5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
The driver’s door
was opened and
closed with the
Press the
“ENGINE START
“ENGINE
STOP” switch
START
turned off and
STOP”
then the
switch
“ENGINE START
while
STOP” switch
depress-
was put in
ing the
ACCESSORY
clutch
mode twice with-
pedal.
out the engine
being started.
Once
Press the
(Flashes)
“ENGINE
During an engine
START
(Vehicles with a manual
starting proce-
STOP”
transmission)
dure in the event
switch
that the electronic
while
key was not func-
depress-
tioning properly
ing the
(→P. 456), the
clutch
“ENGINE START
pedal
STOP” switch
within 10
was touched with
seconds
the electronic
of the
key.
buzzer
sounding.
420
86_EE (OM18071E)
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
Indicates that the
Release
steering lock has
the steer-
Once
not been
ing lock.
(Flashes)
released.
(→P. 180)
(Flashes quickly in green)
The “ENGINE
START STOP”
Con-
switch has been
Shift the
tinu-
turned off with the
shift lever
ous
shift lever in a
to P.
(Flashes)
position other
(Vehicles with an auto-
than P.
matic transmission)
After the
“ENGINE START
STOP” switch
Turn the
has been turned
“ENGINE
5
Once
off with the shift
START
lever in a posi-
STOP”
(Flashes)
tion other than P,
switch off.
(Vehicles with an auto-
the shift lever has
matic transmission)
been shifted to P.
■ Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.
421
86_EE (OM18071E)
5-2. Steps to take in an emergency
If you have a flat tire (vehicles with an emergency tire puncture repair kit)
Your vehicle is not equipped with a spare tire, but instead is
equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire tread
can be repaired temporarily using the emergency tire puncture repair
kit. (The kit contains a bottle of sealant. The sealant can be used only
once to temporarily repair one tire without removing the nail or
screw from the tire.) Depending on the damage, this kit cannot be
used to repair the tire. (→P. 424)
After temporarily repairing the tire with the kit, have the tire repaired
or replaced by any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional. Repairs conducted using
the emergency tire puncture repair kit are only a temporary measure.
Have the tire repaired and replaced as soon as possible.
422
86_EE (OM18071E)
5-2. Steps to take in an emergency
■ Before repairing the tire
● Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P (vehicles with an automatic transmis-
sion) or N (vehicles with a manual transmission).
● Stop the engine.
● Turn on the emergency flashers. (→P. 384)
● Check the
degree of the tire
damage.
• Do not remove the nail or
screw from the tire.
Removing the object may
widen the opening and
prevent emergency repair
with the repair kit.
• To avoid sealant leakage,
move the vehicle until the
5
area of the puncture, if
known, is positioned at
the top of the tire.
423
86_EE (OM18071E)
5-2. Steps to take in an emergency
■ A flat tire that cannot be repaired with the emergency tire puncture
repair kit
In the following cases, the tire cannot be repaired with the emergency tire
puncture repair kit. Contact any authorized Toyota dealer or repairer, or
another duly qualified and equipped professional.
● When the tire is damaged due to driving without sufficient air pressure
● When there are any cracks or damage at any location on the tire, such as
on the side wall, except the tread
● When the tire is visibly separated from the wheel
● When the cut or damage to the tread is 4 mm (0.16 in.) long or more
●When the wheel is damaged
● When two or more tires have been punctured (the sealant can be used
only once to temporarily repair one tire)
● When more than 2 sharp objects such as nails or screws have passed
through the tread on a single tire
●When the sealant has expired
424
86_EE (OM18071E)
5-2. Steps to take in an emergency
■ Location of the emergency tire puncture repair kit, jack and
tools
Jack handle
Towing eyelet
Emergency
tire puncture
repair kit
Wheel nut
Jack*
wrench
Screwdriver
*: Use of the jack (→P. 440)
■ Contents
Injection
Quick reference
hose
Valve core tool
Stickers
5
Valve core
(spare)
Sealant
Compressor
Extension hose (for
extracting the sealant)
425
86_EE (OM18071E)
5-2. Steps to take in an emergency
Taking out the emergency tire puncture repair kit
STEP
1
Vehicles with a luggage mat:
Remove the luggage mat.
