170
3-2. Opening, closing and locking the doors
AURIS HV Touring
Sports_EE
(OM12L18E)
3-2. Opening, closing and locking the doors
171
3
AURIS HV Touring
Sports_EE
(OM12L18E)
172
3-2. Opening, closing and locking the doors
WARNING
■ Caution regarding interference with electronic devices
● People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should main-
tain a reasonable distance between themselves and the push button start
antennas. (P. 155)
The radio waves may affect the operation of such devices. If necessary,
the push button start can be disabled. Ask any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional for details,
such as the frequency of radio waves and timing of the emitted radio
waves. Then, consult your doctor to see if you should disable the push
button start.
● Users of any electrical medical device other than implantable cardiac
pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators should consult the manufacturer of
the device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.
Ask any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional for details on disabling the push button start.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-3. Adjusting the seats
173
Front seats
Adjustment procedure
1
Seat position adjustment lever
2
Seatback angle adjustment
lever
3
Vertical height adjustment lever
(if equipped)
Lumbar support adjustment
4
switch (if equipped)
3
AURIS HV Touring
Sports_EE
(OM12L18E)
174
3-3. Adjusting the seats
WARNING
■ When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Make sure to leave enough space around the feet so they do not get stuck.
■Seat adjustment
● Be careful that the seat does not hit passengers or luggage.
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● After adjusting the seat, make sure that the seat is locked in position.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-3. Adjusting the seats
175
Rear seats
The seatbacks of the rear seats can be folded down.
Folding down the rear seatbacks
1
Move the front seats forward. (P. 173)
2
Stow the rear armrest. (if equipped) (P. 420)
3
Stow the rear center seat belt
buckle.
3
4
Lower the head restraints to the lowest position. (P. 178)
From inside
Pull the seatback lock release
5
lever and fold the seatback
down.
Each seatback may be folded sep-
arately.
From outside
Pull the lever on the sidewall of
5
the luggage compartment.
Each seatback may be folded sep-
arately.
AURIS HV Touring
Sports_EE
(OM12L18E)
176
3-3. Adjusting the seats
WARNING
Observe the following precautions. Failure to do so may result in death or
serious injury.
■ When folding the rear seatbacks down
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
position to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
● Do not allow anyone to sit on the rear center seat if the rear right seat is
folded down, as the seat belt buckle for the rear center seat belt is then
concealed under the folded seat and cannot be used.
● Be careful not to get your hand caught when folding the rear seatbacks.
● Adjust the position of the front seats before folding down the rear
seatbacks so that the front seats do not interfere with the rear seatbacks
when folding down the rear seatbacks.
■ After returning the rear seatback to the upright position
● Make sure that the seatback is securely
locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked,
the red marking will be visible on the
seatback lock release lever. Make sure
that the red marking is not visible.
● Check that the seat belts are not twisted
or caught in the seatback.
If the seat belt gets caught between the
seatback's securing hook and latch, it
may damage the seat belt.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-3. Adjusting the seats
177
NOTICE
■ When the partition net unit is installed to the folded down rear
seatbacks (vehicles with a partition net)
When returning the seatbacks, remove the partition net unit then return the
rear seatbacks to their original position. (P. 415)
3
AURIS HV Touring
Sports_EE
(OM12L18E)
178
3-3. Adjusting the seats
Head restraints
Head restraints are provided for all seats.
Vertical adjustment
1
Up
Pull the head restraints up.
2
Down
Push the head restraint down while
pressing the lock release button.
Lock release button
■ Removing the head restraints
Pull the head restraint up while pressing
the lock release button.
Lock release button
■ Adjusting the height of the head restraints
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
■ Adjusting the rear seat head restraint
Always raise the head restraint one level from the stowed position when
using.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-3. Adjusting the seats
179
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
● Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
3
AURIS HV Touring
Sports_EE
(OM12L18E)
180
3-4. Adjusting the steering wheel and mirrors
Steering wheel
Adjustment procedure
Hold the steering wheel and
1
push the lever down.
Adjust to the ideal position by
2
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
Horn
To sound the horn, press on or
close to the
mark.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-4. Adjusting the steering wheel and mirrors
181
WARNING
■ Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.
3
AURIS HV Touring
Sports_EE
(OM12L18E)
182
3-4. Adjusting the steering wheel and mirrors
Inside rear view mirror
The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.
Adjusting the height of rear view mirror (auto anti-glare inside
rear view mirror only)
The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.
Anti-glare function
Manual anti-glare inside rear view mirror
Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.
1
Normal position
2
Anti-glare position
AURIS HV Touring
Sports_EE
(OM12L18E)
3-4. Adjusting the steering wheel and mirrors
183
Auto anti-glare inside rear view mirror
Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.
Changing automatic anti-glare
function mode
On/off
When the automatic anti-glare
function is in on mode, the indica-
tor illuminates.
The function will be set to on mode
each time the power switch is
Indicator
turned to ON mode.
3
Pressing the button turns the function to off mode. (The indicator also turns
off.)
■ To prevent sensor error (vehicles with an auto anti-glare inside rear view
mirror)
To ensure that the sensors operate prop-
erly, do not touch or cover them.
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.
AURIS HV Touring
Sports_EE
(OM12L18E)
184
3-4. Adjusting the steering wheel and mirrors
Outside rear view mirrors
Adjustment procedure
1
To select a mirror to adjust,
press the switch.
1
Left
2
Right
2
To adjust the mirror, press the
switch.
1
Up
2
Right
3
Down
4
Left
Manually folding the mirrors
Manual type
Power type
Push the mirror back in the direc-
Press the switch to fold the mir-
tion of the rear of the vehicle.
rors.
Press it again to extend them to
the original position.
AURIS HV Touring
Sports_EE
(OM12L18E)
3-4. Adjusting the steering wheel and mirrors
185
Automatically folding and extending the mirrors (if equipped)
The automatic folding/extending mirror function allows the folding or
extending of the mirrors to be linked to locking/unlocking of the doors.
Automatic operation can be disabled by performing the following.
1
Turn the power switch off.
2
Press and hold the mirror fold
switch and
of the mirror
angle adjustment switch at the
same time for more than 2 sec-
onds.
Performing the above procedure
3
again will enable automatic opera-
tion.
■ Mirror angle can be adjusted when
The power switch is in ACCESSORY or ON mode.
■ When disconnecting and reconnecting 12-volt battery terminals (vehi-
cles with an automatic folding/extending mirror function)
The automatic folding/extending mirror function will return to on as default. To
turn the function off, press the switch again to select off.
■ When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (P. 390)
■ Using the automatic folding/extending mirror function in cold weather (if
equipped)
When the automatic folding/extending mirror function is used in cold weather,
the outside rear view mirrors could freeze up and automatic folding and
extension may not be possible. In this event, remove any ice and snow from
the outside rear view mirror, then operate the mirror manually by using the
mirror fold switch or moving the mirror by hand.
AURIS HV Touring
Sports_EE
(OM12L18E)
186
3-4. Adjusting the steering wheel and mirrors
WARNING
■ Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.
● Do not adjust the mirrors while driving.
● Do not drive with the mirrors folded.
● Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
■ When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
■ When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.
AURIS HV Touring
Sports_EE
(OM12L18E)
