Safety

Deactivating the passenger front

To assure the safety of your child,

Lateral airbags

airbag

the passenger front airbag must be

Only the passenger front airbag can be

deactivated when you install a rearward

deactivated.

facing child seat on the front passenger

seat.

Otherwise, the child would risk being

seriously injured or killed if the airbag

were deployed.

Reactivating the passenger front

airbag

If fitted to your vehicle, this is a system which

When you remove the child seat, with the

protects the driver and front passenger in the

ignition off, turn the switch to the "ON"

event of a serious side impact in order to limit

position to reactivate the airbag and so assure

the risk of injury to the chest, between the

the safety of your front passenger(s) in the

abdomen and head.

event of an impact.

Each lateral airbag is fitted in the seat backrest

F

With the ignition off, insert the key in the

When the ignition is switched on,

frame, door side.

passenger airbag deactivation switch.

this warning lamp comes on in the

F

Turn it to the "OFF" position.

seat belt warning display screen for

Deployment

F

Remove the key keeping the switch in the

approximately one minute to signal

The lateral airbags are deployed unilaterally in

new position.

that the front airbag is activated.

the event of a serious side impact applied to all

or part of the side impact zone, perpendicular

When the ignition is on, this warning

Operating fault

to the longitudinal centreline of the vehicle on a

lamp comes in the seat belt warning

If this warning lamp comes on in the

horizontal plane and directed from the outside

display screen. It stays on while the

instrument panel, you must contact

towards the inside of the vehicle.

airbag is deactivated.

an authorized Toyota dealer or

The lateral airbag inflates between the

repairer, or another duly qualified and

equipped professional to have the

abdomen and head of the front occupant of the

system checked. The airbags may no

vehicle and the corresponding door trim panel.

longer be deployed in the event of a

serious impact.

170

Safety

Curtain airbags (row 2 and 3)

If fitted to your vehicle, this is a system that

Operating fault

contributes towards greater protection for the

If this warning lamp comes on in the

passengers (with the exception of the centre

instrument panel, you must contact an

seats) in the event of a serious side impact in

authorized Toyota dealer or repairer,

order to limit the risk of injury to the side of the

or another duly qualified and equipped

head.

professional to have the system

Each curtain airbag is built into the pillars and

checked.

the upper passenger compartment area.

The airbags may no longer be deployed in the

Deployment

event of a serious impact.

In the event of a minor impact or bump

on the side of the vehicle or if the

5

vehicle rolls over, the airbags may not

be deployed.

In the event of a rear or front collision,

none of the lateral airbags is deployed.

The curtain airbag is deployed in the event

of a serious side impact applied to all or part

of the side impact zone B, perpendicular to

the longitudinal centreline of the vehicle on a

horizontal plane and directed from the outside

towards the inside of the vehicle.

The curtain airbag inflates between the outer

rear occupant of the vehicle and the windows.

171

Safety

Advice

For the airbags to be fully effective, observe the safety

Lateral airbags

recommendations below:

Use only approved covers on the seats,

compatible with the deployment the lateral

Sit in a normal upright position.

The bag inflates almost instantly (within

airbags. For information on the range of

Wear a correctly adjusted seat belt.

a few milliseconds) then deflates within

seat covers suitable for your vehicle, you

Do not leave anything between the

the same time discharging the hot gas via

can contact an authorized Toyota dealer

occupants and the airbags (a child, pet,

openings provided for this purpose.

or repairer, or another duly qualified and

object...), nor fix or attach anything close to

equipped professional.

the inflation trajectory of the airbags; this

For more information on Accessories, refer

could cause injuries during their deployment.

to the corresponding section.

Never modify the original definition of your

Do not fix or attach anything to the seat

vehicle, particularly in the area directly

Front airbags

backs (clothing...). This could cause injury

around the airbags.

to the chest or arms if the lateral airbag is

After an accident or if the vehicle has been

Do not drive holding the steering wheel by its

deployed.

stolen or broken into, have the airbag

spokes or resting your hands on the centre

Do not sit with the upper part of the body any

systems checked.

part of the wheel.

nearer to the door than necessary.

All work on the airbag system must be

Passengers must not place their feet on the

carried out by an authorized Toyota dealer

dashboard.

or repairer, or another duly qualified and

Do not smoke as deployment of the airbags

Curtain airbags

equipped professional.

can cause burns or the risk of injury from a

Even if all of the precautions mentioned are

cigarette or pipe.

