Driving

Operating fault

Depending on your vehicle's equipment:

The Stop & Start system requires a

12 V battery with a special specification

In the event of a fault with the

and technology.

system, this warning lamp flashes in

the instrument panel.

All work on this type of battery must be

done by an authorized Toyota dealer or

The warning lamp in this button

repairer, or another duly qualified and

flashes and a message appears,

equipped professional.

accompanied by an audible signal.

For more information on the

Have it checked by an authorized Toyota

12 V battery, refer to the corresponding

dealer or repairer, or another duly qualified and

section.

equipped professional.

In the event of a fault in STOP mode, the

vehicle may stall.

All of the instrument panel warning lamps

come on.

Depending on version, an alert message may

also be displayed, asking you to place the gear

lever in position N and put your foot on the

brake pedal.

With the vehicle stationary, you must switch off

the ignition and then start the engine again.

221

Driving

Buttons

Activation / Deactivation

Head-up display

System which projects various information onto

a smoked blade in the driver's field of vision so

that they do not have to take their eyes off the

road.

Displays during operation

1. On.

Off (long press).

F With the engine running, press button 1 to

Brightness adjustment.

activate the system and deploy the blade.

Display height adjustment.

F Press and hold button 2 to

deactivate the system and retract

the blade.

The activated/deactivated state is saved and

retained on restarting the engine.

Once the system has been activated, the

following information is grouped together in the

head-up display:

A. The speed of your vehicle.

B. Cruise control/speed limiter information.

C. If your vehicle is so equipped, inter-vehicle

distance information, automatic emergency

braking alerts and navigation instructions.

For more information on Navigation,

D. If your vehicle is so equipped, speed limit

refer to the Audio and telematics

information.

section.

222

Driving

Height adjustment

Brightness adjustment

We recommend that adjustments are

made using these buttons only when

the vehicle is stationary.

When stationary or while driving, no

objects should be placed around the

blade (or in its recess) so as to not

impede deployment of the blade and its

correct operation.

In certain extreme weather conditions

(rain and/or snow, bright sunshine, ...)

the head-up display may not be legible

F With the engine running, adjust the display

F With the engine running, adjust the

or may suffer temporary interference.

to the desired height using buttons 4:

brightness of the information displayed

Some sunglasses may hamper reading

- up to move the display up,

using buttons 3:

of the information.

- down to move the display down.

- the "sun" to increase the brightness,

To clean the blade, use a clean, soft

- the "moon" to decrease the brightness.

cloth (such as a spectacles cloth or

microfibre cloth). Do not use a dry or

abrasive cloth or detergent or solvent

products as these could scratch the

blade or damage the non-reflective

coating.

This system operates when the engine

is running and the settings are stored

when the ignition is switched off.

223

Driving

Adjustable Speed Limiter (ASL)

This function allows speeds to be saved,

F Select the system for which you want to

Memorised speeds are

which can then be offered to set the two

memorise new speed settings:

MEM

recalled by pressing this

systems: the speed limiter (to limit the

button.

speed of the vehicle) or the cruise control

● speed limiter

(for a vehicle cruising speed).

You can memorise up to six speed settings for

each of the two systems.

● cruise control.

Programming

The speed settings can be adjusted in the

touch screen.

F In the Driving menu, select "Adjust speed

settings".

F Press the button corresponding to the

speed setting you want to modify.

F Enter the new value using the numerical

As a safety measure, the driver should

keypad and confirm.

carry out these operations when

F Confirm to save the modification and quit

stationary.

the menu.

224

Driving

The automatic reading of road signs is a

Road Sign Assist

driving assistance system and does not

Principles

always display speed limits correctly.

The speed limit signs present on the

road always take priority over the

Depending on equipment, the

display by the system.

system takes account of speed limit

The system cannot in any

information from the navigation system

circumstances replace the need for

mapping.

vigilance on the part of the driver.

The driver must observe the driving

regulations and must adapt the speed

of the vehicle to suit the weather and

This system allows the speed limit detected by

traffic.

the camera to be displayed in the instrument

It is possible for the system to not

panel.

display the speed limit if it does not

Specific speed limits, such as those for heavy

detect a speed limit sign within a preset

goods vehicles, are not displayed.

period.

The display of the speed limit in the instrument

The system is designed to detect signs

panel is updated as you pass a speed limit sign

that conform to the Vienna Convention

intended for cars (light vehicles).

on road signs.

