Safety

The airbags do not operate when the

Deployment of one or more of the

Airbags

ignition is switched off.

airbags is accompanied by a slight

System designed to contribute towards

This equipment will only deploy once.

emission of smoke and a noise, due

improving the safety of the occupants (with the

If a second impact occurs (during the

to the activation of the pyrotechnic

exception of the centre seat in rows 2 and 3, if

same or a subsequent accident), the

cartridge incorporated in the system.

so equipped) in the event of violent collisions.

airbag will not be deployed again.

This smoke is not harmful, but sensitive

The airbags supplement the action of the seat

individuals may experience slight

belts fitted with force limiters.

irritation.

If a collision occurs, the electronic detectors

The noise of detonation related to the

record and analyse the front and side impacts

Impact detection zones

deployment of one or more airbags may

sustained in the impact detection zones:

result in a slight loss of hearing for a

in the case of a serious impact, the airbags

short time.

are deployed instantly and contribute

towards better protection of the occupants

of the vehicle (with the exception of

the centre seat in rows 2 and 3, if so

equipped); immediately after the impact,

the airbags deflate rapidly so that they

do not hinder visibility or the exit of the

occupants,

in the case of a minor or rear impact or in

certain roll-over conditions, the airbags

may not be deployed; the seat belt

A. Front impact zone.

alone contributes towards ensuring your

B. Side impact zone.

protection in these situations.

170

Safety

Front airbags

Deployment

The airbags are deployed, except the

passenger front airbag if it is deactivated, in

the event of a serious front impact to all or part

of the front impact zone A, in the longitudinal

centreline of the vehicle on a horizontal plane

and directed from the front to the rear of the

vehicle.

The front airbag inflates between the thorax

and head of the front occupant of the vehicle

and the steering wheel, driver's side, and the

dashboard, passenger side to cushion their

forward movement.

System which protects the driver and

When driving, keep the glove box

passenger(s) in the event of a serious front

closed. Otherwise there is a risk of

impact in order to limit the risk of injury to the

injury in the event of an accident or

head and thorax.

sudden braking.

The driver's airbag is fitted in the centre of the

steering wheel; the front passenger airbag is

fitted in the dashboard above the glove box.

171

Safety

Deactivating the passenger front

To assure the safety of your child,

Lateral airbags

airbag

the passenger front airbag must be

Only the passenger front airbag can be

deactivated when you install a rearward

deactivated.

facing child seat on the front passenger

seat.

Otherwise, the child would risk being

seriously injured or killed if the airbag

were deployed.

Reactivating the passenger front

airbag

If fitted to your vehicle, this is a system which

When you remove the child seat, with the

protects the driver and front passenger in the

ignition off, turn the switch to the "ON"

event of a serious side impact in order to limit

position to reactivate the airbag and so assure

the risk of injury to the chest, between the

the safety of your front passenger(s) in the

abdomen and head.

event of an impact.

Each lateral airbag is fitted in the seat backrest

With the ignition off, insert the key in the

When the ignition is switched on,

frame, door side.

passenger airbag deactivation switch.

this warning lamp comes on in the

Turn it to the "OFF" position.

seat belt warning display screen for

Deployment

Remove the key keeping the switch in the

approximately one minute to signal

The lateral airbags are deployed unilaterally in

new position.

that the front airbag is activated.

the event of a serious side impact applied to all

or part of the side impact zone, perpendicular

When the ignition is on, this warning

Operating fault

to the longitudinal centreline of the vehicle on a

lamp comes in the seat belt warning

If this warning lamp comes on in the

horizontal plane and directed from the outside

display screen. It stays on while the

instrument panel, you must contact an

towards the inside of the vehicle.

airbag is deactivated.

authorized Toyota dealer or repairer,

The lateral airbag inflates between the

or another duly qualified and equipped

abdomen and head of the front occupant of the

professional to have the system checked.

vehicle and the corresponding door trim panel.

The airbags may no longer be deployed

in the event of a serious impact.

172

Safety

Advice

For the airbags to be fully effective, observe the safety

Lateral airbags

recommendations below:

Use only approved covers on the seats,

compatible with the deployment the lateral

Sit in a normal upright position.