Do not fix or attach anything to the roof. This

observed, a risk of injury or of minor burns

Never remove or pierce the steering wheel or

could cause injury to the head if the curtain

to the head, chest or arms when an airbag is

hit it violently.

airbag is deployed.

deployed cannot be ruled out.

Do not fit or attach anything to the steering

If fitted on your vehicle, do not remove the

wheel or dashboard, this could cause

grab handles installed on the roof, they play

injuries with deployment of the airbags.

a part in securing the curtain airbags.

172

Safety

General points relating to child seats

Although one of Toyota's main criteria when designing your vehicle, the safety of your children also

depends on you.

For maximum safety, please observe the

Toyota recommends that children

following recommendations:

should travel on the rear seats of your

-

in accordance with European regulations,

vehicle:

all children under the age of 12 or less

-

rearward facing up to the age of 3,

than one and a half metres tall must

-

forward facing over the age of 3.

travel in approved child seats suited to

their weight, on seats fitted with a seat

belt or ISOFIX mountings*,

-

statistically, the safest seats in your

vehicle for carrying children are the

5

rear seats,

-

a child weighing less than 9 kg must

travel in the rearward facing position

both in the front and in the rear.

* The regulations on carrying children are

specific to each country. Refer to the

legislation in force in your country.

173

Safety

Child seat at the rear

Rearward facing

Forward facing

Row 3

When a rearward facing child seat is installed

When a forward facing child seat is installed

If fitted to your vehicle, when a child seat is

on a rear passenger seat, move the vehicle's

on a rear passenger seat, move the vehicle's

installed on a passenger seat in the 3rd row,

front seat forward and straighten the backrest

front seat forward and straighten the backrest

move the seats in the 2nd row forward and

so that the rearward facing child seat does not

so that the legs of the child in the forward

straighten the backrests so that the child seat

touch the vehicle's front seat.

facing child seat do not touch the vehicle's front

and the child's legs do not touch the seats in

Adjust the rear seat to the fully back position,

seat.

the 2nd row.

with the backrest straightened.

Adjust the rear seat to the fully back position,

with the backrest straightened.

Ensure that the seat belt is correctly

tensioned.

For child seats with a support leg,

ensure that this is in firm contact with

the floor. If necessary, adjust the front

seat of the vehicle.

174

Safety

Child seat at the front*

Rearward facing

Forward facing

5

When a rearward facing child seat is installed

When a forward facing child seat is installed on

Passenger seat in the fully back and

on the front passenger seat, adjust the seat

the front passenger seat, adjust the vehicle's

highest position.

to the fully back and highest position, with the

seat to the fully back and highest position with

backrest straightened.

the seat backrest straightened and leave the

The passenger's front airbag must be

passenger's front airbag activated.

deactivated. Otherwise, the child risks being

seriously injured or killed if the airbag is

deployed.

Ensure that the seat belt is correctly

tensioned.

For child seats with a support leg,

ensure that the support leg is in firm

* Refer to the legislation in force in your country

and stable contact with the floor. If

before carrying your child in this seating

necessary, adjust the passenger seat.

position.

175

Safety

Passenger airbag OFF

Deactivating the passenger front airbag

Never install a rearward facing child

restraint system on a seat protected by

an active front airbag.

This could cause the death of the child

or serious injury.

For more information on the Airbags,

refer to the corresponding section.

The warning label present on both sides of the

passenger sun visor repeats this advice.

In line with current legislation, the following

tables contain this warning in all of the

languages required.

176

Safety

AR

BG

НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да причини

СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето.

CS

NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí

nebezpečí SMRTI DÍTĚTE nebo VÁŽNÉHO ZRANĚNÍ.

DA

Brug ALDRIG en bagudvendt barnestol på et sæde, der er beskyttet af en AKTIV AIRBAG. BARNET risikerer at blive ALVORLIGT

K VÆSTET eller DR ÆBT.

DE

Montieren Sie auf einem Sitz mit AKTIVIERTEM Front-Airbag NIEMALS einen Kindersitz oder eine Babyschale entgegen der

Fahrtrichtung, das Kind könnte schwere oder sogar tödliche Verletzungen erleiden.