The units for the speed limits (mph or

Depending on equipment, using a camera at

To maintain correct operation of the

km/h) depend on the country you are

the top of the windscreen, this system detects

system: regularly clean the area in front

driving in.

and reads speed limit and end of speed limit

of the camera.

It should be taken into account so that

signs.

you observe the speed limit.

For the system to operate correctly

For the speed limit information given

when you change country, the units for

Depending on equipment, the system takes

by the navigation system to be correct,

speed in the instrument panel must be

account of the camera and information from the

your mapping software must be

those for the country you are driving in.

navigation system mapping.

regularly updated.

225

Driving

Display in the instrument panel

Display of the speed

Activation / Deactivation

The system is activated or deactivated via the

vehicle configuration menu.

With the audio system

The system is active but is not detecting speed

limit information.

In the "Personalisation-configuration" menu,

activate/deactivate "Speed recommendation".

Head-up display

On detection of speed limit information, the

system displays the figure.

With the touch screen

In the vehicle settings menu, activate/

deactivate "Displaying of the recommended

The driver can, if desired, adjust the

speed.".

speed of the vehicle according to the

1. Indication of the speed limit.

information given by the system.

226

Driving

Operating limits

Memorising the speed

Steering mounted controls

The legislation on speed limits is specific to

setting

each country.

This memorisation is in addition to the display

The system does not take account of reduced

of Road Sign Assist.

speed limits in the following cases:

poor weather (rain, snow),

atmospheric pollution,

trailer, caravan,

driving with snow chains fitted,

puncture repair using the temporary

Select speed limiter/cruise control mode.

repair kit,

The driver can choose to adapt the speed

Memorise a speed setting.

young drivers.

setting to the speed limit suggested, by

pressing the memorisation button at the speed

limiter controls, with the standard cruise control

Operation of the system may be disrupted or it

or the adaptive cruise control.

may not work at all in the following situations:

This speed setting then replaces the previous

poor visibility (inadequate street lighting,

speed setting for the speed limiter and/or

falling snow, rain, fog),

adaptive cruise control.

windscreen area ahead of the camera dirty,

misty, frosty, covered with snow, damaged

or masked by a sticker,

For more information on the

fault with the camera,

Speed limiter, Cruise control or

obsolete or incorrect mapping,

Adaptive cruise control, refer to the

hidden road signs (other vehicles,

corresponding sections.

vegetation, snow),

speed limit signs that do not conform to the

standard, are damaged or distorted.

Clean the area of the windscreen in

front of the camera regularly.

227

Driving

Display in the instrument panel

Memorising

F When the speed limiter/cruise control is

F Press this button again to

MEM

switched on, the corresponding information

confirm the new speed setting.

is displayed.

Head-up display

On detection of a speed limit sign, the system

displays the speed limit value and offers to

make it the speed setting.

"MEM" flashes in the screen for a few seconds.

3. Speed limiter indication.

4. Memorise the speed.

F Make an initial press on this

5. Current speed setting.

MEM

button to display the suggested

limit speed.

228

Driving

Display in the instrument panel

Speed limiter ("LIMIT")

System which prevents the vehicle from exceeding the speed programmed by the driver.

Once the programmed speed limit is reached,

Steering mounted controls

additional pressure on the accelerator pedal

has no effect.

The programmed speed remains in the

memory when the ignition is switched off.

The speed limiter cannot, in any

circumstances, replace the need to

observe speed limits, nor can it replace the

need for vigilance on the part of the driver.

Head-up display

For more information on this button

1. Select speed limiter mode.

and the Adaptive cruise control,

2. Lower the programmed speed.

GAP

refer to the corresponding section.

3. Raise the programmed speed.

4. Speed limiter on / pause.

5. If fitted to your vehicle, display the list of

memorised speeds or memorise the speed

For more information on

suggested by the Road Sign Assist system.

Adjustable Speed Limiter (ASL),

refer to the corresponding section.

MEM

6. Speed limiter on/pause indication.

For more information on Road Sign

7. Speed limiter mode selection indication.

Assist and memorising them in

8. Speed value setting.

particular, refer to the corresponding

section.

229

Driving

Switching on / Pause

The programmed speed can be

Adjusting the speed limiter

exceeded temporarily by pressing

setting

Switching on the speed limiter requires a

the accelerator firmly beyond the

programmed speed of at least 20 mph (30 km/h).

