LIGHTING – LIGHTING SYSTEM
LI–1
LI
LIGHTING SYSTEM
PRECAUTION
1.
DISCONNECT AND RECONNECT CABLE OF
NEGATIVE BATTERY TERMINAL
NOTICE:
When disconnecting the cable from the negative (-)
battery terminal, initialize the following systems after
the cable is reconnected.
(a) Before performing electronic work, disconnect the
cable from the negative (-) battery terminal in order
to prevent it from shorting and burning out.
(b) Before disconnecting and reconnecting the battery
cable, turn the ignition switch OFF and the headlight
dimmer switch OFF. Then loosen the terminal nut
completely. Do not damage the cable or terminal.
(c) When the battery cable is disconnected, the clock
and radio settings and stored DTCs are erased.
Therefore, before disconnecting the battery cable,
make a notes of them.
System Name
See procedure
METER / GAUGE SYSTEM
See page
Negative (-)
Battery Terminal
Cable
D033496E01