EL

Μη χρησιμοποιείτε ΠΟΤΕ παιδικό κάθισμα με την πλάτη του προς το εμπρός μέρος του αυτοκινήτου, σε μια θέση που προστατεύεται από

ΜΕΤΩΠΙΚΟ αερόσακο που είναι ΕΝΕΡΓΟΣ. Αυτό μπορεί να έχει σαν συνέπεια το ΘΑΝΑΤΟ ή το ΣΟΒΑΡΟ ΤΡΑΥΜΑΤΙΣΜΟ του ΠΑΙΔΙΟΥ

EN

NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the

CHILD can occur

ES

NO INSTALAR NUNCA un sistema de retención para niños de espaldas al sentido de la marcha en un asiento protegido mediante un

AIRBAG frontal ACTIVADO, ya que podría causar lesiones GRAVES o incluso la MUERTE del niño.

5

ET

Ärge MITTE KUNAGI paigaldage “seljaga sõidusuunas“ lapseistet juhi kõrvalistmele, mille ESITURVAPADI on AKTIVEERITUD.

Turvapadja avanemine võib last TÕSISELT või ELUOHTLIKULT vigastada.

FI

ÄLÄ KOSKAAN aseta lapsen turvaistuinta selkä ajosuuntaan istuimelle, jonka edessä suojana on käyttöön aktivoitu TURVATYYNY. Sen

laukeaminen voi aiheuttaa LAPSEN KUOLEMAN tai VAKAVAN LOUKKAANTUMISEN.

FR

NE JAMAIS installer de système de retenue pour enfants faisant face vers l’arrière sur un siège protégé par un COUSSIN GONFLABLE

frontal ACTIVÉ.

Cela peut provoquer la MORT de l’ENFANT ou le BLESSER GRAVEMENT

HR

NIKADA ne postavljati dječju sjedalicu leđima u smjeru vožnje na sjedalo zaštićeno UKLJUČENIM prednjim ZRAČNIM JASTUKOM. To bi

moglo uzrokovati SMRT ili TEŠKU OZLJEDU djeteta.

HU

SOHA ne használjon menetiránynak háttal beszerelt gyermekülést AKTIVÁLT (BEKAPCSOLT) FRONTLÉGZSÁKKAL védett ülésen. Ez a

gyermek HALÁLÁT vagy SÚLYOS SÉRÜLÉSÉT okozhatja.

IT

NON installare MAI seggiolini per bambini posizionati in senso contrario a quello di marcia su un sedile protetto da un AIRBAG frontale

ATTIVATO. Ciò potrebbe provocare la MORTE o FERITE GR AVI al bambino.

LT

NIEKADA neįrenkite vaiko prilaikymo priemonės su atgal atgręžtu vaiku ant sėdynės, kuri saugoma VEIKIANČIOS priekinės ORO

PAGALVĖS. Išsiskleidus oro pagalvei vaikas gali būti MIRTINAI arba SUNKIAI TR AUMUOTAS.

177

Safety

LV

NEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS priekšējais DROŠĪBAS GAISA

SPILVENS.

Tas var izraisīt BĒRNA NĀVI vai radīt NOPIETNUS IEVAINOJUMUS.

MT

Qatt m’ghandek thalli tifel/tifla marbut f’siggu dahru lejn l-Airbag attiva, ghaliex tista’ tikkawza korriment serju jew anke mewt lit-tifel/tifla

NL

Plaats NOOIT een kinderzitje met de rug in de rijrichting op een zitplaats waarvan de AIRBAG is INGESCHAKELD. Bij het afgaan van de

airbag kan het KIND LEVENSGEVAARLIJK GEWOND RAKEN

NO

Installer ALDRI et barnesete med ryggen mot kjøreretningen i et sete som er beskyttet med en frontal AKTIVERT KOLLISJONSPUTE,

BARNET risikerer å bli DREPT eller HARDT SKADET.

PL

NIGDY nie instalować fotelika dziecięcego w pozycji "tyłem do kierunku jazdy" na siedzeniu wyposażonym w CZOŁOWĄ PODUSZKĘ

POWIETRZNĄ w stanie AKTYWNYM. Może to doprowadzić do ŚMIERCI DZIECKA lub spowodować u niego POWAŻNE OBRAŻENIA

CIAŁA.

PT

NUNCA instale um sistema de retenção para crianças de costas para a estrada num banco protegido por um AIRBAG frontal ACTIVADO.