The bag inflates almost instantly (within

airbags. For information on the range of

Wear a correctly adjusted seat belt.

a few milliseconds) then deflates within

seat covers suitable for your vehicle, you

Do not leave anything between the

the same time discharging the hot gas via

can contact an authorized Toyota dealer

occupants and the airbags (a child, pet,

openings provided for this purpose.

or repairer, or another duly qualified and

object...), nor fix or attach anything close to

equipped professional.

the inflation trajectory of the airbags; this

For more information on Accessories, refer

could cause injuries during their deployment.

to the corresponding section.

Never modify the original definition of your

Do not fix or attach anything to the seat

vehicle, particularly in the area directly

Front airbags

backs (clothing...). This could cause injury

around the airbags.

to the chest or arms if the lateral airbag is

After an accident or if the vehicle has been

Do not drive holding the steering wheel by its

deployed.

stolen or broken into, have the airbag

spokes or resting your hands on the centre

Do not sit with the upper part of the body any

systems checked.

part of the wheel.

nearer to the door than necessary.

All work on the airbag system must be

Passengers must not place their feet on the

carried out by an authorized Toyota dealer

dashboard.

The vehicle's front door panels include side

or repairer, or another duly qualified and

Do not smoke as deployment of the airbags

impact sensors.

equipped professional.

can cause burns or the risk of injury from a

A damaged door or any unauthorised or

Even if all of the precautions mentioned are

cigarette or pipe.

incorrectly executed work (modification or

observed, a risk of injury or of minor burns

Never remove or pierce the steering wheel or

repair) on the front doors or their interior trim

to the head, chest or arms when an airbag is

hit it violently.

could compromise the operation of these

deployed cannot be ruled out.

Do not fit or attach anything to the steering

sensors - Risk of malfunction of the lateral

wheel or dashboard, this could cause

airbags!

injuries with deployment of the airbags.

Such work must only be done by an

authorized Toyota dealer or repairer,

or another duly qualified and equipped

professional.

173

Safety

General points relating to child seats

Although one of Toyota's main criteria when designing your vehicle, the safety of your children also

depends on you.

For maximum safety, please observe the

Toyota recommends that children

following recommendations:

should travel on the rear seats of your

in accordance with European regulations,

vehicle:

all children under the age of 12 or less

rearward facing up to the age of 3,

than one and a half metres tall must

forward facing over the age of 3.

travel in approved child seats suited to

their weight, on seats fitted with a seat

belt or ISOFIX mountings*,

statistically, the safest seats in your

vehicle for carrying children are the

rear seats,

a child weighing less than 9 kg must

travel in the rearward facing position

both in the front and in the rear.

* The regulations on carrying children are

specific to each country. Refer to the

legislation in force in your country.

174

Safety

Child seat at the rear

Rearward facing

Forward facing

Row 3

When a rearward facing child seat is installed

When a forward facing child seat is installed

If fitted to your vehicle, when a child seat is

on a rear passenger seat, move the vehicle's

installed on a passenger seat in the 3rd row,

front seat forward and straighten the backrest

move the seats in the 2nd row forward and

so that the rearward facing child seat does not

so that the legs of the child in the forward

straighten the backrests so that the child seat

touch the vehicle's front seat.

facing child seat do not touch the vehicle's front

and the child's legs do not touch the seats in

Adjust the rear seat to the fully back position,

seat.

the 2nd row.

with the backrest straightened.

Adjust the rear seat to the fully back position,

with the backrest straightened.

Ensure that the seat belt is correctly

tensioned.

For child seats with a support leg,

ensure that this is in firm contact with

the floor. If necessary, adjust the front

seat of the vehicle.

175

Safety

Child seat at the front*

Rearward facing

Forward facing

When a rearward facing child seat is installed

When a forward facing child seat is installed on

Passenger seat in the fully back and

on the front passenger seat, adjust the seat

the front passenger seat, adjust the vehicle's

highest position.

to the fully back and highest position, with the

seat to the fully back and highest position with

backrest straightened.

the seat backrest straightened and leave the

The passenger's front airbag must be

passenger's front airbag activated.

deactivated. Otherwise, the child risks being

seriously injured or killed if the airbag is

deployed.

Ensure that the seat belt is correctly

tensioned.

For child seats with a support leg,

ensure that the support leg is in firm

* Refer to the legislation in force in your country

and stable contact with the floor. If

before carrying your child in this seating

necessary, adjust the passenger seat.

position.