STEP
2
Take out the emergency tire puncture repair kit.
Emergency repair method
STEP
1
Shake the sealant bottle up and down several times and
remove the cap of the sealant bottle.
STEP
2
Connect the injection hose by
screwing onto the sealant. As it
Injection
is screwed in, the aluminum seal
hose
on the bottle will be torn.
Sealant
STEP
3
Position the nail or screw that
has punctured the tire at the bot-
tom, in contact with the ground.
Remove the cap from the valve.
Valve
Cap
426
86_EE (OM18071E)
5-2. Steps to take in an emergency
STEP
4
Bring the protruding part of the
valve core tool into contact with
Valve core
tool
the valve to discharge air.
Valve
Protruding
part
STEP
5
Pull out the valve core by turning
it
counterclockwise using the
valve core tool.
Valve core
STEP
6
Remove the plug from the injec-
tion hose.
Plug
5
Injection
hose
STEP
7
Connect the injection hose to the
Valve
valve.
Injection
hose
427
86_EE (OM18071E)
5-2. Steps to take in an emergency
STEP
8
Inject the sealant that is in the
bottle. Hold and tilt the bottle,
then squeeze sealant out of the
bottle as shown.
STEP
9
Remove the injection hose from
Valve
the valve and screw the valve
core tool
core in the valve securely by
turning it clockwise with the
valve core tool.
Valve core
STEP
10
Attach the sticker as shown.
Remove any dirt and moisture
from the wheel before attaching
the label. If it is impossible to
attach the label, make sure to tell
any authorized Toyota dealer or
repairer, or another duly qualified
and equipped professional when
you have them repair and replace
the tire that sealant is injected.
STEP
11
Store the kit and then attach the
sticker as shown.
428
86_EE (OM18071E)
5-2. Steps to take in an emergency
STEP
12
Connect the compressor power
Power plug
plug to the power outlet.
Vehicles without a smart entry &
start system: The engine switch
must be in the “ACC” position.
Power
Vehicles with a smart entry & start
outlet
system: The
“ENGINE START
STOP” switch must be in ACCES-
SORY mode.
STEP
13
Connect the air compressor
hose by threading it on the valve.
Compressor
Hose
STEP
14
Left-hand drive vehicles: Check
the specified inflation pressure.
The label is placed as shown in
5
the illustration.
STEP
14
Right-hand drive vehicles: Check
the specified inflation pressure.
The label is placed as shown in
the illustration.
429
86_EE (OM18071E)
5-2. Steps to take in an emergency
STEP
15
Turn the compressor switch “ON”
and fill the tire with air until the
specified inflation pressure is
reached.
Switch
STEP
16
Turn the switch “OFF” when the pressure gauge connected to
the hose reads the specified pressure.
If the inflation pressure is not attained within 10 minutes, emergency
repair is not possible due to severe damage. Contact any authorized
Toyota dealer or repairer, or another duly qualified and equipped pro-
fessional.
After completely filling the tire with air, disconnect the hose
STEP
17
from the valve on the tire and pull the power plug of the com-
pressor out of the power outlet on the vehicle.
STEP
18
To spread the liquid sealant evenly in the tire, immediately
drive for about 10 minutes.
STEP
19
After driving about 10 minutes,
pull your vehicle over in a safe
place and reconnect the com-
pressor.
430
86_EE (OM18071E)
5-2. Steps to take in an emergency
STEP
20
Read the inflation pressure on
the pressure gauge.
If the pressure is 130 kPa (1.3
kgf/cm2 or bar, 19 psi) or above,
fill the tire with air using the com-
pressor until the specified infla-
tion pressure is reached.