Esta instalação poderá provocar FERIMENTOS GRAVES ou a MORTE da CRIANÇA.

RO

Nu instalati NICIODATA un sistem de retinere pentru copii, dispus cu spatele in directia de mers, pe un loc din vehicul protejat cu AIRBAG

frontal ACTIVAT. Aceasta ar putea provoca MOARTEA COPILULUI sau RANIREA lui GRAVA.

RU

ВО ВСЕХ СЛУЧАЯХ ЗАПРЕЩАЕТСЯ использовать обращенное назад детское удерживающее устройство на сиденье,

защищенном ФУНКЦИОНИРУЮЩЕЙ ПОДУШКОЙ БЕЗОПАСНОСТИ, установленной перед этим сиденьем.

Это может привести к ГИБЕЛИ РЕБЕНКА или НАНЕСЕНИЮ ЕМУ СЕРЬЕЗНЫХ ТЕЛЕСНЫХ ПОВРЕЖДЕНИЙ

SK

NIKDY neinštalujte detské zádržné zariadenie orientované smerom dozadu na sedadlo chránené AKTIVOVANÝM čelným AIRBAGOM.

Mohlo by dôjsť k SMRTEĽNÉMU alebo VÁŽNEMU PORANENIU DIEŤAŤA.

SL

NIKOLI ne nameščajte otroškega sedeža s hrbtom v smeri vožnje, če je VARNOSTNA BLAZINA pred sprednjim sopotnikovim sedežem

AKTIVIRANA. Takšna namestitev lahko povzroči SMRT OTROKA ali HUDE POŠKODBE.

SR

NIKADA ne koristite dečje sedište koje se okreće unazad na sedištu zaštićenim AKTIVNIM VAZDUŠNIM JASTUKOM ispred njega, jer

mogu nastupiti SMRT ili OZBILJNA POVREDA DETETA.

SV

Passagerarkrockkudden fram MÅSTE vara avaktiverad om en bakåtvänd bilbarnstol installeras på denna plats. Annars riskerar barnet att

DÖDAS eller SKADAS ALLVARLIGT.

TR

KESİNLKLE HAVA YASTIĞI AKTİF olan ön koltuğa yüzü arkaya dönük bir çocuk koltuğu yerleştirmeyiniz. Bu ÇOCUĞUN ÖLMESİNE veya

ÇOK AĞIR YARALANMASINA sebep olabilir.

178

Safety

Child seats recommended by Toyota

Toyota offers a range of child seats which are secured using a three point seat belt.

Group 0+: from birth to 13 kg

5

L1

"TOYOTA GO + BABYSAFE PLUS"

Installed rearward facing.

179

Safety

Groups 2 and 3: from 15 to 36 kg

L5

"TOYOTA KIDIFIX XP SICT"

L6

Can be fitted to the vehicle's ISOFIX

"TOYOTA DUO PLUS"

mountings.

The child is restrained by the seat belt.

The child is restrained by the seat belt.

180

Safety

Locations for child seats secured with a seat belt

In line with European legislation, this table indicates the options for installing child seats secured using a seat belt and universally approved (a) for the

weight of the child and the seat in the vehicle.

Weight of the child and indicative age

Under 13 kg

From 9 to 18 kg

From 15 to 25 kg

From 22 to 36 kg

Seat

(groups 0 (b)

(group 1)

(group 2)

(group 3)

and 0+)

1 to 3 years

3 to 6 years

6 to 10 years

Up to approx 1 year

approx

approx

approx

With captain seat,

U

U

U

U

passenger seat

With bench seat,

5

Row 1 (c) (d)

U

U

U

U

outer seat

With bench seat,

X

X

X

X

centre seat

Outer seats

U

U

U

U

Row 2 (e) (f)

Centre seat

U

U

U

U

Outer seats

U

U

U

U

Row 3 (e) (f)

Centre seat

U

U

U

U

181

Safety

(a)

Universal child seat: child seat that can be

U

Seat suitable for the installation of a child

Remove and stow the head restraint

installed in any vehicle using the seat belt.

seat secured using the seat belt and

before installing a child seat with

(b)

Group 0: from birth to 10 kg. Infant car

universally approved, rearward facing and/

backrest on a passenger seat.

seats and "car cots" cannot be installed on

or forward facing.