176

Safety

Passenger airbag OFF

Deactivating the passenger front airbag

Never install a rearward facing child

restraint system on a seat protected by

an active front airbag.

This could cause the death of the child

or serious injury.

For more information on the Airbags,

refer to the corresponding section.

The warning label present on both sides of the

passenger sun visor repeats this advice.

In line with current legislation, the following

tables contain this warning in all of the

languages required.

177

Safety

НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да причини

СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето.

NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí

nebezpečí SMRTI DÍTĚTE nebo VÁŽNÉHO ZRANĚNÍ.

Brug ALDRIG en bagudvendt barnestol på et sæde, der er beskyttet af en AKTIV AIRBAG. BARNET risikerer at blive ALVORLIGT

K VÆSTET eller DR ÆBT.

Montieren Sie auf einem Sitz mit AKTIVIERTEM Front-Airbag NIEMALS einen Kindersitz oder eine Babyschale entgegen der

Fahrtrichtung, das Kind könnte schwere oder sogar tödliche Verletzungen erleiden.

Μη χρησιμοποιείτε ΠΟΤΕ παιδικό κάθισμα με την πλάτη του προς το εμπρός μέρος του αυτοκινήτου, σε μια θέση που προστατεύεται από

ΜΕΤΩΠΙΚΟ αερόσακο που είναι ΕΝΕΡΓΟΣ. Αυτό μπορεί να έχει σαν συνέπεια το ΘΑΝΑΤΟ ή το ΣΟΒΑΡΟ ΤΡΑΥΜΑΤΙΣΜΟ του ΠΑΙΔΙΟΥ

NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the

CHILD can occur

NO INSTALAR NUNCA un sistema de retención para niños de espaldas al sentido de la marcha en un asiento protegido mediante un

AIRBAG frontal ACTIVADO, ya que podría causar lesiones GRAVES o incluso la MUERTE del niño.

Ärge MITTE KUNAGI paigaldage “seljaga sõidusuunas“ lapseistet juhi kõrvalistmele, mille ESITURVAPADI on AKTIVEERITUD.

Turvapadja avanemine võib last TÕSISELT või ELUOHTLIKULT vigastada.

ÄLÄ KOSKAAN aseta lapsen turvaistuinta selkä ajosuuntaan istuimelle, jonka edessä suojana on käyttöön aktivoitu TURVATYYNY. Sen

laukeaminen voi aiheuttaa LAPSEN KUOLEMAN tai VAKAVAN LOUKKAANTUMISEN.

NE JAMAIS installer de système de retenue pour enfants faisant face vers l’arrière sur un siège protégé par un COUSSIN GONFLABLE

frontal ACTIVÉ.

Cela peut provoquer la MORT de l’ENFANT ou le BLESSER GRAVEMENT

NIKADA ne postavljati dječju sjedalicu leđima u smjeru vožnje na sjedalo zaštićeno UKLJUČENIM prednjim ZRAČNIM JASTUKOM. To bi

moglo uzrokovati SMRT ili TEŠKU OZLJEDU djeteta.

SOHA ne használjon menetiránynak háttal beszerelt gyermekülést AKTIVÁLT (BEKAPCSOLT) FRONTLÉGZSÁKKAL védett ülésen. Ez a

gyermek HALÁLÁT vagy SÚLYOS SÉRÜLÉSÉT okozhatja.

NON installare MAI seggiolini per bambini posizionati in senso contrario a quello di marcia su un sedile protetto da un AIRBAG frontale

ATTIVATO. Ciò potrebbe provocare la MORTE o FERITE GR AVI al bambino.

NIEKADA neįrenkite vaiko prilaikymo priemonės su atgal atgręžtu vaiku ant sėdynės, kuri saugoma VEIKIANČIOS priekinės ORO

PAGALVĖS. Išsiskleidus oro pagalvei vaikas gali būti MIRTINAI arba SUNKIAI TR AUMUOTAS.

178

Safety

NEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS priekšējais DROŠĪBAS GAISA

SPILVENS.

Tas var izraisīt BĒRNA NĀVI vai radīt NOPIETNUS IEVAINOJUMUS.

