3-1. Using the air conditioning system and defogger
Rear window and outside rear view mirror defoggers
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Vehicles with manual air conditioning system
On/off
The defoggers will automati-
cally turn off after approxi-
mately
15 minutes. Pressing
the switch again also turns the
rear window defogger off.
Vehicles with automatic air conditioning system
On/off
The defoggers will automati-
cally turn off after approxi-
mately
15 minutes. Pressing
the switch again also turns the
rear window defogger off.
270
URBAN CRUISER_OM_OM52F47E_(EE)
3-1. Using the air conditioning system and defogger
■ The defoggers can be operated when
Vehicles without smart entry & start system
The engine switch is in the “ON” position.
Vehicles with smart entry & start system
The “ENGINE START STOP” switch is in the IGNITION ON mode.
■ The outside rear view mirror defoggers
Turning the rear window defogger on will turn the outside rear view mirror
defoggers on.
CAUTION
■ When the outside rear view mirror defoggers are on
3
Do not touch the outside surface of the rear view mirrors, as they can
become very hot and burn you.
271
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
Audio system types∗
With navigation system
Owners of models equipped with a navigation system should
refer to the “Navigation System Owner’s Manual”.
Without navigation system
Title
Page
Using the radio
P. 274
Using the CD player
P. 278
Playing back MP3 and WMA discs
P. 285
Optimal use of the audio system
P. 293
Using the AUX port
P. 296
Using the steering switches
P. 297
∗: If equipped
272
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
NOTICE
■ To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine off.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.
3
273
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
Using the radio
Press
or
to choose an MW or FM band.
Power Volume
Station selector
AF mode button
TA mode button
Seeking the
frequency
Adjusting the
frequency
Automatic presetting
AM·DAB/FM
Changing the
radio stations
mode buttons
program types
Setting station presets
■ Manually
In AF-ON mode the radio changes frequency to the strongest sig-
nal of the selected station.
STEP
1
Search for desired stations by turning the
dial or
pressing “∧” or “∨” on
274
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
STEP
2
Press and hold the button (from
to
) the station is
to be set to, and you hear a beep.
■ Automatically
Press and hold
until you hear a beep.
Up to 6 stations are set in order of reception quality. When the settings
are finished, 2 beeps will be heard.
In the FM1 or FM2 mode, the stations automatically set by the audio sys-
tem will be set in the FM3 presets.
RDS (Radio Data System)
This feature allows your radio to receive station and program informa-
3
tion
(classical, news, etc.) from radio stations that broadcast this
information.
■ Listening to stations of the same network
Press
AF-ON, REG-OFF modes: A station among those of the same net-
work with strong reception is selected.
Switching between different regional
programs of the same station might
occur.
AF-ON, REG-ON modes: A station among those of the same net-
work with strong reception and broad-
casting the same program is selected.
Each time
is pressed, the mode changes in the order of AF-ON,
REG-OFF→AF-ON, REG-ON→AF-OFF, REG-OFF.
275
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ Specifying program type
Press
Each time
is pressed, the program type changes in the order of
“NEWS”→“SPORTS”→“TALK”→“POP”→“CLASSICS”.
■ Traffic information
Press
TP mode: The system automatically switches to traffic information
when a broadcast with a traffic information signal is
received.
The station returns to the previous one when the traffic infor-
mation ends.
TA mode: Traffic information can be heard only when a signal is
received. The system switches to the mute mode when
a signal is not received. In the CD or MP3/WMA mode,
the system automatically switches to traffic information
when a signal is received.
The audio system returns to the mute, CD or MP3/WMA
mode when the traffic information ends.
The audio system mode changes as follows each time
is
pressed.
FM modes: TP→TA→OFF
Modes other than the radio modes: TA→OFF
■ Emergency broadcast reception mode
“ALARM” appears in the display in the event that an emergency
broadcast is received, and the emergency broadcast is aired.
276
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ EON (Enhanced Other Network) system (for traffic announcement
function)
If the RDS station (with EON data) you are listening to is not broadcasting a
traffic information program and the audio system is in the TA
(traffic
announcement) mode, the radio will be switched automatically to a station
broadcasting a traffic information program in the EON AF list when traffic
information begins.
