Toyota Auris Touring Sports (2017 year). Instruction - part 11

170

3-3. Adjusting the seats

WARNING

Observe the following precautions. Failure to do so may result in death or

serious injury.

■ When folding the rear seatbacks down

● Do not fold the seatbacks down while driving.

● Stop the vehicle on level ground, set the parking brake and shift the shift

lever to P (Multidrive) or N (manual transmission).

● Do not allow anyone to sit on a folded seatback or in the luggage compart-

ment while driving.

● Do not allow children to enter the luggage compartment.

● Do not allow anyone to sit on the rear center seat if the rear right seat is

folded down, as the seat belt buckle for the rear center seat belt is then

concealed under the folded seat and cannot be used.

● Be careful not to get your hand caught when folding the rear seatbacks.

● Adjust the position of the front seats before folding down the rear

seatbacks so that the front seats do not interfere with the rear seatbacks

when folding down the rear seatbacks.

■ After returning the rear seatback to the upright position

● Make sure that the seatback is securely

locked in position by lightly pushing it

back and forth.

If the seatback is not securely locked,

the red marking will be visible on the

seatback lock release lever. Make sure

that the red marking is not visible.

● Check that the seat belts are not twisted

or caught in the seatback.

If the seat belt gets caught between the

seatback's securing hook and latch, it

may damage the seat belt.

3-3. Adjusting the seats

171

NOTICE

■ When the partition net unit is installed to the folded down rear

seatbacks (vehicles with a partition net)

When returning the seatbacks, remove the partition net unit then return the

rear seatbacks to their original position. (P. 441)

3

172

3-3. Adjusting the seats

Head restraints

Head restraints are provided for all seats.

Vertical adjustment

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while

pressing the lock release button.

Lock release button

■ Removing the head restraints

Pull the head restraint up while pressing

the lock release button.

Lock release button

■ Adjusting the height of the head restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■ Adjusting the rear seat head restraint

Always raise the head restraint one level from the stowed position when

using.

3-3. Adjusting the seats

173

WARNING

■ Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to

do so may result in death or serious injury.

● Use the head restraints designed for each respective seat.

● Adjust the head restraints to the correct position at all times.

● After adjusting the head restraints, push down on them and make sure

they are locked in position.

● Do not drive with the head restraints removed.

3

174

3-4. Adjusting the steering wheel and mirrors

Steering wheel

Adjustment procedure

Hold the steering wheel and

1

push the lever down.

Adjust to the ideal position by

2

moving the steering wheel hori-

zontally and vertically.

After adjustment, pull the lever up

to secure the steering wheel.

Horn

To sound the horn, press on or

close to the

mark.

3-4. Adjusting the steering wheel and mirrors

175

WARNING

■ Caution while driving

Do not adjust the steering wheel while driving.

Doing so may cause the driver to mishandle the vehicle and cause an acci-

dent, resulting in death or serious injury.

■ After adjusting the steering wheel

Make sure that the steering wheel is securely locked.

Otherwise, the steering wheel may move suddenly, possibly causing an

accident, and resulting in death or serious injury. Also, the horn may not

sound if the steering wheel is not securely locked.

3

176

3-4. Adjusting the steering wheel and mirrors

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable suffi-

cient confirmation of the rear view.

Adjusting the height of rear view mirror (auto anti-glare inside

rear view mirror only)

The height of the rear view mirror can be adjusted to suit your driving

posture.

Adjust the height of the rear view

mirror by moving it up and down.

Anti-glare function

 Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced

by operating the lever.

1

Normal position

2

Anti-glare position

3-4. Adjusting the steering wheel and mirrors

177

 Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles

behind, the reflected light is automatically reduced.

Changing automatic anti-glare

function mode

On/off

When the automatic anti-glare

function is in on mode, the indica-

tor illuminates.

Vehicles without a smart entry &

start system: The function will be

Indicator

set to on mode each time the

3

engine switch is turned to the “ON”

position.

Vehicles with a smart entry & start system: The function will be set to on

mode each time the engine switch is turned to IGNITION ON mode.

Pressing the button turns the function to off mode. (The indicator also turns

off.)

■ To prevent sensor error (vehicles with an auto anti-glare inside rear view

mirror)

To ensure that the sensors operate prop-

erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident,

resulting in death or serious injury.

178

3-4. Adjusting the steering wheel and mirrors

Outside rear view mirrors

Adjustment procedure

1

To select a mirror to adjust,

press the switch.

1

Left

2

Right

2

To adjust the mirror, press the

switch.

