and release the
“Learn” or “Smart” button.

Perform

within 30 sec-

onds after performing

367

SEQUOIA_OM_USA_OM0C011U

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence (press/hold/
release) up to 3 times to
complete programming.

If the garage door opener
motor operates when the
HomeLink

button is

pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)

When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of a garage door through indicators
in your vehicle.

2-way communication is only available if the garage door opener
motor used is a compatible device. (To check device compatibility,
refer to www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has
been completed, if the garage door opener motor is trained to
HomeLink

, both garage door operation indicators will flash rap-

idly green and the light on the garage door opener motor will
blink twice, indicating that 2-way communication is enabled.

If the indicators do not flash, perform

and

within the first 10

presses of the HomeLink

button after programming has been

completed.

368
