PP–56

PREPARATION  –  AIR CONDITIONING

PP

(09963-00500)

Pin 5

PREPARATION  –  AIR CONDITIONING

PP–57

PP

RECOMMENDED TOOLS

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set

95146-00180

Halogen Leak Detector
DENSO Part No.

PP–58

PREPARATION  –  AIR CONDITIONING

PP

EQUIPMENT

Voltmeter

Ohmmeter

Vacuum pump

Vinyl tape

Dial indicator or dial indicator with magnetic base

Torque wrench

Service wire harness

Radiator cap tester

PREPARATION  –  AIR CONDITIONING

PP–59

PP

LUBRICANT

Item

Capacity

Classification

Compressor oil

-

ND-OIL8 or equivalent

When replacing No. 1 cooler evaporator

40 cc (1.35 fl. oz.)

ND-OIL8 or equivalent

When replacing cooler condenser

40 cc (1.35 fl. oz.)

ND-OIL8 or equivalent
