5-1. Using the air conditioning system and defogger
289
Seat heaters∗
1
Heats the left front seat
2
Heats the right front seat
The indicator light comes on when
the seat heater is operating.
● The seat heaters can be used when the power switch is in ON mode.
● When not in use, turn off the switch. The indicator light turns off.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-
5
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
●Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
●Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent 12-volt battery discharge, do not use the functions when the
hybrid system is off.
∗: If equipped
PRIUS +_OM_OM47B24E_(EE)
290
5-2. Using the interior lights
Interior lights list
1
Rear interior light (→P. 292)
2
Front personal/interior lights (→P. 291)
3
Shift lever lighting
4
Footwell lights (if equipped)
5
Front door courtesy lights
PRIUS +_OM_OM47B24E_(EE)
5-2. Using the interior lights
291
Front interior light
X Vehicles without panoramic roof
X Vehicles with panoramic roof
1
Turns the lights off
1
Turns the lights off
2
Turns the door position on
2
Turns the door position on
3
Turns the lights on
3
Turns the lights on
Front personal lights
X Vehicles without panoramic roof
X Vehicles with panoramic roof
5
Turns the lights on/off
Turns the lights on/off
PRIUS +_OM_OM47B24E_(EE)
292
5-2. Using the interior lights
Rear interior light
Turns the door position on
1
When the front interior light main
switch is in the off position, the rear
interior light will not turn on even if
the door is opened with the rear
interior light switch in door position.
Turns the light on
2
● Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors
are locked/unlocked, and whether the doors are opened/closed.
●If the interior lights remain on when the power switch is turned off, the light
will go off automatically after 20 minutes.
● Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features: →P. 477)
NOTICE
To prevent 12-volt battery discharge, do not leave the lights on longer than
necessary when the hybrid system is off.
PRIUS +_OM_OM47B24E_(EE)
5-3. Using the storage features
293
List of storage features
5
1
Card holders
4
Glove boxes (→P. 294)
(if equipped: →P. 298)
5
Bottle holders/door pockets
2
Auxiliary boxes (→P. 297)
(→P. 295)
3
Cup holders (→P. 295)
6
Console box (→P. 294)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
PRIUS +_OM_OM47B24E_(EE)
294
5-3. Using the storage features
Glove boxes
X Upper glove box
X Lower glove box
Pull up the lever.
Pull up the lever.
If the lower glove box is opened when the front position lights are illuminated,
the light illuminates.
Console box
Push the button to open the lid.
The lid can be opened by pushing
either the front or rear button.
PRIUS +_OM_OM47B24E_(EE)
5-3. Using the storage features
295
Cup holders/bottle holders/door pockets
■ Cup holders
X Front passenger’s side
X Center console
Push the lid.
1
Front
2
Rear
■ Bottle holders/door pockets
X Front doors
X Rear doors
5
X Third seats
PRIUS +_OM_OM47B24E_(EE)
296
5-3. Using the storage features
● When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles or glass
and paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.
PRIUS +_OM_OM47B24E_(EE)
5-3. Using the storage features
297
Auxiliary boxes
X Type A (if equipped)
X Type B
Press in the lid.
The overhead console is useful for
temporarily storing small items.
X Type C (if equipped for right-
hand drive vehicles)
5
WARNING
Do not store items heavier than 200 g (0.44 lb.).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident. (type A)
PRIUS +_OM_OM47B24E_(EE)
298
5-3. Using the storage features
Card holders
X Left-hand drive vehicles
X Right-hand drive vehicles
(if equipped)
PRIUS +_OM_OM47B24E_(EE)
5-3. Using the storage features
299
Luggage compartment features
Cargo hooks
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
Auxiliary boxes
X Center
X Side
5
Lift the deck board.
Lift the center deck board and
then lift the side deck boards.
When closing, lift the deck board
slightly and then fold it towards the
Lift the side deck board from the
rear of the vehicle.
front side of the vehicle to prevent
hitting the cargo hook.
PRIUS +_OM_OM47B24E_(EE)
300
5-3. Using the storage features
Luggage cover (if equipped)
■ Installing the luggage cover
Set the holder of one side into
the installation position, then
install both holders from below
with the cover in its contracted
state.
■ Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.
Attach the hooks to the head
restraints.
■ Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
PRIUS +_OM_OM47B24E_(EE)
5-3. Using the storage features
301
■ Stowing the luggage cover
Lift the center deck board
1
and remove the side deck
boards.
Fold inwards together with
2
the head restraint installation
hooks and secure. Then,
stow in the auxiliary boxes.
5
WARNING
● To avoid injury, always return the cargo hooks to their stowed positions
when not in use.
● If the deck boards are removed, return them to their original positions
before driving. In the event of sudden braking, an accident may occur due
to an occupant being struck by the deck boards or the items stored in the
auxiliary box.
●Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.
PRIUS +_OM_OM47B24E_(EE)
302
5-4. Using the other interior features
Other interior features
Sun visors
To set the visor in the forward
1
position, flip it down.
To set the visor in the side posi-
2
tion, flip down, unhook, and
swing it to the side.
Vanity mirrors
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity lights remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the hybrid system is off.
PRIUS +_OM_OM47B24E_(EE)
5-4. Using the other interior features
303
Clock
The clock can be adjusted by pressing the buttons.
1
Adjusts the hours
2
Adjusts the minutes
3
Rounds to the nearest hour*
*: e.g. 1:00 to 1:29→1:00
1:30 to 1:59→2:00
●The clock is displayed when the power switch is in ACCESSORY or ON
mode.
● Even after the power switch has been turned off, the time will continue to be
displayed for approximately 30 seconds or until a door is locked.
5
PRIUS +_OM_OM47B24E_(EE)
304
5-4. Using the other interior features
Power outlet
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).
X Front
X Rear
Open the cover.
Open the cover.
The power outlet can be used when the power switch is in ACCESSORY or
ON mode.
NOTICE
● To avoid damaging the power outlet, close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short
circuit.
● To prevent 12-volt battery discharge, do not use the power outlet longer
than necessary when the hybrid system is off.
PRIUS +_OM_OM47B24E_(EE)
5-4. Using the other interior features
305
Coat hooks
The coat hooks are provided with
the rear assist grips.
WARNING
Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.
Assist grips
An assist grip installed on the ceil-
5
ing can be used to support your
body while sitting on the seat.
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
NOTICE
To prevent damage to the assist grip, do not hang any heavy object or put a
heavy load on the assist grip.
