Toyota Urban Cruiser (2015 year). Instruction

2-4. Using other driving systems

■ Turning off both TRC and VSC systems

To turn the TRC and VSC systems off, press and hold

for more than 3

seconds while the vehicle is stopped.

The “TRC OFF” indicator light and VSC OFF indicator light will come on.

Press

again to turn the systems back on.

■ When the “TRC OFF” indicator light comes on even if the VSC OFF

switch has not been pressed

TRC cannot be operated. Contact any authorized Toyota dealer or repairer,

or another duly qualified and equipped professional.

■ Sounds and vibrations caused by the ABS, brake assist, TRC and VSC

systems

● A sound may be heard from the engine compartment when the brake

pedal is depressed repeatedly, when the engine is started or just after the

vehicle begins to move. This sound does not indicate that a malfunction

has occurred in any of these systems.

● Any of the following conditions may occur when the above systems are

operating. None of these indicates that a malfunction has occurred.

• Vibrations may be felt through the vehicle body and steering.

• A motor sound may be heard after the vehicle comes to a stop.

• The brake pedal may pulsate slightly after the ABS is activated.

• The brake pedal may move down slightly after the ABS is activated.

■ EPS operation sound

When the steering wheel operates, a motor sound (whirring sound) may be

heard. This dose not indicate a malfunction.

225

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

■ Automatic reactivation of TRC and VSC systems

After turning the TRC and VSC systems off, the systems will be automati-

cally re-enabled in the following situations:

●When the engine is turned off

● If only the TRC system is turned off, the TRC will turn on when vehicle

speed increases

If both the TRC and VSC systems are turned off, automatic re-enabling

will not occur when vehicle speed increases.

■ Reduced effectiveness of the EPS system

The effectiveness of the EPS system is reduced to prevent the system from

overheating when there is frequent steering input over an extended period of

time. The steering wheel may feel heavy as a result. Should this occur,

refrain from excessive steering input or stop the vehicle and turn the engine

off. The EPS system should return to normal within 10 minutes.

226

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

CAUTION

■ The ABS does not operate effectively when

●The limits of tire gripping performance have been exceeded (such as

excessively worn tires on a snow covered road).

●The vehicle hydroplanes while driving at high speed on the wet or slick

roads.

■ Stopping distance when the ABS is operating may exceed that of nor-

mal conditions

The ABS is not designed to shorten the vehicle’s stopping distance. Always

maintain a safe distance from the vehicle in front of you, especially in the fol-

lowing situations:

● When driving on dirt, gravel or snow-covered roads

●When driving with tire chains

●When driving over bumps in the road

● When driving over roads with potholes or uneven surfaces

■ TRC may not operate effectively when

Directional control and power may not be achievable while driving on slip-

pery road surfaces, even if the TRC system is operating.

Drive the vehicle carefully in conditions where stability and power may be

lost.

■ When the VSC is activated

The slip indicator light flashes. Always drive carefully. Reckless driving may

cause an accident. Exercise particular care when the indicator light flashes.

■ When the TRC/VSC systems are turned off

Be especially careful and drive at a speed appropriate to the road condi-

tions. As these are systems to ensure vehicle stability and driving force, do

not turn the TRC/VSC systems off unless necessary.

227

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

CAUTION

■ Replacing tires

Make sure that all tires are of the specified size, brand, tread pattern and

total load capacity. In addition, make sure that the tires are inflated to the

recommended tire inflation pressure level.

The ABS, TRC and VSC systems will not function correctly if different tires

are installed on the vehicle.

Contact any authorized Toyota dealer or repairer, or another duly qualified

and equipped professional for further information when replacing tires or

wheels.

■ Handling of tires and suspension

Using tires with any kind of problem or modifying the suspension will affect

the driving assist systems, and may cause the system to malfunction.

228

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

Four-wheel drive lock (4WD models)

Four-wheel drive lock mode can be used when a large amount of

drive power needs to be applied to all the wheels, such as when the

vehicle gets stuck in mud and you need to free it.

Push the button.