Qatt m’ghandek thalli tifel/tifla marbut f’siggu dahru lejn l-Airbag attiva, ghaliex tista’ tikkawza korriment serju jew anke mewt lit-tifel/tifla

Plaats NOOIT een kinderzitje met de rug in de rijrichting op een zitplaats waarvan de AIRBAG is INGESCHAKELD. Bij het afgaan van de

airbag kan het KIND LEVENSGEVAARLIJK GEWOND RAKEN

Installer ALDRI et barnesete med ryggen mot kjøreretningen i et sete som er beskyttet med en frontal AKTIVERT KOLLISJONSPUTE,

BARNET risikerer å bli DREPT eller HARDT SKADET.

NIGDY nie instalować fotelika dziecięcego w pozycji "tyłem do kierunku jazdy" na siedzeniu wyposażonym w CZOŁOWĄ PODUSZKĘ

POWIETRZNĄ w stanie AKTYWNYM. Może to doprowadzić do ŚMIERCI DZIECKA lub spowodować u niego POWAŻNE OBRAŻENIA

CIAŁA.

NUNCA instale um sistema de retenção para crianças de costas para a estrada num banco protegido por um AIRBAG frontal ACTIVADO.

Esta instalação poderá provocar FERIMENTOS GRAVES ou a MORTE da CRIANÇA.

Nu instalati NICIODATA un sistem de retinere pentru copii, dispus cu spatele in directia de mers, pe un loc din vehicul protejat cu AIRBAG

frontal ACTIVAT. Aceasta ar putea provoca MOARTEA COPILULUI sau RANIREA lui GRAVA.

ВО ВСЕХ СЛУЧАЯХ ЗАПРЕЩАЕТСЯ использовать обращенное назад детское удерживающее устройство на сиденье,

защищенном ФУНКЦИОНИРУЮЩЕЙ ПОДУШКОЙ БЕЗОПАСНОСТИ, установленной перед этим сиденьем.

Это может привести к ГИБЕЛИ РЕБЕНКА или НАНЕСЕНИЮ ЕМУ СЕРЬЕЗНЫХ ТЕЛЕСНЫХ ПОВРЕЖДЕНИЙ

NIKDY neinštalujte detské zádržné zariadenie orientované smerom dozadu na sedadlo chránené AKTIVOVANÝM čelným AIRBAGOM.

Mohlo by dôjsť k SMRTEĽNÉMU alebo VÁŽNEMU PORANENIU DIEŤAŤA.

NIKOLI ne nameščajte otroškega sedeža s hrbtom v smeri vožnje, če je VARNOSTNA BLAZINA pred sprednjim sopotnikovim sedežem

AKTIVIRANA. Takšna namestitev lahko povzroči SMRT OTROKA ali HUDE POŠKODBE.

NIKADA ne koristite dečje sedište koje se okreće unazad na sedištu zaštićenim AKTIVNIM VAZDUŠNIM JASTUKOM ispred njega, jer

mogu nastupiti SMRT ili OZBILJNA POVREDA DETETA.

Passagerarkrockkudden fram MÅSTE vara avaktiverad om en bakåtvänd bilbarnstol installeras på denna plats. Annars riskerar barnet att

DÖDAS eller SKADAS ALLVARLIGT.

KESİNLKLE HAVA YASTIĞI AKTİF olan ön koltuğa yüzü arkaya dönük bir çocuk koltuğu yerleştirmeyiniz. Bu ÇOCUĞUN ÖLMESİNE veya

ÇOK AĞIR YARALANMASINA sebep olabilir.

179

Safety

Child seats recommended by Toyota

Toyota offers a range of child seats which are secured using a three point seat belt.

Group 0+: from birth to 13 kg

"TOYOTA GO + BABYSAFE PLUS"

Installed rearward facing.

180

Safety

Groups 2 and 3: from 15 to 36 kg

"TOYOTA KIDIFIX XP SICT"

Can be fitted to the vehicle's ISOFIX

mountings.

"TOYOTA DUO PLUS"

The child is restrained by the seat belt.

181

Safety

Locations for child seats secured with

a seat belt

In line with European legislation, this table indicates the options for installing child seats secured using a seat belt and universally

approved (a) for the weight of the child and the seat in the vehicle.

