8-1. Specifications

NOTICE

■ Notice on fuel quality

●Do not use improper fuels. If improper fuels are used the engine will be

damaged.

●Do not use leaded gasoline.

Leaded gasoline will cause the three-way catalytic converter to lose its

effectiveness and emission control system to function improperly.

● EU area: Bioethanol fuel sold under names such as “E50” or “E85” and

fuel containing a large amount of ethanol should not be used. The use of

these fuels will damage the vehicle’s fuel system. In case of any doubt,

ask any authorized Toyota dealer or repairer, or another duly qualified and

equipped professional.

● Except EU area: Bioethanol fuel sold under names such as “E50” or “E85”

and fuel containing a large amount of ethanol should not be used. Your

vehicle can use gasoline mixed with 10% max ethanol. The use of fuel

with more than 10% ethanol content (E10) will damage the vehicle’s fuel

system. You must ensure that refueling is carried out only from a source

where fuel specification and quality can be guaranteed. In case of any

doubt, ask any authorized Toyota dealer or repairer, or another duly quali-

fied and equipped professional.

●Do not use the methanol blended gasoline such as M15,M85,M100. The

use of gasoline containing methanol may cause engine damage or failure.

PRIUS +_OM_OM47B24E_(EE)

8-2. Customization

477

Customizable features

Your vehicle includes a variety of electronic features that can be

personalized to suit your preferences. The settings of these fea-

tures can be changed using the multi-information display, the

navigation system, or at any authorized Toyota dealer or

repairer, or another duly qualified and equipped professional.

Some function settings are changed simultaneously with other func-

tions being customized. Contact any authorized Toyota dealer or

repairer, or another duly qualified and equipped professional for fur-

ther details.

Customizing vehicle features

When customizing vehicle features, ensure that the vehicle is parked

in a safe place with the parking brake set and the shift position in P.

■ Changing using the multi-information display (if equipped)

Press

of the meter control switches, select

and then press

Press

of the meter control switches, select the item,

and then press

Press

of the meter control switches, select the desired

setting, and then press

To go back to the previous screen or exit the customize mode,

press

■ Changing using the navigation system

Press the “SETUP” button.

Select “Vehicle” on the “Setup” screen and select “Vehicle cus-

tomization”.

Various settings can be changed. Refer to the list of settings that

can be changed for details.

PRIUS +_OM_OM47B24E_(EE)

478

8-2. Customization

Customizable features

Settings that can be changed using the multi-information display

Vehicles with navigation system: Settings that can be changed

using the navigation system

Settings that can be changed by any authorized Toyota dealer or

repairer, or another duly qualified and equipped professional

Definition of symbols: O = Available, - =Not available

■ Smart entry & start system and wireless remote control

(→P. 140, 153)

Default

Customized

Function

setting

Operation signal

Off

(emergency flashers)

Open door reminder

buzzer (When locking the

Off

vehicle)

Time elapsed before the

60 seconds

automatic door lock func-

tion is activated if a door is

30 seconds

not opened after being

120 seconds

unlocked

■ Smart entry & start system (→P. 153)

Default

Customized

Function

setting

Smart entry & start

Off

system

PRIUS +_OM_OM47B24E_(EE)

8-2. Customization

479

■ Wireless remote control (→P. 140)

Default

Customized

Function

setting

Wireless remote control

Off

■ Automatic light control system (→P. 223)

Default

Customized

Function

setting

Light sensor sensitivity

Level 0

Level -2 to 2

■ Illumination (→P. 290)

Default

Customized

Function

setting

Off

Time elapsed before the

15 seconds

7.5 seconds

interior lights turn off

30 seconds

Operation after the power

Off

switch is turned off

Operation when the doors

are unlocked with the

smart entry & start system

Off

or the wireless remote

control function or the

mechanical key

Operation when you

approach the vehicle with

Off

the electronic key on your

person

Footwell lighting*

Off

Footwell lighting control

Off

*: If equipped

PRIUS +_OM_OM47B24E_(EE)

480

8-2. Customization

■ Instrument cluster (→P. 111)

Default

Customized

Function

setting

Sensor sensitivity for

darkening the brightness

of the instrument cluster

Standard

-2 to 2

depending on the outside

brightness

Sensor sensitivity for

returning the brightness of

the instrument cluster to

Standard

-2 to 2

the original level depend-

ing on the outside bright-

ness

French

German

Language*

English

Spanish

Italian

Units

km (km/L)

(L/100km)

Pop-up display

Off

*: The default setting varies according to countries.

