Access
Locking the rear wing doors with
Remote control problem
Changing the battery
glass windows
Battery ref.: CR1620 / 3 volts.
Following disconnection of the vehicle battery,
F
If fitted to your vehicle, check that the
If the battery is flat, you are
replacement of the remote control battery or
electric child lock is not on.
informed by lighting of this warning
in the event of a remote control malfunction,
F
Open the left-hand door.
lamp in the instrument panel, an audible signal
2
you can no longer unlock, lock or locate your
and a message in the screen.
vehicle.
F First of all, use the key in the lock to unlock
or lock your vehicle.
F Then reinitialise the remote control.
If the problem persists, contact an authorized
Toyota dealer or repairer, or another duly
qualified and equipped professional as soon as
possible.
Reinitialisation
F Lock the driver's door using the
key.
F
Insert the key into the latch aperture on the
F Press one of the remote control
F
Unclip the cover using a screwdriver in the
edge of the door (without forcing) and slide
buttons.
cut-out.
the assembly upward.
F
Remove the cover.
F
Remove the key.
F
Extract the flat battery from its location.
F
Close the door and check from the outside
F
Place the new battery into its location
that it has locked correctly.
observing the original direction.
F
Clip the cover in place.
Unlocking
F Use the interior door handle.
Do not throw the remote control
F Turn the key to position 2 (Ignition on).
batteries away, they contain metals
F Switch off the ignition and remove the key
which are harmful to the environment.
from the ignition switch.
Take them to an approved collection
The remote control is fully operational again.
point.
51
Access
Unlocking
Locking
"Smart Entry & Start
F To unlock the vehicle, press
F To totally lock the vehicle, press
System"
this button.
this button.
If fitted to your vehicle, pressing
With electric sliding door(s)
and holding this button allows the
Remote control
windows to be closed. The window
stops when you release the button.
F To unlock the vehicle
and open the side door,
press and hold this
button until the door has
opened
Ensure that no person or object could
prevent the correct closing of the
windows.
Be particularly aware of children when
Unlocking is signalled by the rapid
operating the windows.
flashing of the direction indicators for
It allows the central locking or unlocking of the
about two seconds.
If a door is not correctly shut (except
vehicle from a distance.
Depending on version, the door mirrors
the right-hand door with rear wing
It is also used to locate and start the vehicle, as
unfold at the same time.
doors with glass windows):
well as providing protection against theft.
-
vehicle stationary and the engine
running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,
-
vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.
52
Access
To deadlock the vehicle.
Driving with the doors locked may make
Power door locking*
access to the passenger compartment by
F Then within five seconds after
the emergency services more difficult in
Power door locking renders the exterior
locking, press this button again.
the event of an emergency.
and interior door controls inoperative.
As a safety measure (children on board),
2
It also deactivates the manual central
never leave the vehicle without your
control button.
If your vehicle is not fitted with an
remote control, even for a short period.
Therefore, never leave anyone inside
alarm, power door locking is signalled
the vehicle when it is power door
by the fixed illumination of the direction
If your vehicle is not fitted with an
locked.
indicators for about two seconds.
alarm, locking is signalled by the fixed
illumination of the direction indicators
for about two seconds.
Depending on version, the door mirrors
fold at the same time.
To lock the vehicle,
F Press this button.
If fitted to your vehicle, pressing
If one of the doors remains open, the
and holding this button allows the
central locking does not take place.
windows to be closed. The window
If the vehicle is inadvertently unlocked,
stops when you release the button.
it will automatically lock itself again
Depending on version, the door mirrors
after about thirty seconds, if no door is
fold at the same time.
opened.
And if fitted to your vehicle, the alarm is
reactivated (with volumetric monitoring,
even if you had deactivated it).
Ensure that no person or object could
prevent the correct closing of the
windows.
The automatic folding and unfolding
Be particularly aware of children when
of the electric door mirrors can be
operating the windows.
deactivated by an authorized Toyota
dealer or repairer, or another duly
qualified and equipped professional.
* If equipped.
53
Access
"Smart Entry & Start
In the ignition on (accessories) position,
The folding and unfolding of the door
System" on your person
with the "START/STOP" button, the
mirrors by the remote control can be
hands-free function is deactivated.
deactivated by an authorized Toyota
For more information on "Smart Entry
dealer or repairer, or another duly
& Start System" and in particular
qualified and equipped professional.
the "ignition on" position, refer to the
corresponding section.
As a safety measure (children on
board), never leave the vehicle without
taking your Smart Entry & Start System
remote control, even for a short period.