If the pressure is less than 130
kPa (1.3 kgf/cm2 or bar, 19 psi),
the emergency repair that have
been performed is not safe for
use as damage to the tire is too
severe. Do not continue to drive
the vehicle. Contact any autho-
5
rized Toyota dealer or repairer, or
another duly qualified and
equipped professional.
Taking precautions to avoid sudden braking, sudden accelera-
STEP
21
tion and sharp turns, drive carefully at under 80 km/h (50
mph) to the nearest authorized Toyota dealer or repairer, or
another duly qualified and equipped professional for tire repair
or replacement.
431
86_EE (OM18071E)
5-2. Steps to take in an emergency
■ After a tire is repaired with the emergency tire puncture repair kit
●The tire pressure warning valve and transmitter should be replaced.
●Even if the tire inflation pressure is at the recommended level, the tire
pressure warning light may come on/flash.
■ Note for checking the emergency tire puncture repair kit
Check the sealant expiry date occasionally.
The expiry date is shown on the bottle. Do not use sealant whose expiry
date has already passed. Otherwise, repairs conducted using the emer-
gency tire puncture repair kit may not be performed properly.
■ Emergency tire puncture repair kit
●The sealant stored in the emergency tire puncture repair kit can be used
only once to temporarily repair a single tire. If the sealant has been used
and needs to be replaced, purchase a new bottle at any authorized
Toyota dealer or repairer, or another duly qualified and equipped profes-
sional. The compressor is reusable.
●The sealant can be used when the outside temperature is -40°C (-40°F)
or more.
●The repair kit is exclusively designed for size and type of tires originally
installed on your vehicle. Do not use it for tires that a different size than
the original ones, or for any other purposes.
●The sealant has a limited lifespan. The expiry date is marked on the bot-
tle. The bottle of sealant should be replaced with a new bottle before the
expiry date. Contact any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional for replacement.
● If the sealant gets on your clothes, it may stain.
● If the sealant adheres to a wheel or the surface of the vehicle body, the
stain may not be removable if it is not cleaned at once. Immediately wipe
away the sealant with a wet cloth.
●During operation of the repair kit, a loud operation noise is produced.
This does not indicate a malfunction.
●Do not use to check or to adjust the tire pressure.
432
86_EE (OM18071E)
5-2. Steps to take in an emergency
WARNING
■ Do not drive the vehicle with a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair.
Driving with a flat tire may cause a circumferential groove on the side wall. In
such a case, the tire may explode when using a repair kit.
■ Caution while driving
● Store the repair kit in the trunk.
Injuries may result in the event of an accident or sudden braking.
●The repair kit is exclusively only for your vehicle.
Do not use repair kit on other vehicles, which could lead to an accident
causing death or serious injury.
●Do not use repair kit for tires that are different size than the original ones,
or for any other purpose. If the tires have not been completely repaired, it
could lead to an accident causing death or serious injury.
■ Precautions for use of the sealant
● Ingesting the sealant is hazardous to your health. If you ingest sealant,
consume as much water as possible, and then immediately consult a doc-
tor.
● If sealant gets in eyes or adheres to skin, immediately wash it off with
5
water. If discomfort persists, consult a doctor.
433
86_EE (OM18071E)
5-2. Steps to take in an emergency
WARNING
■ When fixing the flat tire
● Stop your vehicle in a safe and flat area.
● If force is used to turn the valve core tool while air remains in the tire, spe-
cial care should be taken because the valve core could fly out.
● Be careful, as sealant may fly out if you shake the bottle with the hose
installed.
●Do not touch the wheels or the area around the brakes immediately after
the vehicle has been driven.
After the vehicle has been driven, the wheels and the area around the
brakes may be extremely hot. Touching these areas with hands, feet or
other body parts may result in burns.
●Connect the valve and hose securely with the tire installed on the vehicle.
If the hose is not properly connected to the valve, air leakage may occur
as sealant may be sprayed out.
●If the hose comes off the valve while inflating the tire, there is a risk that
the hose will move abruptly due to air pressure.
434
86_EE (OM18071E)
