Toyota Celica (2005 year). Instruction - part 14
’05MY CELICA U (L/O 0409)
(c) Jump starting
To avoid serious personal injury and
JUMP STARTING PROCEDURE
damage to your vehicle which might re-
D The gas normally produced by a
1.
If the booster battery is installed in
battery will explode if a flame or
sult from battery explosion, acid burns,
another vehicle, make sure the vehicles
spark is brought near. Use only
electrical burns, or damaged electronic
are not touching. Turn off all unneces-
standardized jumper cables and do
components, these instructions must be
sary lights and accessories.
followed precisely.
not smoke or light a match while
jump starting.
When boosting, use the battery of
If you are unsure about how to follow this
matching or higher quality. Any other
procedure, we strongly recommend that
battery may be difficult to jump start
you seek the help of a competent me-
NOTICE
with.
chanic or towing service.
If jump starting is difficult, charge the
The battery used for boosting must
battery for several minutes.
CAUTION
be 12 V. Do not jump start unless you
are sure that the booster battery is
2.
If required, remove all the vent plugs
D Batteries contain sulfuric acid
correct.
from the booster and discharged batter-
which is poisonous and corrosive.
ies. Lay a cloth over the open vents
Wear protective safety glasses when
on the batteries. (This helps reduce the
jump starting, and avoid spilling
explosion hazard, personal injuries and
acid on your skin, clothing, or ve-
burns.)
hicle.
3.
If the engine in the vehicle with the
D If you should accidentally get acid
booster battery is not running, start it
on yourself or in your eyes, remove
and let it run for a few minutes. During
any contaminated clothing and flush
jump starting, run the engine at about
the affected area with water imme-
2000 rpm with the accelerator pedal
diately. Then get immediate medical
lightly depressed.
attention. If possible, continue to
apply water with a sponge or cloth
while en route to the medical office.
187
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
Discharged battery
Jumper cable
Booster
battery
Positive
terminal
Discharged battery
(“+” mark)
Booster
Jumper cable
Positive terminal
Negative terminal
battery
(“+”
mark)
(“−” mark)
Connecting point
4. Make the cable connections in the or-
c. Connect the clamp of the negative
der a, b, c, d.
(black) jumper cable to the negative (-)
terminal on the booster battery.
Do not connect the cable to or near
a. Connect the clamp of the positive
any part that moves when the engine
(red) jumper cable to the positive
(+)
d. Connect the clamp at the other end
is cranked.
terminal on the discharged battery.
of the negative
(black) jumper cable to
a solid, stationary, unpainted, metallic
b. Connect the clamp at the other end
CAUTION
point of the vehicle with the discharged
of the positive
(red) jumper cable to
battery.
the positive (+) terminal on the booster
When making the connections, to
battery.
The recommended connecting point is
avoid serious injury, do not lean over
shown in the following illustration:
the battery or accidentally let the
jumper cables or clamps touch any-
thing except the correct battery termi-
nals or the ground.
188
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
If your engine stalls while
If you cannot increase engine
driving
speed (2ZZ−GE engine)
5. Start your engine in the normal way.
If your engine stalls while driving...
If engine speed does not increase when
After starting, run it at about
2000 rpm
the accelerator pedal is depressed, there
1. Reduce your speed gradually, keeping
for several minutes with the accelerator
may be a problem somewhere in the elec-
a straight line. Move cautiously off the
pedal lightly depressed.
tronic throttle control system.
road to a safe place.
6. Carefully disconnect the cables in the
At this time, vibration may occur. Howev-
2. Turn on your emergency flashers.
exact reverse order: the negative cable
er, if you depress the accelerator pedal
3. Turn the ignition key to
“ACC” or
and then the positive cable.
more firmly and slowly, you can drive your
“LOCK”, and try starting the engine
vehicle at low speeds. Have your vehicle
7. Carefully dispose of the battery cover
again.
checked by your Toyota dealer as soon as
cloths—they may now contain sulfuric
If the engine will not start, see
“If your
possible.
acid.
vehicle will not start” in this Section.
Even if the abnormality of the electronic
8. If removed, replace all the battery vent
throttle control system is corrected during
plugs.