The torque of the engine is dis-

tributed to the rear wheels to

the maximum extent possible

in accordance with driving con-

ditions.

Push the button again cancels

four-wheel drive lock mode

and returns the Active Torque

Control

4WD system to nor-

mal mode. (→P. 223)

■ Four-wheel drive lock mode can be operated when

Vehicles without smart entry & start system

The engine switch is in the “ON” position.

Vehicles with smart entry & start system

The “ENGINE START STOP” switch is in IGNITION ON mode.

■ Four-wheel drive lock mode

●Four-wheel drive lock mode is canceled when the brakes are applied to

ensure the ABS and VSC system operate effectively.

●Four-wheel drive lock mode is canceled when the vehicle speed exceeds

40 km/h (25 mph).

229

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

Diesel Particulate Filter system (diesel engine only)

When the deposit collected by the filter reaches a predetermined

amount, it is automatically cleaned.

■ Cleaning the DPF catalytic converter

Cleaning the DPF catalytic converter is performed as necessary

in accordance with driving conditions.

■ Equipment characteristics

The DPF system has the following characteristics:

● Idle speed increases during cleaning

● The smell of the exhaust gas changes

● When starting the engine, white-colored steam (water vapor)

may be expelled during cleaning

● Acceleration performance may degrade during cleaning

230

URBAN CRUISER_OM_OM52F47E_(EE)

2-4. Using other driving systems

■ Replacing the engine oil

Make sure to use an oil of the recommended grade or of matching quality.

(→P. 514)

CAUTION

■ Exhaust pipe

Do not touch the exhaust pipe during cleaning, as the exhaust pipe and

exhaust gases will become particularly hot. Also, make sure that there are

no people or flammable materials near the exhaust pipe while the vehicle is

stopped.

Failure to do so may cause injury by burning or a fire.

NOTICE

■ To prevent the DPF system from failing

●Do not use fuel other than the specified type

●Do not use engine oil other than the recommended type

●Do not modify the exhaust pipe

231

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

Cargo and luggage

Take notice of the following information about storage precautions,

cargo capacity and load.

● Stow cargo and luggage in the luggage compartment whenever

possible.

● Be sure all items are secured in place.

● To maintain vehicle balance while driving, position luggage

evenly within the luggage compartment.

● For better fuel economy, do not carry unnecessary weight.

CAUTION

■ Things that must not be carried in the luggage compartment

The following things may cause a fire if loaded in the luggage compartment:

●Receptacles containing gasoline

●Aerosol cans

232

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

CAUTION

■ Storage precautions

Observe the following precautions.

Failing to do so may result in death or serious injury.

● Stow cargo and luggage in the luggage compartment whenever possible.

●Do not stack anything in the luggage compartment higher than the seat-

backs. Such items may be thrown about and possibly injure people in the

vehicle in the event of sudden braking or in an accident.

●Do not place cargo or luggage in or on the following locations as the item

may get under the clutch, brake or accelerator pedal and prevent the ped-

als from being depressed properly, block the driver’s vision, or hit the

driver or passengers, causing an accident.

• At the feet of the driver

• On the front passenger or rear seats (when stacking items)

• On the instrument panel

• On the dashboard

• Auxiliary box or tray that has no lid

●Secure all items in the occupant compartment, as they may shift and injure

someone during sudden braking, sudden swerving or an accident.

●When you fold down the rear seats, long items should not be place directly

behind the front seats.

●Never allow anyone to ride in the enlarged luggage compartment. It is not

designed for passengers. They should ride in their seats with their seat

belts properly fastened. Otherwise, they are much more likely to suffer

death or serious injury, in the event of sudden braking, sudden swerving or

an accident.

233

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

Winter driving tips

Carry out the necessary preparations and inspections before driving

the vehicle in winter. Always drive the vehicle in a manner appropri-

ate to the prevailing weather conditions.

■ Pre-winter preparations

● Use fluids that are appropriate to the prevailing outside tem-

peratures.

• Engine oil

• Engine coolant

• Washer fluid

● Have a service technician inspect the level and specific grav-

ity of battery electrolyte.