■ When the battery is disconnected
All preset stations are erased.
■ Reception sensitivity
●Maintaining perfect radio reception at all times is difficult due to the con-
tinually changing position of the antenna, differences in signal strength
3
and surrounding objects, such as trains, transmitters, etc.
●When
is used, automatic station selection and automatic registering
of stations may not be possible.
●The radio antennas are mounted on the rear roof.
The rear roof antenna can be removed from the base by turning.
■ Digital Audio Broadcast (DAB) radio
The optional radio antenna and tuner are necessary for the use of Digital
Audio Broadcast (DAB) radio.
NOTICE
■ To prevent damage, remove the antenna in the following cases
●The antenna will touch the ceiling of a garage.
●A cover will be put on the roof.
●When driving through an automatic car wash.
● Any other cases where there is a risk of touching surrounding parts.
277
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
Using the CD player
Insert a CD or press
with a CD inserted.
Power Volume
Selecting a track,
fast-forwarding or
CD eject
reversing
CD slot
Repeat play
Random play
Playback
Displays text message
Loading a CD
Insert a CD.
Ejecting a CD
Press
and remove the CD.
278
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
Selecting a track
Press “∧” to move up or “∨” to move down using
until the
desired track number appears on the display.
Fast forwarding and rewinding tracks
Press and hold “∧” or “∨” on
3
Random playback
■ Current CD
Press
(RAND).
Tracks are played in random order until the button is pressed once
again.
Repeating a track or a disc
■ Repeating a track
Press
(RPT).
Switching the display
Press
Each time the button is pressed, the display changes in the order of Track
no./Elapsed time→CD title→Track again.
279
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ Display
Up to 12 characters can be displayed at a time.
If there are 13 characters or more, pressing and holding
for 1 sec-
ond or more will display the remaining characters.
A maximum of 24 characters can be displayed.
If
is pressed for 1 second or more again or has not been pressed
for 6 seconds or more, the display will return to the first 12 characters.
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.
■ Canceling random and repeat playback
Press
(RAND) or
(RPT) again.
280
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ Error messages
Refer to the following table and take the appropriate measures. If the prob-
lem is not rectified, take the vehicle to any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.
Correction
Message
Cause
Procedures
Operation is stopped
Eject the CD and allow
WAIT
due to a high tempera-
the player to cool down
ture inside the player
• The CD may be dirty or
damage
• Clean the CD
ERROR1
• The CD may be
• Insert the CD correctly
inserted upside down
3
There is a problem
ERROR3
Eject the CD
within the system
Ask any authorized
Toyota dealer or
ERROR4
Over-current
repairer, or another
duly qualified and
equipped professional
281
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
■ Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea-
tures, or due to scratches, dirt or deterioration.
CDs with copy-protect features may not play correctly.
■ CD player protection feature
To protect the internal components, playback is automatically stopped when
a problem is detected.
■ If CD is left inside the CD player or in the ejected position for extended
periods
CD may be damaged and may not play properly.
■ Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.
CAUTION
■ Certification for the CD player
This product is a class I laser product.
●A laser beam leak may result in hazardous radiation exposure.
●Do not open the cover of the player or attempt to repair the unit yourself.
Refer servicing to qualified personnel.
● Laser power: No hazardous
282
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
NOTICE
■ CDs and adapters that cannot be used
Do not use the following types of CDs.
Also, do not use 8 cm (3 in.) CD adapters, DualDiscs or printable discs.
Doing so may damage the player and/or the CD insert/eject function.
● CDs that have a diameter that is not 12
cm (4.7 in.)
3
● Low-quality and deformed CDs
● CDs with a transparent or translucent
recording area
● CDs that have tape, stickers or CD-R
labels attached to them, or that have
had the label peeled off
283
URBAN CRUISER_OM_OM52F47E_(EE)
3-2. Using the audio system
NOTICE
■ Player precautions
Failure to follow the precautions below may result in serious damage to the
CDs or the player itself.
●Do not insert anything other than CDs into the CD slot.
●Do not apply oil to the CD player.
● Store CDs away from direct sunlight.
●Never try to disassemble any part of the CD player.
284