The unlocking, locking or power door
Guard against theft when the Smart
locking does not take place:
Entry & Start System remote control is
-
if the ignition is on,
in the recognition zone with the vehicle
-
if one of the doors or the boot is still
This allows the unlocking, locking and starting
unlocked.
open,
the vehicle while keeping the remote control on
In order to preserve the charge of the
-
if the key for the Smart Entry &
your person.
cell battery in the remote control, the
Start System has been left inside
"hands-free" functions go into extended
the vehicle.
stand-by after 21 days of non-use.
When the vehicle is locked (with the
To restore these functions, press one of
remote control or Smart Entry & Start
the remote control buttons or start the
System), if it is unlocked inadvertently, it
engine with the remote control at the
will lock itself again automatically after
reader.
about thirty seconds unless a door has
been opened.
And if your vehicle has an alarm, this
will be reactivated (with volumetric
monitoring, even if this had been
deactivated).
54
Access
Unlocking
With electric sliding slide door(s)
With a rear tailgate
2
F To unlock the vehicle, remote control on
F To unlock the vehicle, remote control
F To unlock the vehicle, remote control on
your person and in the recognition zone A,
on your person and in the recognition
your person and in the recognition zone A,
pass your hand behind one of the door
zone A, pull and release the door handle to
pull the rear tailgate handle.
handles (front doors, manual sliding side
trigger the electric powered opening of the
F Raise the rear tailgate.
doors and rear wing doors with glass
corresponding door.
windows).
F Pull the handle to open the corresponding
door.
55
Access
With an opening rear screen in the tailgate
Locking
With electric sliding side door(s)
F To totally lock the vehicle, with the remote
control in the recognition zone A, press
F To totally lock the vehicle, with the remote
F To unlock the vehicle, remote control on
with a finger or thumb at the markings on
control in the recognition zone A, press
your person and in the recognition zone A,
one of the front or manual sliding side door
with a finger or thumb at the markings on
press the unlocking button for the rear
handles.
one of the front door handles.
tailgate.
The screen partly opens.
If a door is not properly closed
(except the right-hand door with rear
wing doors with glass windows):
-
vehicle stationary and the engine
running, this warning lamp
Unlocking is signalled by the rapid
comes on, accompanied by an
flashing of the direction indicators for
alert message for a few seconds,
about two seconds.
-
vehicle moving (speed above
Depending on version, the door mirrors
6 mph (10 km/h)), this warning
unfold, the alarm is deactivated.
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.
56
Access
With rear wing doors with glass
With a rear tailgate
Ensure that no one might prevent the
windows
correct operation of the windows.
Be particularly aware of children when
operating the windows.
2
If your vehicle is not fitted with an
alarm, locking is confirmed by fixed
illumination of the direction indicators
for about two seconds.
Depending on version, the door mirrors
F To lock the vehicle, with the remote control
F To lock the vehicle, with the remote control
fold at the same time.
in the recognition zone A, press the left-
in the recognition zone A, press the rear
hand door locking control.
tailgate locking control.
If fitted to your vehicle, pressing and
Driving with the doors locked may
holding the locking controls allows
render access for the emergency
the windows to be opened. The
services difficult in an emergency.
window stops when you release the
button.
57
Access
Power door locking*
With electric sliding side door(s)
With rear wing doors with glass
windows
F To totally lock the vehicle, with the remote
F To lock the vehicle, with the remote control
Power door locking renders the exterior
control in the recognition zone A, press
in the recognition zone A, press the left-
and interior door controls inoperative.
with a finger or thumb at the markings on
hand door locking control.
It also deactivates the manual central
one of the front door handles.
F To powerlock the vehicle, press the control
locking button.
F To deadlock the vehicle, press the marking
again within five seconds.
Therefore, never leave anyone inside
again within five seconds.
the vehicle when it is power door
locked.
F To totally lock the vehicle, with the remote
control in the recognition zone A, press
with a finger or thumb at the markings on
one of the front or manual sliding side door
handles.
F To deadlock the vehicle, press the marking
again within five seconds.
* If equipped.
58
Access
With a rear tailgate
Locating your vehicle
Anti-theft protection
This function allows you to identify your vehicle
from a distance, particularly in poor light. Your
Electronic engine immobiliser
vehicle must have been locked for more than
The remote control contains an electronic chip
2
five seconds.
which has a special code. When the ignition is
switched on, this code must be recognised in
F Press this button
order for starting to be possible.
This electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
This switches on the courtesy lamps and the
starting of the engine by anyone who does not
direction indicators flash for about ten seconds.
have the key.