● Have the vehicle fitted with four snow tires or purchase a set

of tire chains for the front tires.

Ensure that all tires are the same size and brand, and that chains

match the size of the tires.

235

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

■ Before driving the vehicle

Perform the following according to the driving conditions.

● Do not try to forcibly open a window or move a wiper that is

frozen. Pour warm water over the frozen area to melt the ice.

Wipe away the water immediately to prevent it from freezing.

● To ensure proper operation of the climate control system fan,

remove any snow that has accumulated on the air inlet vents

in front of the windshield.

● Remove any ice that has accumulated on the vehicle chassis.

● Periodically check for and remove any excess ice or snow

that may have accumulated in the wheel well or on the

brakes.

■ When driving the vehicle

Accelerate the vehicle slowly and drive at a reduced speed suit-

able to road conditions.

■ When parking the vehicle (in the winter time or in the cold

latitudes)

Park the vehicle and move the shift lever to “R” without setting

the parking brake. The parking brake may freeze up, preventing

it from being released. If necessary block the wheels to prevent

inadvertent sliding or creeping.

236

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

Selecting tire chains

Use the correct tire chain size when mounting the tire chains.

Chain size is regulated for each tire size.

Side chain

(3.0 mm [0.12 in.] in diameter)

Cross chain

(4.0 mm [0.16 in.] in diameter)

Regulations on the use of tire chains

Regulations regarding the use of tire chains vary according to loca-

tion and type of road. Always check local regulations before installing

chains.

■ Tire chains

Observe the following precautions when installing and removing chains.

●Install and remove tire chains in a safe location.

● Install tire chains on the front tires only. Do not install tire chains on the

rear tires.

●Install tire chains on front tires as tightly as possible. Retighten chains

after driving 0.5 - 1.0 km (1/4 - 1/2 mile).

●Install tire chains following the instructions provided with the tire chains.

237

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

CAUTION

■ Driving with snow tires

Observe the following precautions to reduce the risk of accidents.

Failure to do so may result in a loss of vehicle control and cause death or

serious injury.

●Use tires of the size specified.

● Maintain the recommended level of air pressure.

●Do not drive at speeds in excess of the speed limit or the speed limit spec-

ified for the snow tires being used.

●Use snow tires on all, not just some wheels.

■ Driving with tire chains

Observe the following precautions to reduce the risk of accidents.

Failure to do so may result in the vehicle being unable to be driven safely,

and may cause death or serious injury.

●Do not drive in excess of the speed limit specified for the tire chains being

used or 50 km/h (30 mph), whichever is lower.

● Avoid driving on bumpy road surfaces or over potholes.

● Avoid sudden turns and braking, as use of chains may adversely affect

vehicle handling.

●Slow down sufficiently before entering a curve to ensure that vehicle con-

trol is maintained.

238

URBAN CRUISER_OM_OM52F47E_(EE)

2-5. Driving information

Trailer towing

Your vehicle is designed primarily as a passenger carrying vehicle.

Towing a trailer will have an adverse effect on handling, perfor-

mance, braking, durability, and fuel consumption. Your safety and

satisfaction depend on the proper use of correct equipment and cau-

tious driving habits. For your safety and the safety of others, do not

overload the vehicle or trailer.

To tow a trailer safely, use extreme care and drive the vehicle in

accordance with the trailer’s characteristics and operating condi-

tions.

Toyota warranties do not apply to damage or malfunction caused by

towing a trailer for commercial purposes.

Ask your local authorized Toyota dealer or repairer, or another duly

qualified and equipped professional, for further details before tow-

ing, as there are additional legal requirements in some countries.

■ Weight limits

Check the allowable towing capacity, GVM

(Gross Vehicle

Mass), MPAC (Maximum Permissible Axle Capacity), and per-

missible drawbar load before towing. (→P. 506)

■ Towing hitch/bracket

Toyota recommends the use of the Toyota hitch/bracket for your

vehicle. Other products of a suitable nature and comparable

quality may also be used.

239

URBAN CRUISER_OM_OM52F47E_(EE)

Toyota Urban Cruiser (2015 year). Instruction - part 16
