3-2. Using the audio system
Steering wheel audio switches∗
Some audio features can be controlled using the switches on the
steering wheel.
Operation may differ depending on the type of audio system or navi-
gation system. For details, refer to the manual provided with the
audio system or navigation system.
3
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
∗: If equipped
285
86_EE (OM18071E)
3-3. Using the interior lights
Interior lights list
Interior light (→P. 287)
Engine switch light (vehicles without a smart entry & start sys-
tem)
“ENGINE START STOP” switch light (vehicles with a smart entry
& start system)
Door courtesy lights (if equipped)
286
86_EE (OM18071E)
3-3. Using the interior lights
Interior light
Interior light
Turns the light off
Turns the door position on
Turns the light on
■ Illuminated entry system
3
Vehicles without a smart entry & start system
The lights automatically turn on/off according to the engine switch position,
whether the doors are locked/unlocked, and whether the doors are open/
closed.
Vehicles with a smart entry & start system
The lights automatically turn on/off according to “ENGINE START STOP”
switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are open/closed.
■ To prevent battery discharge
If the following lights remain on when the door is not fully closed, the lights
will go off automatically after 20 minutes:
● Interior light (when the switch is in the “DOOR” position)
●Engine switch light (vehicles without a smart entry & start system)
●“ENGINE START STOP” switch light (vehicles with a smart entry & start
system)
●Door courtesy lights (if equipped)
■ Customization that can be configured at any authorized Toyota dealer
or repairer, or another duly qualified and equipped professional
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features →P. 487)
287
86_EE (OM18071E)
3-4. Using the storage features
List of storage features
Glove box
Bottle holders
Cup holders/console tray
WARNING
■ Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
288
86_EE (OM18071E)
3-4. Using the storage features
Glove box
Glove box
Pull up the lever to open the
glove box.
WARNING
3
■ Caution while driving
Keep the glove box closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
glove box or the items stored inside.
289
86_EE (OM18071E)
3-4. Using the storage features
Bottle holders
Bottle holders
■ When using the bottle holder
● When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
WARNING
■ Items unsuitable for the bottle holder
Do not place anything other than a pet bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■ Items unsuitable for the bottle holder
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.
290
86_EE (OM18071E)
3-4. Using the storage features
Cup holders/console tray
Cup holders/console tray
■ Changing the cup holder position
3
Remove the cup holder and change the
holder position.
■ Changing the console tray size
Remove the cup holder.
291
86_EE (OM18071E)
3-4. Using the storage features
Cup holders/console tray
WARNING
■ Caution while driving
Observe the following precautions.
Failure to do so may cause an accident resulting in death or serious injury.
● Before driving, place the cup holder in the rear position so that it does not
hinder shift lever operation.
● When placing the cup holder, make
sure it is facing the correct direction.
Failure to do so will cause the cup
holder to not be secure in the console
tray and hinder shift lever operation.
■ Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent burns.
292
86_EE (OM18071E)
3-5. Other interior features
Sun visors
To set the visor in the for-
ward position, flip it down.
To set the visor in the side
position, flip down, unhook,
and swing it to the side.
3
293
86_EE (OM18071E)
3-5. Other interior features
Vanity mirrors
Open the cover to use.
Vehicles with vanity lights: The
light turns on when the cover is
opened.
NOTICE
■ To prevent battery discharge (vehicles with vanity lights)
Do not leave the vanity lights on for extended periods while the engine is off.
294
86_EE (OM18071E)
3-5. Other interior features
Clock
The clock can be adjusted by pressing the buttons.
Adjusts the hours
Adjusts the minutes
Rounds to the nearest
hour*
*: e.g.1:00 to 1:29 → 1:00
00
1:30 to 1:59 → 2:00
3
■ The clock is displayed when
Vehicles without a smart entry & start system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart entry & start system
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON
mode.
■ When disconnecting and reconnecting battery terminals
The clock data will be reset.
295
86_EE (OM18071E)
3-5. Other interior features
Ashtray∗
The ashtray can be installed in
the cup holder. (→P. 291)
WARNING
■ When not in use
Keep the ashtray closed. In the event of sudden braking, an accident may
occur due to an occupant being struck by the open ashtray or ash flying out.
■ To prevent fire
●Fully extinguish matches and cigarettes before putting them in the ashtray,
then make sure the ashtray is fully closed.
●Do not place paper or any other type of flammable object in the ashtray.
∗: If equipped
296
86_EE (OM18071E)
3-5. Other interior features
Power outlets
The power outlet can be used for 12 V accessories that run on 10 A
or less.
In the console tray
3
In the glove box
297
86_EE (OM18071E)
3-5. Other interior features
■ The power outlet can be used when
Vehicles without a smart entry & start system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart entry & start system
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON
mode.
NOTICE
■ To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.
■ To prevent the fuse from being blown
Do not use an accessory that uses more than 12 V 10 A.
■ To prevent battery discharge
Do not use the power outlet longer than necessary when the engine is not
running.
298
86_EE (OM18071E)
3-5. Other interior features
Seat heaters∗
Press the switch to warm the
seats.
The indicator light comes on
when a seat heater is turned
on.
Rapid heating
Normal heating
■ The seat heaters can be used when
The “ENGINE START STOP” switch is in IGNITION ON mode.
3
■ When not in use
Turn the seat heater off. The indicator light goes off.
WARNING
■ Burns
●Use caution when seating the following persons in a seat with the seat
heater on to avoid the possibility of burns:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
●Do not cover the seat with anything when using the seat heater.
Using the seat heater with a blanket or cushion increases the temperature
of the seat and may lead to overheating.
●Do not use the seat heater more than necessary. Doing so may cause
minor burns or overheating.
∗: If equipped
299