CAUTION
low speed driving, the system may not be
If the cause of your battery discharging is
recovered until the engine is stopped and
not apparent
(for example, lights left on),
If the engine is not running, the pow-
the ignition key is turned to
“ACC” or
you should have it checked at your Toyota
er assist for the brakes and steering
“LOCK” position.
dealer.
will not work so steering and braking
will be much harder than usual.
If the first start attempt is not success-
CAUTION
ful...
Be especially careful to prevent erro-
Check that the clamp on the jumper
neous pedal operation.
cables are tight. Recharge the discharged
battery with the jumper cables connected
for several minutes and restart your en-
gine in the normal way.
If the another attempt is not successful,
the battery may be depleted. Have it ch-
ecked at your Toyota dealer.
189
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
If your vehicle overheats
If
your engine coolant temperature
3. Look for obvious coolant leaks from the
gauge indicates overheating, if you ex-
radiator, hoses, and under the vehicle.
CAUTION
perience a loss of power, or if you hear
However, note that water draining from
Do not attempt to touch the coolant
a loud knocking or pinging noise, the
the air conditioning is normal if it has
reservoir tank when the engine and
engine has probably overheated. You
been used.
should follow this procedure...
radiator are hot. Serious injury could
result from scalding hot fluid and
1. Pull safely off the road, stop the ve-
CAUTION
steam blown out under pressure.
hicle and turn on your emergency
When the engine is running, keep
flashers. Put the transmission in
“P”
(automatic) or neutral (manual) and ap-
hands and clothing away from the
ply the parking brake. Turn off the air
moving fan and engine drive belts.
conditioning if it is being used.
2. If coolant or steam is boiling out of the
4. If the coolant is leaking, stop the en-
radiator or reservoir, stop the engine.
gine immediately. Call a Toyota dealer
Wait until the steam subsides before
for assistance.
opening the hood. If there is no coolant
5. If there are no obvious leaks, check
boiling over or steam, leave the engine
the coolant reservoir.
running and make sure the electric
If it is dry, call a Toyota dealer for
cooling fan is operating. If it is not,
assistance as soon as possible.
turn the ignition off.
If there is enough coolant in the reser-
voir, again check the coolant level in
CAUTION
the reservoir after the engine coolant
temperature has cooled to normal. Seri-
To help avoid personal injury, keep
ous coolant loss indicates a leak in the
the hood closed until there is no
system. You should have it checked as
steam. Escaping steam or coolant is
soon as possible at you Toyota dealer.
a sign of very high pressure.
For the coolant type, see “Coolant type
selection” in Section
7−2.
190
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
If you have a flat tire—
1.
Reduce your speed gradually,
CAUTION
D Make sure to set the jack prop-
keeping a straight line. Move cau-
erly in the jack point. Raising
tiously off the road to a safe place
When jacking, be sure to observe
the vehicle with jack improper-
well away from the traffic. Avoid
the following to reduce the possi-
ly positioned will damage the
stopping on the center divider of
bility of personal injury:
vehicle or may allow the ve-
a highway. Park on a level spot
hicle to fall off the jack and
with firm ground.
D Follow jacking instructions.
cause personal injury.
2.
Stop the engine and turn on your
D Do not put any part of your
D Never get under the vehicle
emergency flashers.
body under the vehicle sup-
when the vehicle is supported
ported by the jack. Otherwise,
3.
Firmly set the parking brake and
by the jack alone.
personal injury may occur.
put the transmission in “P” (auto-
D Use the jack only for lifting
matic) or reverse (manual).
D Do not start or run the engine
your vehicle during wheel
while your vehicle is supported
4.
Have everyone get out of the ve-
changing.
by the jack.
hicle on the side away from traffic.
D Do not raise the vehicle with
D Stop the vehicle on a level firm
5.
Read the following instructions
someone in the vehicle.
ground, firmly set the parking
thoroughly.
brake and put the transmission
D When raising the vehicle, do
in “P” (automatic) or reverse
not place any objects on top
(manual). Block the wheel diag-
of or underneath the jack.
onally opposite to the one be-
D Raise the vehicle only high
ing changed if necessary.
enough to remove and change
the tire.
191
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
NOTICE
Type A
Do not continue driving with a
deflated tire. Driving even a
short distance can damage a
tire and wheel beyond repair.