■ Automatic air conditioning system (→P. 280)

Default

Customized

Function

setting

A/C auto switching opera-

Off

tion

Heating/cooling operation

minimized in Eco drive

Off

mode

PRIUS +_OM_OM47B24E_(EE)

8-2. Customization

481

■ Panoramic roof shades* (→P. 306)

Default

Customized

Function

setting

Door lock linked automatic

Off

closing function

*: If equipped

■ Reverse buzzer (→P. 218)

Default

Customized

Function

setting

Signal (buzzer) when the

Intermittent

Single

shift position is in R

■ Alarm* (→P. 98)

Default

Customized

Function

setting

Deactivates the alarm

when the doors are

Off

unlocked

using

the

mechanical key

*: If equipped

PRIUS +_OM_OM47B24E_(EE)

482

8-2. Customization

■ In the following situations, customize mode in which the settings can be

changed through the multi-information display will automatically be

turned off.

●A warning message appears after the customize mode screen is displayed.

● The power switch is turned off.

●The vehicle begins to move while the customize mode screen is displayed.

WARNING

■ Cautions during customization

As the hybrid system needs to be operating during customization, ensure

that the vehicle is parked in a place with adequate ventilation. In a closed

area such as a garage, exhaust gases including harmful carbon monoxide

(CO) may collect and enter the vehicle. This may lead to death or a serious

health hazard.

NOTICE

■ During customization

To prevent 12-volt battery discharge, ensure that the hybrid system is oper-

ating while customizing features.

PRIUS +_OM_OM47B24E_(EE)

8-3. Initialization

483

Item to initialize

The following item must be initialized for normal system opera-

tion after such cases as the 12-volt battery being reconnected,

or maintenance being performed on the vehicle:

Item

When to initialize

Reference

• When rotating the tires on

vehicles with differing front

and rear tire inflation pres-

sures

Tire pressure warning

• When changing the tire infla-

P. 342

system

tion pressure by changing

traveling speed or load

weight, etc.

• When changing the tire size

PRIUS +_OM_OM47B24E_(EE)

485

Index

What to do if...

(Troubleshooting)

486

Alphabetical index

490

For vehicles with navigation system or multimedia system,

refer to the

“Navigation and multimedia system Owner’s

Manual” for information regarding the equipment listed below.

• Navigation system

• Rear view monitor system

• Audio/visual system

• IPA (Intelligent Parking Assist)

PRIUS +_OM_OM47B24E_(EE)

486

What to do if... (Troubleshooting)

If you have a problem, check the following before contacting any

authorized Toyota dealer or repairer, or another duly qualified

and equipped professional.

The doors cannot be locked, unlocked, opened or closed

You lose your keys

● If you lose your mechanical keys, new genuine mechanical keys can be

made by any authorized Toyota dealer or repairer, or another duly qualified

and equipped professional. (→P. 141)

● If you lose your electronic keys, the risk of vehicle theft increases signifi-

cantly. Contact any authorized Toyota dealer or repairer, or another duly

qualified and equipped professional immediately. (→P. 143)

The doors cannot be locked or unlocked

● Is the electronic key battery weak or depleted? (→P. 361)

● Is the power switch in ON mode?

When locking the doors, turn the power switch off. (→P. 210)

● Is the electronic key left inside the vehicle?

When locking the doors, make sure that you have the electronic key on

your person.

● The function may not operate properly due to the condition of the radio

wave. (→P. 156)

The rear door cannot be opened

● Is the child-protector lock set?

The rear door cannot be opened from inside the vehicle when the lock is

set. Open the rear door from outside and then unlock the child-protector

lock. (→P. 147)

PRIUS +_OM_OM47B24E_(EE)

What to do if... (Troubleshooting)

487

If you think something is wrong

The hybrid system does not start

● Did you press the power switch while firmly depressing the brake pedal?

(→P. 207)

● Is the shift position in P? (→P. 207)

● Is the electronic key anywhere detectable inside the vehicle? (→P. 153)

● Is the electronic key battery weak or depleted?

In this case, the hybrid system can be started in a temporary way.

(→P. 450)

● Is the 12-volt battery discharged? (→P. 452)

The windows do not open or close by operating the power

window switches

● Is the window lock switch pressed?

The power windows except for the one at the driver’s seat cannot be oper-

ated if the window lock switch is pressed. (→P. 191)

The power switch is turned off automatically

● The auto power off function will be operated if the vehicle is left in

ACCESSORY or ON mode (the hybrid system is not operating) for a

period of time. (→P. 211)

PRIUS +_OM_OM47B24E_(EE)

488

What to do if... (Troubleshooting)

A warning buzzer sounds during driving

● The seat belt reminder light is flashing

Are the driver and the front passenger wearing the seat belts? (→P. 392)

● The parking brake indicator is on

Is the parking brake released? (→P. 222)

Depending on the situation, other types of warning buzzer may also sound.