F
To lock the vehicle, with the remote control
In the event of a fault, you are
in the recognition zone A, press the rear
informed by illumination of this
tailgate locking control.
warning lamp, an audible signal and
F
To deadlock the vehicle, press the control
a message in the screen.
again within five seconds.
Remote operation of lighting
In this case, your vehicle will not start; contact
an authorized Toyota dealer or repairer,
If fitted to your vehicle.
or another duly qualified and equipped
A short press on this button switches
professional as soon as possible.
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).
Keep safely, away from your vehicle,
the label attached to the keys given to
If your vehicle is not fitted with an alarm,
you on acquisition of the vehicle.
deadlocking is confirmed by fixed
A second press on this button before
illumination of the direction indicators
the end of the timed period cancels
for about two seconds.
the remote lighting.
59
Access
Back-up control(s)
Integral key
Locking the driver's door
Locking the front passenger door
F Open the door.
It is used to lock and unlock the vehicle when
the remote control cannot operate:
-
cell battery flat, vehicle battery discharged
or disconnected, ...
-
vehicle located in an area with strong
electromagnetic signals.
F Insert the integral key into the door lock,
then turn it to the rear.
F Remove the cap on on the edge of the
door.
Unlocking
F Insert the key into the latch aperture
F Insert the integral key into the door lock,
(without forcing) and turn the assembly.
then turn it to the front.
F Remove the key and refit the cap.
F Close the door and check from the outside
F
Press and hold button 1 to extract the
If your vehicle has an alarm, it will not
that the vehicle has locked correctly.
integral key 2.
be deactivated/activated on unlocking/
locking the vehicle.
Opening a door will trigger the alarm,
If the alarm is activated, the audible
Unlocking
which can be stopped by switching the
signal triggered on opening a door
F Use the interior door handle.
ignition on.
with the key (integral with the remote
To deadlock the vehicle, turn the key
control) will stop when the ignition is
again within five seconds of locking.
switched on.
60
Access
Locking a sliding side door
Locking the rear wing doors with
F If fitted to your vehicle, check that the
glass windows
electric child lock is not on.
F If fitted to your vehicle, check that the
F Open the door.
electric child lock is not on.
2
F Open the left-hand rear wing door.
F Insert the key (without forcing) into the
F Remove the cap on the edge of the door.
latch aperture located on the edge of the
F Insert the key into the latch aperture
door and slide the assembly upward.
(without forcing) and turn the assembly.
F Remove the key.
F Remove the key and refit the cap.
F Close the door and check from the outside
F Close the door and check from the outside
that the vehicle has locked correctly.
that the vehicle has locked correctly.
Unlocking
F Use the interior door handle.
Unlocking
For more information on the child lock,
F Use the interior door handle.
refer to the corresponding section.
61
Access
Remote control problem
Changing the cell battery
Following disconnection of the vehicle battery,
Battery ref.: CR2032 / 3 volts.
replacement of the remote control battery or
This replacement battery is available from an
in the event of a remote control malfunction,
authorized Toyota dealer or repairer, or another
you can no longer unlock, lock or locate your
duly qualified and equipped professional.
vehicle.
A message appears in the instrument panel screen
F First, use the integral key in the door lock
when replacement of the battery is needed.
to unlock or lock your vehicle.
F Then, reinitialise the remote control.
Reinitialisation
F Place the remote control against the
reader.
F Unlock the driver's door using the integral
F Keeping it in place, switch on the ignition
key.
F Unclip the cover using a small screwdriver
by pressing "START/STOP".
at the cutout.
F Press one of the remote control
The remote control is fully operational again.
F Lift off the cover.
buttons.
F Remove the flat battery from its location.
F Fit the new battery into its location
F Place the integral key in the lock to unlock
observing the original direction of fitment.
your vehicle.
F Clip the cover onto the casing.
Do not throw the remote control
If the problem persists, contact an
batteries away, they contain metals
authorized Toyota dealer or repairer,
which are harmful to the environment.
or another duly qualified and equipped
Take them to an approved collection
professional as soon as possible.
point.