1

Up

2

Right

3

Down

4

Left

Manually folding the mirrors

 Manual type

 Power type

Push the mirror back in the direc-

Press the switch to fold the mir-

tion of the rear of the vehicle.

rors.

Press it again to extend them to

the original position.

3-4. Adjusting the steering wheel and mirrors

179

Automatically folding and extending the mirrors (if equipped)

The automatic folding/extending mirror function allows the folding or

extending of the mirrors to be linked to locking/unlocking of the doors.

Automatic operation can be disabled by performing the following.

1

Turn the engine switch off.

2

Press and hold the mirror fold

switch and

of the mirror

angle adjustment switch at the

same time for more than 2 sec-

onds.

Performing the above procedure

3

again will enable automatic opera-

tion.

■ Mirror angle can be adjusted when

 Vehicles without a smart entry & start system

The engine switch is in the “ACC” or “ON” position.

 Vehicles with a smart entry & start system

The engine switch is in ACCESSORY or IGNITION ON mode.

■When disconnecting and reconnecting battery terminals (vehicles with

an automatic folding/extending mirror function)

The automatic folding/extending mirror function will return to on as default. To

turn the function off, press the switch again to select off.

■ When the mirrors are fogged up

The outside rear view mirrors can be cleared using the mirror defoggers. Turn

on the rear window defogger to turn on the outside rear view mirror defog-

gers. (P. 406, 413)

■ Using the automatic folding/extending mirror function in cold weather (if

equipped)

When the automatic folding/extending mirror function is used in cold weather,

the outside rear view mirrors could freeze up and automatic folding and

extension may not be possible. In this event, remove any ice and snow from

the outside rear view mirror, then operate the mirror manually by using the

mirror fold switch or moving the mirror by hand.

3-5. Opening and closing the windows

181

Power windows

Opening and closing procedures

The power windows can be opened and closed using the switches.

Operating the switch moves the windows as follows:

 One-touch opening/closing on driver’s window only type

1

Closing

2

One-touch closing (driver’s win-

dow only)*

3

Opening

3

4

One-touch opening

(driver’s

window only)*

*: To stop the window partway, oper-

ate the switch in the opposite direc-

tion.

 One-touch opening/closing on all windows type

1

Closing

2

One-touch closing*

3

Opening

4

One-touch opening*

*: To stop the window partway, oper-

ate the switch in the opposite direc-

tion.

Window lock switch

Press the switch to lock the pas-

senger window switches.

Use this switch to prevent children

from accidentally opening or clos-

ing a passenger window.

: If equipped

3-5. Opening and closing the windows

183

■ When the power window does not close normally (windows with one-

touch closing function only)

If the jam protection function is operating abnormally and a window cannot be

closed, perform the following operations using the power window switch on

the relevant door.

● Vehicles without a smart entry & start system: After stopping the vehicle, the

window can be closed by holding the power window switch in the one-touch

closing position while the engine switch is turned to the “ON” position.

Vehicles with a smart entry & start system: After stopping the vehicle, the

window can be closed by holding the power window switch in the one-touch

closing position while the engine switch is turned to IGNITION ON mode.

● If the window still cannot be closed even by carrying out the operation as

explained above, initialize the function by performing the following proce-

dure.

3

Hold the power window switch in the one-touch closing position. Continue

1

holding the switch for a further 6 seconds after the window has closed.

Hold the power window switch in the one-touch opening position. Con-

2

tinue holding the switch for a further 2 seconds after the window has

opened completely.

Hold the power window switch in the one-touch closing position once

3

again. Continue holding the switch for a further 2 seconds after the win-

dow has closed.

If you release the switch while the window is moving, start again from the

beginning.

If the window continues to close but then re-open slightly even after perform-

ing the above procedure correctly, have the vehicle inspected by any autho-

rized Toyota dealer or repairer, or another duly qualified and equipped

professional.

186

4-1. Before driving

Driving the vehicle

The following procedures should be observed to ensure safe

driving:

Starting the engine

P. 209, 213

Driving

 Multidrive

1

With the brake pedal depressed, shift the shift lever to D. (P. 223)

2

Release the parking brake. (P. 234)

3

Gradually release the brake pedal and gently depress the accelera-

tor pedal to accelerate the vehicle.

 Manual transmission

1

While depressing the clutch pedal, shift the shift lever to 1.

(P. 230)

2

Release the parking brake. (P. 234)

Gradually release the clutch pedal. At the same time, gently

3

depress the accelerator pedal to accelerate the vehicle.