(→P. 387, 400)

An alarm is activated and the horn sounds (vehicles with

alarm)

● Did anyone inside the vehicle open a door during setting the alarm?

The sensor detects it and the alarm sounds. (→P. 98)

To stop the alarm, turn the power switch to ON mode or start the hybrid sys-

tem.

A warning buzzer sounds when leaving the vehicle

● Is the electronic key left inside the vehicle?

Vehicles without multi-information display: →P. 154

Vehicles with multi-information display: →P. 414

A warning light turns on or a warning message is displayed

● When a warning light turns on or a warning message is displayed, refer to

P. 387, 400.

PRIUS +_OM_OM47B24E_(EE)

What to do if... (Troubleshooting)

489

When a problem has occurred

If you have a flat tire

● Vehicles without spare tire

Stop the vehicle in a safe place and repair the flat tire temporarily with the

emergency tire puncture repair kit. (→P. 431)

● Vehicles with spare tire

Stop the vehicle in a safe place and replace the flat tire with the spare tire.

(→P. 417)

The vehicle becomes stuck

● Try the procedure for when the vehicle becomes stuck in mud, dirt, or

snow. (→P. 462)

PRIUS +_OM_OM47B24E_(EE)

490

Alphabetical index

Airbags

A/C

280

Airbag manual on-off

Air conditioning filter

357

system

Automatic air conditioning

Airbag operating conditions

system

280

Airbag precautions for your

Climate remote control

child

switches

288

Airbag warning light

388

Pollen removal mode

283

Correct driving posture

ABS

Curtain shield airbag

(Anti-lock Brake System)

256

operating conditions

Function

256

Curtain shield airbag

Warning light

388

precautions

Air conditioning filter

357

General airbag precautions

Air conditioning system

280

Locations of airbags

Air conditioning filter

357

Modification and disposal of

Automatic air conditioning

airbags

system

280

Side airbag operating

Climate remote control

conditions

switches

288

Side airbag precautions

Pollen removal mode

283

Side and curtain shield

Air intake vent

airbags operating

Airbag manual on-off

conditions

system

Side and curtain shield

airbags precautions

SRS airbags

PRIUS +_OM_OM47B24E_(EE)

Alphabetical index

491

Alarm

Back door

148

Warning buzzer

387

Back-up lights

Anchor brackets

Replacing light bulbs

372

Antenna

Wattage

474

Smart entry & start system

153

Battery (12-volt battery)

Anti-lock brake system

Battery checking

337

(ABS)

256

If the 12-volt battery is

Function

256

discharged

452

Warning light

388

Preparing and checking

Approach warning

246

before winter

274

Assist grips

305

Warning light

387

Audio input*

Battery (traction battery)

Audio system*

Bluetooth®*

Automatic air conditioning

Bottle holders

295

system

Brake

Air conditioning filter

357

Fluid

472

Automatic air conditioning

Parking brake

222

system

280

Regenerative braking

Automatic headlight leveling

Warning light

387

system

225

Brake assist

256

Function

225

Break-in tips

197

Warning light

391

Brightness control

Automatic light control

Instrument cluster light

system

224

control

114

AUX port*

Auxiliary boxes

297, 299

*: Refer to the “Navigation and multimedia system Owner’s Manual”.

PRIUS +_OM_OM47B24E_(EE)

492

Alphabetical index

Rear door child-protectors

147

Card holder

298

Removed key battery

Care

precautions

362

Aluminum wheels

311

Seat belt precautions

Exterior

310

Seat heater precautions

289

Interior

315

Child-protectors

147

Panoramic roof

314

Cleaning

Radar sensor

254, 269

Aluminum wheels

311

Seat belts

316

Exterior

310

Cargo hooks

299

Interior

315

CD player*

Panoramic roof

314

Chains

275

Radar sensor

254, 269

Child restraint system

Seat belts

316

Baby seat definition

Climate remote control

288

Baby seat installation

Clock

303

Child seat definition

Condenser

334

Child seat installation

Console box

294

Installing CRS with ISOFIX

Coolant

rigid anchors

Capacity

470

Installing CRS with seat belt ... 68

Checking

333

Installing CRS with top strap...76

Preparing and checking

Junior seats definition

before winter

274

Junior seat installation

Cooling system

333

Child safety

Hybrid system overheating ...457

12-volt battery precautions

339

Consumption screen

133

Airbag precautions

Cruise control

Back door precautions

150

Cruise control

235

Child restraint system

Dynamic radar cruise

How your child should wear

control

239

the seat belt

Warning messages

403

Installing child restraints

Cup holders

295

Power window lock switch

191

Curtain shield airbags

Power window precautions ...193

Customizable features

477

PRIUS +_OM_OM47B24E_(EE)

Toyota Prius+ (2016 year). Instruction - part 29