Type B
Spare tire with turning direction in-
Compact spare tire
dicators (some models)
The compact spare tire is designed
The spare tires with turning direc-
for temporary emergency use only.
tion indicators are directional and
The compact spare tire is identified
intended to be used so that they
by
the
distinctive
wording
turn in the same direction as the
“TEMPORARY USE ONLY” molded
turning direction indicators.
into the side wall of the tire.
Installing the wheel on the driver side
The compact spare tire saves space
of the vehicle will not affect tire perfor-
in your trunk or luggage compartment,
mance. If the spare tire is used on
and its lighter weight helps to improve
the driver side of the vehicle, it should
fuel economy and permits easier
be used only temporarily and then re-
installation in case of a flat tire.
placed with the correct one.
192
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Required tools and spare
tire
The compact spare tire can be used
D Replace the compact spare tire
many times, if necessary. It has tread
with the standard tire as soon
life of up to 4800 km (3000 miles) de-
as possible.
pending on road conditions and your
driving habits. When tread wear indi-
D Avoid sudden acceleration,
cators appear on the tire, replace the
sudden deceleration and sharp
tire.
turns with the compact spare
tire.
See also the tire information in Sec-
tion 7−2 for details on the tread wear
indicators and other service informa-
NOTICE
tion.
Your ground clearance is re-
CAUTION
duced when the compact spare
With a compact spare tire
tire is installed so avoid driving
D The compact spare tire was de-
over obstacles and drive slowly
signed especially for your To-
on rough, unpaved roads and
yota. Do not use it on any other
speed bumps. Also, do not at-
vehicle.
tempt to go through an auto-
D Do not use more than one com-
matic car wash as the vehicle
pact spare tire at the same
may get caught, resulting in
time.
damage.
D The pressure for the compact
spare tire must be 420 kPa (4.2
kgf/cm2 or bar, 60 psi).
D Do not exceed
80 km/h
(50
mph) when driving with the
compact spare tire.
With a standard spare tire
193
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
1. Get the required tools and
spare tire.
1
Jack
2
Wheel nut wrench
3
Spare tire
4
Jack handle
To prepare yourself for an emergency,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.
To remove the jack:
2. Twist the jack head clockwise and
pull out the jack.
1. Turn the jack joint by hand until
the jack becomes free.
CAUTION
When removing the jack, be care-
ful not to injure your hands with
the edge of the trim.
194
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Blocking the wheel
To store the jack, put the jack base
To remove the spare tire:
2. Block the wheel diagonally op-
on the fitting place. Turn the joint until
posite the flat tire to keep the
1. Remove the spare tire cover.
the jack upper side fits securely with
vehicle from rolling when it is
2. Loosen the bolt and remove it.
the protrusion of the carrier.
jacked up.
Then take the spare tire out of the
This prevents the jack from flying for-
When blocking the wheel, place a
vehicle.
ward during a collision or sudden
wheel block in front of one of the front
braking.
When storing the spare tire, put it in
wheels or behind one of the rear
place with the inner side of the wheel
wheels.
CAUTION
facing up. Then secure the tire by re-
peating the above removal steps in
When storing the jack, be careful
reverse order to prevent it from flying
not to injure your hands with the
forward during a collision or sudden
edge of the trim.
braking.
195
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Removing wheel ornament
—Loosening wheel nuts
3. Remove the wheel ornament.
Pry off the wheel ornament, using the
beveled end of the wheel nut wrench
as shown.
CAUTION
Do not try to pull off the orna-
ment by hand. Take due care in
handling the ornament to avoid
unexpected personal injury.
Steel wheels
4. Loosen all the wheel nuts.
Always loosen the wheel nuts before
raising the vehicle.
Turn the wheel nuts counterclockwise
to loosen. To get maximum leverage,
fit the wrench to the nut so that the
handle is on the right side, as shown
above. Grab the wrench near the end
of the handle and pull up on the han-
dle. Be careful that the wrench does
not slip off the nut.
Do not remove the nuts yet—just un-
screw them about one—half turn.
Aluminum wheels
196
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Positioning the jack
—Raising your vehicle
CAUTION
Never use oil or grease on the
bolts or nuts. The nuts may loose
and the wheels may fall off,
which could cause a serious ac-
cident.
5. Position the jack at the correct
6. After making sure that no one
jack point as shown.
is in the vehicle, raise it high
enough so that the spare tire
Make sure the jack is positioned on
can be installed.
a level and solid place.