Weight of the child and indicative age

Under 13 kg

From 9 to 18 kg

From 15 to 25 kg

From 22 to 36 kg

Seat

(groups 0 (b)

(group 1)

(group 2)

(group 3)

and 0+)

1 to 3 years approx

3 to 6 years approx

6 to 10 years approx

Up to approx 1 year

With individual

seat, passenger

seat

With bench seat,

Cab / Row 1 (c) (d)

outer seat

With bench seat,

centre seat

Left-hand outer

seat

Row 2 (e)

Centre seat

Right-hand outer

seat

* Submitted for type approval.

182

Safety

(a)

Universal child seat: child seat that can be

Seat suitable for the installation of a child

Remove and stow the head restraint

installed in any vehicle using the seat belt.

seat secured using the seat belt and

before installing a child seat with

(b)

Group 0: from birth to 10 kg. Infant car

universally approved, rearward facing and/

backrest on a passenger seat.

seats and "car cots" cannot be installed on

or forward facing.

Refit the head restraint once the child

the front passenger seat.

Seat not suitable for the installation of a

seat has been removed.

(c)

Consult the legislation in force in your

child seat of the weight group indicated.

country before installing your child on

this seat.

(d)

When a rearward facing child seat is

installed on the front passenger seat,

the front passenger airbag must be

deactivated. Otherwise the child risks

being seriously injured or killed if the airbag

is deployed.

(e)

To install a child seat on a rear seat, move

the seat in front forward, then straighten

the backrest to allow sufficient space for

the child seat and the child's legs.

183

Safety

In line with European legislation, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)

for the weight of the child and the seat in the vehicle.

Weight of the child and indicative age

Under 13 kg

From 9 to 18 kg

From 15 to 25 kg

From 22 to 36 kg

Seat

(groups 0 (b) and 0+)

(group 1)

(group 2)

(group 3)

Up to approx 1 year

1 to 3 years approx

3 to 6 years approx

6 to 10 years approx

With individual

with passenger airbag

seat,

deactivated "OFF"

passenger

with passenger airbag

seat

activated "ON"

With bench

with passenger airbag

seat,

deactivated "OFF"

Row 1 (c)

centre

with passenger airbag

seat

activated "ON"

With bench

with passenger airbag

seat,

deactivated "OFF"

outer

with passenger airbag

seat

activated "ON"

Left-hand outer seat

Row 2

Centre seat

Right-hand outer seat

Left-hand outer seat

Row 3

Centre seat

Right-hand outer seat

184

Safety

(a) Universal child seat: child seat that can be

Refit the head restraint once the child

installed in any vehicle using the seat belt.

seat has been removed.

(b) Group 0: from birth to 10 kg. Infant car

seats and "car cots" cannot be installed on

the front passenger seat(s) or the seats in

row 3.

country before installing your child on

this seat.

U Seat suitable for the installation of a child

seat secured using the seat belt and

universally approved, rearward facing

and/or forward facing.

UF Seat suitable for the installation of a child

seat secured using the seat belt and

universally approved forward facing.

X Seat not suitable for the installation of a

child seat of the weight group indicated.

185

Safety

"ISOFIX" mountings

This ISOFIX mounting system provides fast,

fix the hook on the end of the upper strap

reliable and safe fitting of the child seat in your

to the rear ring B,

Your vehicle has been approved to the latest

vehicle.

tighten the upper strap.

ISOFIX regulation.

The ISOFIX child seats are fitted with two

If fitted on your vehicle, the regulation ISOFIX

latches which are secured on the two front

mountings are located by labels.

rings A.

The incorrect installation of a child seat

The mountings comprise three rings for each

Some also have an upper strap which is

in a vehicle compromises the child's

seat:

attached to the rear ring B.

protection in the event of an accident.

Two front rings A, located between

To secure the child seat to the Top Tether:

the vehicle seat backrest and cushion,

remove and stow the head restraint before

Observe strictly the fitting instructions

indicated by an "ISOFIX" marking,

installing a child seat on this seat (refit it

provided with the child seat.

If fitted to your vehicle, a rear ring B,

once the child seat has been removed),

located behind the vehicle's seat, called

pass the child seat upper strap over the

the Top Tether, for securing the upper

top of the seat backrest, between the

strap, indicated by a "Top Tether" marking.

apertures for the head restraint rods,

For information on the possibilities for

The Top Tether is used to secure the upper

installing ISOFIX child seats in your

strap of child seats that have one. In the event

vehicle, refer to the locations table.

of a front impact, this system limits the forward

tipping of the child seat.

186

Content .. 9 10 11 12 ..