Refit the head restraint once the child

the front passenger seat.

X

Seat not suitable for the installation of a

seat has been removed.

(c)

Consult the legislation in force in your

chld seat of the weight group indicated.

country before installing your child on this

seat.

(d)

When a rearward facing child seat is

installed on the front passenger seat,

the front passenger airbag must be

deactivated. Otherwise the child risks

being seriously injured or even killed if the

airbag is deployed.

When a forward facing child seat is

installed on the front passenger seat, the

front passenger airbag must remain active.

(e)

To install a child seat on a rear seat, move

the seat in front forward, then straighten

the backrest to leave sufficient space for

the child seat and the child's legs.

(f)

To install a child seat on a rear seat,

rearward facing or forward facing, adjust

the rear seat to the fully back position with

the backrest straightened.

182

Safety

"ISOFIX" mountings

This ISOFIX mounting system provides fast,

-

fix the hook on the end of the upper strap

reliable and safe fitting of the child seat in your

to the rear ring B,

5

vehicle.

-

tighten the upper strap.

Your vehicle has been approved to the latest

The ISOFIX child seats are fitted with two

ISOFIX regulation.

latches which are secured on the two front

If fitted on your vehicle, the regulation ISOFIX

rings A.

mountings are located by labels.

Some also have an upper strap which is

The incorrect installation of a child seat

The mountings comprise three rings for each

attached to the rear ring B.

in a vehicle compromises the child's

seat:

To secure the child seat to the Top Tether:

protection in the event of an accident.

-

Two front rings A, located between

-

remove and stow the head restraint before

the vehicle seat backrest and cushion,

Observe strictly the fitting instructions

installing a child seat on this seat (refit it

indicated by an "ISOFIX" marking,

provided with the child seat.

once the child seat has been removed),

-

If fitted to your vehicle, a rear ring B,

-

pass the child seat upper strap over the

located behind the vehicle's seat, called

top of the seat backrest, between the

the Top Tether, for securing the upper

apertures for the head restraint rods,

strap, indicated by a "Top Tether" marking.

For information on the possibilities for

The Top Tether is used to secure the upper

installing ISOFIX child seats in your

strap of child seats that have one. In the event

vehicle, refer to the locations table.

of a front impact, this system limits the forward

tipping of the child seat.

183

Safety

ISOFIX child seats recommended by Toyota

Toyota offers a range of ISOFIX child seats listed and type approved for your vehicle.

Refer also to the child seat manufacturer's fitting instructions for information on installing and removing the seat.

"TOYOTA GO + BABYSAFE PLUS"

and its ISOFIX base

(size category: E)

Group 0+: from birth to 13 kg

Installed rearward facing using an ISOFIX

base which is attached to the rings A.

The base has a support leg, adjustable for

height, which sits on the vehicle's floor.

This child seat can also be secured with a

seat belt. In this case, only the shell is used

and attached to the vehicle's seat by the

three-point seat belt.

184

Safety

TOYOTA DUO PLUS

(size category: B1)

Group 1: from 9 to 18 kg

Is installed only in the forward facing

position.

5

Is attached to the rings A and the upper

ring B, referred to as the TOP TETHER,

using an upper strap.

Three seat body angles: sitting, reclining,

lying down.

This child seat can also be used on seats

not equipped with ISOFIX mountings. In

this case, it must be secured to the vehicle's

seat by the three-point seat belt. Adjust the

position of the vehicle's front seat so that the

child's feet are not touching the backrest.

185

Safety

Locations for ISOFIX child seats

In line with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIX mountings.

In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G, is indicated on the child

seat next to the ISOFIX logo.

Weight of the child / indicative age

Less than 10 kg

Less than 10 kg

(group 0)

(group 0)

From 9 to 18 kg (group 1)

Less than 13 kg

Up to approx.

From approx. 1 to 3 years

(group 0+)

6 months

Up to approx. 1 year

Type of ISOFIX child seat

Cot

rearward facing

rearward facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

Row 1 with 2-seat bench seat

Not ISOFIX

or captain seat

Right outer

X

X

IL-SU

X

IUF, IL-SU

seat

Row 2 with

2-seat bench

Centre seat

X

X

IL-SU

X

IUF, IL-SU

seat in row 1

Left outer seat

X

IL-SU

IL-SU

IUF, IL-SU

186