62
Access
Lost keys, remote control
Locking the vehicle
When purchasing a second-
hand vehicle
Visit an authorized Toyota dealer or repairer,
Driving with the doors locked may make
or another duly qualified and equipped
access to the passenger compartment by
Have the key codes memorised by an
professional with the vehicle's registration
the emergency services more difficult in an
authorized Toyota dealer or repairer,
2
certificate, your personal identification
emergency.
or another duly qualified and equipped
documents and if possible, the label bearing
As a safety precaution (with children on
professional, to ensure that the keys in your
the key code.
board), remove the key from the ignition
possession are the only ones which can start
The an authorized Toyota dealer or repairer,
or take the remote control with you when
the vehicle.
or another duly qualified and equipped
leaving the vehicle, even for a short time.
professional will be able to retrieve the key
code and the transponder code required to
order a new key.
Remote control
Electrical interference
Accumulations (water, dust, grime,
salt...) on the inner surface of the door
The high frequency remote control is a
The Smart Entry & Start System remote
handle may affect detection.
sensitive system; do not operate it while it is
control may not operate if close to certain
If cleaning the inner surface of the door
in your pocket as there is a possibility that
electronic devices: telephone, laptop
handle using a cloth does not restore
it may unlock the vehicle, without you being
computer, strong magnetic fields, ...
detection, contact an authorized Toyota
aware of it.
dealer or repairer, or another duly
Do not repeatedly press the buttons of your
qualified and equipped professional.
remote control out of range and out of sight
A sudden splash of water (stream of
of your vehicle. You run the risk of stopping
water, high pressure jet washer, …) may
it from working and the remote control would
be identified by the system as the desire
have to be reinitialised.
Anti-theft protection
to open the vehicle.
The remote control does not operate when
Do not make any modifications to the
the key is in the ignition, even when the
electronic engine immobiliser system; this
ignition is switched off.
could cause malfunctions.
Do not forget to turn the steering to engage
the steering lock.
63
Access
Locking / unlocking from inside
Locking the vehicle
Manual
Unlocking the vehicle
F Press this button.
F Press this button.
The indicator lamp comes on to confirm the
The indicator lamp goes off to confirm the
locking.
unlocking.
When carrying long objects with the
rear tailgate or rear doors open, you
The indicator lamp also goes off when
can press this button to lock just the
unlocking one or more doors.
cabin doors.
This button is inoperative if the vehicle
When locking from inside, the door
has been locked or deadlocked from
mirrors do not fold.
outside (using the key, remote control or
Smart Entry & Start System, according
to equipment) or if one of the doors is
still open.
Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
Automatic
difficult in an emergency.
The cabin doors lock automatically while
driving (speed above 6 mph (10 km/h)); the
indicator lamp comes on.
If the vehicle is powerlocked or locked
F To activate or deactivate this
with the remote control or the door
function, with the ignition on,
handles, the button is not active. In this
press this button until a message
case, use the key or the remote control
appears in the screen.
to unlock.
64
Access
From inside
Closing
Front doors
F
Push or pull the door to close it, then
Opening
lock it.
From outside
When a door is not fully closed:
2
-
vehicle stationary and engine
running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,
-
vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
Vehicle locked.
message for a few seconds.
F Pull the interior control lever on a door to
totally unlock the vehicle and open the
F
After unlocking the vehicle (using the key,
door.
remote control or Smart Entry & Start
For more information on the Key,
System, depending on equipment, pull the
Remote control or Smart Entry &
door handle.
Start System and in particular locking
If the door is unlocked, pull the handle
the vehicle, refer to the corresponding
to open the door.
section.
For more information on the Key,
Remote control or Smart Entry &
Start System and in particular
The interior door controls do not
unlocking the vehicle, refer to the
operate when the vehicle is deadlocked.
corresponding section.
65
Access
Manual sliding side door(s)
From outside
From inside
Vehicle unlocked and child lock deactivated.
F Pull the handle toward the rear to open the
door.
For more information on the Child lock,
refer to the corresponding section.
F After unlocking the vehicle (using the key,
To hold the sliding side door in the open
remote control or Smart Entry & Start
position, open the door fully to engage the latch
System, depending on equipment) pull the
(located at the bottom of the door).
door handle.
For more information on the Key,
Take care not to block the guide space
Remote control or Smart Entry &
on the floor to allow the door to slide
Start System and in particular
correctly.
unlocking the vehicle, refer to the
As a safety measure and for functional
corresponding section.
reasons, do not drive with the sliding
side door open.
66
Access
Closing
From outside
From inside
If a sliding side door is not fully
closed:
-
vehicle stationary and engine
2
running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,
-
vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.
F Pull the handle toward you, then to the
F Push the handle forward to close the door,
front, and if necessary lock the vehicle.
and if necessary lock the vehicle.
For more information on the Key,
Remote control or Smart Entry &
Start System and in particular locking
the vehicle, refer to the corresponding
section.
67