You do not have to switch the speed limiter on

point of resistance.

The speed limiter is paused by operation of the

in order to set the speed.

control.

Once the function is selected, you can modify

To return to the programmed speed,

the speed setting by:

simply release the accelerator

using buttons 2 and 3, raising or lowering

pedal until the vehicle returns to the

the speed displayed:

programmed speed limit.

F by successive short presses, to modify

by + or - 1 mph (km/h),

F by a maintained press, to modify in steps

of + or - 5 mph (km/h).

F Turn thumbwheel 1 to the "LIMIT" position:

the speed limiter mode is selected but is

not switched on (Pause).

F Switch the speed limiter back on by

pressing button 4, if the speed displayed

is suitable (by default, the last speed

pressing button 5, if your vehicle has speed

programmed).

memorisation:

F You can temporarily stop the speed limiter

F the six speeds memorised are displayed

by pressing button 4 again: the display

in the touch screen,

confirms that it has been stopped (Pause).

F press the button corresponding to the

speed limit chosen.

The value is then displayed in the instrument

panel.

The selection screen closes after a few

moments.

230

Driving

Temporarily exceeding the

Operating fault

programmed speed

F Press firmly on the accelerator pedal,

going beyond the point of resistance, to

exceed the programmed speed limit.

The speed limiter is deactivated temporarily

Flashing of the dashes indicates a fault with the

and the displayed programmed speed flashes.

speed limiter.

An audible signal accompanies the flashing

Have it checked by an authorized Toyota

dealer or repairer, or another duly qualified and

of the programmed speed when exceeding

equipped professional.

the speed is not due to an action by the driver

On sharp acceleration, as when

(steep hill...).

descending a steep hill, the speed

by pressing button 5, if your vehicle has

As soon as the vehicle's speed returns to the

limiter will not be able to prevent

Road Sign Assist:

programmed value, the limiter operates again:

the vehicle from exceeding the

F the speed to be memorised is displayed

the display of the programmed speed becomes

programmed speed.

in the instrument panel,

steady again.

The limiter is temporarily deactivated

F press button 5 again to save the speed.

and the displayed programmed speed

The value is then displayed in the instrument

flashes.

panel.

An audible signal accompanies the

Switching off

flashing of the programmed speed

when exceeding the speed is not due to

an action by the driver.

The use of mats not approved by Toyota

may interfere with the operation of the

speed limiter.

To avoid any risk of jamming of the

For more information on Road

F Turn thumbwheel 1 to the "0" position.

pedals:

Sign Assist, refer to the

The display of speed limiter information

ensure that the mat is secured

corresponding section.

disappears.

MEM

correctly,

do not fit one mat on top of another.

231

Driving

Steering mounted controls

Cruise control ("CRUISE")

System which automatically maintains

Switching off the ignition cancels any

the speed of the vehicle at the value

programmed speed value.

programmed by the driver, without any

action on the accelerator pedal.

The cruise control system cannot, in

any circumstances, replace the need to

observe speed limits, nor can it replace the

need for vigilance on the part of the driver.

You are advised to keep your feet near the

1. Select cruise control mode.

pedals at all times.

2. Programme a speed setting/Lower the

speed setting.

3. Programme a speed setting/Raise the

For more information on

speed setting.

Adjustable Speed Limiter (ASL),

4. Pause-resume cruise control.

MEM

refer to the corresponding section.

5. If fitted to your vehicle, display the list of

memorised speeds or memorise the speed

offered by the Road Sign Assist system.

For more information on Road

Sign Assist, refer to the

MEM

corresponding section.

232

Driving

Display in the instrument panel

Switching on

It is possible to exceed the programmed

speed temporarily by pressing the

The cruise control is switched on manually: it

accelerator pedal.

requires a minimum vehicle speed of 25 mph

To return to the programmed speed,

(40 km/h).

simply release the accelerator pedal

If your vehicle has a manual gearbox, third or

until the programmed cruise speed is

fourth gear, or higher, must be engaged.

reached again.

If your vehicle has an automatic or electronic

gearbox, second gear or higher must be

engaged.

Head-up display

F Turn thumbwheel 1 to the "CRUISE"

position: the cruise control mode is

selected but is not switched on (Pause).

6. Cruise control pause/resume indication.

F Press on button 2 or 3: your vehicle's

7. Cruise control mode selection indication.

current speed becomes the cruise speed.

8. Speed value setting.

The cruise control is activated (ON).

