BO–56

–

BODY

ROOF DRIP SIDE MOULDING

3609

(b)

Lift the moulding release sheet from the face of moulding.

NOTICE:
When the moulding release sheet is removed, make sure
that no dirt or dust can get onto the coated area.
(c)

Install the moulding.

NOTICE:

Make sure that the body and moulding are heated to
a proper temperature.

Do not depress the adhesive coated parts excessive-
ly but just hold them down with your thumb.

Scrape off any overflowing adhesive with a plastic
spatula and clean the surface with a dry rag.

Take care not to drive the vehicle during the time de-
scribed in the table below.

Temperature

Minimum time prior to driving the vehicle

35

°

C (95

°

F)

1.5 hours

20 °

C (68

°

F)

5 hours

5

°

C (41

°

F)

24 hours

6.

w/ Roof rack:
INSTALL ROOF RACK (See page

BO–173

)

Torque: 11 N·m (115kgf·cm, 8 ft·lbf)

BO46F–01

H16706

Roof Side Rail Weatherstrip

Center Pillar Upper
End Weatherstrip

–

BODY

ROOF DRIP SIDE FINISH MOULDING

BO–57

3610

ROOF DRIP SIDE FINISH MOULDING

COMPONENTS

H16707

BO46G–01

H16708

H16709

BO–58

–

BODY

ROOF DRIP SIDE FINISH MOULDING

3611

REMOVAL

1.

REMOVE CENTER PILLAR UPPER END WEATH-
ERSTRIP

Using a screwdriver, remove the weatherstrip.
HINT:
Tape the screwdriver tip before use.

2.

REMOVE ROOF SIDE RAIL WEATHERSTRIP

Using SST, pull off the roof side rail weatherstrip from end.

SST

09806–30010

HINT:
At the time of installation, please refer to the following item.
Attach the upper edge of the weatherstrip to body flange. Tap
on the weatherstrip by hand.

BO46H–01

–

BODY

ROOF DRIP SIDE FINISH MOULDING

BO–59

3612

INSTALLATION

Installation is in the reverse order of removal (See page

BO–58

).