Remember you will need more ground
clearance when putting on the spare
tire than when removing the flat tire.
To raise the vehicle, insert the jack
handle into the jack (it is a loose fit)
and turn it clockwise. As the jack
touches the vehicle and begins to lift,
double−check that it is properly posi-
tioned.
197
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Changing wheels
CAUTION
Never get under the vehicle when
the vehicle is supported by the
jack alone.
7. Remove the wheel nuts and
Before putting on wheels, remove any
change tires.
corrosion on the mounting surfaces
with a wire brush or such. Installation
Lift the flat tire straight off and put it
of wheels without good metal−to−met-
aside.
al contact at the mounting surface can
Roll the spare wheel into position and
cause wheel nuts to loosen and
align the holes in the wheel with the
eventually cause a wheel to come off
bolts. Then lift up the wheel and get
while driving.
at least the top bolt started through
its hole. Wiggle the tire and press it
back over the other bolts.
198
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Reinstalling wheel nuts
—Lowering your vehicle
CAUTION
Never use oil or grease on the
bolts or nuts. Doing so may lead
to overtightening the nuts and
damaging the bolts. The nuts
may loose and the wheels may
fall off, which could cause a seri-
ous accident. If there is oil or
grease on any bolt or nut, clean
it.
8. Reinstall all the wheel nuts fin-
9. Lower the vehicle completely
ger tight.
and tighten the wheel nuts.
Reinstall the wheel nuts (tapered end
Turn the jack handle counterclock-
inward) and tighten them as much as
wise to lower the vehicle.
you can by hand. Press back on the
Use only the wheel nut wrench and
tire back and see if you can tighten
turn it clockwise to tighten the nuts.
them more.
Do not use other tools or any addition-
al leverage other than your hands,
such as a hammer, pipe or your foot.
Make sure the wrench is securely en-
gaged over the nut.
Tighten each nut a little at a time in
the order shown. Repeat the process
until all the nuts are tight.
199
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—Reinstalling wheel ornament
10.Reinstall the wheel ornament.
CAUTION
1. Put the wheel ornament into posi-
tion.
D When lowering the vehicle,
make sure all portions of your
Steel wheels—Align the cutout of the
body and all other persons
wheel ornament with the valve stem
around will not be injured as
as shown.
the vehicle is lowered to the
2. Press hand firmly on one side of
ground.
wheel ornament and then firmly
D Have the wheel nuts tightened
tap the other side around the edge
with torque wrench to 103 N·m
of wheel ornament with the heel
(10.5 kgf·m, 76 ft·lbf), as soon
of your hand to snap into place.
as possible after changing
Steel wheels
wheels. Otherwise, the nuts
CAUTION
may loosen and the wheels
may fall off, which could cause
Take due care in handling the or-
a serious accident.
nament to avoid unexpected per-
sonal injury.
Aluminum wheels
200
2005 CELICA from Sep. ’04 Prod. (OM20888U)
’05MY CELICA U (L/O 0409)
—After changing wheels
If your vehicle becomes stuck
11. Check the air pressure of the re-
If your vehicle becomes stuck in snow,
CAUTION
mud, sand, etc., then you may attempt
placed tire.
to rock the vehicle free by moving it
Adjust the air pressure to the specifi-
Before driving, make sure all the
forward and backward.
cation designated in Section 8. If the
tools, jack and flat tire are se-
pressure is lower, drive slowly to the
curely in place in their storage
CAUTION
nearest service station and fill to the
location to reduce the possibility
correct pressure.
Do not attempt to rock the vehicle
of personal injury during a colli-
free by moving it forward and back-
Do not forget to reinstall the tire infla-
sion or sudden braking.
ward if people or objects are any-
tion valve cap as dirt and moisture
where near the vehicle. During the
could get into the valve core and
rocking operation the vehicle may
possibly cause air leakage. If the cap
suddenly move forward or backward
is missing, have a new one put on as
as it becomes unstuck, causing injury
soon as possible.
or damage to nearby people or ob-
12.Restow all the tools, jack and
jects.
flat tire securely.
As soon after changing wheels as
possible, tighten the wheel nuts to the
torque specified in Section 8 with a
torque wrench. Have a technician re-
pair the flat tire and replace the spare
tire with it.
201
2005 CELICA from Sep. ’04 Prod. (OM20888U)