233

Driving

Modification of the initial

Pause

speed setting

The cruise control is paused manually or

If the cruise control is switched on, you can

by pressing the brake or clutch pedal or

then modify the initial speed in one of the

on triggering of the ESC system for safety

following ways:

reasons.

using buttons 2 or 3:

F by successive short presses, to modify

the speed by + or - 1 mph (km/h),

F by a long press, to modify the speed in

steps of + or - 5 mph (km/h),

Once switched on, you can pause the cruise

control at any time by pressing button 4: the

screen confirms the pause.

by pressing on button 5, if your vehicle is

equipped with speed memorisation:

F the speed to be memorised is displayed

F the six memorised speeds are displayed

in the instrument panel,

in the touch screen,

F press on button 5 again to save the

F select a value: it is displayed in the

speed.

instrument panel.

The value is then displayed in the instrument

The selection screen closes after a few

panel.

moments.

The modification is then accepted.

For more information on Road Sign

Assist, refer to the corresponding

section.

234

Driving

Exceeding the programmed

Operating fault

When the cruise control is switched on,

speed

be careful if you maintain the pressure

on one of the programmed speed

If the programmed speed is exceeded, the

changing buttons: this may result in a

displayed speed flashes.

very rapid change in the speed of your

Once the vehicle returns to the programmed

vehicle.

speed, the display becomes steady again.

Do not use the cruise control on

Flashing of the dashes indicates a fault with the

slippery roads or in heavy traffic.

cruise control.

Have it checked by an authorized Toyota

Switching off

dealer or repairer, or another duly qualified and

equipped professional.

On a steep descent, the cruise control

will not be able to prevent the vehicle

from exceeding the programmed speed.

On steep climbs or when towing,

the programmed speed may not be

achieved or maintained.

Turn thumbwheel 1 to the "0" position.

The display of information related to the

cruise control disappears.

The use of mats not approved by Toyota

may interfere with the operation of the

cruise control.

To avoid any risk of jamming of the

pedals:

ensure that the mat is secured

correctly,

never fit one mat on top of another.

235

Driving

Adaptive cruise control ("CRUISE")

This systems allows the vehicle's speed to

Steering mounted controls

be maintained at a value set by the driver.

In addition it allows (when circumstances

By default, the inter-vehicle distance is

permit) an inter-vehicle distance that you

set at "Normal".

have selected to be maintained between

Otherwise, the last setting made will be

your vehicle and the vehicle in front.

used when switching on the system.

Activation / Deactivation

The cruise control selection

thumbwheel must be at the

"CRUISE" position, otherwise the

Select cruise control mode.

selection is not taken into account.

Programme a speed setting/Reduce the

Activation or deactivation of

speed setting.

the system is via the vehicle

Programme a speed setting/Increase the

configuration menu.

speed setting.

Pause / Resume cruise control.

If fitted to your vehicle, display the list of

With the touch screen

memorised speeds or memorise the speed

suggested by the Road Sign Assist system.

Select the inter-vehicle distance ("Close",

"Normal", "Distant").

In the Driving menu, activate/deactivate

"Dynamic cruise control".

The state of the system is memorised on

switching off the ignition.

236

Driving

The adaptive cruise control must be selected in

Display in the instrument panel

Switching on

the "Driving" menu.

The adaptive cruise control is switched on

manually, it requires that the speed of the

vehicle be between 25 mph (40 km/h) and

90 mph (150 km/h).

If the cruise speed setting is above 90 mph

(150 km/h), the adaptive cruise control switches

to normal cruise control mode (without

automatic regulation of the safe inter-vehicle

distance).

If your vehicle has a manual gearbox, third or

Head-up display

fourth gear, or higher, must be engaged.

Turn the thumbwheel 1 to the "CRUISE"

position: cruise control mode is selected,

but not started (Pause).

If your vehicle has an automatic or electronic

Press one of the buttons 2 or 3: the current

gearbox, second gear or higher must be

speed of your vehicle becomes the cruise

engaged.

speed setting.

The cruise control is activated (ON).

For more information on the Cruise

7. Indication of cruise control pause/resume.

control, refer to the corresponding

8. Indication of selection of cruise control

section.

mode, or vehicle speed adjustment phase.

9. Cruise speed setting.

For more information on the Head-up

display, refer to the corresponding

section.

237

Toyota ProAce (2017 year). Instruction - part 14
